Kneader PF 100 Bedienungsanleitung
Owner’s Manual
Part number: PF 100
Fermenter
General household articles
(Not for commercial use)
Thank you for purchasing the Kneader Fermenter PF 102.
Please keep this manual so that you can refer to it in the future.
Before using this appliance, be sure to read all the instructions.
This appliance was designed for use in Japan only and should not be used in other countries.
Table of contents
Safety concerns - Please observe
Meanings of symbols
Warnings
Cautionary measures
Tank usage
Features of the Fermenter PF100
Names of parts
Main parts
How to use
Preliminary preparation of Fermenter
Using the Fermenter
Maintenance
Main body parts.
Disassembly and storage.
In case of malfunction
After-sales service
Specications
2
6
5
7
13
17
16
18
1
使用しているマークについて
Damaged or modied cords are re and electrical shock hazards!
Electrical shock hazard.Damaged cords are re and electrical shock hazards!
Dusty plugs are re and electrical shock hazards.
Remove dust from the power plug. Do not damage or modify
the power cord.
Do not use plug with wet hands.
Do not excessively twist,
pull or bend the power cord.
Doing so can damage the cord.
警 告
Doing so may produce severed elements and shorted circuits.
In addition do not damage the power cord. If the power cord
is damaged, it may cause an electric shock or re.
Do not place objects on power cord.
●What may occur in case of wrong usage:
●使用しているマーク(絵表示)と意味は、次の通りです。
Be sure to unplug.
Do not handle plug with
wet hands.
Extremely hot.
Specific explanations on
appliance.
Use only in dry environment.
Never use in damp places,
such as baths, washrooms,
or on wet oors.
Always obey the display
signals.
Do not attempt to repair or
modify the appliance.
Refer all servicing to
authorised repair technicians.
Do not use near re.
Do not overload outlets.
May overload circuits, causing malfunction and electric shock.
Safety instructions
and warnings
The content below consists of important safety instructions to prevent harm or damage to yourself or
others. Please be sure to follow the instructions.
Can lead to serious injury or death.
Can lead to harm to persons or damage to property.
Caution
Warning
Use this appliance according to the written cautions and warnings. Carefully avoid any accidents.
Do not touch.
Never do.
2
Do not wash heating parts.
If water gets inside the heater, it may cause short circuiting or
malfunction.
Do not use near re.
Warning
火災の危険があります。
Children are strictly prohibited from
using this product. Do not keep within
reach of children.
Heating parts should not be
disassembled or modied.
Disassembly or modication of heating parts can cause
malfunction or re. Inside this appliance and high-voltage
component there is a high risk of electric shock causing serious
physical injury. Any internal inspection, repairs for this product not
disclosed or described in this manual should be referred to our
support desk.
Risk of burns, electric shock and injury.
Use with 100V AC outlet only.
Overload of electrical current may cause electric shock or
malfunction.
Do not share outlet with other
appliances.
Branch outlet becomes abnormally hot when used with other
appliances, posing a risk of re.
Leave the front of the appliance free of
other objects and keep a space of
more than 4.5 cm from sides and walls.
Close quarters may cause malfunction or a re.
Do not place the lower shelf plate
directly in front of the heater surface.
May cause malfunction or re.
Caution
Do not use on an unstable surface or
on a powdery/oily surface.
Falling or tipping of this product can cause injury.
Always use placed on a at stable surface.
Never place any objects on top of
the appliance.
Placing things on the appliance surface may cause it to be
deformed or damaged.
Do not place more than a weight of 2kg
on the shelf plate.
Do not place excessive weight on the shelf plate. There is risk of
damage.
When disassembling make sure to
start from door.
Otherwise door may fall, causing risk of injury.
Do not touch the hot plate (see p.6) or
humidication dish while in use or
immediately afterwards.
The top of the heating plate may reach a temperature of 100°C.
Please do not touch.
Fire hazard.
Do not pour water over the operating
panel.
Electrical circuit may fail. Wipe immediately with a dry cloth when
wet.
Do not use for other than fermentation
of bread dough or yeast (leaven).
May overheat and cause accident if used to dry cloth material.
Do not clean with ammable solvents.
Keep unplugged when not in operation
(e.g., cleaning or maintenance).
Risk of injury. Be sure to unplug during maintenance.
3
12
Recommendations for appliance operation
◆In the following cases, unplug and stop operation immediately. Please consult
our support desk.
・When power switch doesn’t work.
・If power cord or plug is damaged or frayed.
・If the appliance has been deformed from falling.
・If any liquid gets into the appliance (frame).
・If the appliance has been exposed to rain and/or wind for prolonged periods.
・If the appliance emits smoke or burnt smell, does not work normally even in
accordance with the Instruction Manual.
◆The warning label attached to the appliance contains important notes for your
safety. Please observe the following precautions:
・The attached safety label must be in a visible place, and may not be covered or
hidden.
・Do not remove or modify the label.
・If the label has become damaged or soiled, please request a new one. You may
contact our support desk to obtain a new label.
◇Accidents, failure, or visible deterioration due to factors such as (excessive UV) light,
extreme temperatures, humidity, detergent, oil, mold, prolonged non-use may occur
due to natural aging. Also, general abrasion of parts and abrasion caused by
repeated opening and closing of door over several years may lead to deteriorative
failure.
◇Please always remember to unplug after use, to prevent accidents.
4
The Fermenter PF100 can be easily assembled without tools, can be
folded into a compact size and doesn't take up storage space.
The Storage Unit employs a double plastic structure, lightweight and
durable with excellent insulation (PAT.4613253).
Can be used for up to 24 hours at a time (auto-off).
Wide temperature range (25 ~ 42°C).
The Fermenter does not have cooling capacity; it will not operate below room temperature.
Water condensation recovery system (patent pending).
The heater is moisture-proof and can be cleaned by spraying lightly.
(But cannot be submerged in water.)
1
2
4
3
5
6
●About temperature-control function
When the inside of this appliance reaches setting temperature, the heater will restart
automatically and continue operating at the proper temperature.
Features of
the Fermenter PF100
5
Temp. Display
Red light
Temperature selector knob
Shelves (plastic ABS)
Dish part
Folding Plate
(Hollow construction)
(plastic PP)
Power switch
Top Plate (Hollow construction)
(plastic PP)
Door
(plastic PC)
Power Plug
Lower convection board
(Foam PP)
Temperature sensor
Humidifcation dish (PP)
Heater
(flame-resistant plastic ABS)
Mounting Knob (2)
(Nylon)
Operation manual Recipe
Warranty card
Appliance □Fermenter (heater, folding plate, top plate, door).
Accessories □Shelf plates (2) □Humidification dish □User's manual (this booklet)
□Warranty card □Recipes □ Mounting Knob (2) □Convection board
【Appliance and accessories】First, please check whether the following items are all included.
Names of parts
Main components
6
1Place heater on a stable surface.
2Unfold the folding plate.
Preparing the Fermenter
3Attach the folding plate to the heater.
①Fit the groove of the folding plate to the heater
at the mounting knob,
②Snap the rear folding plate onto the heater,
pressing against the top of the folding plate for
easy attachment.
③Be careful not to apply impact to
the Temperature Sensor as that may cause
it to disfunction.
Mounting knob
Groove
Mounting knob
Groove
①
②
③Temp. sensor
Operating Instructions
8
7
6
4Mount and attach the top
plate by lightly tapping
by hand from the top.
5
“マエ (Front)” is written on the inside
of the top plate. Please place it properly.
Attach door while holding up
the folding plate.
Hold the door with both hands after you
have fitted the protrusion at the top of the
door into the hole into the top plate, while
lifting the top plate lightly in the direction
of the arrow, and attach the lower
protrusion of the door to the heater.
Firmly attach the door to the heater and folding plate
with the mounting knob
Both sides
Completed product
8
8
74.5ｃｍ
4.5ｃｍ4.5ｃｍ
前面
9Placing the humidification dish.
Attach shelf plate and convection board.
Shelves can be added as purchase options.Shelves can be added as purchase options.
Shelf plate
Shelf plate
FIll dish with small amount of cold or lukewarm
water and place in the center of the hot plate.
If used for a long time add more water to the
humidification dish.
9
Place on horizontal surface at proper
distance from walls and other objects.
The front of the appliance should be kept clear.
Please leave a space of more than 4.5 cm from
back and sides.
Please make sure that the table on which the
Fermenter is placed is secure.
Convection board
Humidification dish
