Chapter 4: Installation
Installation Procedure
Installation Procedure
1. Determine an appropriate mounting position for the reader. The reader drawing below is actual
size and may be used as a template. Install a single or double gang electrical box or drill the
appropriate mounting for #6 fasteners. If mounting to a metal surface, drill two 7/64 (.109) inch
holes and use the enclosed self tapping screws for mounting.
2. Route the interface cable from the reader and/or power supply to the Host.
3. Prepare the cable by cutting the cable jacket back 2 (two) inches and strip the wires 1/4 inch.
Tinning the wires is not required.
4. Pry off the center face plate by placing a thin blade into the grove that outlines the face of the
reader. Use care to avoid scratching the surface of the reader. The face plate is attached to the
reader by friction only. The screws that hold the enclosure pieces together will be exposed. Loosen
the four screws to open the enclosure (the enclosure screws are captive to the cover).
5. Install the cable fitting on the rear of the reader. Feed the cable through the cable fitting, tighten
the fitting nut so the cable jacket is flush with the printed circuit board. Dress the cable conductors
and connect the reader to the Host according to the terminal descriptions in the dimension diagram
and wiring table. The descriptions are on the PCB guard in the reader. Connect the drain line of the
shield to terminal 2 (Power Supply Ground). Terminal 5, Data Return, is to be connected to the
ground of the Host if the power supply ground is not common with the Host. The opposite end of the
drain line should be cut flush with the jacket and left disconnected.
6. Mount the base of the reader that holds the electronics to the gang box or surface using the two
holes located on the center axis of the reader. Two #6-32 x 1 inch screws are provided for mounting
to a gang box or metal surface.
7. Set the JUMPER switches according to the table in the section,Jumper Switch Settings.
8. After wiring the Reader and power supply, the Reader is ready to be tested. Power up the Reader
and the LED and Beeper will flash and beep 1 times. This indicates that the micro-controller unit is
working properly. If the switches have been set for external control only, the Reader will 3 shorts
and a long. Present an ID card to the Reader and the LED should momentarily turn green,
indicating a read of the card. If the Reader LED is controlled by the Host refer to the Host
description of the LED operation.
Replace the top cover and face plate.
