These are the Ci200.2QS and Ci200.2QR,

generous in size and outstanding in

performance. Audiophile quality sound is

derived from KEF’s Uni-Q®driver array

technology, providing your room with an

expansive soundscape, excellent bass

extension and so creating the perfect

sound stage.

Deciding whether to place the Ci200.2QS

and Ci200.2QR in the walls or ceiling has

never been more simple. Thanks to KEF’s

simple and ingenious screw down clamping

system you’ll find them easy and quick

to install.

Designed with moisture-resistant fixings

allowing placement in the harshest

environments such as bathrooms or even

outside (under eaves).

The Ci200.2QS and Ci200.2QR offer

excellent quality with no sacrifice.

Features and Benefits:

The 2-way Ci200.2QS and Ci200.2QR

combine 100W power handling and 89dB

sensitivity, for a maximum output of 108dB.

A 200mm (8”) polypropylene cone

bass/mid unit with a coincident mounted

25mm (1”) soft dome, ferrofluid cooled

high-frequency unit provide superb

off-axis dispersion characteristics.

The bezel and grille can be painted or

covered by fabric to match the interior décor.

KEF Audio (UK), Eccleston Road,T

ovil, Maidstone, Kent, ME15 6QP U.K. Telephone: + 44 (0) 1622 672261. Fax: + 44 (0) 1622 750653 www.kef.com

KEF America, 10

Timber Lane,Marlboro,New Jersey, 07746 USA. Telephone: + 1 732 683 2356. Fax: + 1 732 683 2358 www.kefamerica.com

GP Acoustics GmbH, Heinrichstraße 51, D-44536 Lünen, Deutschland. Telephone: +49 (0) 231 9860-320. Fax: +49 (0) 231 9860-330. www.kefaudio.de

Information Sheet

Polar graphs

Directivity Index / Beamwidth

Frequency / Power response, Input impedance

Specifications

Installation

Architectural specifications:

The Ci Series Ci200.2QS and Ci200.2QR

comprise Uni-Q®coincident mounted

25mm soft dome ferrofluid cooled

tweeter with 200mm white polypropylene

bass/mid unit. Performance should meet

or exceed the following criteria: frequency

response 1 metre on-axis with swept

sinewave shall be 43Hz to 20 kHz,

sensitivity shall be at least 89dB for

2.83V@1m. The impedance and maximum

power shall be 100W at 8 ohms. The Ci

Series Ci200.2QS and Ci200.2QR is best

suited where high quality music and speech

reinforcement applications require hi-fi

performance such as:

· Multi Room systems.

· Home Theatre systems.

· Lounges, Bars, Boutiques.

· Boardrooms & Offices.

· Airports, Convention Centres, Hotels.

· Live Theatre/Concert Hall fill-in.

· Houses of Worship.

· Sports Arenas.

Frequency range 43Hz - 20kHz

Sensitivity (2.83v @ 1m) 89dB

Rec. amplifier power 10 -100W

Nominal Impedance 8Ω(min. 4.8Ω)

Crossover Frequency 2.7kHz

Enclosure material N/A

Terminals spring terminals up to Ø2.5mm (0.1”)

conductor

Dimensions (H x W x D) 265 x 265 x 107 mm, 10.4 x 10.4 x 4.2 in.

Net weight 2.1kg (4.6lbs)

500Hz 1kHz

2kHz 4kHz

8kHz 16kHz

PL1600EN

1

3

2

4

5

6
