Kogan 6 Series Bedienungsanleitung

QUICK START GUIDE

24” HD LED TV

Series 6, EH6200

(KALED24EH6200QA)

QUICK START GUIDE

24” HD LED TV

Series6, E H6200

(KALED24EH6200QA)

COMPONENTS

A Kogan 24”HD

LED TV

B Remote control

C Stand (x2)

D B4 x 20mm screw (x4)

E AAA battery (x2)

F Quick-start guide

G Warranty card

B C D

NOT INCLUDED

Phillips head screwdriver, antenna cable, broadband internet connection.

F G

MENU to open the quick menu

16 EXIT to quit the current interface

navigating menus and settings

10 INTRO to display the time of chapter

GOTO to jump to the appointed chapter

or title

AB to select the segment to repeat

PROGROM INTRO GOTO AB are

used for models with DVD function omly

Colour buttons for navigational

use within apps

11 Sleep to set the sleep timer

12 SOURCE displays the list of input

source channels.

13 ENTER selected option or execute

the selected operation.

14 / / / Direction buttons for

4 Number buttons, press to select

7 DISPLAY,display TV information

8 EJECT , eject the DVD-DISC in

DVD mode

channels or input passwords

1 Power, press to enter or exit

standby mode

2 Mute

3 Mode control buttons including

to switch the program number.

to switch back and forth between

the current and previous channels.

select the stereo mode, picture ratio,

picture and sound mode.

9 to start to record

10 PROGROM to select the disc progrom

AutoAdjust the picture automatically

in pc mode.

17 SUBTITLE to toggle subtitles on/o

18 + CH - to scroll channels

19 + VOL - to scroll channels

20 T.SHIFT Start / Stop time shi recording

ANGLE to select the angle in DVD model

21 Media control buttons including play, pause, backward, forward，and skip to

previous and next chapter for use in Media mode

HOLD to freeze a multi-page passage in Teletext mode

REVEVL to reveal or hide the hidden information in Teletext mode

SIZE to diaplay the top,buttom or all of page in Teletext mode

INDEX to go to the index page in Teletext mode

S.PAGE to carry out the function of SUBCODE in the text

22 TEXT for Teletext options. Not available in Australia.

ZOOM to select the zomm picture

23 FAV set the " Favorite List"

MENU to return the root menu or exit the DVD main menu

24 AUDIO select the DTV audio

25 DTV switch to DTV (Digital TV) mode

26 EPG Enter electronic program guide

27 TV/RADIO: Switch between TV and RADIO

20 19

BEFORE YOU GET STARTED

Spread cushioning ﬂat to lay the TV on. This willhelp to prevent damage.

1. Stand assembly

a. Attach stands to base of TV.

b. Insert two 20mm screws for each stand and use Phillipshead

screwdriver (not supplied) to tighten.

2. Remote control assembly

a. Open the battery compartment cover on the backside.

b. Insert two 1.5V AAAsize batteries, making sure to match the polarity

markings (+ / -) of the batteries with the diagram inside

the compartment.

c. Replace battery compartment cover.

2a 2b 2c

ASSEMBLY AND INSTALLATION

LAN

4. Turning TV on

Plug the power cord into a suitable power outlet, then press the

POWER () button on the remote control, making sure to aim it at the

sensor at the front of the TV. Alternatively, you can press the power

button on the lower side of the backpanel on the TV.

3. Connect to antenna

a. Connect anantenna cable (not supplied) via the ‘ANT’ input port at

the back of the TV.

b. Ensure the antenna cable is also connected to a working antenna,

eithervia an antenna wallsocket in yourhome, ordirectly.

TURNING TV OFF

Press the POWER ( ) button on the remote control to enter standby mode.

To power down the TV completely, unplug the power cord from the power

outlet.

Do not leave your set in standby mode for long periods of time. If you will

not use the TV for a long time, it is recommended to unplug the set from

both the power outlet and aerial.

Antenna

wall socket

Antenna cable

(not supplied)

HDMI 4 HDMI 3 HDMI 2 HDMI 1

(ARC) ANT USB 2.0

(5V / 500mA)

AUDIO OUT

DIGITAL

AUDIO OUT

R -AUDIO- L VIDEO

EARPHONE VGA VIDEO L - IN - R PC AUDIO ANT COAXIAL

‘ANT’ input

Following these options, the Auto Tuningscreen willappear. Ensure you

have anantenna cable connected to the ‘ANT’ input port at the back of

the TV (4a).

The auto tuning function will search for and save allavailable free-to-air

TV channels. Aer conﬁrming your settings (the default will be set for

Australia), the process willautomatically begin. The number of searched

channels willbe displayed on the screen.

HDMIUSB

EARPHONE VGA VIDEO L - IN - R PC AUDIO ANT COAXIAL

FIRST TIME SETUP

HDMI USB Y Pb Pr

You will now be welcomed with the initial set-up screen

You can press le/rigt button to select Language,Country,Time Zone

and Tune Type. Press ENTER button to enter the Auto Tuning.Press

MENU key to exit.

INPUT SOURCE

Press SOURCE to open the input source list, then press to highlight an

input and press OK to switch.

Poorpicture and sound quality

• Try a dierent channel

• Adjust the antenna

• Check allconnections

No picture orsound in TV status

• Try anotherchannel

• Press the TV/AV button

• Make sure TV is plugged in

• Check the antenna connection

No sound or sound is too low at

maximum volume

• Check the volume settings on any

external speakers connected to your

television

• Adjust the TV volume accordingly

• Check anotherchannel or input

• Check that MUTE hasn’t been

turned on

No colour, wrong colour or tints

• Make sure the program itself is

broadcast in colour

• Select the picture menu, thenadjust

the colour and tint submenus

Picture rolls vertically

• Check allconnections

Blurred orsnowy picture, distorted

sound

• Checkdirection, location and

connections to your antenna

• Issues may be caused by the use of

an indoor antenna (poor signal)

Remote control malfunctions

• Replace remote control batteries

• Checkbattery terminals

• Remote isout of range, move closer

to TV

• Remove any obstructionsbetween

remote andIR sensor of TV

• Make sure the power cord to your TV

is plugged in and turnedon

Image isnot centred on the screen

• Adjust the horizontal and vertical

position

“NoSignal” on HDMI source

• Test the device with a dierent HDMI

cable

• Plug the device into another HDMI

port

• Try a dierent device connected to

the same cable and port

• Perform a factory reset on your TV

For ourfull TV troubleshooting guide

and extended UserManual for this

TV, head online to help.kogan.com

BASIC TROUBLESHOOTING
