hop instruction manual

Model 114

WARNINGS & SAFETY INFORMATION

THANK YOU FOR BUYING OUR STROLLER!

To ensure that your stroller is used in accordance with these instructions please read

them fully. This stroller conforms to ASTM F833-13 and is guaranteed for 1 year from

the date of purchase against manufacturing defects. This limited warranty extends only

to the original retail purchaser and is only valid when supplied with proof of purchase.

uAvoid serious injury from falling or sliding out. ALWAYS use

restraint system.

uNEVER leave child unattended, even when sleeping.

uAdjust the restraint system snugly around child.

uAVOID PINCH INJURY. Keep ﬁngers clear of hinged joints

when folding and unfolding stroller.

uMake sure the stroller is LOCKED in the use position before

placing child in stroller.

uWhen making adjustments, always ensure child’s body parts

are clear of any moving parts.

uDO NOT allow child to climb on stroller or stand in seat.

uDO NOT lift stroller by front bumper bar.

uNo more than 1 occupant per seat.

uALWAYS apply breaks when parking the stroller.

uParcels or accessory items, or both, place on the unit may

cause the unit to become unstable.

uDO NOT hang items from the handles as this may affect

the strollers stability. Use the basket provided: max. weight 5 lbs.

Excessive weight may cause a hazardous unstable condition to exist.

uDO NOT place hot liquids in cup holder. Max. weight 1 pound.

Read all instructions BEFORE use of product.

KEEP INSTRUCTIONS FOR FUTURE USE.

Maximum weight: 40 lbs. per seat.

Rear seat suitable: 3+ months. Front Seat suitable: 6+ months.

WARNINGS

TABLE OF CONTENTS

STROLLER ASSEMBLY

Opening Stroller ................................................................ 3

Attaching Canopy ............................................................. 4

Attaching Cup Holder ....................................................... 4

STROLLER OPERATION

Seat Restraint Operation .................................................. 5

Adjust Seat Back .............................................................. 5

Adjusting The Legrest ...................................................... 6

Folding The Stroller ........................................................... 6

Attaching An Infant Car Seat ...................................... 7,8

Routine Care & Maintenance ........................................ 9

STROLLER ASSEMBLY STROLLER ASSEMBLY

Release the folding clip. Pull the handle

bars up to unfold stroller.

Step the folding piece down

until you hear lock mechanism

“click” into position.

Push up to attach front

wheels.

To lock the wheels in the straight position, pull the

locking tab up. Push the locking tab down to unlock

the front wheels- the front wheels will now swivel.

Push the lever down to

activiate the brake. To

release the brake, pull the

same lever up with your foot.

OPENING THE STROLLER

Push down lever to lock canopy open.

Pull up lever of canopy for folding.

ATTACHING CANOPY

ATTACHING CUP HOLDER

Slide cup holder down into

place using the

attachment point on

the frame.

Insert two side clips on frame to

assemble canopy.

TO SECURE CANOPY, attach velcro tabs around stroller frame.

1 2

STROLLER OPERATION STROLLER OPERATION

Pull up the folding piece

with your foot.

Step the side second lock down to

fold stroller.

Push the handle bars down

to fully fold. Attach folding clip.

FOLDING THE STROLLER

ADJUSTING THE LEGREST

To move up, gently lift

legrest.

To lower, slide both levers on underside of seat

and push down.

Secure child with harness by inserting

waist straps into crotch strap buckle.

Adjust waist straps by moving slide

adjusters.

Insert shoulder harness straps to

crotch strap buckle and adjust by

moving slide adjusters.

To adjust height of shoulder harness, pull

the webbing strap through the seat back

and reposition to one of the 3 locations.

ADJUSTING SEAT BACK

SEAT RESTRAINT OPERATION

3 4

Press center button to release.

Front seat: Push the buttons

on top of the recline mecha-

nism behind front seat.

Rear seat: Change seat

positions by adjusting the

recline mechanism.

Pull up on tab

to return to the

upright position.

21 3

ATTACHING AN INFANT CAR SEAT ATTACHING AN INFANT CAR SEAT

WARNINGS

Failure to follow these warnings and the assembly

instructions could result in serious injury or death.

uUSE ONLY AN APPROVED INFANT CAR SEAT WITH THIS

PRODUCT. For a current list of compatible car seats refer to

Kinderwagon.com. Improper use of this stroller with other

manufacturers’ car seats may result in serious injury or death.

uONLY SUITABLE FOR USE WITH ONE CAR SEAT.

uREAD THE INSTRUCTION MANUAL provided with your

car seat before using it with your stroller.

uALWAYS SECURE your child with the car seat harness when

using the car seat on the stroller.

1. Unsnap front seat fabric

from bumper bar and

remove from upright bars.

2, 3. Remove

adaptor straps

from each side

of the bumper

bar.

ENSURE FRONT SEAT IS IN THE FULLY RECLINED POSITION.

To remove the infant car seat release the

clip and remove the straps. Lift up on car

seat. Replace the straps back around

the bar and attach front seat fabric.

Place infant car seat into position

by aligning the mounting notches

over the front bumper bar.

Pull straps through vehicle belt hooks on

each side of the infant car seat.

Push down on the foot area of the

car seat to ensure proper placement on

the stroller.

6 7

To secure the infant car seat in

position, connect the clip and pull

the loose end of the strap.

CHECK THAT THE

INFANT CAR SEAT

IS SECURELY ATTACHED

BY PULLING UP.

ROUTINE CARE & MAINTENANCE

This stroller requires regular maintenance by the user.

• For cleaning use only mild detergent and warm water.

•DO NOT USE BLEACH.

• From time to time check your stroller for loose screws, worn parts, torn

materials or loose stitching. Replace or adjust parts as needed.

• We advise that your stroller is not stored or left outside at anytime.

At Kinderwagon, providing you, our customer, the best service and best

products possible are two of our top priorities. In the event we have

product related information we need the ability to contact you.

Please visit www.Kinderwagon.com to register your product.

Be assured, your contact information will be handled conﬁdentially

and only used for the purpose described above.

Please have the following information available:

Model Number ______________________________

Manufacture Date ___________________________
