Kioti KL120 Bedienungsanleitung

Warranty Coverage :

Daedong-USA, Inc., KIOTI Tractor Division, herein referred to as KIOTI, undertakes to replace or repair any part of a KIOTI loader

where damage has been proven to be caused by defects in material or workmanship.

This Warranty is valid for a period of 1 year from the date of the original retail sale. Parts replaced or repaired under the terms of this

Warranty are guaranteed only until the original warranty expires. Warranty only applies to the original purchaser.

It is further understood and agreed that the defect should be immediately reported to the Selling Dealer. The Selling Dealer will generally

perform Warranty repairs or replacements and the Purchaser shall deliver the KIOTI loader to the Dealer's place of business for repair.

The obligation of KIOTI to the Purchaser under this Warranty is limited to the repair or replacement of defective parts by an authorized

KIOTI dealer. Repair or replacement in accordance with this Warranty shall constitute fulfillment of all liabilities of KIOTI and the Selling

Dealer in respect to KIOTI loader.

There are no warranties beyond those which expressly appear herein. Any implied warranty of merchantability or

fitness for a particular purpose is specifically excluded here from.

WARRANTY CONDITIONS

Warranty Provisions :

KIOTI's liability under this warranty is subject to the observance by the Purchaser of the following provisions:

1. The purchaser shall at all times in the operation of any KIOTI Product, use those brands and grades of lubricating oils, lubricants or fuel

and spare parts officially approved by KIOTI.

2. The KIOTI loader shall have been used in accordance with the procedures specified in the Operator's Manual. This Warranty does not

extend to damage resulting from misapplication, abuse, misuse, failure to preform maintenance, negligence, fire, accidents or changes

or faulty mounting carried out by the Purchaser. When making a Warranty exchange of parts, the Purchaser shall compensate KIOTI

for the time that the parts have been used if they have been exposed to extreme wear.

3. Compensation is not paid for physical harm, deadlock, resulting damages or other losses.

4. To obtain warranty service, the Purchaser must (1) report the product defect to an authorized KIOTI dealer and request repair within

the applicable warranty term and (2) present evidence of purchase.

5. The Warranty shall be void if the KIOTI loader has been altered or repaired outside of a KIOTI dealership or travel of dealer personnel

to customer location for Warranty repair. The customer shall also pay any premium for overtime labor requested by the dealership

6. Temporary repairs or additional costs due to the work being performed after normal working hours will not be compensated.

7. The above warranty is in lieu of all other warranties on KIOTI's behalf and neither party assumes any other liability in connection with

KIOTI's Products.

8. Any dispute arising between KIOTI and the Purchaser concerning the liability of KIOTI under this warranty shall be subject to the laws

of the State of North Carolina.

Right To Make Design and Product Changes:

KIOTI reserves the right to make changes in the design and other changes in its KIOTI Products at any time without incurring any obligation

with respect to any product previously ordered, sold or shipped.

PLEASE NOTE

Make sure all potential operators of this equipment review this manual and all safety messages con-

tained within.

Signs Description

CAUTION

This safety symbol indicates important safety messages in this manual. When you see this

symbol, carefully read the message that follows and be alert to the possibility of personal injury

or death.

WARNING

IMPORTANT

NOTE

This mark indicates potentially hazardous situation which, if not observed, may result in death

or moderate injury.

This mark indicates emphasis on notable characteristics in working procedures or information

on working procedures and technology for convenient use.

This mark indicates general comments or notes.

1. SAFETY PRECAUTIONS ......................................................

2. SAFETY DECALS .................................................................

3. LOADER SPECIFICATIONS .................................................

4. INTRODUCTION ..................................................................

5. TRACTOR PREPARATION ...................................................

6. LOADER OPERATION ..........................................................

7. LOADER REMOVAL ..............................................................

8. LOADER MOUNTING ...........................................................

9. LUBRICATION AND MAINTENANCE ...................................

10. TROUBLESHOOTING .........................................................

11. HYDRAULIC SYSTEM ..........................................................

12. TORQUE TIGHTENING CHARTS ........................................

CONTENTS I

13. PARTS ILLUSTRATIONS....................................................

CONTENTS II

13.1 GENERAL INFORMATION ......................................................... 13-2

13.2 BUCKET ASSEMBLY ............................................................... 13-4

13.3 QUICK ATTACHMENT ............................................................. 13-6

13.4 FRONT GRILL ASSEMBLY(OPTION) ..................................... 13-8

13.5 BEARING BOX ASSEMBLY .................................................. 13-10

13.6 BOOM ASSEMBLY ................................................................. 13-14

13.7 BOOM HOSE FITTING ASSEMBLY ....................................... 13-18

13.8 IN-OUT HOSE FITTING ASSEMBLY ..................................... 13-20

13.9 BOOM CYLINDER ASSEMBLY ............................................. 13-22

13.10 BUCKET CYLINDER ASSEMBLY ......................................... 13-24

13.11 DECALS .................................................................................. 13-28

14. LOADER INSTALLATION ....................................................

15. INDEX .................................................................................

1. SAFETY PRECAUTIONS

1-2 KL120

Understand that your safety and the safety of other persons is

measured by how you service and operate this loader. Know the

position and operations of all controls before you try to operate.

Make sure you check all controls in a safe area before

starting.

Read this manual completely and thoroughly and make sure

you understand all controls. All equipment has a limit. Make sure

you are aware of the stability and load characteristics of this loader

before you begin operation.

The safety information given in this manual does not replace any

safety codes, insurance needs, federal, state and local laws. Make

sure your machine has the correct equipment required by your

local laws and regulations.

SAFETY SAFETY PRECAUTIONS

Before starting the engine of your tractor, make sure all operation

controls are in park lock or neutral position.

Operate controls only when seated in the operator's seat.

Equip your tractor with a ROPS cab or frame for your protection.

See your tractor operator's manual for correct seat belt usage.

A frequent cause of personal injury or death is persons falling off

and being run over. Do not permit others to ride on your tractor.

Only one person, the operator, should be on the machine when it is

in operation.

Before leaving the tractor, stop the engine, put all controls in neutral,

engage the parking brake and remove the key from the ignition.

When using remote hydraulic tractor valves on some tractors, the

loader lift and dump cylinders will continue moving unless the con-

trol levers are manually returned to neutral, or until relief pressure

is reached at the ends of piston strokes. Observe the bucket move-

ment and maintain control with the control levers.

Stop the loader arms gradually when lowering or lifting loads.

Stay off of slopes too steep for safe operation. Shift down before

you start up or down a hill with a heavy load. Avoid "free wheeling"

CAUTION

This safety alart symbol indicates important safety

messages in this manual. When you see this symbol,

carefully read the message that follows and be alert

to the possibility of personal injury or death.
