Kolin EU-OSK103 Bedienungsanleitung
USER MANUAL OF SMART
CONTROLLER
Read the manual carefully before
installing or connecting your Smart Kit (Wireless
Module). Make sure to save this manual for
future reference.
IMPORTANT NOTE:
www.kolinphil.com.ph
QR CODE
2
Hereby, we declare that this AC is in
compliance with the essential requirements and
other relevant provisions of Directive 2014/53/EU.
A copy of the full DOC is attached.
SPECIFICATION
3
PRECAUTIONS
3
DOWNLOAD AND INSTALLATION OF APP
5
INSTALLATION OF SMART KIT
5
USER REGISTRATION
6
NETWORK CONFIGURATION
9
HOW TO USE THE APP
32
SPECIAL FUNCTIONS
36
CONTENTS
DECLARATION OF CONFORMITY
3
Model: EU-OSK103
Standard: IEEE 802. 11b/g/n
Antenna Type: Printed PCB Antenna
Frequency: WLAN 2400~2483.5 MHz
Operation Temperature: 0ºC~45ºC/32ºF~113ºF
Operation Humidity: 10%~85%
Power Input: DC 5V/300mA
Maximum Transmitted Power: 19.8dBm Max
Applicable system: iOS, Android.
(iOS 8.0 or above, Android 6.0 or above)
- Please keep your APP up to date with the
latest version.
- Due to some situations, we affirm: Not all
Android and iOS systems are compatible
with the APP. We will not be liable for any
issue as a result of the incompatibility.
Wireless Safety Strategy
Smart kit only supports WPA-PSK/WPA2-PSK
encryption and none encryption.
WPA-PSK/WPA2-PSK encryption is
recommended.
1. SPECIFICATION
2. PRECAUTIONS
4
Due to different network situation, control
process may time-out in some occasions. If this
situation occurs, the display between board
and APP may not be the same, please don’t
get confused.
Smart phone camera needs to be 5
million pixels or above to scan the QR
code sufficiently.
Request time-out could happen due
to different network situation. Hence,
it is mandatory to do network
configuration once again.
The APP system is subject to update
without prior notice due to some
product function improvement. The
actual network configuration process
may slightly be different from the
manual, so, the actual process shall
prevail.
Wi-Fi signal must be strong in order for
the Air-conditioning unit to work
properly. If Wi-Fi signal is weak in the
room wherein the AC unit is placed,
usage of repeater is advised.
WARNING:
5
The following QR code is only available for
DOWNLOADING the app.
Android iOS
For Android Phone users: scan Android QR
code or go to google play then search
“NetHome Plus” app and download it.
For iOS users: scan iOS QR code or go to
App Store then search “NetHome Plus”
app and download it.
1. Remove the protective cap of the Smart
Kit (wireless module)
2. Open the front panel and insert the Smart
Kit (wireless module) into the reserved
interface.
3. DOWNLOAD AND INSTALLATION OF
NETHOME PLUS APPLICATION
4. INSTALL THE SMART KIT (Wireless
Module)
WARNING:
6
3. The QR code packed with Smart Kit
(wireless module) is attached to the side
panel of the machine to ensure that it will
be scanned by the mobile phone. Other
option is to take the picture of the QR
code and save it to their phone. It is also
available on the front page of the user
manual.
This interface is only compatible with Smart
Kit (Wireless Module) provided by the
manufacturer.
Please ensure your mobile device is
connected to the Wi-Fi router. The wireless
5. USER REGISTRATION
WARNING:
7
router must be connected to the internet
before doing the registration and network
configuration.
It is better to log-in your email on the box
and activate your account by clicking the
link in case you forget your password. You
can also log in using the Third Party
applications (Facebook & Twitter)
FOLLOW THE STEPS BELOW:
STEP 1: Click “Create Account”
8
For iOS users, you will receive a
verification e-mail with the attached link
in your registered e-mail address while for
Android users, you can already log in
after registration.
STEP 2: Enter your email address and password
then click “Registration”
NOTE:
9
It is necessary to forget any other network
which is around the premises and make
sure your device is connected to the
wireless network you want to configure.
Make sure your device’s wireless function
works well and can be connected back to
your original wireless network
automatically.
6. NETWORK CONFIGURATION
WARNING:
10
1. Make sure your mobile device has
already been connected to the
wireless network which you wish to use.
Also, you need to forget other irrelevant
wireless network in case it influences
your configuration process.
2. Disconnect the power supply of AC.
3. Connect the power supply of AC and
continuously press the “LED DISPLAY” or
“DO NOT DISTURB” button seven times
in 10 seconds.
4. When the AC displays “AP”, it means
that the AC wireless has already
entered into “AP” mode.
Some type of AC does not need step 2 to
be in AP mode.
֍Using Android device to do network
configuration
