Keysight Technologies 16380C Kurzanleitung

Keysight 16380C Capacitance

Standard Set



Operating Note

Notices

The information contained in this document is subject to change without notice.

This document contains proprietary information that is protected by copyright. All rights

are reserved. No part of this document may be photocopied, reproduced, or translated to

another language without the prior written consent of the Keysight Technologies.

Keysight Technologies Japan, Ltd.

Component Test PGU-Kobe

1-3-3 Higashikawasaki-cho, Chuo-ku Kobe, Hyogo, Japan

Manual Printing History

The manual’s printing date and part number indicate its current edition. The printing date

changes when a new edition is printed. (Minor corrections and updates that are

incorporated at reprint do not cause the date to change.) The manual part number changes

when extensive technical changes are incorporated.

1985 Edition 1(part number: 16380-90200)

November 1998 Edition 2(part number: 16380-90201)

March 2000 Edition 3(part number: 16380-90201)

November 2000 Edition 4 (part number: 16380-90211)

June 2001

Safety Summary

The following general safety precautions must be observed during all phases of operation,

service, and repair of this instrument. Failure to comply with these precautions or with

specific WARNINGS elsewhere in this manual may impair the protection provided by the

equipment. In addition it violates safety standards of design, manufacture, and intended use

of the instrument.

Keysight Technologies assumes no liability for the customer’s failure to comply with

these requirements.

NOTE 16380C comply with INSTALLATION CATEGORY I and POLLUTION DEGREE 2 in

IEC61010-1. 16380C are INDOOR USE product.

•DO NOT Substitute Parts Or Modify Instrument

February 2015

Edition 5(part number: 16380-90221)

Edition 6 (part number: 16380-90221)

Because of the danger of introducing additional hazards, do not install substitute parts

or perform unauthorized modifications to the instrument. Return the instrument to a

Keysight Technologies Sales and Service Office for service and repair to ensure that

safety features are maintained.

•Dangerous Procedure Warnings

Warnings, such as the example below, precede potentially dangerous procedures

throughout this manual. Instructions contained in the warnings must be followed.

Safety Symbol

General definitions of safety symbols used on the instrument or in manuals are listed

below.

Instruction Manual symbol: the product is marked with this symbol when it is necessary for

the user to refer to the instrument manual.

WARNING This warning sign denotes a hazard. It calls attention to a procedure, practice,

condition or the like, which, if not correctly performed or adhered to, could result in

injury or death to personnel.

CAUTION This Caution sign denotes a hazard. It calls attention to a procedure, practice, condition or

the like, which, if not correctly performed or adhered to, could result in damage to or

destruction of part or all of the product.

NOTE Note denotes important information. It calls attention to a procedure, practice, condition or

the like, which is essential to highlight.

Certification

Keysight Technologies certifies that this product met its published specifications at the time

of shipment from the factory. Keysight Technologies further certifies that its calibration

measurements are traceable to the United States National Institute of Standards and

Technology, to the extent allowed by the Institution’s calibration facility, or to the

calibration facilities of other International Standards Organization members.

Warranty

This Keysight Technologies instrument product is warranted against defects in material and

workmanship for a period corresponding to the individual warranty periods of its

component products. Instruments are warranted for a period of one year. Fixtures and

adapters are warranted for a period of 90 days. During the warranty period, Keysight

Technologies Company will, at its option, either repair or replace products that prove to be

defective.

For warranty service or repair, this product must be returned to a service facility designated

by Keysight Technologies. Buyer shall prepay shipping charges to Keysight Technologies

and Keysight Technologies shall pay shipping charges to return the product to Buyer.

However, Buyer shall pay all shipping charges, duties, and taxes for products returned to

Keysight Technologies from another country.

Keysight Technologies warrants that its software and firmware designated by Keysight

Technologies for use with an instrument will execute its programming instruction when

property installed on that instrument. Keysight Technologies does not warrant that the

operation of the instrument, or software, or firmware will be uninterrupted or error free.

Limitation of Warranty

The foregoing warranty shall not apply to defects resulting from improper or inadequate

maintenance by Buyer, Buyer-supplied software or interfacing, unauthorized modification

or misuse, operation outside the environmental specifications for the product, or improper

site preparation or maintenance.

IMPORTANT No other warranty is expressed or implied. Keysight Technologies specifically disclaims the

implied warranties of merchantability and fitness for a particular purpose.

Exclusive Remedies

The remedies provided herein are buyer’s sole and exclusive remedies. Keysight

Technologies shall not be liable for any direct, indirect, special, incidental, or

consequential damages, whether based on contract, tort, or any other legal theory.

Assistance

Product maintenance agreements and other customer assistance agreements are available

for Keysight Technologies products.

For any assistance, contact your nearest Keysight Technologies Sales and Service Office.

Addresses are provided at the back of this manual.

Contents

1. General Information

Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Initial Inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

2.Specifications and Supplemental Performance Charateristics

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Operating Conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Accessories Furnished. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Supplemental Performance Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Capacitance Temperature Coefficient . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Capacitance Stability. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Maximum Allowable Voltage/Current . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Residual Capacitance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Storage Conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

3. Service

Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Recommended Calibration Cycle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Repair . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Contents

1General Information

8Chapter 1

General Information

Description

The Keysight 16380C Capacitance Standard Set consists of three precision capacitors 0.01

µF (16385A), 0.1 µF (16386A), and 1 µF (16387A). One precision capacitor 10 µF

(16388A) is also added with the option. All four capacitors have high capacitance stabillity

and are virtually unaffected by changes in environmental temperature, ensuring

measurement repeatability and reliability.

The 16380C was designed for use in calibrating precision impedance measuring

instruments (such as LCR meters, impedance analyzers, etc.) that have capacitance ranges

between 0.01 µF and 10 µF. The 16380C can be used to directly certify capacitance

measurement accuracy over the 0.01 µF to 10 µF range.

Contents

The 16380C contents are listed in Table 1-1.

Initial Inspection

Inspect the shipping container for damage. If the shipping container or cushioning material

is damaged, it should be kept until the contents of the shipment have been checked for

completeness and the instrument has been checked mechanically.The contents of the

shipment should be as shown in Table 1-1 If the shipment is incomplete, or if there is

mechanical damage or defects, notify the nearest Keysight office. If the shipping container

is damaged, or the cushioning material shows signs of stress, notify the carrier as well as

the Keysight office. Keep the shipping materials for carrier’s inspection. The Keysight

office will arrange for repair or replacement at Keysight Option, without waiting for claim

settlement.

Table 1-1

Description Keysight Part No. Qty.

16385A (0.01 µF) Not Assigned 1

16386A (0.1 µF) Not Assigned 1

16387A (1 µF) Not Assigned 1

16388A (10 µF) (option 001) Not Assigned 1

BNC(f)-(f) Adapters 1250-0080 4

Case 16380-85104 1

Calibration Report Not Assigned 1

Operating Note (This Manual) 16380-90221 1
