ilmax Software current limit R/W mA 1000.0 0.0 1000.0
lckon Disable | enable interlock functionality R/W 0 0 1
lmodgain Laser current AIN1 modulation gain R/W mA/V 0 -
100000.0 +100000.0
tecon Disable | enable TEC current R/W 0 0 1
tprot Disable | enable temperature protection R/W 1 0 1
rtset Thermistor resistance setpoint R/W Ω 10000.0 rtmin rtmax
rtact Actual value of thermistor resistance R Ω
itec TEC current R A
vtec TEC voltage R V
pgain Proportional gain of the temperature controller R/W 0.001 0.0 0.1
igain Integral gain of the temperature controller R/W 0.0001 0.0 0.1
dgain Differential gain of the temperature controller R/W 0.005 0.0 0.1
rtmin
Minimum thermistor resistance. If temperature
protection is enabled, the laser current is
automatically disabled below this value.
R/W Ω 5000.0 2000.0 50000.0
rtmax
Maximum thermistor resistance. If temperature
protection is enabled, the laser current is
automatically disabled above this value.
R/W Ω 15000.0 2000.0 50000.0
vtmin Minimum TEC voltage R/W V -2.0 -3.0 0.0
vtmax Maximum TEC voltage R/W V 2.0 0.0 3.0
tmodgain Temperature AIN2 modulation gain R/W Ω/V 0 -
100000.0 +100000.0
iphd Photodiode current R mA 0.0 2.5
ain1 AI1 pin voltage R V 0.0 2.5
ain2 AI2 pin voltage R V 0.0 2.5
tboard Board temperature R °C
version Firmware version R v0.17
status Return lason, vlaser, itec, vtec, rtact, iphd, ain1,
ain2.R
save Save configuration in internal memory (no
argument) W
serial Return the serial number R
userdata
write Write the user data (e.g. userdata write ABC) W 31 chars
