Manual P/N 2535-7201-00 Rev D

ATTENTION: Please take a few minutes to thoroughly read

this user’s guide which should be saved for future reference

and passed on to any subsequent owner.

Carbon Monoxide Alarm

User’s Guide

Models: 8LLCO and

8LLDCO (with digital display)

Model: 8LLCO

Model: 8LLDCO

with Digital Display

EN 50291-1: 2010

Licence No: KM 98848

2535-7201-00_revD_V1.indd 12535-7201-00_revD_V1.indd 1 2011.12.26 9:35:54 AM2011.12.26 9:35:54 AM

Carbon Monoxide Alarm Procedure

If alarm sounds ( 4 loud audible pulses followed by a pause

for 5 seconds):

1) Immediately move to fresh air - outdoors or by an open door/

window. Do a head count to check that all persons are

accounted for. Do not re-enter the premises nor move away

from the open door/window until the emergency services

responders have arrived, the premises have been aired out, and

your alarm remains in its normal condition.

2) Call Gas Emergency Services: 0800 111 999 , or your local Gas

Safe Registered Engineer:

Never restart the source of a CO problem until it has been

corrected. Never ignore the sound of the alarm!

If the alarm is sounding, pressing the test/reset button will

terminate the alarm. If the CO condition that caused the alert

in the first place continues, the alarm will reactivate. If the

unit alarms again within six minutes, it is sensing high levels

of CO which can quickly become a dangerous situation.

WARNING:

Activation of the CO

Alarm indicates the presence of Carbon

Monoxide (CO) which can kill you.

PHONE NUMBER:

What to do When the Alarm Sounds!

2535-7201-00_revD_V1.indd 22535-7201-00_revD_V1.indd 2 2011.12.26 9:35:55 AM2011.12.26 9:35:55 AM

Welcome

Note: Many times throughout this User’s Guide, we will refer to

Carbon Monoxide as “CO”.

This Kidde carbon monoxide (CO) alarm is an important part of your

family’s home safety plan. This alarm has been designed and tested to

detect CO buildup in a residential environment. Your alarm is for use

specifically in the home. As an owner of a CO alarm, there are some

basic facts you should know about for your protection.

Many people think that CO alarms operate like smoke alarms. Like

smoke alarms, CO alarms monitor the air in your home and sound a

loud alarm to warn you of trouble. The way you respond to a CO alarm

is quite different than a smoke alarm. That’s because a house fire and a

CO problem are two distinctly different situations. If your smoke alarm

were to alarm, you would quickly be able to judge the level of danger

you were in with your senses. You can see and smell the smoke, feel the

heat, see, and possibly hear the fire burning. You can also readily see

if your smoke alarm is alarming in a non-emergency situation. Because

your sense of sight, smell, hearing and touch give you information, you

can almost instantly judge what action to take if you hear your smoke

alarm.

CO is an invisible, odourless, tasteless and non-irritating gas – completely

undetectable to your senses. That’s why it is important to your safety

that you have a CO alarm.

Important Warning Statements

IMPORTANT: This carbon monoxide alarm is designed to detect

carbon monoxide from ANY source of combustion. It is NOT

designed to detect smoke, fire, or any other gas.

WARNING: Carbon monoxide alarms are not smoke alarms. This

carbon monoxide alarm is not a substitute for installing and

maintaining an appropriate number of smoke alarms in your

home.

This carbon monoxide alarm will not sense smoke, fire, or any

poisonous gas other than carbon monoxide even though carbon

monoxide can be generated by fire. For this reason you must

install smoke alarms to provide early warning of fire and to pro-

tect you and your family from fire and its related hazards.

CAUTION: This alarm will only indicate the presence of carbon

monoxide at the sensor. Carbon monoxide may be present in

other areas.

2535-7201-00_revD_V1.indd 32535-7201-00_revD_V1.indd 3 2011.12.26 9:35:55 AM2011.12.26 9:35:55 AM

Important Warning Statements

This product is intended for use in ordinary indoor locations of

family living units. It is not designed to measure compliance with

Occupational Safety and the Health & Safety Executive (HSE).

The installation of this device should not be used as a substitute

for proper installation, use and maintenance of fuel burning

appliances, including appropriate ventilation and exhaust sys-

tems. It does not prevent CO from occurring, nor can it solve and

existing CO problem.

WARNING: This device is designed to protect individuals from

acute effects of carbon monoxide exposure. It may not prevent

the chronic effects of carbon monoxide exposure. It may not fully

safeguard individuals with specific medical conditions. If in doubt,

consult a medical practitioner.

Individuals with medical problems may consider using warning

devices which provide audible and visual signals for carbon mon-

oxide concentrations under 30 PPM.

This carbon monoxide alarm requires a continuous supply of elec-

trical power – it will not work without power.

Contents of This User’s Guide

1. Information About Carbon Monoxide

2. Product Features and Specifications

3. Installation Locations

4. Installation Instructions

5. 8LLCO Operating Characteristics

6. 8LLDCO (with digital display) Operating Characteristics

7. Alarm Characteristics

8. Maintenance

9. Limited Warranty

Environmental Protection

Waste electrical products should not be disposed of with

household waste. Please recycle where facilities exist.

Check with Local Authority or retailer for recycling advice.

2535-7201-00_revD_V1.indd 42535-7201-00_revD_V1.indd 4 2011.12.26 9:35:55 AM2011.12.26 9:35:55 AM

1. Information About Carbon Monoxide

General Carbon Monoxide Information

Carbon monoxide is a colourless, odourless and tasteless poison gas

that can be fatal when inhaled. CO inhibits the blood’s capacity to carry

oxygen.

Periodically review this alarm manual and discuss your CO alarm emer-

gency procedure with all the members of your family. Never ignore a CO

alarm. A true alarm is an indication of potentially dangerous levels of

CO. CO alarms are designed to alert you to the presence of CO before

an emergency – before most people would experience symptoms of CO

poisoning, giving you time to resolve the problem calmly.

Determine if anyone in the household is experiencing symptoms of CO

poisoning. Many cases of reported CO poisoning indicate that while

victims are aware they are not well, they become so disoriented they

are unable to save themselves by either exiting the building or calling

for assistance. Also, young children and household pets may be the first

affected. You should take extra precautions to protect high-risk persons

from CO exposure because they may experience ill effects from CO at

levels that would not ordinarily affect a healthy adult.

Symptoms of CO Poisoning

The following common symptoms are related to CO poisoning and

should be discussed with ALL members of the household.

Mild Exposure:

Slight headache, nausea, vomiting, fatigue (often described as “flu-like”

symptoms).

Medium Exposure:

Severe throbbing headache, drowsiness, confusion, fast heart rate.

Extreme Exposure:

Unconsciousness, convulsions, cardio-respiratory failure, death.

If you experience even mild symptoms of CO poisoning, consult your

doctor immediately!

2535-7201-00_revD_V1.indd 52535-7201-00_revD_V1.indd 5 2011.12.26 9:35:55 AM2011.12.26 9:35:55 AM

1. Information About Carbon Monoxide

Carbon Monoxide PPM Levels

(model 8LLDCO with digital display only)

Model 8LLDCO is equipped with a digital display that shows levels of

CO (displayed in PPM – parts per million). Learn the difference between

dangerous, high, mid and low levels.

Dangerous Levels:

When someone is experiencing symptoms of CO poisoning and CO read-

ings are generally above 100 PPM. Anytime someone is experiencing the

symptoms of CO poisoning this should be treated as an emergency. See

“What to do When the Alarm Sounds” (inside front cover).

High Levels:

Generally above 100 PPM, with no one experiencing symptoms. This

should be treated as an urgent situation. See “What to do When the

Alarm Sounds” (inside front cover).

Mid Levels:

Generally between 50 PPM to 100 PPM. This should be cause for concern

and should not be ignored or dismissed. See “What to do When the

Alarm Sounds” (inside front cover).

Low Levels:

Generally below 50 PPM. Kidde recommends you take action to eliminate

the source of CO. See “What to do When the Alarm Sounds” (inside

front cover).

IMPORTANT: Model 8LLCO does not have a digital display and

does not display carbon monoxide levels in PPM. If the alarm

sounds, it should be treated as a potentially serious condition. See

“What to do When the Alarm Sounds” (inside front cover).

Possible Sources of Carbon Monoxide

Inside your home, appliances used for heating and cooking are the

most likely sources of CO. Vehicles running in attached garages can also

produce dangerous levels of CO.

CO can be produced when burning any fossil fuel, such as gasoline, pro-

pane, natural gas, oil and wood. It can be produced by any fuel-burning

appliance that is malfunctioning, improperly installed, or not ventilated

correctly, such as:

• Cars, furnaces, gas ranges/stoves, gas clothes dryers, water heaters,

portable fuel burning space heaters and generators, fireplaces, wood-

burning stoves and certain swimming pool heaters.

• Blocked chimneys or flues, back drafts and changes in air pressure, cor-

roded or disconnected vent pipes, loose or cracked furnace

exchangers.

2535-7201-00_revD_V1.indd 62535-7201-00_revD_V1.indd 6 2011.12.26 9:35:55 AM2011.12.26 9:35:55 AM

1. Information About Carbon Monoxide

• Vehicles and other combustion engines running in an open or

closed garage, attached or near a home.

• Burning charcoal or fuel in grills and barbecues in an enclosed area.

Conditions That Can Produce Carbon Monoxide

The following conditions can result in transient CO situations:

• Excessive spillage or reverse venting of fuel-burning appliances

caused by outdoor ambient conditions, such as, wind direction and/

or velocity, including high gusts of wind, heavy air in the vent pipes

(cold/humid air with extended periods between cycles).

• Negative pressure resulting from the use of exhaust fans.

• Simultaneous operation of several fuel-burning appliances competing

for limited internal air.

• Vent pipe connections vibrating loose from clothes dryers, furnaces,

or water heaters.

• Obstructions in, or unconventional, vent pipe designs which can

amplify the above situations.

• Extended operation of unvented fuel-burning devices (range, oven,

fireplace, etc.).

• Temperature inversions which can trap exhaust gases near the

ground.

• Vehicle idling in an open or closed garage, or near a home.

Caravans and Boats

The following can lead to carbon monoxide being produced;

• Using LPG cooking appliances for space heating

• Leaving LPG appliances on overnight

• Barbecue’s within the boat cabin or near a caravan door (e.g. under

an awning)

To be safe, know the possible sources of CO in your home. Keep fuel-

burning appliances and their chimneys and vents in good working

condition. Learn the early symptoms of exposure, and if you suspect

CO poisoning, move outside to fresh air and get emergency help. Your

first line of defense is an annual inspection and regular maintenance of

your appliances. Contact a licensed contractor or call your local utility

company for assistance.

2535-7201-00_revD_V1.indd 72535-7201-00_revD_V1.indd 7 2011.12.26 9:35:55 AM2011.12.26 9:35:55 AM

1. Information About Carbon Monoxide

Information About Carbon Monoxide Alarms –

What They Can and Cannot Do:

CO alarms provide early warning of the presence of CO, usually before a

healthy adult would experience symptoms. This early warning is possible,

however, only if your CO alarm is located, installed and maintained as

described in this guide.

Because carbon monoxide is a cumulative poison, long-term exposures to

low levels may cause symptoms, as well as short-term exposures to high

levels. This Kidde unit has a time-weighted alarm – the higher the level of

CO present, the sooner the alarm will be triggered.

This CO alarm can only warn you of the presence of CO. It does not

prevent CO from occurring, nor can it solve an existing CO problem. If

your unit has alarmed and you’ve provided ventilation by leaving your

windows and doors open, the CO buildup may have dissipated by the

time help responds. Although your problem may appear to be temporar-

ily solved, it’s crucial that the source of the CO is determined and that

the appropriate repairs are made.

This CO alarm is designed to act as a monitor; it is not designed for use

as a short-term testing device to perform a quick check for the presence

of CO.

CO alarms have limitations. Like any other electronic device, CO alarms

are not fool-proof. CO alarms have a limited operational life. You must

test your CO alarm weekly, because it could fail to operate at any time.

If your CO alarm fails to test properly, or if its self-diagnostic test reveals

a malfunction, immediately have the unit replaced. This alarm will not

monitor CO levels while in an error condition.

CO alarms can only sense CO that reaches the unit’s sensor. It’s possible

that CO may be present in other areas without reaching the alarm. The

rate and ability that which CO reaches the alarm may be affected by:

• Doors or other obstructions.

• Fresh air from a vent, an open window or other source.

• CO being present on one level of the home and not reach a CO alarm

installed on a different level. (For example, CO in the basement may

not reach an alarm on the second level, near the bedrooms).

For these reasons, we recommend you provide complete coverage by

placing a CO alarm on every level of the home. Please carefully read all

information in sections 3 and 4 on properly installing this CO alarm.

CO alarms should not be used to detect the presence of natural gas

(methane), propane, butane, or other combustible fuels.

Instruct children never to touch, unplug or otherwise interfere with the

alarm. Warn children of the dangers of CO poisoning.

2535-7201-00_revD_V1.indd 82535-7201-00_revD_V1.indd 8 2011.12.26 9:35:55 AM2011.12.26 9:35:55 AM

2. Product Features and Specifications

Green,

Power LED

Red,

Alarm LED

Test / Reset

Button

Peak Level Button

Digital Display

Green,

Power LED

Red,

Alarm LED

Test / Reset

Button

WARNING: Ten (10) years from initial power up, this alarm will

“beep” two times every 30 seconds to indicate that it is time

to replace the alarm. Replace the alarm immediately! It will not

detect CO in this condition.

To help identify the date to replace the alarm, a label has been affixed

to the side of the alarm. Write the installation date in a permanent

marker on this label.

Model 8LLCO

Model 8LLDCO

with digital display

2535-7201-00_revD_V1.indd 92535-7201-00_revD_V1.indd 9 2011.12.26 9:35:55 AM2011.12.26 9:35:55 AM

Recommended Installation Locations

CO alarms should be mounted in

or near bedrooms and living areas.

It is recommended that you install

a Kidde CO alarm on each level of

your home.

When choosing your installation

locations, make sure you can hear

the alarm from all sleeping areas.

If you install only one CO alarm in your home, install it near bedrooms

to increase your chances of hearing the alarm as you sleep, not in the

basement or furnace room.

• When wall mounting, place out of reach of children. Under no

circumstances should children be allowed to handle the CO alarm.

• Placing the alarm at eye level allows for optimum monitoring of the

digital display.

3. Installation Locations

DINING KITCHEN BEDROOM BEDROOM

BEDROOM

LIVING ROOM

Recommended Locations

Temperature:

Operating Range: 0° to 40°C

Humidity:

Operating range: Up to 90% (non-condensing)

Audible Alarm:

85+ dB at 1 metre @ 3.4±0.5 KHz pulsing alarm

Sensor:

Electrochemical

Power:

Sealed-in Lithium batteries

Accuracy of Digital Display: (Model 8LLDCO Only)

30-999 PPM +/-30% when measured in conditions of 80° F (+/- 10°

F), atmospheric pressure +/- 10% and 40% +/- 3% relative humidity.

Display readings may vary slightly depending on changes in the ambient

condition (temperature, humidity) and the condition of the sensor.

Alarm Response Times:

30 PPM = no alarm in 120 minutes., 50 PPM = Must alarm in 60-90 minutes.,

100 PPM = Must alarm in 10-40 minutes., 300 PPM = Must alarm within 3minutes.

2. Product Features and Specifications

2535-7201-00_revD_V1.indd 102535-7201-00_revD_V1.indd 10 2011.12.26 9:35:55 AM2011.12.26 9:35:55 AM

Andere Handbücher für 8LLCO

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Kidde Kohlenmonoxid-Alarm Handbücher

Kidde

Kidde KN-COPP-B-LS-UK Bedienungsanleitung

Kidde

Kidde P4010ACSCO-WF Bedienungsanleitung

Kidde

Kidde KN-COP-DP Bedienungsanleitung

Kidde

Kidde KN-COB-IC Bedienungsanleitung

Kidde

Kidde KN-COB-ICB-CA Bedienungsanleitung

Kidde

Kidde KN-COPP-3 Bedienungsanleitung

Kidde

Kidde P4010ACLEDSCO-2 Bedienungsanleitung

Kidde

Kidde NIGHTHAWK KN-COSM-B Bedienungsanleitung

Kidde

Kidde KN-COPF-I Bedienungsanleitung

Kidde

Kidde KN-COB-LCB-A Bedienungsanleitung

Kidde

Kidde KN-COB-B-LPM Bedienungsanleitung

Kidde

Kidde KN-COPP-3 Bedienungsanleitung

Kidde

Kidde KN-COPP-B-LS-UK Bedienungsanleitung

Kidde

Kidde K7CO Bedienungsanleitung

Kidde

Kidde P4010ACSCO-WF Bedienungsanleitung

Kidde

Kidde KN-COB-B-LS (900-0233) Bedienungsanleitung

Kidde

Kidde KN-COB-DP-H) Bedienungsanleitung

Kidde

Kidde KN-COB-B-LS (900-0233) Bedienungsanleitung

Kidde

Kidde KN-COPF-I Bedienungsanleitung

Kidde

Kidde P4010DCSCO-W Bedienungsanleitung

Kidde

Kidde KN-OOB-B Bedienungsanleitung

Kidde

Kidde KN-COB-DP2 Bedienungsanleitung

Kidde

Kidde CO120X Bedienungsanleitung

Kidde

Kidde KN-COPP-3-RC Bedienungsanleitung

Beliebte Kohlenmonoxid-Alarm Handbücher anderer Marken

Honeywell

Honeywell H450EN Bedienungsanleitung

First Alert

First Alert FCD2B Bedienungsanleitung

Honeywell

Honeywell SF350RVUL Bedienungsanleitung

Poolguard

Poolguard DAPT-2 Bedienungsanleitung

Ei Electronics

Ei Electronics Ei 261D Handbuch

Bacharach

Bacharach Model 105 Handbuch

Firex

Firex COZ-1 Bedienungsanleitung

Costar

Costar 12RV-D Bedienungsanleitung

First Alert

First Alert CO410 Bedienungsanleitung

FireAngel

FireAngel CO-9X Bedienungsanleitung

Costar

Costar 12-24SIR Bedienungsanleitung

System Sensor

System Sensor CO1224T Bedienungsanleitung

Deltronic Security

Deltronic Security CN-1231 Bedienungsanleitung

GE Interlogix

GE Interlogix 240 COE - Carbon Monoxide Alarm Bedienungsanleitung

Sygonix

Sygonix 2377794 Bedienungsanleitung

Convoy Tech

Convoy Tech CO311 Bedienungsanleitung

nest

nest PROTECT Bedienungsanleitung

Bosch

Bosch CRS-WLCD-TA869 Bedienungsanleitung
