Kenwood TK-6900S Bedienungsanleitung

These units are available in the following frequency

bands: 800 MHz, 900 MHz, UHF and VHF MHz repeaters and

base stations and low band base stations. Choose from

the following mounting configurations: Standard 7'

equipment racks or high quality locking equipment

cabinets in 42" (20U) or 77" (40U). Available in LTR®,

CTCSS, DCS repeater control, conventional repeaters and

simplex stations are availalble with tone or DC remote

control. A full line of duplexers/combiners is also available.

LTR®is a registered trademark of E.F. Johnson Company.

Kenwood reliable, high performance

repeaters with 100% continuous

duty cycle

Configuration of cabinet may vary.

Single Channel LTR

Conventional Repeaters and Base Stations

ADS#01405 Printed in USA

JQA-QMA1205

TKR - 9300S TKR - 9301S

Repeater Specifications

Base Station Specifications

RECEIVER

TK-6900S

GENERAL

TRANSMITTER

RECEIVER

Frequency Range

Type 1 29.7 ≈37.0 MHz

Type 2 35.0 ≈43.0 MHz

Type 3 40.0 ≈50.0 MHz

Number of Channels 160

Channel Spacing

Wide 20 kHz (PLL step: 5 kHz)

Narrow

Input Voltage 115/230 VAC, 47 ≈63Hz

Duty Cycle 100%

Kenwood follows a policy of continuous advancement in development.

For this reason specifications may be changed without notice.

Sensitivity

12db Sinad 0.25 µV

20db Quieting 0.35 µV

Selectivity

Wide 85 dB

Narrow

Spurious Response 90 dB

Audio output 13 watt at 4 Ohm

Band Spread

Type 1 7.3 MHz

Type 2 8 MHz

Type 3 10.0 MHz

RF Power Output 30, 80, 130 Watts 130 Watts

Frequency Stability ±0.00015% ±0.00001%

RF Output Impedance 50 Ω50

Modulation 16KOF1D, 16KOF3E 11KOF1D, 11KOF3E

Audio Distortion Less than 2% Less than 5%

Frequency Range RX: 806.0125 ≈820.9875 MHz RX: 896.0125 ≈900.9875 MHz

TX: 851.0125 ≈865.9875 MHz TX: 935.0125 ≈939.9875 MHz

Number of Channels 1 1

Channel Spacing 25 kHz (PLL step: 12.5 kHz) 12.5 kHz (PLL step: 12.5 kHz)

Input Voltage 115/230 VAC, 47– 63Hz 115/230 VAC, 47– 63Hz

Duty Cycle 100% 100%

Sensitivity (EIA 12 dB SINAD) 0.3 µV 0.3 µV

Selectivity -75 dB -70 dB

Modulation Acceptance ± 7 kHz ±3.5 kHz

Spurious and image rejection -85 dB -80 dB

Intermodulation -70 dB -70 dB

Frequency Stability ±0.00015% ±0.00001%

TK-6900S

TRANSMITTER

RF Power Output 100 W

Type of emission:

Wide 16KOF3E

Narrow

Spurious Response 80 dB

FM hum and noise

Wide 55 dB

Narrow

Audio Distortion < 2% at 1000 Hz

Band Spread

Type 1 7.3 MHz

Type 2 8.0 MHz

Type 3 10.0 MHz

information and specifications are subject to change without notice. Custom options and configurations are available, if needed. For more information, call 1-800-TRUNKING.
