Kenmore K Series Bedienungsanleitung

Use & Care Guide

Manual de Uso y Cuidado

Upright Freezer/

Refrigerator

Congelador/ Refrigerador vertical

#=colornumber,númerodecolor

Customer Assistance / Asistencia al Cliente

1-833-946-4239

Kenmore and the Kenmore logo are registered trademarks of

KCD IP, LLC and/orTransform SR Brands Management LLC, and are used under license by

Winiadaewoo Electronics America, Inc.

Models/Modelos: K*FU015AWD# - White - 15 cu.ft.

K*FU018AWD# - White - 18 cu.ft.

K*FU021AWD#- White - 21 cu.ft.

K*FU021AWE#- White - 21 cu.ft.

Kenmore

냉동고_K@FU015AWD(EN+ES).indd 1 2021-03-29 오전 11:05:33

Record Model/

Serial Numbers

Please read and save

these instructions

This Use & Care Guide provides specific

operating instructions for your model. Use

your unit only as instructed in this guide.

These instructions are not meant to cover

every possible condition and situation that

may occur. Common sense and caution must

be practiced when installing, operating, and

maintaining any appliance.

Please record your model and serial

numbers below for future reference. This

information is found on the lower left wall

inside the appliance.

Model Number: K*FU

or Serial

Number: Purchase

Date:

IMPORTANT

Use only soap and water to clean

serial plate.

Table of Contents

Record Model/Serial Numbers ......................2

Important Safety Instructions..........................2

Appliance Setup ...............................................5

Appliance Features...........................................6

Temperature Control.........................................9

Door Handle Installation (Optional).............12

Door Swing Reversal (Optional)....................13

Door Handle Reversal.....................................15

Care & Cleaning............................................. 16

Power or Appliance Failure........................... 17

Before You Call ............................................... 18

Warranty..........................................................20

Service.............................................. Back Cover

Important Safety

Instructions

Safety Precautions

Do not attempt to install or operate

your unit until you have read the safety

precautionsin this Use & Care Guide.

Safety items throughout this manual are

labeled with a Danger, Warning, or

Caution based on the risk type.

Definitions

This is the safety alert symbol. It is

used to alert you to potential personal

injury hazards. Obey all safety messages

that follow this symbol to avoid possible

injury or death.

DANGER

DANGER indicates an imminently

hazardous situation which, if not

avoided, will result in death or serious

injury.

WARNING

WARNING indicates a potentially

hazardous situation which, if not

avoided, could result in death or serious

injury.

CAUTION

CAUTION indicates a potentially

hazardous situation which, if not

avoided, may result in minor or

moderate injury.

IMPORTANT

Indicates installation, operation, or

maintenance informationwhich is

important but not hazard-related.

냉동고_K@FU015AWD(EN+ES).indd 2 2021-03-29 오전 11:05:33

Important Safety Instructions

DANGER

ANGER Risk of fire or explosion.

Flammable refrigerant used. Do not use

mechanical devices to defrost refrigerator.

Do not puncture refrigerant tubing.

DANGER Risk of fire or explosion.

Flammable refrigerant used.To be repaired

only by trained service personnel. Do not

puncture refrigerant tubing.

CAUTION

CAUTION Risk of fire or explosion.

Flammable refrigerant used. Consult

repair manual/owner’s guide before

attempting to service this product. All

safety precautions must be followed.

CAUTION Risk of fire or explosion.

Dispose of properly in accordance with

federal or local regulations. Flammable

refrigerant used.

CAUTION Risk of fire or explosion

due to puncture of refrigerant tubing.

Follow handling instructions carefully.

Flammable refrigerant used.

WARNING

Read all safety instructions before using

your new appliance.

For Your Safety

• Do not store or use gasoline or other

flammable liquids in the vicinity of this or

any other appliance. Read product labels

for warnings regarding flammability and

other hazards.

• Do not operate the unit in the presence of

explosive fumes.

• Remove and discard any spacers used to

secure the basket during shipping. Small

objects are a choke hazard to children.

• Remove all staples from the carton.

Staples can cause severe cuts and also

destroy finishes if they come in contact

with other appliances or furniture.

Child Safety

Destroy or recycle the carton, plastic bags,

and any exterior wrapping material

immediately after the unit is unpacked.

Children should never use these items to

play. Cartons covered with rugs, bedspreads,

plastic sheets or stretch wrap may become

airtight chambers and can quickly cause

suffocation.

Proper disposal of your appliance

DANGER: Risk of child entrapment!

Child entrapment and suffocation are not

problems of the past. Junked or abandoned

appliances are still dangerous – even if they

will sit for “just a few days.” If you are

getting rid of your appliance, please follow

the instructions below to help prevent

accidents.

Before you throw away your old unit:

• Remove door.

• Leave shelves in place within appliance so

children may not easily climb inside.

• Have refrigerant removed by a qualified

service technician.

CAUTION

It may not open easily when you try

to open the freezer door immediately

after closing it. It is not a problem with

the freezer because it is caused by the

pressure difference.

To solve this, it opens easily after a

certain period of time (1 minute).

냉동고_K@FU015AWD(EN+ES).indd 3 2021-03-29 오전 11:05:33

Important Safety Instructions

IMPORTANT

Your old unit may have a cooling system

that used CFCs or HCFCs (chlorofluoro-

carbons or hydrochlorofluorocarbons).

CFCs and HCFCs are believed to harm

stratospheric ozone if released to the

atmosphere. Other refrigerants may cause

harm to the environment if released to the

atmosphere. If you are throwing away

your old unit, make sure the refrigerant is

removed for proper disposal by a

qualified technician. If you intentionally

release refrigerant, you may be subject to

fines and imprisonment under the

provisions of environmental legislation.

WARNING

These guidelines must be followed to

ensure that safety mechanisms in this

unit will operate properly.

Electrical Information

•

The unit must be plugged into its own

dedicated 10 amp minimum, 115 Volt, 60

Hz, AC only electric outlet. The power

cord of the appliance is equipped with a

three-prong grounding plug to protect

against shock hazards. It must be plugged

directly into a properly grounded three-

prong receptacle. The receptacle must be

installed in accordance with local codes

and ordinances. Consult a qualified

electrician. Do not use an extension cord

or adapter plug.

• Immediately repair or replace any power

cord that becomes frayed or damaged.

• Never unplug the appliance by pulling

on the power cord. Always grip the plug

firmly, and pull straight out from the

receptacle to prevent damaging the

power cord.

• Unplug the appliance before cleaning

and before defrosting to avoid

electrical shock.

• Performance may be affected if the

voltage varies by 10% or more.

Operating the unit with insufficient

power can damage the motor. Such

damage is not covered under the

warranty.

• Do not plug the unit into an outlet

controlled by a wall switch or pull cord

to prevent the appliance from being

turned off accidentally.

• Avoid connecting unit to a Ground

Fault Circuit Interruptor (GFCI).

냉동고_K@FU015AWD(EN+ES).indd 4 2021-03-29 오전 11:05:33

Appliance Setup

This Use & Care Guide provides specific

operating instructions for your model. Use

the unit only as instructed in this Use & Care

Guide. Before starting the appliance, follow

these important setup steps.

Installation

• Choose a place that is near a grounded

electrical outlet. Do Not use an extension

cord or an adapter plug.

• For the most efficient operation, the

appliance should be located where

surrounding temperatures will not exceed

110°F (43°C). Temperatures of 32°F (0°C)

and below will NOT affect appliance

operation. Additional compressor heaters

are not recommended.

• Allow space around the unit for good air

circulation. Leave a 1-inch (25.4 mm)

space at the back and on top and a

3/8-inch (9.5 mm) space on the sides of

the appliance for adequate circulation.

Leveling

The appliance must have all bottom corners

resting firmly on a solid floor that is strong

enough to support a fully loaded appliance.

It is Very Important for the appliance to be

level in order to function properly. If not

level, the door may be misaligned and not

close or seal properly, causing cooling,

frost, or moisture problems.

The appliance is equipped with adjustable

front leveling feet. Turn the foot clockwise

to heighten (H) the side of the unit. Turn

counterclockwise to lower (L) the side. Adjust

each side as needed until front of unit is

level. Also adjust so that front of unit is 1/4˝

higher than back, so that door stays closed.

Cleaning

• Wash any removable parts, the

appliance interior, and exterior with mild

detergent and warm water. Wipe dry.

Do not use harsh cleaners on these

surfaces.

• Do not use razor blades or other sharp

instruments, which can scratch the ap-

pliance surface when removing adhesive

labels. Any glue left from the tape can

be removed with a mixture of warm

water and mild detergent, or touch the

residue with the sticky side of tape

already removed. Do not remove the

serial plate.

Energy Saving Ideas

for Freezer Mode

• The freezer should be

located in the coolest area

of the room, away from

heat producing appliances

or heating ducts, and out of

direct sunlight.

• Let hot foods cool to room temperature

before placing in freezer. Overloading

the freezer forces the compressor to run

longer. Foods that freeze too slowly may

lose quality or spoil.

• Be sure to wrap foods properly, and

wipe containers dry before placing

them in the freezer. This cuts down on

frost build-up inside the freezer.

• Do not line freezer shelves and bins

with aluminum foil, wax paper, or paper

toweling. Liners interfere with cold air

circulation, reducing freezer efficiency.

• Organize and label food to reduce lid

openings and avoid extended searches.

• Remove as many items as needed at one

time, and close door as soon as possible.

냉동고_K@FU015AWD(EN+ES).indd 5 2021-03-29 오전 11:05:33

Appliance Features

- K*FU015AWD# (15cf) / K*FU018AWD# (18cf)

1Freezer Compartment Shelves

- For storage of frozen food, meat, fish, ice cream

2Freezer Compartment Door Bins

- For storage of frozen food.

3Freezer Compartment Drawer Bins

- For storage of frozen food.

4LED Light

- For lighting the freezer interior

5Temperature Control Panel

- For choosing the ideal temperature for food

냉동고_K@FU015AWD(EN+ES).indd 6 2021-03-29 오전 11:05:33

- K*FU021AWD# (21cf)

1Freezer Compartment Shelves

- For storage of frozen food, meat, fish, ice cream

2Freezer Compartment Door Bins

- For storage of frozen food.

3Freezer Compartment Drawer Bins

- For storage of frozen food.

4LED Light

- For lighting the freezer interior

5Temperature Control Panel

- For choosing the ideal temperature for food

냉동고_K@FU015AWD(EN+ES).indd 7 2021-03-29 오전 11:05:34

Appliance Features

- K*FU021AWE# (21cf)

1Freezer Compartment Glass shelves

- For storage of frozen food, meat, fish, ice cream

2Freezer Compartment Door Bins

- For storage of frozen food.

3Freezer Compartment Drawer Bins

- For storage of frozen food.

4LED Light

- For lighting the freezer interior

5Front Control Panel (located on freezer door exterior)

- For adjusting the temperature without opening the door

냉동고_K@FU015AWD(EN+ES).indd 8 2021-03-29 오전 11:05:34

Temperature Control

(K*FU015AWD, K*FU018AWD, K*FU021AWD)

Freezer Use

• To turn the freezer on, plug the power

cord into a properly grounded 3 prong

electrical outlet. The green Power On

light located on the temperature control

will illuminate.

•For safe food storage, allow four hours

after plugging the for the freezer to cool

down completely. The freezer will run

continuously for the first several hours.

Foods that are already frozen may be

placed in the freezer after the first few

hours of operation. Unfrozen foods should

NOT be loaded into the freezer until the

freezer has operated for four hours..

• When loading the freezer, freeze only

three pounds of fresh food per cubic foot

of freezer space at one time. Distribute

packages to be frozen evenly throughout

the freezer.

1Freezer Temperature

Press the Mode button and the

temperature setting changes in the

sequence as shown below:

Colder →Coldest →Cold

Setting Cold Colder Coldest

Temperature (°C) -15 -18 -21

Temperature (°F) 6 0 -6

2Lock function

The control panel must be unlocked for

any adjustments to be made.

Unlock: To unlock control panel, press

and hold Mode button for 3 seconds. The

LED will blink 3 times to indicate that

panel is unlocked.

Lock: When Mode button is pressed and

held for 3 seconds, the LED will blink 3

times to indicate that panel is locked

from use.

NOTE

The control panel automatically locks

itself if Mode button is not pressed for 20

seconds.

Press the Mode button and the

냉동고_K@FU015AWD(EN+ES).indd 9 2021-03-29 오전 11:05:34

Temperature Control

(K*FU021AWE)

Freezer Temperature

When freezer mode is turned on press

“-” or “+” button to switch the set

temperatures as below.

set temp.

(°C) -15 -16 -17 -18 -19 -20 -21 -22

set temp.

(°F) 6 4 2 0 -2 -4 -6 -8

Refrigerator temperature

When fridge mode is turned on press

“-” or “ +” button to switch the set

temperatures as below.

set temp.

(°C) 7 6 5 4 3 2 1

set temp.

(°F) 45 43 41 39 37 35 33

Freezer/ Fridge switch mode

1) Switch from Freezer mode to Fridge

mode

Press and hold Mode button for 3 seconds.

The LED will blink 3 times and Fridge

indicator will stay lit.

At the same time the Freezer indicator will

go off. The Fridge mode is now on at the

default temperature of 37°F (3°C).

2) Switch from Fridge mode to Freezer

mode

Press and hold Mode button for 3 seconds.

The LED will blink 3 times and Freezer

indicator will stay lit.

At the same time the Fridge indicator will

go off. The Freezer mode is now on at the

default temperature of 0° F (-18°C).

냉동고_K@FU015AWD(EN+ES).indd 10 2021-03-29 오전 11:05:35

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Sprachen:

Andere Kenmore Kühlschrank Handbücher

Kenmore

Kenmore Kenmore Side by Side Refrigerator Bedienungsanleitung

Kenmore

Kenmore Compact refrigerator Sears 461.90482 Bedienungsanleitung

Kenmore

Kenmore 795.51022.001 Bedienungsanleitung

Kenmore

Kenmore 596.7759?800 Bedienungsanleitung

Kenmore

Kenmore Side by side refrigerator Bedienungsanleitung

Kenmore

Kenmore ELITE 795.7834 Series Bedienungsanleitung

Kenmore

Kenmore 795.6827 Series Bedienungsanleitung

Kenmore

Kenmore KKUF07 Bedienungsanleitung

Kenmore

Kenmore 255.99763 Bedienungsanleitung

Kenmore

Kenmore KLBH031A E Series Bedienungsanleitung

Kenmore

Kenmore 596.57002600 Bedienungsanleitung

Kenmore

Kenmore 218621400A Bedienungsanleitung

Kenmore

Kenmore 111.72695120 Bedienungsanleitung

Kenmore

Kenmore 795.7107 Series Bedienungsanleitung

Kenmore

Kenmore 7531 - 22.0 cu. Ft. Top Freezer Refrigerator Bedienungsanleitung

Kenmore

Kenmore Refrigerator Bedienungsanleitung

Kenmore

Kenmore 5736 - 25.1 cu. Ft. Refrigerator Bedienungsanleitung

Kenmore

Kenmore 795.5101 Series Bedienungsanleitung

Kenmore

Kenmore 564.9933611 Bedienungsanleitung

Kenmore

Kenmore Kenmore 596.7753 Bedienungsanleitung

Kenmore

Kenmore 106.5117 Bedienungsanleitung

Kenmore

Kenmore 795.78542.801 Bedienungsanleitung

Kenmore

Kenmore 795.78402.801 Bedienungsanleitung

Kenmore

Kenmore 596.53462302 Bedienungsanleitung

Beliebte Kühlschrank Handbücher anderer Marken

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Bedienungsanleitung

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Bedienungsanleitung

Sharp

Sharp SJ-BA31IEXW2-EU Bedienungsanleitung

CORBERO

CORBERO CC2300MCW Bedienungsanleitung

KitchenAid

KitchenAid 2205264 Bedienungsanleitung

Stengel

Stengel KU 1101 A++ Bedienungsanleitung

NEFF

NEFF KI181 Series Bedienungsanleitung

Hoshizaki

Hoshizaki Reach-In Bedienungsanleitung

Amana

Amana ASD2524VES00 Bedienungsanleitung

BOMANN

BOMANN KGC 213 Bedienungsanleitung

Danby

Danby DAR044A1SLDD Montageanleitung

Samsung

Samsung RF323TE Bedienungsanleitung

Beko

Beko CSA31022 Bedienungsanleitung

IKEA

IKEA FROSTIG C 185 E Bedienungsanleitung

Electrolux

Electrolux ER 6821 D Bedienungsanleitung

True

True TS-28 Bedienungsanleitung

Frigidaire

Frigidaire FSC23R5DW9 Bedienungsanleitung

Beko

Beko LSP4579W Bedienungsanleitung
