Kentix AlarmManager-BASIC Bedienungsanleitung

kentix.com

User-Manual

Kentix AlarmManager

MultiSensors

KeyPad and Accessories

Kentix DoorLock

Kentix360 Cloud and SIM



Page (06-2017, subject to change) kentix.com2

Kentix360 - Cloud and SIM

DoorLock

KeyPad-Touch & Accessories

MultiSensors

Kentix-Systems - basic infos

The AlarmManager



1. Introduction and summary 7

1.1. Features 7

1.2. Applications 7

1.3. Safety note 7

2. Connection examples and installation notes 8

2.1. StarterSet-BASIC/PRO-1 8

2.2. StarterSet-PRO-2 8

2.3. StarterSet with optional equipment 9

2.4. Alarm-inputs 10

2.5. Relay contacts 10

2.6. Power supply 10

3. Overview KENTIX System Topology 11

4. AlarmManager-BASIC/PRO 12

4.1. Login to the AlarmManager 12

4.2. Changing IP-Settings 12

4.3. Communication- / Network ports 13

4.4. Default settings / Factory defaults 13

4.5. Configuration in 8 steps 14

4.6. Visual and acoustic signaling 15

4.7. Alarm zones 16

4.8. Quitting Alarms 16

4.9. User accounts 17

4.10. SMS commands for remote control of AlarmManager 18

4.11. Settings - AlarmManager-BASIC and -PRO 19

4.12. Settings - AlarmManager-PRO only 21

4.13. SMS gateway function 22

4.14. SMS Limit 22

4.15. MIB for SNMP-Systems 23

4.16. Execution of Firmware Updates 24

4.17. License management and upgrade 24

4.18. Connections - AlarmManager-BASIC/PRO 25

5. MultiSensors 26

5.1. Mounting instructions for MultiSensor-RF / -LAN / -LAN-RF 26

5.2. Coverage of the integrated PIR movement detector 26

5.3. Calibration of the temperature / humidity sensor 27

5.4. Kentix system jack at MultiSensor-RF / -LAN / -LAN-RF 27

5.5. MultiSensor-RF 28

5.5.1. Adding a MultiSensor-RF 28

5.6. MultiSensor-LAN 29

5.6.1. Default settings / Factory defaults 29

5.6.2. Software function MultiSensor-LAN 29

5.6.3. Configuration - Basic configuration 31

5.6.4. Configuration - MultiSensor (Sensor- and alarm settings) 32

5.6.5. Users 33

5.6.6. System 34

5.6.7. Switch alarm output 2 34

5.7. MultiSensor-Door / MultiSensor-RACK-MINI 35

5.7.1. Mounting instructions 36

5.7.2. Usage of the reed contact 37

5.7.3. Opening of the casing / replacement of battery 38

Page (06-2017, subject to change) kentix.com3



5.7.4. Adding a MultiSensor-Door / -RACK-MINI 38

5.7.5. Settings 38

5.7.6. Test of the settings 39

5.8. MultiSensor-Rack 40

5.8.1. Safety note and installation 40

5.8.2. Default settings 40

5.8.3. Overview connections 41

5.8.4. Kentix system jack at MultiSensor-RACK 42

5.8.5. Recommended installation 42

5.8.6. ConfigurationConfiguration 43

5.8.7. EnergySensor - Energy 43

5.8.8. Control 46

5.8.9. Configuration - EnergySensor 47

5.8.10. Users 48

5.8.11. System 48

5.8.12. Configuration of the vibration sensor 48

5.9. Control a network camera with MultiSensor-LAN/RACK 49

5.10.Communication Interfaces MultiSensor-LAN/RACK 49

5.11.Perform software update on MultiSensor-LAN / -RACK 50

6. How to open the AlarmManager chassis for inserting a SIM card 51

7. KeyPad-Touch (KKPT) 52

7.1. Adding a KeyPad 52

7.2.Operation KeyPad 53

8. Enhancements 55

8.1. Leakage sensor (KLS03) 55

8.2. Leakage sensor rope (KLS03-ROPE) 57

8.3. Kentix Power-Adapter (KIO1) with digital input clips 58

8.4. Kentix Power-Adapter (KIO2) for powering a MultiSensor 59

8.5. Kentix Power-Adapter (KIO3) with digital I/O clips 60

8.6. Overview and application examples for Power-Adapters (KIO1-3) 61

8.7. Kentix Alarm sirene (KFLASH1) 62

8.7.1. Configuration 63

8.8. Kentix IO-Modules 64

8.9. MultiSensor-LAN-RF (LAN-ZigBee Repeater) 65

9. Kentix DoorLock 66

9.1. Components 66

9.1.1. Online knob (DoorLock-DC) and profile cylinder 67

9.1.2. Online door lever (DoorLock-LE) 67

9.1.3. Online wall reader (DoorLock-WA) 67

9.1.4. Online cabinet lock (DoorLock-RA) 67

9.1.5. Master card set 68

9.1.6. AccessPoint 68

9.1.7. Accessories 68

9.2. Installation & Programming (Inbetriebnahme) 69

9.2.1. Online knob 69

9.2.2. Online door lever 70

9.2.3. Online wall reader 73

9.2.4. Online cabinet lock 77

9.2.5. AccessPoint 80

9.3. Configuration and operation modes 81

9.3.1. DoorLock-device without AccessPoint (offline-mode) 81

Page (06-2017, subject to change) kentix.com4



9.3.1.1. Initial setup - insert / activate batteries 81

9.3.1.2. Initial setup - Master card set 82

9.3.2. DoorLock-devices with AccessPoint (online-mode) 84

9.3.2.1. Default settings / factory defaults 84

9.3.2.2. Communication ports 84

9.3.2.3. Dashboard - Access logbook 85

9.3.2.4. Dashboard - DoorLock control 85

9.3.2.5. Access - Users 86

9.3.2.6. Teach-in of RFID-media in the online-mode 87

9.3.2.7. Access - Access profiles 88

9.3.2.8. Access - Time profiles 88

9.3.2.9. Access - DoorLocks 88

9.3.2.10. Access - DoorLocks - Switching of alarm zones 90

9.3.2.11. Configuration - General 90

9.3.2.12. Configuration - Network 91

9.3.2.13. Configuration - Communication 91

9.3.2.14. Configuration - Master/Slave Mode 92

9.3.2.15. Configuration - Network cameras 92

9.3.2.16. Kentix360 93

9.3.2.17. System - Logbook 93

9.3.2.18. System - SD card 93

9.3.2.19. System - System settings 93

9.3.2.20. System - Help 94

9.3.3. Master-Slave-mode (Compound operation with multiple AccessPoints) 94

9.3.4. Reset of components 94

9.3.5. Battery replacement 95

9.3.6. Emergency opening 96

9.3.7. Dismantling 96

10.Kentix AlarmManager Smartphone-App 97

10.1. The Profile menu 97

10.2. AlarmManager 98

10.2.1. SMS Control 98

10.3. MultiSensor-LAN / -LAN-RF / -RACK 98

10.4. AccessPoint 99

11. Kentix360 Cloud 100

11.1. Setup 100

11.2. Administration 101

11.3. Manage AccessPoint 102

12. Kentix SIM card 103

12.1. Setup 103

12.2. Telephone number and PIN 103

12.3. SMS alarming 103

13. Data sheets 104

13.1. Data sheet AlarmManager-BASIC/PRO (KAM-BASIC/PRO) 104

13.2. Data sheet MultiSensor-RF (KMS-RF) 105

13.3. Data sheet MultiSensor-LAN (KMS-LAN) 106

13.4. Data sheet MultiSensor-LAN-RF (KMS-LAN-RF) 107

13.5. Data sheet MultiSensor-RACK (KMS-RACK) 108

13.6. Data sheet MultiSensor-Door (KMS-Door) 109

13.7. Data sheet MultiSensor-RACK-MINI (KMS-RACK-MINI) 110

13.8. Data sheet KeyPad (KKPT) 111

Page (06-2017, subject to change) kentix.com5



13.9. Data sheet AccessPoint (KXP-16) 112

13.10. Data sheet Online Door knob DoorLock-DC (KXC-KN1/2) 113

13.11. Data sheet DoorLock-LE (KXC-LE) 114

13.12. Data sheet DoorLock-WA (KXC-WA) 115

13.13. Data sheet DoorLock-RA1 (KXC-RA1) 116

13.14. Data sheet digital I/O expansion-module (KIO7052) 117

13.15. Data sheet digital I/O expansion-module (KIO7053) 118

13.16. Data sheet leakage sensor (KLS03) 119

14.Checklist - Acceptance report 120

15. Support 123

Page (06-2017, subject to change) kentix.com6



1. Introduction and summary

Thank you for your decision to buy a KENTIX monitoring solution based on the KENTIX MultiSensor technology.

1.1. Features

The KENTIX AlarmManager-BASIC/PRO is the central system unit, where all the information of the

MultiSensors are collected. The AlarmManager is installed in the server room or rack. It controls and forwards

all alarm and fault messages to the responsible persons. The configuration is done with a comfortable PC client,

the Kentix ControlCenter. The connection and installation of the devices is done plug&play with external power

supplies and RJ45 cabling.

1.2. Applications

•Industry and Trade

•Banks

•Authorities and hospitals

•Telecommunications

•Law firms and medical practices

•Energy and water utility

1.3. Safety note

The installation of the AlarmManager must be run by a competent person.

The sole responsibility for protection against misuse of the SIM card is the card owner. The device allows the

use of a PIN number.

In a power failure, the settings of the AlarmManager are not lost. Energized relays drop out and go back when

the power returns in the unswitched output state.

The device sends power outages directly via SMS. The internal energy supply can protect short-term power

failures for 3-5 minutes. To bridge a longer downtimes, use a suitable UPS system.

Installation

To ensure the security and integrity of the operator and the correct operation of the KENTIX AlarmManager, the

execution of the installation only has to be done by an expert. There must also be ensured, that the relevant

requirements are met.

Environment

The installation must be such that the KENTIX AlarmManager and all associated cables are not affected by the

environmental conditions listed here: dust, humidity, excessive heat, direct sunlight, heat sources, devices that

build strong electromagnetic fields, liquids or corrosive chemicals.

See the technical data sheet for more technical data and environment conditions.

Protection

During the installation of the AlarmManager, certain degrees of protection must be guaranteed. Observe the

relevant regulations for installation in certain environments such as industrial or residential and commercial

buildings.!

Page (06-2017, subject to change) kentix.com7

Kentix-Systems - basic infos



2. Connection examples and installation notes

2.1. StarterSet-BASIC/PRO-1

2.2. StarterSet-PRO-2

Page (06-2017, subject to change) kentix.com8

CompleteSet-PRO 2:

1. Connect the MultiSensor-RF with the AlarmManager or the KIO-Power-Adapter.#

Connect the MultiSensor-LAN with a PoE-Switch.#

Follow steps 2 to 8 described for „StarterSet-BASIC/PRO-1“.

2. The KeyPad is added to the configuration like a Radio Sensor.#

For the configuration please follow the steps as described on p.52 in this manual.

3. Save the Configuration to transfer it into the AlarmManager.

Kentix-Systems - basic infos

1. Connect AlarmManager and MultiSensor via

patchcable.

2. Connect power supply to AlarmManager and

current.

3. Download, install and start Kentix ControlCenter.#

(Software-Download on www.kentix.com)

4. Enter Kentix-Default-IP-Address

(192.168.100.222) and the default user data

(admin/password) and press „Login“.#

(check your own network-settings).

5. Setup IP-Address of AlarmManager in the settings.

6. Add Radio Sensor in „Sensor-Devices“.

7. Make individual setup.

8. Save the Configuration to transfer it into the

AlarmManager.



2.3. StarterSet with optional equipment

1. MultiSensor-LAN:#

Establish network connection and external power supply, if needed.#

Connect to the sensor via browser by entering the Default-IP (192.168.100.223).#

Press „Login“ to reach configurations menu (Username: „admin“, Password: „password“).#

Activate AlarmManager communication in the network-section.#

After saving the settings and a restart, the sensor can be configured with the Kentix ControlCenter.

2. Leakage-Sensor:!

The connection of a Leakage-Sensor is realized either by a direct connection to an AlarmManager,

MultiSensor-LAN or MultiSensor-Rack or with a KIO1-Power-Adapter (required for a connection to a

MultiSensor-RF). The configuration is then done on the device to which the leakage sensor is connected.#

Enter a name in the field „System input 1“ and switch the alarming of the input to „Alarm when open“ and

„Always-Active“.

3. MultiSensor-Door / -Rack-Mini:!

Please follow the the instructions for adding new sensors as described in this manual. Also note that there

are differences in procedure depending on the type of MultiSensor.

Page (06-2017, subject to change) kentix.com9

Kentix-Systems - basic infos



2.4. Alarm-inputs

When installing the device follow the instructions in this manual. Please note polarity and technical data of the

inputs.

2.5. Relay contacts

When installing the device follow the instructions listed in this manual.

Connected devices must installed properly following the specifications in this manual. Pay particular attention to

the allowed supply voltages and services for the various consumers in the technical data-sheet.

2.6. Power supply

The devices are supplied with a DC voltage between 10-32VDC. Use only recommended power supplies or

listed power supplies in this document. The polarity of the cable must not be interchanged. According to the two

operation types "Plug'n Play" and "fixed installation", you can power devices from the plug power supply or via a

fixed connection.

Example 1: Power supply of one MultiSensor via the system jack of the AlarmManager

Example 2: Power supply of two MultiSensors via Power Adapter (KIO1) and plug power supply

Electronic equipment is not domestic waste - in accordance with directive 2002/96/EC OF THE

EUROPEAN PARLIAMENT AND THE COUNCIL dated 27th January 2003 concerning used electrical

and electronic appliances, it must be disposed of properly. At the end of its service life, take this unit for

disposal at a designated public collection point.

Spent batteries are special waste!

Do not throw spent batteries into your domestic waste; take them to a collection point for spent batteries.

The products complies with applicable European standards and directives and is confirmed by the CE

mark.

The CE conformity declaration is available on request.



Page (06-2017, subject to change) kentix.com10

Kentix-Systems - basic infos

Andere Handbücher für AlarmManager-BASIC

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Kentix Sicherheitssystem Handbücher

Kentix

Kentix MultiSensor-LAN Bedienungsanleitung

Beliebte Sicherheitssystem Handbücher anderer Marken

Inner Range

Inner Range Concept 2000 Bedienungsanleitung

Climax

Climax Mobile Lite R32 Montageanleitung

CADDX

CADDX NX-6 Bedienungsanleitung

FBII

FBII XL-31 Series Bedienungsanleitung

Johnson Controls

Johnson Controls PENN Connected PC10 Bedienungsanleitung

Aeotec

Aeotec Siren Gen5 Bedienungsanleitung

Blaupunkt

Blaupunkt SA 2700 Bedienungsanleitung

IDEAL

IDEAL Accenta Betriebsanleitung

AJAX

AJAX DoubleButton Bedienungsanleitung

Swann

Swann SW-P-MC2 Bedienungsanleitung

Ecolink

Ecolink Siren+Chime Bedienungsanleitung

Digital Monitoring Products

Digital Monitoring Products XR150 Bedienungsanleitung

EDM

EDM Solution 6+6 Wireless-AE Bedienungsanleitung

Highway Safety Group

Highway Safety Group EA401 Bedienungsanleitung

Siren

Siren LED GSM Bedienungsanleitung

Detection Systems

Detection Systems 7090i Montageanleitung

Se-Kure Controls

Se-Kure Controls MicroMini SK-4841 Bedienungsanleitung

Siemens

Siemens FDM273 Bedienungsanleitung
