KDP80 SPECIFICATIONS KDP80
DIGITAL PIANO
CA1045E-D1005 Version 1
Printed in Japan
Copyright © 2010 KAWAI Musical Instruments Mfg. Co., Ltd. All Rights Reserved.
www.kawai.co.jp/worldwide
Keyboard 88 weighted keys
Action Advanced Hammer Action IV-F with Acoustic Reaction™ technology
Sound Source Harmonic Imaging™ technology
Internal Sounds 15 voices
Polyphony max. 96 notes
Reverb Room, Stage, Hall
Effects Chorus (Preset)
Recorder 1 song, 1 track recorder - 7,500 notes
Demo Songs 15 songs
Concert Magic 40 songs
Lesson Function Alfred* or Burgmüller and Czerny lessons
Other Features Dual, Four hands, Transpose, Tuning,
Damper Effect, MIDI Functions, Metronome
Jacks MIDI (IN/OUT), Headphones x 2
Pedals Damper (with Half-Pedal support), Sostenuto, Soft
Speakers 12 cm x 2
Output Power 20 W x 2
Dimensions 136 (W) x 40 (D) x 85 (H) cm
Weight 37.0 kg
* USA, Canada, Australia and UK only.
e Advanced Hammer Action IV-F keyboard has been developed to represent the
distinctive touch of a traditional grand piano, with its remarkable springless design
providing consistent upward and downward motion for a smooth, more natural, piano
playing experience. Moreover, just as acoustic pianos utilise heavier bass hammers and
lighter treble hammers, the AHA IV-F keyboard also employs dierent hammer weights,
appropriately graded for each playing range. Such attention to detail allows greater
stability during fortissimo passages, while preserving delicate pianissimo control, to satisfy
the demands of even the most discerning pianist.
e authentic sound of KAWAI digital pianos begins with the world renowned KAWAI
EX Concert grand piano. Placed inside an anechoic chamber, free of audio reections, the
rich sound of this world class instrument is meticulously analysed and recorded by our
Master Piano Artisans. e acoustic portrait of each note is later transformed into a
precise three dimensional digital representation, employing KAWAI’s proprietary
Harmonic Imaging™technology. is unique process faithfully reproduces the broad
dynamic range of the original grand piano, from subtle pianissimos to thunderous
fortissimos.
OUCH Advanced Hammer Action IV-F
Harmonic Imaging™ Technology
ONE
e convenient lesson feature allows aspiring pianists to learn the piano using a built-in
collection of etudes from Alfred* or Burgmüller and Czerny. e left and right hand parts
of each piece can be practiced separately, adjusting the tempo to perfect dicult passages,
before being recorded and played back for self-evaluation.
Built-in Lessons
EATURES
KDP80 SPECIFICATIONS KDP80
DIGITAL PIANO
CA1045E-D1005 Version 1
Printed in Japan
Copyright © 2010 KAWAI Musical Instruments Mfg. Co., Ltd. All Rights Reserved.
www.kawai.co.jp/worldwide
Keyboard 88 weighted keys
Action Advanced Hammer Action IV-F with Acoustic Reaction™ technology
Sound Source Harmonic Imaging™ technology
Internal Sounds 15 voices
Polyphony max. 96 notes
Reverb Room, Stage, Hall
Effects Chorus (Preset)
Recorder 1 song, 1 track recorder - 7,500 notes
Demo Songs 15 songs
Concert Magic 40 songs
Lesson Function Alfred* or Burgmüller and Czerny lessons
Other Features Dual, Four hands, Transpose, Tuning,
Damper Effect, MIDI Functions, Metronome
Jacks MIDI (IN/OUT), Headphones x 2
Pedals Damper (with Half-Pedal support), Sostenuto, Soft
Speakers 12 cm x 2
Output Power 20 W x 2
Dimensions 136 (W) x 40 (D) x 85 (H) cm
Weight 37.0 kg
* USA, Canada, Australia and UK only.
