Menu at a Glance
Software Control and Visualization
You can monitor and control the instrument from a Web browser by
using the instrument's Web interface. To connect, simply enter the
instrument's IP address or hostname in your browser's address bar and
press Enter.
To remotely control the instrument, click the Control Instrument tab and
enter the password (default is keysight).
For detailed operating information, refer to the E36731A User’s Guide.
Switches the instrument function to Power Supply mode (P.Supply) or Load mode (Load).
When function is set to Power Supply mode:
Configures the output sense to 2-wire or 4-wire.
Configures the preferred mode for output on/off transitions.
Configures the protection settings for the output.
Configures the voltage slew rate.
When function is set to Load mode:
Configures the operating mode to CC, CV, CR, or CP.
Configures the input sense to 2-wire or 4-wire.
Configures the protection setting for the load input.
Configures the measurement range for the load input.
Enable or disable the input short.
Common menu for both Power Supply and Load mode
Output Settings > or Input Settings >
Enables or disables the output coupling or synchronization between multiple input/output channels.
Configures the inhibit input mode and Digital IO Pin 3.
Saves and recalls instrument states.
Displays and configures the I/O parameters for remote operations over the USB, LAN, GPIB, or digital
IO interface.
Accesses the self-test, calibration, and help function as well as configures the user preferences, and
sets date and time.
Displays the instrument's error queue. Errors will be cleared after viewing or instrument reset.
Creates, copies, deletes, and renames files and folders on the USB drive attached to the front panel.
Also allows you to capture the current screen to either a bitmap (*.bmp) or portable network graphics
(*.png) file.
Locks and unlocks the display.
