Emergency Response
Guide
Version_1
1
OPTIMA PHEV
(JF PHEV)
1. Identification / Recognition
3
2. Immobilization / Stabilization / Lifting
8
3. Disable Direct Hazards / Safety Regulations
9
4. Access to the
Occupants
15
5. Stored
Energy / Liquid / Gases / Solids
18
6. In
Case of Fire
21
7. In
Case of Submersion
25
8. Towing / Transportation /
Storage
26
9. Important
Additional Information
28
Contents
2
OPTIMA PHEV
1. Identification /
Recognition
Initial Response: Identify, Immobilize and Disable
Identify
•
The OPTIMA PHEV is an hybrid electric vehicle. Emergency responders should
respond
to emergency scenarios involving the OPTIMA PHEV accordingly, exercising
extreme
care and caution to avoid contact with the high voltage system within the vehicle.
The
following procedures should be used whenever you are dealing with a OPTIMA
PHEV
at
an emergency scene. However, all operations should be consistent with
your
department's
standard operating procedures, guidelines, and any applicable laws. When
an
PHEV
is damaged in a crash, the high voltage safety systems may have
been
compromised
and present a potential high voltage electrical shock hazard. Exercise
caution
and
wear appropriate personal protective equipment (PPE) safety gear, including
high
voltage
safety gloves and boots. Remove all metallic jewelry, including watches and rings.
3
OPTIMA PHEV
WARNING
1. Identification /
Recognition
1.1 Identifying a Kia OPTIMA PHEV
Charging Port
•
The charging port is located on the side of the vehicle.
#Note
: The doors must be un-locked to open the charge port door.
How to open the charging port
1.
Press the unlock door button, depress
the brake pedal and apply the Electric
Parking Brake (EPB).
2.
Turn OFF all switches, put the vehicle in
P(Park)
position and turn off the vehicle.
3.
Open the charging inlet door by pressing rear
center
edge of the charging inlet door
Unlock
charging door in emergency
4
Orange
Color Cable
Orange color cables run under the floor of the vehicle and under the hood. When opening
the hood, the orange color cable identifies a PHEV.
OPTIMA PHEV
•
If the charging door does not open due to
battery
discharge, open the hood and slightly pull
the
emergency cable as shown left.
•
The charging port door will then open.
1. Identification /
Recognition
1.1 Identifying a Kia OPTIMA PHEV
VIN Label
The
VIN (Vehicle Identification Number) identifies the Plug-in hybrid with a “D”
displayed
in
the 8th position, as shown in the below drawing.
The VIN can be found:
1) VIN Plate can be seen through the windshield from outside.
2) Underneath the front passenger seat (or driver seat)
3)
On the vehicle certification label attached to the driver’s side center pillar
5
OPTIMA PHEV
XXXXXXXDXXXXXXXXX
1. Identification /
Recognition
1.1 Identifying a Kia OPTIMA PHEV
The
OPTIMA plug-in hybrid Cluster Instrument Panel displays the PHEV specific
features
such
as high voltage battery SOC (State of Charge) in the highlighted part.
OPTIMA PHEV Cluster Instrument Panel
6
OPTIMA PHEV
1. Identification /
Recognition
1.1 Identifying a Kia OPTIMA PHEV
Charge Status Indicator
The
High Voltage battery Charge Status Indicator is visible from outside the vehicle. It
is
seen
through the windshield at the center of the crash pad and is illuminated when
the
vehicle
is plugged-in and charging.
7
OPTIMA PHEV
2. Immobilization / Stabilization / Lifting
Chock the wheels
Set the Electronic Parking
Brake (EPB)
Put the vehicle
in P (Park) position
2.2 Vehicle Stabilization
Use standard stabilization (lift) points, as
shown beside. Always be sure to connect to a
structural component of the vehicle and avoid
placing cribbing under high voltage cables,
and other areas not normally considered
acceptable.
2.1 Immobilization
The next step is to immobilize the vehicle to prevent any accidental movement that can
endanger response personnel or civilians. When the OPTIMA PHEV is damaged in a crash, the
vehicle may appear to be shut off, even when it actually is not, due to a lack of engine sounds.
When the "READY" mode light is illuminated on the Instrument Panel, the vehicle can move
silently using the electric motor. Responders should approach the vehicle from the sides and
stay away from the front or rear as they are potential paths for vehicle movement. Be sure to
immobilize the vehicle in the following manner.
8
OPTIMA PHEV
•
When installing a block or jack, avoid high voltage cable, battery and fuel system.
•
If high voltage components or cables are exposed, do not place any support on them.
WARNING
3.
Disable Direct Hazards / Safety Regulations
The
final step in the initial response process, conducted after immobilizing the vehicle, is
to
disable
the vehicle, its SRS components and the high voltage electrical system. To
prevent
current
flow through the system, use one of the following procedures to disable the vehicle
.
3.1 Disabling the System – Smart Key System and “POWER”
START/STOP Button
1.
Confirm the status of the READY light
on
the instrument panel. If the
READY
light is illuminated, the vehicle is ON.
“POWER” START/STOP Button
a)
If the READY light is
NOT
illuminated,
the vehicle is off. Do
not
push
the “POWER”
START/STOP
button
because the vehicle may
start
(go
into READY mode).
b)
To turn OFF the system, put the vehicle in ‘P' (Park) position, and press the
POWER
button
.
9
Case I
Power
Off
12V battery
disconnection
High voltage
shut off
Case II*
12V battery
disconnection
Fuse removal
(Fuse box)
High voltage
shut off
OPTIMA PHEV
*In case of emergency
3.
Disable Direct Hazards / Safety Regulations
2.
If necessary, lower the windows, unlock the doors and open the trunk as
required,
before
disconnecting the 12V battery. Once the 12V battery is disconnected,
power
controls
will not operate. (Refer to below “4. –b” for 12V battery disconnection)
3.
Before disconnecting the 12V battery, remove the Smart Key at least 2 meters
away
from
the vehicle to prevent accidental restart.
10
While depressing the brake pedal
Pressing POWER
button
POWER button
LED color Vehicle condition
One time Off Ready to drive
Without depressing
the brake pedal
Pressing
POWER button
POWER button
LED color Vehicle condition
One time Amber Electrical accessories are operational.
Two times Reddish orange The warning lights can be checked
before the vehicle is started.
Three times Off Off
OPTIMA PHEV
