KFE KF-HP12-M Bedienungsanleitung

INSTALLATION & OPERATION MANUAL

Gas Countertop Hot Plate

MODELS: KF-HP12-M, KF-HP24-M & KF-HP36-M

(12”-2 burners) (24”-4 burners) (36”-6 burners)

For Service on Your Gas Hot Plate:

Please call the Service Department and ask for contact information for your local service company.

WARNING:

IMPROPER INSTALLATION, ADJUSTMENT, ALTERATION,SERVICE OR

MAINTENANCE CAN CAUSE PROPERTY DAMAGE, INJURY OR DEATH. READ THE

INSTALLATION, OPERATING AND MAINTENANCE INSTRUCTIONS THOROUGHLY

BEFORE INSTALLING OR SERVICING THIS EQUIPMENT.

This manual contains important safety instructions which must be strictly followed when using this

equipment. Please retain this manual for future reference.

Index

ATTENTION OWNERS AND OPERATORS........................................................................................3

UNPACKING & INSTALLATION…………………………………………………………………….……….4-5

WARNINGS & SAFEGUARDS FOR OPERATION .............................................................................6

OPERATINGINSTRUCTIONS………………………………………………………………….……….……7

CLEANING INSTRUCTIONS …………………………………………………………………………….…..8

TROUBLESHOOTING .........................................................................................................................9

LIMITED WARRANTY………………………………………………………………………………………....10

Attention Owners and Operators

The equipment is designed to provide safe and productive processing, cooking and warming of food products

as long as the equipment is used in accordance with the instructions in this manual and is properly maintained.

Unless the operator is adequately trained and supervised there is a possibility of serious injury. Owners of this

equipment bear the responsibility to make certain that this equipment is used properly and safely, and to

strictly follow all of the instructions contained in this manual and the requirements of local, state or federal law.

Owners should not permit anyone to touch this equipment unless they are over 18 years old, are adequately

trained and supervised, and have read and understood this manual. Do not attempt to repair or convert any

gas types on your own. Repairs and conversions are to be made solely by an authorized local servicer.

Owners should also ensure that no customers, visitors or other unauthorized personnel come in contact with

this equipment. Please remember that supplier cannot anticipate every circumstance or environment in which

its equipment will be operated. It is the responsibility of the owner and the operator to remain alert to any

hazards posed by the function of this equipment. If you are ever uncertain about a particular task or the proper

method of operating this equipment, ask your supervisor.

This manual contains a number of precautions to follow to help promote safe use of this equipment.

Throughout the manual you will see additional warnings to help alert you to potential hazards.

Warnings affecting your personal safety indicated by:

Warnings affecting your possible damage to the equipment and property are indicated by:

If any warning labels or this manual are misplaced, damaged, or illegible, or if you require additional copies,

please contact your nearest representative or vender directly for these items at no charge.

Please remember that this manual or the warning labels do not replace the need to be alert,

to properly train and supervise operators, and to use sense when using this equipment.

Please remember that this manual or the warning labels do not replace the need to be alert,

to properly train and supervise operators, and to use sense when using this equipment.

Model

GAS

Number Of Burners

BTU/hr Input Rating

12”-2 burners

Natural

50,000

24”-4 burners

Natural

100,000

36”-6 burners

Natural

150,000

TO AVOID SERIOUS PERSONAL INJURY AND PROPERTY DAMAGE:

·ALWAYS install equipment in a work area with adequate light and space.

·ONLY operate on a solid, level, nonskid surface that is nonflammable and away from sinks and water

hazards.

·NEVER bypass, alter or modify this equipment in any way from its original condition. Doing so may create

hazards and will void warranty.

GAS and GAS PRESSURE

Unit installation must conform with the National Fuel Gas Code, ANSI Z223.1/NFPA 54, the National Gas

Installation Code, CSA-B149.1, or the Propane Installation Code, CSA-B149.2 as applicable and in

accordance with local codes.

The appliance and it’s individual shutoff valve (to be supplied by user) must be disconnected from the gas

supply piping system during any pressure testing of that system at test pressures in excess of ½ psi (3.45

kPa).

These models are designed, built, and sold for commercial use only.

Instructions must be posted in a prominent location. All safety precautions must be taken in the event the user

smells gas. Safety information can be obtained from your local gas supplier.

UNPACKING

Unpack the hot plate immediately after receipt. Remove the gas hot plate from the crate; remove all packaging

on and surrounding the unit and be certain to remove all protective plastics and residues from all surfaces.

Make sure that all parts provided including the L.P. gas conversion kit are located.

If the machine is found to be damaged, save the packaging material and contact the carrier within fifteen (15)

days of delivery. Immediately contact KFE or your local dealer of the equipment. You have no recourse for

damage after fifteen (15) days.

Unpacking & Installation

INSTALLATION

1. Read this manual thoroughly before installation and operation. DO NOT

proceed with installation and operation if you have any questions or do not

understand anything in this manual. Contact your local representative.

2. Select a location for the hot plate that has a level, solid, nonskid surface that is

nonflammable and away from water hazards or sinks, and is in a well-lighted work area

away from children and visitors.

3. Equipment must be installed under proper ventilation as required per local code.

NOTICE: Local codes regarding installation and ventilation vary greatly by area. The

National Fire Protection Association, Inc, states in its NFPA 96 latest edition (see NFPA

page at the beginning of this manual) that local codes are “authority having jurisdiction”

when it comes to requirements for installation of equipment. Therefore, installation

should comply with all local codes.

4. This appliance is equipped for Natural gas, for conversion to LP gas please see another

conversion kits instruction.

5. Screw legs into the permanently fastened nuts on the four corners of the unit and tighten

by hand. Legs must be installed to adequately provide proper ventilation to the unit.

6. Level unit by adjusting the four feet and tighten securely. The adjustable feet have an

adjustment of one inch for lineup with other countertop lines. Do not slide unit with legs

mounted, lift if necessary to move unit.

7. The supplied gas pressure regulator is factory set at 4'' Natural gas W.C. or 10'' for L.P.

8. THESE UNITS ARE SUITABLE FOR INSTALLATION ON NON-COMBUSTIBLE

SURFACES ONLY.

Noncombustible clearances: 0'' sides (0 mm) 6'' rear (152 mm) 4'' floor (102 mm)

9. Do not obstruct the flow of combustion and ventilation air, under the unit by the legs or

behind the unit by the flue. Do not place objects between the bottom of the unit and the

counter top.

10.There must be adequate clearance for removal of the front panel. All major parts

except the burners are removable thru the front if the gas line is disconnected.

11. It may be necessary to adjust the balance of gas volume and air supply to each burner.

This must be done by an authorized service technician.

12. Pipe threading compound must be resistant to the action of liquefied petroleum gases.

DO NOT use an open flame to check for leaks. Check all gas piping for

leaks with a soap and water solution before operating unit.

COMMISSIONING:

Commissioning of your new hot plate is of the utmost importance. Commissioning is the

thorough and methodical testing of the equipment, sub systems, and systems to ensure that

the final product functions properly and safely at the work site. By identifying any potential

problems (i.e.: equipment location, ventilation, local fire/electrical codes, installation,

operator training and certification) prior to equipment being placed into service, costly

outages and potential damages may be avoided.

SAFETY ALWAYS.

TO AVOID SERIOUS PERSONAL INJURY AND PROPERTY DAMAGE:

For your safety, do not store or use gasoline or other flammable vapors or liquids

in the vicinity of this or any other appliances. Keep the area free and clear of

combustible. ( See ANSI Z83. 14B, 1991).

Improper installation, adjustment, alteration, service or maintenance of this

equipment can cause property damage, personal injury, or death and voids

warranty. Read the installation operating and maintenance instructions

thoroughly before installing, or operating this equipment.

Instructions must be posted in a prominent location. All safety precautions must

be taken in the event the user smells gas. If you smell gas, immediately shut off

the main gas valve, extinguish all heat and flames, and call 911. Safety

information can be obtained from your local gas supplier.

IMPORTANT SAFEGUARDS & SAFETY INSTRUCTIONS

When using gas cooking equipment, basic safety precautions should always be

followed, including the following:

The hot plate burners, cooking grates and outside surfaces may become HOT after use. Use caution when

touching the unit.

·Never directly touch the burners or cooking grates while the hot plate is on.

·Always turn off the unit when not in use, servicing or adjusting any parts or attachments, and before

cleaning.

·Never leave the hot plate on overnight.

·Do not operate any equipment with a damaged or leaking gas line, ignitor or valves or if the unit is dropped

or damaged in any manner. Call for service.

·The use of attachments not recommended or sold by the manufacturer may cause fire, injury or even

death.

·Do not use outdoors.

·Do not use this equipment for any use other than the use intended by the manufacturer.

·Never use the hot plate as a heating source

·The hot plate does not contain any user-serviceable parts. Dealers or recommended qualified technicians

should carry out repairs. Do not remove any components or service panels on this product.

·Never bypass, alter, modify or attach any unauthorized parts to this equipment. Doing so may create

hazards and will void warranty

·Supplier takes every care to ensure that all products are safe. Steel cutting procedures used to

manufacture these items result in sharp edges. These sharp edges are removed to the best of our ability;

however, we insist the operator take care when in contact with this piece of equipment.

·Always keep hands, hair and clothing away from heating source.

·Allow the hot plate to cool down after use and before dismantling for cleaning; the unit will be too hot to

handle immediately after use.

Operating Instructions

Operating the Hot Plate - Pilot Lighting Instructions

Before operating hot plate, it should be checked to see that it is sitting level. Adjust the feet to level the hot

plate. Be sure the catch tray has been properly placed.

The pilot lights on the appliance have been set at the factory. Each burner has a pilot light.

1. Make sure all knobs are in the “OFF” position.

2. The main gas valve should be “CLOSED/OFF” for five (5) minutes prior to lighting pilots to clear

any existing gas. (Main gas valve is supplied by others.)

3. Turn “ON/OPEN” the main gas valve to the unit.

4. Light and hold an ignition source (match) at the pilots. When the flame is

established, remove the ignition source. Repeat this step for each burner as each burner has its own

individual pilot. The pilot can be reached through the holes in the front of the unit.

5, Adjust the pilot valve, make sure the pilot flame at 1/2 inch height.

6, Turn each burner knob “ON”. If the burners do not ignite promptly, turn the knobs “OFF”. From the

opening in the front panel, use a screwdriver and turn the pilot valve screw counterclockwise which

will increase the flame height and repeat step 4.

The pilot flame should be as small as possible but large enough to guarantee reliable ignition of the

burners when the knobs are turned to “ON”. The holes located in the front panel are pilot valve

adjustments. Use a screwdriver to turn the valve to adjust the flame height to your desired level.

Igniting the Burner

To ignite the burner, turn knob to the “ON” position. Then back off to the desired flame level. The range of

adjustment is virtually infinite between “ON” and “OFF”.

The space between the legs at the bottom admits combustion air. DO NOT BLOCK THIS SPACE.

All burners are lit from constantly burning pilots. Turning the valve to the desired flame height is all that is

required to put the unit in service.

Do not permit fans to blow directly at the unit. Wherever possible, avoid open windows next to the unit’s sides

or back. Avoid wall type fans which create air cross-currents within a room.

It is also necessary that sufficient air should be allowed to enter the room to compensate for the amount of air

removed by any ventilating system. Otherwise, a subnormal atmospheric pressure will occur, affecting

operation and causing undesirable working conditions.

A properly designed and installed hood will act as the heart of the ventilating system for the room or area in

which the unit is installed, and will leave the unit independent of changing draft conditions.

NOTE: It may be necessary to adjust the balance of gas, volume and air supply to each burner. This

must be done by an authorized service technician.

Shutdown burner

To turn 'OFF' the appliance completely, turn the gas control knob completely clockwise to the 'O' position, the

pilot burner will extinguish.

·DO NOT use any abrasive or flammable cleaning fluids.

·DO NOT hose down, immerse or pressure wash any part of the hot plate, excluding the catch tray.

·NEVER use a scrubber pad, steel wool or abrasive material, or cleaners containing chlorine, iodine and

ammonia or bromine chemicals as these will deteriorate the stainless steel and shorten the life of the unit.

IF CLEANING THE BURNER OF THE HOT PLATE, THE MAIN GAS VALVE MUST BE SWITCHED

TO THE CLOSED POSITION. AFTER CLEANING, THE GAS LINE CAN BE SWITCHED BACK TO

THE OPEN POSITION. PLEASE FOLLOW THE LIGHTING INSTRUCTIONS IN THIS MANUAL TO

RELIGHT

THE HOT PLATE’S PILOT LIGHTS.

RECOMMENDED CLEANING

It takes very little time and effort to keep the hot plate attractive and performing at top efficiency. Please follow

the cleaning steps below:

PART

REQUIRED ACTION

FREQUENCY

Grates

Wash with soap and water.

Daily

Body

Use a clean cloth and a non-abrasive cleaner to clean the stainless

steel body of the hot plate. Wipe the polished areas with a soft cloth.

Daily

Controls

Unit should be turned off when not in use. It is recommended that

the unit be disconnected from the gas supply by closing the main

gas valve. Use a clean cloth to wipe any down controls and/or knobs

Daily

Catch Tray

Once the unit has cooled, remove the catch tray and discard the

waste, debris and crumbs. CAUTION: If the catch tray is permitted to

fill too high, debris is likely to accumulate under the unit. The catch

tray/drawer is removed by pulling forward. USE CAUTION WHEN

REMOVING!

per Use or at least

Daily

Burner Air

Shutter

Openings

Main burner ports must be kept clean. Close the gas valve to the unit

shutting of the gas and extinguishing the pilot light. Clean in place

with a wire brush or clean gas ports with a sharp-pointed metal

instrument to insure open ports or the burners may be removed and

washed in soapy water for 15-20 minutes.

As needed

Regulator

Make sure the vent opening is open and not blocked in any way.

Failure to do so will cause variations in pressure. Your unit will not

function as well and it could shorten the life of the product.

Monthly

Troubleshooting

ISSUE

CAUSE

SOLUTION

Hot plate not lighting

Main gas line is closed

Open valve

Pilot light is not lit

Ignite pilot light

Cause unknown

Call for service

Flame is too high or too low

Adjustment knob is turned up or

down

Adjust flame with control knob

Pilot light not staying lit

Flame is too low

Adjust pilot light flame height

Pilot tube clogged

Replace pilot tube. Call for service

Strong smell of gas in cooking

area

Main gas line leak

Turn off main gas valve. DO NOT

LIGHT FLAME, ignite anything, or

turn/switch on anything electrical

Call fire department if needed and

call for service

Cooking surface is heating up

slowly

Carbon build up

Ensure that the burners are kept

clean and free from carbon build

up/ debris

Gas type of Unit needs to be

converted

Unit ships from the factory Natural

gas. Conversion from Natural Gas

to L.P. is possible for this unit

Contact an authorized servicer.

Do not attempt conversion on

your own

If problems persist and the assigned solution does not remedy the issue, please call

Service Department or your local service company.

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere KFE Kochfeld Handbücher

KFE

KFE CP-HP12-M Bedienungsanleitung

Beliebte Kochfeld Handbücher anderer Marken

Bonnet

Bonnet OPTIMUM 700 Betriebsanleitung

Jenn-Air

Jenn-Air JGCP430 Bedienungsanleitung

Frigidaire

Frigidaire FES367FCC Kurzanleitung

Ztove

Ztove EZ2 DUO Bedienungsanleitung

Kleenmaid

Kleenmaid cooking GCTK9011 Installationsanleitung

Casselin

Casselin CSASRE24 Bedienungsanleitung

Jenn-Air

Jenn-Air JGC2536EB00 Bedienungsanleitung

Waldorf

Waldorf RN8603E-B Bedienungsanleitung

Whirlpool

Whirlpool SMP658CNEIXL Bedienungsanleitung

Wolf

Wolf CI243C/B Bedienungsanleitung

Fulgor Milano

Fulgor Milano F5PGK305S1 Bedienungsanleitung

GE JP389 Bedienungsanleitung

Wells

Wells WV-2HFG Bedienungsanleitung

IKEA

IKEA Lagan HGA4K Bedienungsanleitung

Samsung

Samsung NA36N9755 Bedienungsanleitung

Miele

Miele KM 404 Bedienungsanleitung

Lacor

Lacor 69562 Technisches Datenblatt

Keating Of Chicago

Keating Of Chicago MG-2 Bedienungsanleitung
