Kilotech S-2000 Bedienungsanleitung

S-2000

Price Computing Scale

OWNER’S MANUAL

CONTENTS

PRECAUTIONS 4

PREFACE 6

NAMES AND FUNCTIONS 6

OPERATIONS 8

1. How to Convert the Unit of Weight 8

2. General Weighing 10

3. Weighing with Tare 10

4. Saving a Currently Called Unit Price 12

5. Saving a Current Tare 12

6. Add-up Sales 14

7. Recalling the Added Total Price 14

8. Saving a PLU to Memory 15

9. How to Call to PLU 16

ERROR MESSAGE 18

SPECIFICATIONS 19

PRECAUTIONS

Keep the scale away from strong EMI noises may cause incorrect weight

readings.

Do not subject the scale to sudden

temperature changes.

Place the scale on a flat and stable

surface.

If the scale is not properly

level, please adjust the 4 legs

at the bottom of the scale

(turn legs clockwise or

counterclockwise) so as to

center the bubble of the

leveling gauge inside the

indicated circle.

Do not subject the platter to sudden

shocks. This scale must be installed in a dry

and liquid free environment.

Leveling gauge

Make sure that you plug your scale into the proper power outlet.

Plug into a power outlet 10 minutes before operations.

PREFACE

NAMES AND FUNCTIONS

Thank you for purchasing our CAS S-2000 Series.

These series have been designed with CAS reliability, under rigid quality control

and with outstanding performance. Your specialty departments can enjoy these

high quality reliable CAS products.

We believe that your needs will be satisfied and you will have proper reliability.

This manual will help you with proper operation and care of the S-2000 Series.

Please keep it handy for future reference.

OVERALL VIEW

PLATTER

DISPLAY

ADJUSTING

BOLT

LEVELING

GAUGE

KEYBOARD

DISPLAYS

15x0.005kg 30x0.01lb

ZERO

TARE

CAPACITY

CAPACITE

ZERO NET lb kg

WEIGHT

POIDS TOTAL PRICE

PRIX TOTAL

UNIT PRICE

PRIX UNITAIRE

SAVE

/100g

/lb

/kg

WEIGHT

POIDS

ZERO NET lb kg

CAPACITY

CAPACITE

15x0.005kg 30x0.01lb

UNIT PRICE

PRIX UNITAIRE

SAVE

/100g

/lb

/kg

TOTAL PRICE

PRIX TOTAL

S-2000

Operator Side

Customer Side

KEYBOARD

789

123

456

0C00

M1 M2 M3

MW MR

ADD

RE-

CALL

ZERO TARE kg/lb

100g

SAVE

KEY FUNCTIONS

M1 M3

100g

SAVE

Used to enter all the numerical data.

Used to enter a double zeros.

Used to clear all the numerics on the unit price display.

Used to clear sum total price.

Direct PLU(Price Look Up) keys.

In metric mode, allows unit price per 100g.

Used to store PLU to memory.

Used to call indirect PLU in memory.

Used to saves currently called unit price and tare.

KEYS FUNCTIONS

OPERATIONS

KEY FUNCTIONS

ADD

ZERO

TARE

kg/ lb

RE-

CALL

Used to add a transaction.

Used to call a total price of add up transactions.

Used to correct the zero point.

Used to enter a tare weight.

Used to delete a tare weight.

Toggle between metric and non-metric mode.

KEYS FUNCTIONS

1. How to Convert the Unit of Weight

kg/ lb

This is the metric mode.

Press the kg/lb key. The weight display should read “Pound” and

remain this way for about 2 seconds.

The weight display should read “0.00”

automatically.

Now, you can use the non-metric mode.

Make sure that kg lamp should be on.

100g mode: Note that you can use this function only in the metric mode.

If you want to use this mode, press the 100g key.

Make sure that 100g lamp should be on.

NOTE: To use non-metric mode from 100g mode, please do the followings.

Press the 100g key, Now you are in the metric mode.

Press the kg/lb key, Now you are in the non-metric mode.

kg/ lb

This is the non-metric mode.

Press the kg/lb key. The weight display should read “nEtric” and

remain this way for about 2 seconds.

The weight display should read “0.000”

automatically.

Now, you can use the metric mode.

WARNING: When you change the unit of weight, avoid leaving any item or

items on the platter.

A) From metric mode to non-metric mode

Make sure that lb lamp should be on.

B) From non-metric mode to metric mode

B) Known Tare(Keyboard Tare) Mode

TARE

Enter tare weight by pressing the numeric key. Press TARE key.

Place the container on the platter and enter

a unit price. Place the commodity in the container.

Remove commodity with container from

the platter.

5 00

Place a commodity on the platter. Enter a unit price.

2. General Weighing

TARE

Remove the commodity from the platter.

NOTE 1: The represents the lamps on the displays above.

This is the metric mode, so kg lamp should be on.

NOTE 2: The unit price is cleared automatically after each transaction.

3. Weighing with Tare

A) Unknown (weighed) tare

Place the container on the platter. Press TARE key.

5 00

Place the commodity in the container. Enter a unit price.

Remove commodity with container from

the platter.

NOTE: The tare is cleared automatically after each transaction.

Not all the countries are applicable with a tare-clear function.

B) Known (manually entered) tare

TARE

5 00

Enter a tare value. Press TARE key.

Place a container on the platter. Place a commodity in the container.

Enter a unit price. Remove the commodity and the container.

The display still shows the tare value and the

unit price.

TARE

Remove the commodity from the platter.

Then the display still shows unit price.

5. Saving a Current Tare

A) Unknown (weighed) tare

Place a container on the platter. Press the TARE key and enter a unit price.

Place a commodity in the container. Remove the commodity from the container.

Remove the container.

Then the display still shows the tare and the

unit price.

5 00

Press the SAVE key and enter a unit price. Place a commodity on the platter.

4. Saving a Currently Called Unit Price

This function saves currently called unit price from automatically clearing.

8. Saving a PLU to Memory

This function stores each PLU into a internal back up memory.

PLU means Price Look Up which has a unit price.

This scale has 3 memories of direct PLUs and 200 memories of indirect PLUs.

A) FOR DIRECT PLU KEYS

For example: $ 2.99 - M1 key

Enter a unit price and place a commodity then

press ADD key. Remove the commodity from the platter.

RE-

CALL RE-

CALL

Press RECALL key. Press RECALL key again to return to weighing

mode.

Place another commodity and enter a unit

price then press ADD key. Remove the commodity from the platter.

NOTE: You can add-up items up to 99 times or $ 9999.99 in this manner.

Otherwise, you will hear a beep sound.

6. Add-up Sales

This add up function adds up a total price of several commodities.

You can check the total price by pressing RECALL key.

7. Recalling the Added Total Price

This function is used in conjunction with the ADD key.

TTP CALL shows the total price of all the added items.

When you press the TTP CALL key without using the add up function, you will

hear a beep sound.

To display the total price of added commodities.

To clear the total price of added commodities.

RE-

CALL C

Press RECALL key. Press C key to clear total price and return to

weighing mode.

2 9 9

Enter a unit price.

Press desired one of the direct PLU keys.

Press MW key.

3 7 5

1 2 5

Enter a unit price. Press MW key.

Enter a desired address of the PLU. Press MW key.

B) FOR INDIRECT PLUS

For example: $ 3.75 - 125 (address)

9. How to Call a PLU

Make sure that the platter is empty when you call a PLU.

The possible numbers of this function are 200.(address 0 through 199)

A) FOR DIRECT PLU KEYS

For example: M1 key - $ 2.99

Press one of the direct PLU keys. Place a commodity on the platter.

Remove the commodity from the platter.

B) FOR INDIRECT PLUS

For example: 125 (address) - $ 3.75

1 2 5

Enter the address of an indirect PLU. Press MR key.

Place a commodity on the platter. Remove the commodity from the platter.

NOTE: Do not use the decimal point while recalling PLU’s.

18 19

SPECIFICATIONS

MODEL

CAPACITIES

DISPLAYS:

WEIGHT

UNIT PRICE

TOTAL PRICE

MAXIMUM TARE

POWER SOURCE

POWER CONSUMPTION

TEMPERATURE RANGE

PLATTER SIZE(mm)

PRODUCT SIZE(mm)

ERROR MESSAGES

To help the customer’s understanding, this scale warns the error messages

properly. Please refer to error table.

An error of the initial zero range

Failure of returning the normal

mode

An over flow was occurred from

ADD key

An over flow was occurred from

FIX ADD key

An over flow of the transaction count

An over flow of the accumulations of

the daily total functions

Failure of the analog module

Failure of the digital module

Condition codes are broken

Key codes are broken

When you go to non-metric mode

from 100g mode, you had a wrong

operation

1.Set the platter empty

2.Make sure there is a platter on the

scale

Call your CAS dealer

Press C key

Call your CAS dealer

Call your CAS dealer for span calibration

Press the 100g key and then press the

kg/lb key.

ERROR REASONS SOLUTIONS

Err 1

Err 2

Err 6

Err 7

Err 8

Err 9

Err 10

Err 11

Err 12

Err 13

Err 14

S-2000 Series

15 0.005kg 30 0.01lb

Vacuum Fluorescent Display

5 DIGITS

6 DIGITS

-9.995kg -30.00lb

AC 110/120/220/240V, 50/60Hz

APPROX. 10W

10°C 40°C

372(W) 278(D)

478(W) 365(D) 495(H)

Inhaltsverzeichnis

Andere Kilotech Skala Handbücher

Kilotech

Kilotech KWD 15K Bedienungsanleitung

Kilotech

Kilotech 851340 Installationshandbuch

Kilotech

Kilotech KPS 60 Bedienungsanleitung

Kilotech

Kilotech KPC 1500 SS Bedienungsanleitung

Kilotech

Kilotech MS-4202L Adult Bedienungsanleitung

Kilotech

Kilotech KPC 160 Bedienungsanleitung

Kilotech

Kilotech KHS 200-30 Bedienungsanleitung

Kilotech

Kilotech KIN 500 Bedienungsanleitung

Kilotech

Kilotech Integrator C30 Bedienungsanleitung

Kilotech

Kilotech KPC 1500SS Gebrauchs- und Pflegehandbuch

Kilotech

Kilotech KRS SWP Series Bedienungsanleitung

Kilotech

Kilotech KPOS 1530 Bedienungsanleitung

Kilotech

Kilotech KPC 1000SS Gebrauchs- und Pflegehandbuch

Kilotech

Kilotech KWS-SW series Bedienungsanleitung

Kilotech

Kilotech CTR Series Bedienungsanleitung

Kilotech

Kilotech KPC 1500SS Bedienungsanleitung

Kilotech

Kilotech KWS 2200 Bedienungsanleitung

Kilotech

Kilotech KPC 5000 Bedienungsanleitung

Kilotech

Kilotech KPC 5000 Gebrauchsanweisung

Kilotech

Kilotech KPOS 1530 Bedienungsanleitung

Kilotech

Kilotech KLE 200 Bedienungsanleitung

Kilotech

Kilotech KSB series Bedienungsanleitung

Kilotech

Kilotech Abacus AB30 Bedienungsanleitung

Kilotech

Kilotech KPC 1000SS Bedienungsanleitung

Beliebte Skala Handbücher anderer Marken

AWS

AWS ZEO-50 Bedienungsanleitung

Gima

Gima Glass Body Fat Analyzer Stücklistenhandbuch

Seca

Seca 374 Bedienungsanleitung

TEC

TEC TEC SL59 SERIES Bedienungsanleitung

Axis

Axis B/E Series Bedienungsanleitung

Alecto

Alecto ACW-40 Bedienungsanleitung

Rice Lake

Rice Lake MSI-4260 IS Bedienungsanleitung

IKA

IKA RCT basic safety control Bedienungsanleitung

ADE

ADE M20011 Bedienungsanleitung

Duronic

Duronic KS3000 Bedienungsanleitung

Digi

Digi SM-720 Bedienungsanleitung

Cardinal

Cardinal CS Series Bedienungsanleitung

Korona

Korona Kastella Bedienungsanleitung

A&D

A&D FC-50Ki Bedienungsanleitung

BDA

BDA CAMARGUE Bedienungsanleitung

Tanita

Tanita HD-357 Bedienungsanleitung

Leifheit

Leifheit 03173 Bedienungsanleitung

Lumme

Lumme LU-1340 Bedienungsanleitung
