COSMOS
Digital TV Antenna
Quick Start Guide
• Wa erproof
• Durable
• An i-UV
COSMOS
Digital TV Antenna
Produc Fea ures
1. The aerial can receive both digital and analogue terrestrial TV signals.
2. The omni-directional (360 degree) design eliminates the need to
locate the direction of your local TV and radio transmitter.
3. High gain with built-in signal amplifier and high receiver sensitivity.
4. Can be permanently fixed on your caravan, motorhome, truck
or boat.
Elec rical Specifica ion
1. Frequency Band: VHF, UHF.
2. Frequency: VHF: 174-233MHz, UHF: 47-870MHz.
3. Gain: 20±2dBi.
4. Working Voltage: 10-l4V.
5. Impedance: 75ohm.
6. Radiation Pattern: Omni-directional.
7. Coax Cable: 3C-2V, L=4 m.
8. Connector: PAL-Male.
Quick Start Guide
Permanen Roof Ins alla ion
1. Make four 5mm diameter holes in the vehicle roof.
2. Choose suitable fixings (not included) to fix the antenna on the vehicle roof.
Bond all surfaces with ikaflex sealant.
3. Route all cables securely and plug the RF connector into the TV and the cigar
plug into a cigar plug socket. The cigar plug MU T be used as it contains the
protection for the electronics in the device. Under no circumstances should
the cigar plug be cut off and the unit hard-wired.
4. After installation, check the roof for leaks.
Magne ic Roof Ins alla ion
1. Use magnetic base to fix antenna to metal surface.
2. Route all cables securely and plug the RF connector into the TV and the cigar
plug into a cigar plug socket. The cigar plug MU T be used as it contains the
protection for the electronics in the device. Under no circumstances should
the cigar plug be cut off and the unit hard-wired.
No e
1. Do not connect the power until installation is complete and sealant has been
applied (if permanent fixing is used).
2. For better reception, the antenna should be kept away from other power
sources, coax cables etc.
3. Install as high as possible. If there is interference between the antenna and
transmission tower it will cause signal attenuation/loss in quality of reception.
4. Please fix the cable carefully to avoid snagging or catching.
INDOOR OUTDOOR
DC
12V-24V
KUMA Limited
www.kuma.co.uk
+44 (0)1594 888 188
Troubleshoo ing
No picture or poor picture:
1. Check all connections from the antenna to the TV and make
sure all the connections are correct.
2. Check power supply equipment is correctly functioning.
Booster light is on.
3. Make sure all the coax cabling is in good condition.
