KTM 65 SX 2016 Handbuch

SETUP INSTRUCTIONS 2016

65 SX

Art. no. 3213431en

INTRODUCTION 1

*3213431en*

3213431en

11/2015

INTRODUCTION

The work described in these setup instructions must be performed before the vehicle is delivered to the customer.

Read the setup instructions in their entirety before beginning work.

These setup instructions were written to correspond to the latest state of this series. We reserve the right to make changes in the interest

of technical advancement without at the same time updating this manual.

We shall not provide a description of general workshop methods. Likewise, safety rules that apply in a workshop are not specified here. It

is assumed that the work will be performed by a fully trained mechanic.

All specifications are non-binding. KTM Sportmotorcycle GmbH specifically reserves the right to modify or delete technical specifications,

prices, colors, forms, materials, services, designs, equipment, etc., without prior notice and without specifying reasons, to adapt these to

local conditions, as well as to stop production of a particular model without prior notice. KTM accepts no liability for delivery options, devi-

ations from illustrations and descriptions, misprints, and other errors. The models portrayed partly contain special equipment that does not

belong to the regular scope of supply.

Reproduction, even in part, as well as copying of all kinds, is permitted only with the express written permission of the copyright owner.

ISO 9001(12 100 6061)

According to the international quality management standard ISO 9001, KTM uses quality assurance processes that lead to

the maximum possible quality of the products.

Issued by: TÜV Management Service

KTM Sportmotorcycle GmbH

5230 Mattighofen, Austria

This document is valid for the following models:

65 SX (F6001P6)

1 MEANS OF REPRESENTATION 2

1.1 Symbols used

The meaning of specific symbols is described below.

Indicates an expected reaction (e.g. of a work step or a function).

Indicates an unexpected reaction (e.g. of a work step or a function).

Indicates a page reference (more information is provided on the specified page).

Indicates information with more details or tips.

Indicates the result of a testing step.

Denotes a voltage measurement.

Denotes a current measurement.

Denotes a resistance measurement.

1.2 Formats used

The typographical formats used in this document are explained below.

Proprietary name Identifies a proprietary name.

Name®Identifies a protected name.

Brand™ Identifies a trademark.

Underlined terms Refer to technical details of the vehicle or indicate technical terms, which are explained

in the glossary.

2 SETUP 3

2.1 Unpacking and setting up the vehicle

201951-10

–Open the box.

Info

To avoid damaging the vehicle while setting it up, do not remove the protec-

tive film on each component until installing the component, and leave it on

the vehicle where possible until work has been completed.

–Remove the front wheel, fender, and the separate enclosure from the box.

–Remove the separate enclosure and unpack it. Check that the scope of supply is

complete on the basis of the enclosed packing list.

–Lift the vehicle out of the box with the assistance of another person.

–Raise the motorcycle with a lift stand. ( p. 4)

–Check the vehicle for transport damage.

201952-10

–Loosen screws .

–Remove the wheel spindle.

–Install the front fender. ( p. 6)

–Install the front wheel. ( p. 4)

–Remove the protective film from the handlebar and start number plate.

K00344-10

–Position the handlebar with handlebar clamps .

–Mount and tighten the screws.

Guideline

Screw, handlebar clamp M8 20 Nm

(14.8 lbf ft)

–Check the handlebar position.

» If the handlebar position is not adjusted as required by the customer:

–Adjust the handlebar position. ( p. 5)

–Remove the screw of brake line guide . Position the brake line. Mount the brake

line guide again and tighten the screw.

–Check that the wiring harness, throttle cables, and brake line have the necessary

freedom of movement and are correctly routed.

–Check that the controls on the handlebar are correctly positioned and firmly seated.

800042-10

–Mount the footrests with the springs and pins. Secure the pins using the washers

and cotter pins.

Pliers for footrest spring (58429083000)

–Fill up with fuel. ( p. 6)

–Prepare the vehicle according to the specifications in the KTM Dealer.net for han-

dover to the customer.

3 WORK 4

3.1 Raising the motorcycle with a lift stand

Note

Danger of damage The parked vehicle may roll away or fall over.

–Always place the vehicle on a firm and even surface.

401942-01

–Raise the motorcycle at the frame underneath the engine.

Lift stand (78929955100)

The wheels must no longer touch the ground.

–Secure the motorcycle against falling over.

3.2 Removing the motorcycle from the lift stand

Note

Danger of damage The parked vehicle may roll away or fall over.

–Always place the vehicle on a firm and even surface.

402581-10

–Remove the motorcycle from the lift stand.

–Remove the lift stand.

–To park the motorcycle, insert plug-in stand into the plug-in stand bracket on

the left side of the vehicle.

Info

Remove the plug-in stand before riding.

3.3 Installing the front wheel

Warning

Danger of accidents Reduced braking efficiency due to oil or grease on the brake discs.

–Always keep the brake discs free of oil and grease, and clean them with brake cleaner when necessary.

601957-11

–Check the wheel bearing for damage and wear.

» If the wheel bearing is broken or worn:

–Change the wheel bearing.

–Clean and grease wheel spindle .

Long-life grease ( p. 10)

–Lift the front wheel into the fork, position it, and insert wheel spindle .

The brake linings are correctly positioned.

–Tighten screws .

Guideline

Screw, fork stub M6 10 Nm (7.4 lbf ft)

3 WORK 5

601956-11

–Mount and tighten screw .

Guideline

Screw, front wheel spindle M10 40 Nm

(29.5 lbf ft)

Loctite®243™

–Remove the motorcycle from the lift stand. ( p. 4)

601958-10

–Operate the hand brake lever several times until the brake linings are in contact

with the brake disc.

–Loosen screws .

–Pull the front wheel brake and push down hard on the fork several times.

This aligns the fork legs.

–Tighten screws .

Guideline

Screw, fork stub M6 10 Nm (7.4 lbf ft)

3.4 Adjusting handlebar position

Warning

Danger of accidents Handlebar breakage.

–If the handlebar is bent or straightened it will cause material fatigue, and the handlebar can break. Always replace handle-

bar.

601951-11

–Remove the screws . Take off the handlebar clamps. Remove the handlebar and

lay it to one side.

Info

Protect the motorcycle and its attachments from damage by covering them.

Do not bend the cables and lines.

–Remove the screws . Remove the handlebar support.

–Place the handlebar support in the required position. Fit and tighten the

screws .

Guideline

Screw, handlebar support M10 40 Nm

(29.5 lbf ft)

Loctite®243™

–Position the handlebar.

Info

Make sure cables and wiring are positioned correctly.

–Position the handlebar clamps. Fit and evenly tighten the screws .

Guideline

Screw, handlebar clamp M8 20 Nm

(14.8 lbf ft)

Info

Make sure the gap width is even.

3 WORK 6

3.5 Installing the front fender

H00141-10

–Position the fender with drill holes in the holding lugs on the start number

plate.

The holding lugs engage in the drilled holes.

602674-11

–Position the front fender. Mount and tighten screws .

Guideline

Remaining screws, chassis M6 10 Nm (7.4 lbf ft)

3.6 Refueling

Danger

Fire hazard Fuel is highly flammable.

–Never refuel the vehicle near open flames or burning cigarettes, and always switch off the engine first. Be careful that no

fuel is spilt, especially on hot vehicle components. Clean up spilt fuel immediately.

–The fuel in the fuel tank expands when warm and may emerge if overfilled. Follow the instructions on refueling.

Warning

Danger of poisoning Fuel is poisonous and a health hazard.

–Fuel must not come into contact with the skin, eyes, or clothing. Do not breathe in the fuel vapors. If contact occurs with

the eyes, rinse with water immediately and contact a physician. Immediately clean contaminated areas on the skin with

soap and water. If fuel is swallowed, contact a physician immediately. Change clothing that is contaminated with fuel.

Warning

Environmental hazard Improper handling of fuel is a danger to the environment.

–Do not allow fuel to get into the ground water, the ground, or the sewage system.

–Switch off the engine.

–Open the filler cap. ( p. 7)

400382-10

–Fill the fuel tank with fuel up to measurement .

Guideline

Measurement of 35 mm (1.38 in)

Fuel tank capac-

ity, approx.

3.5 l (3.7 qt.) Super unleaded (95 octane) mixed

with 2-stroke engine oil (1:60)

( p. 9)

Engine oil, 2-stroke ( p. 9)

–Close the filler cap. ( p. 7)

3 WORK 7

3.7 Opening the filler cap

Danger

Fire hazard Fuel is highly flammable.

–Never refuel the vehicle near open flames or burning cigarettes, and always switch off the engine first. Be careful that no

fuel is spilt, especially on hot vehicle components. Clean up spilt fuel immediately.

–The fuel in the fuel tank expands when warm and may emerge if overfilled. Follow the instructions on refueling.

Warning

Danger of poisoning Fuel is poisonous and a health hazard.

–Fuel must not come into contact with the skin, eyes, or clothing. Do not breathe in the fuel vapors. If contact occurs with

the eyes, rinse with water immediately and contact a physician. Immediately clean contaminated areas on the skin with

soap and water. If fuel is swallowed, contact a physician immediately. Change clothing that has been contaminated with

fuel. Store fuel properly in a suitable canister and keep away from children.

Warning

Environmental hazard Improper handling of fuel is a danger to the environment.

–Do not allow fuel to get into the ground water, the ground, or the sewage system.

H00146-10

–Press release button , turn the filler cap counterclockwise, and lift it free.

3.8 Closing the filler cap

H00147-10

–Replace the filler cap and turn clockwise until the release button locks in

place.

Info

Run the fuel tank breather hose without kinks.

4 TECHNICAL DATA 8

4.1 chassis tightening torques

Spoke nipple M3.5 3 Nm (2.2 lbf ft) –

Remaining nuts, chassis M6 10 Nm (7.4 lbf ft) –

Remaining screws, chassis M6 10 Nm (7.4 lbf ft) –

Screw, ball joint of push rod on foot

brake cylinder

M6 10 Nm (7.4 lbf ft) –

Screw, foot brake cylinder M6 10 Nm (7.4 lbf ft) –

Screw, fork stub M6 10 Nm (7.4 lbf ft) –

Screw, front brake disc M6 14 Nm (10.3 lbf ft) Loctite®243™

Screw, rear brake disc M6 14 Nm (10.3 lbf ft) Loctite®243™

Screw, rear brake lining M6 8 Nm (5.9 lbf ft) –

Screw, throttle grip M6 4.5 Nm (3.32 lbf ft) –

Screw; front brake lining M6 10 Nm (7.4 lbf ft) –

Nut, rim lock M8 10 Nm (7.4 lbf ft) –

Remaining nuts, chassis M8 25 Nm (18.4 lbf ft) –

Remaining screws, chassis M8 25 Nm (18.4 lbf ft) –

Screw, bottom triple clamp M8 15 Nm (11.1 lbf ft) –

Screw, brake caliper M8 20 Nm (14.8 lbf ft) Loctite®243™

Screw, engine bracket M8 30 Nm (22.1 lbf ft) –

Screw, handlebar clamp M8 20 Nm (14.8 lbf ft) –

Screw, rear sprocket M8 25 Nm (18.4 lbf ft) Loctite®243™

Screw, steering stem M8 20 Nm (14.8 lbf ft) –

Screw, tail assembly M8 35 Nm (25.8 lbf ft) Loctite®2701™

Screw, top triple clamp M8 20 Nm (14.8 lbf ft) –

Remaining nuts, chassis M10 45 Nm (33.2 lbf ft) –

Remaining screws, chassis M10 45 Nm (33.2 lbf ft) –

Screw, bottom shock absorber M10 45 Nm (33.2 lbf ft) Loctite®243™

Screw, foot brake lever M10 35 Nm (25.8 lbf ft) Loctite®243™

Screw, front wheel spindle M10 40 Nm (29.5 lbf ft) Loctite®243™

Screw, handlebar support M10 40 Nm (29.5 lbf ft) Loctite®243™

Screw, top shock absorber M10 45 Nm (33.2 lbf ft) Loctite®243™

Nut, swingarm pivot M12x1 40 Nm (29.5 lbf ft) –

Nut, rear wheel spindle M14x1.5 40 Nm (29.5 lbf ft) –

Nut, steering stem M20x1.5 10 Nm (7.4 lbf ft) –

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere KTM Motorrad Handbücher

KTM

KTM 1998 400 R Benutzerhandbuch

KTM

KTM 400 EXC EU 2010 Bedienungsanleitung

KTM

KTM 300 SX Benutzerhandbuch

KTM

KTM 250 EXC-F EU 2010 Bedienungsanleitung

KTM

KTM 450 EXC EU 2016 Bedienungsanleitung

KTM

KTM 390 ADVENTURE 2021 Bedienungsanleitung

KTM

KTM 250 SX-F 2021 Bedienungsanleitung

KTM

KTM 690 Enduro R 2021 Bedienungsanleitung

KTM

KTM 2004 660 SMC Bedienungsanleitung

KTM

KTM 390 Duke 2020 Handbuch

KTM

KTM 450 EXC EU 2013 Handbuch

KTM

KTM 450 Rally Factory Replica 2021 Bedienungsanleitung

KTM

KTM 2001 50 JR ADVENTURE Benutzerhandbuch

KTM

KTM 250 EXC-F Six Days EU Bedienungsanleitung

KTM

KTM 250 SX-F EU Bedienungsanleitung

KTM

KTM 400 LS-E/MIL Benutzerhandbuch

KTM

KTM 250 SX-F EU 2012 Bedienungsanleitung

KTM

KTM 85 SX 2004 Betriebsanleitung

KTM

KTM 1290 Super Adventure S 2018 Handbuch

KTM

KTM 690 SMC USA 2010 Bedienungsanleitung

KTM

KTM 200 Duke US 2020 Bedienungsanleitung

KTM

KTM 2011 990 Supermoto T USA Bedienungsanleitung

KTM

KTM 660SMC Leitfaden

KTM

KTM 1290 Super Duke GT 2018 Handbuch

Beliebte Motorrad Handbücher anderer Marken

OHVALE

OHVALE GP-0 Stücklistenhandbuch

Yamaha

Yamaha Star XV19CTSZ 2009 Bedienungsanleitung

HYOSUNG

HYOSUNG ST7 Bedienungsanleitung

Husqvarna

Husqvarna FC 250 2016 Bedienungsanleitung

Ducati

Ducati SCRAMBLER 800 Gebrauchsanweisung

MOTO GUZZI

MOTO GUZZI QUOTA 1100 ES Bedienungsanleitung

APRILIA

APRILIA ETV MILLE CAPONORD - PART1 02-2001 Bedienungsanleitung

Yamaha

Yamaha 2006 YZF-R1V Bedienungsanleitung

Fantic

Fantic Enduro 125 Bedienungsanleitung

Ducati

Ducati Supersport 750 desmodue Bedienungsanleitung

MV Agusta

MV Agusta 2008 F4 312RR 1078 Gebrauchsanweisung

Yamaha

Yamaha XVS650A Bedienungsanleitung

Yamaha

Yamaha YZF-R6T(C) Handbuch

Ducati

Ducati 748 monoposto strada Bedienungsanleitung

ATK

ATK 1988 250 Bedienungsanleitung

Excelsior-HENDERSON

Excelsior-HENDERSON 1999 HCX Bedienungsanleitung

Triumph

Triumph Thunderbird Bedienungsanleitung

Yamaha

Yamaha 2006 FJR1300A Bedienungsanleitung
