Kia UVO Bedienungsanleitung

2TENE07

UVO SYSTEM USER'S MANUAL

1-2 PART 1. GETTING STARTED

PART 1 GETTING STARTED

DISC EJECT

Ejects the inserted disc.

FM/AM

Turns on FM/AM mode. Each press of the

AM key will change the band in the

order of FM →AM →FM.

3SAT

Turns on SIRIUS

mode.

4MEDIA

Turns on MEDIA mode. Each press of the

MEDIA

key will change the mode in the

order of CD → USB/iPod®/zune®

→JUKEBOX

→AUX →BT Audio →PANDORA →CD.

POWER/VOLUME

Push : Turns Power On/Off.

Dial : Turns Volume Up/Down.

∨SEEK/TRACK ∧

Short (under 0.8 seconds)

In FM/AM mode, automatically searches

and plays the previous or next frequency.

Control Panel

Controls and Features

6 7

※No will be shown if the exterior Amplifier feature is not supported.

PART 1. GETTING STARTED 1-3

GETTING STARTED

In SIRIUS

mode, automatically searches

and plays the previous or next channel.

In MEDIA mode (CD, MP3, USB, iPod

zune

, BT AUDIO), plays the previous or

next track, song, or file. In PANDORA

Radio, PANDORA Radio skip (Seek up).

In JUKEBOX mode, plays the previous or

next track.

Long (over 0.8 seconds)

In FM/AM mode, quickly moves through

the frequencies when the button is pressed

and held. Once released, automatically

searches and plays the previous or next

frequency.

In SIRIUS

mode, quickly moves to the

previous or next channel.

In MEDIA mode (CD, MP3, USB, iPod

zune

, BT AUDIO), REW/FF the current

track, song, or file.

In JUKEBOX mode, REW/FF the current

track.

∨CATEGORY ∧

In SIRIUS

mode, moves to the previous or

next SIRIUS

category.

TUNE

In FM/AM mode, turn the knob to manually

search for frequencies.

In SIRIUS

mode, turn the knob to

manually search for channels. Press the

knob to receive the selected channel.

In MEDIA mode (CD, MP3, USB, iPod

zune

), turn the knob to manually search for

the previous or next track, song, or file.

Press the knob to receive the selected

track, song, or file. In PANDORA Radio,

searches PANDORA Radio stations.

In JUKEBOX mode, turn the knob to

manually search for the previous or next

track. Press the knob to receive the

selected track.

SETUP

Displays SETUP mode.

PHONE

Displays Bluetooth

wireless technology

Phone mode.

eServices

Displays UVO eServices mode.

DISP

Turns off the screen.

RESET

Reset the system to be used if system is

acting abnormally.

1-4 PART 1. GETTING STARTED

PART 1 GETTING STARTED

Steering Wheel

∨SEEK/TRACK ∧

Short (under 0.8 seconds)

In FM/AM mode, automatically searches

and plays the previous or next preset

frequency.

In SIRIUS

mode, automatically searches

and plays the previous or next preset

channel.

In MEDIA mode (CD, MP3, USB, iPod

zune

, BT AUDIO), plays the previous or

next track, song, or file. In PANDORA

Radio, PANDORA Radio skip (Seek up).

In JUKEBOX mode, plays the previous or

next track.

Long (over 0.8 seconds)

In FM/AM mode, quickly moves through

the frequencies when the button is pressed

and held. Once released, automatically

searches and plays the previous or next

frequency.

In SIRIUS

mode, quickly moves to the

previous or next channel.

In MEDIA mode (CD, MP3, USB, iPod

zune

, BT AUDIO), REW/FF the current

6 7

PART 1. GETTING STARTED 1-5

GETTING STARTED

track, song, or file.

In JUKEBOX mode, REW/FF the current

track.

+VOLUME -

Turns Volume Up/Down.

MODE

Short (under 0.8 seconds)

Changes the mode. Each press will

change

modes in the order of FM → AM →

SIRIUS

→CD → USB/iPod

/zune

→

JUKEBOX →AUX → BT Audio →

PANDORA →FM.

Long (over 0.8 seconds)

While the system is off, turn the system on.

While the system is on, turn off the system.

MUTE

Mutes the sound.

Voice Command

Short (under 0.8 seconds)

If Voice recognition is off, turns on Voice

recognition.

If system is speaking, interrupts speaking

and enters listening mode.

Long (over 0.8 seconds)

If Voice recognition is on, turns off Voice

recognition.

SEND (Bluetooth

wireless technology

Phone)

Pressing this key will receive an incoming

call. If the Audio is on, the Bluetooth

wireless technology phone screen will be

displayed.

When a SMS message is received, reads

back message.

END (Bluetooth

wireless technology

Phone)

Pressing this key will reject an incoming

call. If pressed during a call, the current call

will be ended.

When a SMS message is received, ignores

message.

1-6 PART 1. GETTING STARTED

PART 1 GETTING STARTED

Basic Features

System Power

1. Turning System Power On

1. Turn on the ignition.

2.While the system is off, press the

POWER/VOL

knob to turn the system on.

3. The system will automatically restore the

most recently played mode. For example,

pressing the

POWER/VOL

knob will turn on

the system and display FM radio mode if

FM mode had been the last operated

mode prior to turning off the system.

4.You can also turn the system on by

pressing the FM

AM , SAT and MEDIA

keys.

Note

●

Pressing any one of the FM

AM , SAT ,

and MEDIA keys will turn on the system

and display the last mode corresponding to

each key. For example, pressing the MEDIA

key while a CD or other media source is

loaded, will turn on the system and display

CD mode if the last operated MEDIA mode

prior to turning off the system had been CD

mode.

2. Turning System Power Off

1.While the system is on, press the

POWER/VOL

knob to turn off the system.

Note

●

If the system power was on when the ignition

was turned off, the system will turn back on

automatically. Conversely, if the system

power was off when the ignition was turned

off, the system will remain off.

●

If the battery voltage is low, the audio may

take a prolonged time to boot upon turning

on the vehicle.

PART 1. GETTING STARTED 1-7

GETTING STARTED

Select Display Language

The UVO system allows you to select the

preferred display language for maximum

convenience and system usability. The system

provides you with options of three languages -

English, French (Canadian) and Spanish. The

default language is English.

1. Press the SETUP key on the control panel.

2. Press the Main button.

3.Press the English button next to the

Language menu.

4. Select the desired language.

5. The system will reboot and automatically

restore the most recent mode in the new

language.

Resetting and Initializing

UVO system

1. Resetting the system

If the system is behaving abnormally, press the

reset button to reset the system.

1. Use a ball-point pen or similar object to

press the RESET key.

2. The system will reboot and automatically

restore the most recent mode.

Caution

●

The reset button should only be used in case of

system malfunction. Never use the reset key while

the system is operating normally as it may cause

damage to the system.

●

If you wish to reset while the system is operating

normally, turn the power off first then reset.

1-8 PART 1. GETTING STARTED

PART 1 GETTING STARTED

2. Initializing the system

1. Press the SETUP key on the control panel.

2. Press the System button.

3. Press the Factory defaults button.

Note

●

Initializing the system will erase all Phone

settings, and other changes which you have

made to the system.

●

Some songs in the USB or CD may be

misrecognized during the indexing process.

If such problems persist, reset the device

using the Factory Defaults button in

SETUP>System.

●

For updating the system, visit http://www.kia.

com

PART 1. GETTING STARTED 1-9

GETTING STARTED

Sound and Display Settings

Sound Settings

Sound settings can be adjusted from any audio

mode. The system allows you to optimize

various sound settings to add convenience

when listening to the system.

Press the Sound button on the main screen of

each audio mode (FM/AM, SIRIUS

, MEDIA,

PANDORA Radio, JUKEBOX) to enter Sound

Setup.

Note

●

Changes are saved as they are made. In

other words, once you change a setting, the

new setting will become saved.

1. FADER/BALANCE

Fader/Balance allows you to adjust the position

of sound within the vehicle. For instance,

adjusting the sound so that it is closer to the

driver-side seat will proportionally lower the

volume in the passenger-side and rear seats.

1. Press the Fader/Balance setting button.

2.Use the

▲

▼

◀

▶

buttons to

make adjustments to the sound position.

3. Press the button to return to Sound

Setup.

Note

●

Press the Default button to restore the

default setting.

1-10 PART 1. GETTING STARTED

PART 1 GETTING STARTED

2. TONE

Tone allows you to make changes to the

Treble, Middle and Bass settings.

1. Press the Tone setting button.

2.Use the

◀

▶

buttons to make

adjustments to the Treble, Middle and

Bass. Press the button to return to

Sound Setup.

Note

●

Press the Default button to restore the

default setting.

3. Touch Screen Beep

Touch Screen Beep allows you to turn on/off

the beep that sounds when you touch the

screen.

1.In Sound Setup, press the On or

Off button next to the Touch Screen

Beep menu to turn the feature on or off.

4. Speed Dependent Volume Control

Speed Dependent Volume Control allows you

to automatically control the volume according

to the speed of the vehicle. This feature will

gradually increase the volume as speed

increases to offset outside noise.

1. Press the On or Off button next to

the Speed Dependent Volume Control

menu to turn the feature on or off.

Andere Handbücher für UVO

Inhaltsverzeichnis

Andere Kia Auto-Videosystem Handbücher

Kia

Kia Car Multimedia System Bedienungsanleitung

Kia

Kia 2013 Rio Bedienungsanleitung

Kia

Kia ADC10F6GG Bedienungsanleitung

Kia

Kia EV6 Bedienungsanleitung

Kia

Kia Stringer Bedienungsanleitung

Kia

Kia ADB10VEGN Bedienungsanleitung

Kia

Kia CADENZA 2017 Bedienungsanleitung

Kia

Kia AC141C6AN Bedienungsanleitung

Kia

Kia Car Multimedia System Bedienungsanleitung

Kia

Kia ADB10F6GG Bedienungsanleitung

Kia

Kia Optima Hybrid Stücklistenhandbuch

Kia

Kia 2022 Niro Bedienungsanleitung

Kia

Kia MTXM100YPPE Bedienungsanleitung

Kia

Kia Optima Bedienungsanleitung

Kia

Kia AVB40D5AN Bedienungsanleitung

Kia

Kia Sorento 2011 Stücklistenhandbuch

Kia

Kia ADC40DLAN Bedienungsanleitung

Kia

Kia ADBC0G6EE Bedienungsanleitung

Kia

Kia 2012 soul Bedienungsanleitung

Kia

Kia ADBC0H8EE Bedienungsanleitung

Kia

Kia ATC40DQAN Bedienungsanleitung

Kia

Kia Sportage Stücklistenhandbuch

Kia

Kia AVC41G5AN Bedienungsanleitung

Kia

Kia ADBC0DQEE Bedienungsanleitung

Beliebte Auto-Videosystem Handbücher anderer Marken

Stinger

Stinger HEIGH10 RB10RAM13B Bedienungsanleitung

Eonon

Eonon E1057 Bedienungsanleitung

Milion

Milion D2223 Bedienungsanleitung

Metra Electronics

Metra Electronics 99-8153 Bedienungsanleitung

Voxx Electronics

Voxx Electronics HR8MA1 Bedienungsanleitung

Axxera

Axxera AV604Bi Bedienungsanleitung

Clarion

Clarion NX706E Bedienungsanleitung

Pyle view

Pyle view PLDN74BTi Bedienungsanleitung

Clarion

Clarion NX602 Bedienungsanleitung

PowerAcoustik

PowerAcoustik PTID-5850N Bedienungsanleitung

RCA

RCA DRC6296 - Twin 9" Mobile DVD System Benutzerhandbuch

Lanzar

Lanzar SVDVD5 Bedienungsanleitung

Eonon

Eonon E1060 Bedienungsanleitung

Macrom

Macrom M-AN900 Bedienungsanleitung

Hyundai

Hyundai BAPE-L3000N Bedienungsanleitung

r.LiNK

r.LiNK RL2-UCON8-SM Bedienungsanleitung

Blaupunkt

Blaupunkt DVP 01C Bedienungsanleitung

DP Audio Video

DP Audio Video dbd807nav Bedienungsanleitung
