②MIDDLE CONTROL (2nd setting)
To adjust the mid tone level, first select the middle mode by pressing button ②until “MIDDLE”
appears on the display panel. Within 5 seconds of selecting the middle mode, turn button ②right
or left to adjust the mid level as desired. The mid level will be shown on the display panel from a
GENERAL
m
n
mum o
-
oamax
mum o
.
e
sp
ay w
au
oma
ca
yre
urn
o
the normal indication in 5 seconds after the last adjustment or, when another function is activated.
②TREBLE CONTROL (3rd setting)
To adjust the treble tone level, first select the treble mode by pressing button ②until “TREBLE”
appears on the display panel. Within 5 seconds of selecting the treble mode, turn button ②right
or left to adjust the treble level as desired. The treble level will be shown on the display panel from
a minimum of “TREBLE -10” to a maximum of “TREBLE +10”. The display will automatically return
to the normal indication in 5 seconds after the last adjustment, or when another function is
activated.
②BALANCE CONTROL (4th setting)
To adjust the left-right speaker balance, first select the Balance mode by pressing the Select
button ②until the “BAL” indication appears on the display panel. Within 5 seconds of choosing the
Balance mode, turn right/left to adjust the balance as desired. The balance position will be shown
by the bars on the display panel from “BAL 10L” (full left) to “BAL 10R”(full right). When the volume
level between the left and right speakers is equal, “BAL L=R” will be shown on the display panel.
The display will automatically return to the normal indication in 5 seconds after the last adjustment
or when another function is activated.
②FADER CONTROL (5th setting)
To adjust the front-rear speaker balance, first select the Fader mode by pressing the Select button
un
e
n
ca
on appears on
e
sp
ay pane
.
n
secon
so
c
oos
ng
e
Fader mode, turn right/left to adjust the front-rear speaker level as desired. The fader position will
be shown by the bars on the display panel from “FADER 10F” (full front) to “FADER 10R”(full rear).
When the volume level between the front and rear speaker is equal, “FADER F=R” will be shown
on the display panel. The display will automatically return to the normal indication in 5 seconds
after the last adjustment or when another function is activated.
②BEEP CONTROL (6th setting)
To adjust the Beep mode, first select the Beep mode by pressing the Select button ②until “BEEP”
appears on the display panel. The Beep mode will be shown on the display panel from “BEEP
2ND”, “BEEP OFF” and “BEEP ON”. The display will automatically return to the normal indication in
“
”
.
you wish to hear the “BEEP” sound whenever any function button is pressed. Select “BEEP 2ND”
when you wish to hear the “BEEP” sound whenever any Tuner Pre-set button and/or Track cue or
review buttons are pressed. Once the desired setting is displayed, press button ②to save your
selected setting.
②LOUDNESS CONTROL (7th setting)
When listening to music at low volume levels, this feature will boost the bass and treble response.
This action will compensate for the reduction in bass and treble performance experienced at low
volume. To select the loudness feature, press button ②until “LOUD ON” or “LOUD OFF” is
displayed, then turn button ②left or right to activate or deactivate loudness.
5
