Thank you for purchasing this Kidde Combination Smoke/CO Alarm.

This model is battery operated and features a non-replaceable,

sealed-in battery and SMART HUSHTM Control to temporarily silence

nuisance alarms.

Important: Please take a few minutes to thoroughly read this user

guide which should be saved for future reference and passed on to

any subsequent owner.

Teach children how to respond to the alarm and that they should never

play with the unit.

This Kidde Smoke/CO Alarm was designed to detect both smoke and

carbon monoxide from any source of combustion in a residential environ-

ment. It is not designed for use in a recreational vehicle (RV) or boat.

P/N: 2555-7201-00 RevA

For your convenience, write down the following information. If you

call Product Support, these are the first questions you will be asked.

Smoke Alarm Model Number:

(located on back of alarm)

Date Code: (located on back of alarm)

The National Fire Protection Association (NFPA)

and the manufacturer recommend replacing this

alarm ten years from the date code.

Combo Smoke/CO Alarm User Guide

P3010CU

Combination Photoelectric

Smoke and Carbon Monoxide Alarm

with Voice Message System

Where Purchased:

Date of Purchase:

For questions concerning this alarm please call Product Support at 1-800-880-6788.

WHAT TO DO WHEN THE ALARM SOUNDS

SMOKE ALARM ACTIVATION

Smoke alarm pattern is three long beeps, Voice message

Fire!, three long beeps, repeating.

The smoke alarm takes precedence when both smoke

and carbon monoxide are present.

• Alert small children in the home as well as anyone else that might have

difficulty recognizing the importance of the alarm sounding or that

might have difficulty leaving the area without help.

• Leave immediately by your escape plan. Every second counts, so don’t

waste time getting dressed or picking up valuables.

• In leaving, don’t open any inside door without first feeling its surface. If

hot, or if you see smoke seeping through cracks, don’t open that door!

Instead, use your alternate exit. If the inside of the door is cool, place

your shoulder against it, open it slightly and be ready to slam it shut if

heat and smoke rush in.

• Stay close to the floor if the air is smoky. Breathe shallowly through a

cloth, wet if possible.

• Once outside, go to your selected meeting place and make sure every-

one is there.

• Call the fire department from your neighbor’s home - not from yours!

• Don’t return to your home until the fire officials say that it is all right to

do so.

• There are situations where a smoke alarm may not be effective to pro-

tect against fire as stated in the NFPA Standard 72. For instance:

a) smoking in bed

b) leaving children home alone

c) cleaning with flammable liquids, such as gasoline

• If the escape route requires you to go through smoke, crawl low under

the smoke where the air is clearer.

WHAT TO DO WHEN THE ALARM SOUNDS

CO ALARM ACTIVATION

Carbon monoxide (CO) alarm pattern is four quick beeps

repeating every 5 seconds, Followed by voice message

"Warning Carbon Monoxide!"

WARNING: Carbon monoxide alarm

activation indicates the presence of Carbon

Monoxide (CO) at high concentrations which

can kill you.

1) Operate the Test/Hush button.

2) Call your emergency services (Fire Department or 911).

3) Immediately move to fresh air - outdoors or by an open door/window.

Do a head count to check that all persons are accounted for. Do not

reenter the premises nor move away from the open door/window until

the emergency services responders have arrived, the premises have been

aired out, and your alarm remains in its normal condition.

4) After following steps 1-3, if the alarm reactivates within a 24 hour

period, repeat steps 1-3 and call a qualified appliance technician to

investigate sources of CO from fuel burning equipment and appliances,

and to inspect for proper operation of equipment.

If problems are identified during this inspection, have the equipment

serviced immediately. Note any combustion equipment not inspected by

the technician and consult the manufacturer’s instructions, or contact

the manufacturer directly for more information about CO safety and the

equipment. Make sure that motor vehicles are not, or have not been,

operating in a garage attached or adjacent to the residence.

Never restart the source of a CO problem until it has been corrected.

Never ignore the sound of the alarm!

If the unit is sounding, pressing the Test/Hush button will termi-

nate the notification. If the CO condition that caused the alarm in

the first place continues, the unit will reactivate in alarm mode.

If the unit goes into alarm mode again within six minutes, it is

sensing high levels of CO which can quickly become a dangerous

situation.

CONTENTS OF THIS USER GUIDE

1 — LIMITATIONS OF SMOKE AND CARBON MONOXIDE ALARMS

2 — RECOMMENDED LOCATIONS FOR ALARMS

3 — LOCATIONS TO AVOID

4 — INSTALLATION / MOUNTING INSTRUCTIONS

5 — OPERATION AND TESTING

6 — VISUAL AND AUDIBLE INDICATIONS

7 — NUISANCE AND HUSH

8 — BATTERY

9 — DEACTIVATION OF ALARM

10 — GENERAL CARBON MONOXIDE (CO) INFORMATION

11 — CLEANING YOUR ALARM

12 — GOOD SAFETY HABITS

13 — SERVICE AND WARRANTY

This alarm detects products of combustion using photoelectric technology

and carbon monoxide using an electrochemical cell. Many times throughout

this User Guide, we will refer to Carbon Monoxide as “CO.”

After ten (10) years of cumulative power up, this unit will “chirp” two times

every 30 seconds. This is an "operational end of life" feature which will indi-

cate that it is time to replace the alarm.

To help identify the date to replace the unit, a label has been affixed to the

side of the alarm. Write the “Replace by” date (10 years from initial power

up) in permanent marker on the label prior to installing the unit.

Product Features and Specifications:

• Temperature: Operating Range: 40°F (4.4°C) to 100°F (37.8°C)

• Humidity: Operating range: 10-95% non-condensing

• Audible Alarm: 85+ dB at 10’ @ 3.2±0.5 KHz pulsing alarm

• Smoke Sensor: Photoelectric

• CO Sensor: Electrochemical

Two labels have been provided that have important information on what

to do in case of a CO alarm. Place one label next to the alarm after it is

mounted, and one near a fresh air source such as a door or window.

1. LIMITATIONS OF SMOKE ALARMS

WARNING: PLEASE READ CAREFULLY AND THOROUGHLY

• NFPA 72 states: Life safety from fire in residential occupancies is based pri-

marily on early notification to occupants of the need to escape, followed by

the appropriate egress actions by those occupants.

• Fire warning systems for dwelling units are capable of protecting about half

of the occupants in potentially fatal fires. Victims are often intimate with

the fire, too old or young, or physically or mentally impaired such that they

cannot escape even when warned early enough that escape should be pos-

sible. For these people, other strategies such as protection-in-place or assisted

escape or rescue are necessary.

• Smoke alarms are devices that can provide early warning of possible fires at a

reasonable cost; however, alarms have sensing limitations. Ionization sensing

alarms may detect invisible fire particles (associated with fast flaming fires)

sooner than photoelectric alarms. Photoelectric sensing alarms may detect

visible fire particles (associated with slow smoldering fires) sooner than ion-

ization alarms. Home fires develop in different ways and are often unpredict-

able. For maximum protection, Kidde recommends that both Ionization and

Photoelectric alarms be installed.

• A battery powered alarm must have a battery of the specified type, in good

condition and installed properly.

• Smoke alarms must be tested regularly to make sure the battery and the

alarm circuits are in good operating condition.

• Smoke alarms cannot provide an alarm if smoke does not reach the alarm.

Therefore, smoke alarms may not sense fires starting in chimneys, walls, on

roofs, on the other side of a closed door or on a different floor.

• If the alarm is located outside the bedroom or on a different floor, it may not

wake up a sound sleeper.

• The use of alcohol or drugs may also impair one’s ability to hear the smoke

alarm. For maximum protection, a smoke alarm should be installed in each

sleeping area on every level of a home.

This alarm is not intended to alert hearing impaired individuals.

1. LIMITATIONS OF CARBON MONOXIDE ALARMS

WARNING: PLEASE READ CAREFULLY AND THOROUGHLY

• IMPORTANT: This carbon monoxide alarm is designed to detect carbon

monoxide gas from ANY source of combustion. It is NOT designed to detect

any other gas.

CAUTION: This alarm will only indicate the presence of carbon monox-

ide gas at the sensor. Carbon monoxide gas may be present in other areas.

Never restart the source of a CO problem until it has been fixed. NEVER

IGNORE THE ALARM!

WARNING: This product is intended for use in ordinary indoor

locations of family living units. It is not designed to measure compli-

ance with Occupational Safety and Health Administration (OSHA),

commercial or industrial standards. It is not suitable for installation in

hazardous locations as defined in the National Electric Code. It is not

designed for use in a recreational vehicle (RV) or boat.

• The installation of this device should not be used as a substitute for proper

installation, use and maintenance of fuel burning appliances, including

appropriate ventilation and exhaust systems.

• This alarm does not prevent CO from occurring, nor can it solve any existing

CO problem.

WARNING: This device is designed to protect individuals from

acute effects of carbon monoxide exposure. It may not fully safeguard

individuals with specific medical conditions. If in doubt, consult a med-

ical practitioner. Individuals with medical problems may consider using

warning devices which provide audible and visual signals for carbon

monoxide concentrations under 30 PPM.

• This alarm has not been investigated for carbon monoxide detection below

70 PPM.

• This carbon monoxide alarm requires a continuous supply of electrical power

– it will not work without power.

NFPA 72 states: “Smoke alarms in rooms with ceiling slopes greater than

1 ft in 8 ft (.3m in 2.4 m) horizontally shall be located on the high side of

the room.” NFPA 72 states: “A row of detectors shall be spaced and locat-

ed within 3 ft (0.9m) of the peak of the ceiling measured horizontally.”

2. RECOMMENDED LOCATIONS FOR ALARMS

• Locate the smoke alarms in all sleeping areas. Try to monitor the exit path

as the bedrooms are usually farthest from the exit. If more than one sleeping

area exists, locate additional alarms in each sleeping area.

• Locate additional alarms to monitor any stairway as stairways act like

chimneys for smoke and heat.

• Locate at least one alarm on every floor level.

• Locate an alarm in every bedroom.

• Locate an alarm in every room where electrical appliances are operated

(i.e. portable heaters or humidifiers).

• Locate an alarm in every room where someone sleeps with the door

closed. The closed door may prevent an alarm not located in that room

from waking the sleeper.

• Smoke, heat, and combustion products rise to the ceiling and spread

horizontally. Mounting the smoke alarm on the ceiling in the center of

the room places it closest to all points in the room. Ceiling mounting is

preferred in ordinary residential construction.

• For mobile home installation, select locations carefully to avoid thermal

ANYWHERE ALONG

THIS BOLD SURFACE

30.5 cm

Locations permitted for smoke

alarms and smoke detectors

on tray-shaped ceilings.

ANYWHERE ALONG

THIS BOLD SURFACE

30.5 cm

Locations permitted for smoke

alarms and smoke detectors

on tray-shaped ceilings.

FIGURE 1

ANYWHERE ALONG

THIS BOLD SURFACE

30.5 cm

Locations permitted for smoke

alarms and smoke detectors

on tray-shaped ceilings.

Smoke or Smoke/CO Alarms for Required Protection

FIGURE 2 FIGURE 3

barriers that may form at the ceiling. For more details, see MOBILE HOME

INSTALLATION section.

• When mounting an alarm on the ceiling, locate it at a minimum of 4”

(10 cm) from the side wall.

• When mounting the alarm on the wall, use an inside wall with the top edge

of the alarm at a minimum of 4” (10 cm) and a maximum of 12” (30.5 cm)

below the ceiling.

• Put smoke alarms at both ends of a bedroom hallway or large room if the

hallway or room is more than 30 feet (9.1 m) long.

• Install Smoke Alarms on sloped, peaked or cathedral ceilings at or within

3ft (0.9m) of the highest point (measured horizontally).

This equipment should be installed in accordance with the National

Fire Protection Association’s 72 (National Fire Protection Association,

Batterymarch Park, Quincy, MA 02269).

3. LOCATIONS TO AVOID

• In the garage. Products of combustion are present when you start your

automobile.

• Normal cooking may cause nuisance alarms. If a kitchen alarm is desired,

it should have an alarm silence feature or be a photoelectric type.

• Do not install within 6 ft. of heating or cooking appliances.

• Less than 4” (10cm) from the peak of an “A” frame type ceiling.

• In an area where the temperature may fall below 40ºF or rise above 100ºF,

such as garages and unfinished attics.

• In dusty areas. Dust particles may cause nuisance alarm or failure to alarm.

• In very humid areas. Moisture or steam can cause nuisance alarms.

• In insect-infested areas.

• Smoke alarms should not be installed within 3 ft (.9m) of the door to a

bathroom containing a tub or shower, forced air supply ducts used for

heating or cooling, ceiling or whole house ventilating fans, or other high

air flow areas.

• Near fluorescent lights. Electronic “noise” may cause nuisance alarms.

• Smoke alarms are not to be used with detector guards unless the

combination (alarm and guard) has been evaluated and found suitable

for that purpose.

• Do not install near vents, flues, chimneys or any forced/unforced air

ventilation openings

• Do not install near fans, doors, windows or areas directly exposed to

the weather.

MOBILE HOME INSTALLATION

Modern mobile homes have been designed and built to be energy efficient.

Install smoke alarms as recommended above. In older mobile homes that are

not well insulated compared to present standards, extreme heat or cold can

be transferred from the outside to the inside through poorly insulated walls

and roof. This may create a thermal barrier which can prevent the smoke from

reaching an alarm mounted on the ceiling. In such units, install the smoke alarm

on an inside wall with the top edge of the alarm a minimum of 4” (10 cm) and

a maximum of 12” (30.5 cm) below the ceiling.

If you are not sure about the insulation in your mobile home, or if you notice

that the outer walls and ceiling are either hot or cold compared to the room

air temperature, install the alarm on an inside wall. NFPA 72 (National Fire

Protection Association) requires smoke alarms be installed in each sleeping area.

WARNING: Test your smoke/CO alarm operation after mobile

home has been in storage or unoccupied and at least once a week

during use.

4. INSTALLATION

INSTRUCTIONS

ATTACHING MOUNTING PLATE

OPTION 1:

Easy Mount – Drywall Only

1. Choose a mounting location (wall or

ceiling) and drill a 3/16” diameter hole

at least 1/2” deep.

2. Insert the provided screw through

the mounting plate aligning the ribs

on the screw with the slots on the

mounting plate.

3. Tighten the screw/mounting plate to wall

or ceiling until mounting plate is snug

against surface. DO NOT over-tighten.

Ribs (2

places)

Mounting Option 1

Slots

OPTION 2:

Mounting on Other Surfaces

1. Choose a mounting location (wall or

ceiling) and using the mounting plate

provided as a template, mark three-

hole locations.

2. Install the three provided screws

through the mounting plate and tighten.

DO NOT over-tighten screws. (If

mounting in plasterboard or similar

surface, drill 3/16” holes and use the

plastic anchors provided.) Anchors are

not required for mounting on hard

surfaces such as wood.

ATTACHING AND ACTIVATING THE ALARM

This model is equipped with a feature that automatically activates the alarm

when the alarm is attached to the mounting plate for the first time. Once acti-

vated, the battery will supply power to the alarm for the life of the alarm (10

years) under normal conditions.

Align the alarm with the mounting plate and rotate clockwise (right) approxi-

mately 45° until the unit stops and clicks into place. DO NOT over-tighten. If

unit needs to be re-aligned, rotate the alarm counter clockwise, remove and

rotate to desired alignment. NOTE: The alarm will mount to the plate in three

(3) positions (every 120 degrees).

You will know power has been supplied when alarm briefly chirps. Unit will

remain on until unit is deactivated (turned off) by the user at alarm’s end of life.

Do not over tighten the alarm as damage to alarm or mounting surface may

occur.

The alarm is now activated! After installation/activation, test your alarm

as described in Operation and Testing section.

Warning: Failure to properly install and activate this alarm

will prevent proper operation of this alarm and will prevent

its response to fire hazards.

Unit will issue a voice prompt at activation asking the user to press

the test button. Proceed to OPERATION AND TESTING section.

Mounting

Option 2

Andere Handbücher für P3010CU

Inhaltsverzeichnis

Andere Kidde Rauchmelder Handbücher

Kidde

Kidde I9030 Bedienungsanleitung

Kidde

Kidde KN-COSM-B Bedienungsanleitung

Kidde

Kidde Slick 1SF23/9HI Bedienungsanleitung

Kidde

Kidde i1040 Bedienungsanleitung

Kidde

Kidde I5000 Bedienungsanleitung

Kidde

Kidde 0915 Bedienungsanleitung

Kidde

Kidde SL177i Bedienungsanleitung

Kidde

Kidde 0916LL Bedienungsanleitung

Kidde

Kidde Fyrewatch 0913 Bedienungsanleitung

Kidde

Kidde i12040A Bedienungsanleitung

Kidde

Kidde KN-COSM-BA Bedienungsanleitung

Kidde

Kidde FIREX KF3R Bedienungsanleitung

Kidde

Kidde 900-CUDR-V Bedienungsanleitung

Kidde

Kidde KN-COSM-BCA Bedienungsanleitung

Kidde

Kidde p9050CA Bedienungsanleitung

Kidde

Kidde PE910UK Bedienungsanleitung

Kidde

Kidde 123/9HI Bedienungsanleitung

Kidde

Kidde i12060CA Bedienungsanleitung

Kidde

Kidde 123I Bedienungsanleitung

Kidde

Kidde SMOKE AND CARBON MONOXIDE ALARM Bedienungsanleitung

Kidde

Kidde VM-1 Bedienungsanleitung

Kidde

Kidde GSA-PS Montageanleitung

Kidde

Kidde Stratos-HSSD 2 Bedienungsanleitung

Kidde

Kidde i9010 Bedienungsanleitung

Beliebte Rauchmelder Handbücher anderer Marken

x-sense

x-sense SD19-W Bedienungsanleitung

BRK electronic

BRK electronic First Alert P1010 Bedienungsanleitung

FireAngel

FireAngel Thermoptek ST-622 Bedienungsanleitung

teko

teko Astra-42A Bedienungsanleitung

Safetec

Safetec SDS-2/6 Betriebsanleitung

Siemens

Siemens PE-11C Bedienungsanleitung

System Sensor

System Sensor DH500ACDC Bedienungsanleitung

Resolution Products

Resolution Products RE612 CryptiX Bedienungsanleitung

First Alert

First Alert PC900V Bedienungsanleitung

Eminent

Eminent EM6590 E-Domotica Bedienungsanleitung

Ei Electronics

Ei Electronics Ei Ei168RC Bedienungsanleitung

Carrier

Carrier Kidde Quell Q301 Bedienungsanleitung

VESDA

VESDA VLF-500 Bedienungsanleitung

ELRO

ELRO FS8110 Bedienungsanleitung

Heiman

Heiman SMOKI NS-626PHS Bedienungsanleitung

Regin

Regin SDD-S65 Bedienungsanleitung

Family Gard

Family Gard FG225 Bedienungsanleitung

Greystone

Greystone DSD120 Bedienungsanleitung
