Kuppersbusch FKF8800.1i Bedienungsanleitung
BEDIENUNGSANWEISUNG
mit Montageanweisungen
INSTRUCTIONS FOR USE
and installation
Lesen Sie unbedingt die Gebrauchsanleitung
und den Montageplan vor Aufstellung,
Installation sowie Inbetriebnahme.
Please read the users and installation
instructions carefully before installation
of the appliance and before starting to use it.
Service und Kundendienst
Telefon: 0209 – 401 631
Email: [email protected]
FKF8800.1i
EN PT ES
CONTENTS
Safety information 2
Safety instructions 4
Installation 6
Control Panel 8
Daily use 10
Hints and tips 11
Care and cleaning 14
Troubleshooting 14
Noises 18
Technical data 18
Information for test institutes 19
Subject to change without notice.
VISIT OUR WEBSITE TO:
Get usage advice, brochures, trouble shooter, service and repair
information:
www.kueppersbusch-home.com
SAFETY INFORMATION
Before the installation and use of the appliance, carefully
read the supplied instructions. The manufacturer is not
responsible for any injuries or damage that are the result of
incorrect installation or usage. Always keep the instructions
in a safe and accessible location for future reference.
Children and vulnerable people safety
•This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
the use of the appliance in a safe way and understand the
hazards involved.
•Children aged from 3 to 8 years are allowed to load and
unload the appliance provided that they have been
properly instructed.
•This appliance may be used by persons with very
extensive and complex disabilities provided that they have
been properly instructed.
•Children of less than 3 years of age should be kept away
from the appliance unless continuously supervised.
•Do not let children play with the appliance.
2
•Children shall not carry out cleaning and user maintenance
of the appliance without supervision.
•Keep all packaging away from children and dispose of it
appropriately.
General Safety
•This appliance is intended to be used in household and
similar applications such as:
–Farm houses; staff kitchen areas in shops, offices and
other working environments;
–By clients in hotels, motels, bed and breakfast and other
residential type environments.
•To avoid contamination of food respect the following
instructions:
–do not open the door for long periods;
–clean regularly surfaces that can come in contact with
food and accessible drainage systems;
–store raw meat and fish in suitable containers in the
refrigerator, so that it is not in contact with or drip onto
other food.
•WARNING: Keep ventilation openings, in the appliance
enclosure or in the built-in structure, clear of obstruction.
•WARNING: Do not use mechanical devices or other
means to accelerate the defrosting process, other than
those recommended by the manufacturer.
•WARNING: Do not damage the refrigerant circuit.
•WARNING: Do not use electrical appliances inside the
food storage compartments of the appliance, unless they
are of the type recommended by the manufacturer.
•Do not use water spray and steam to clean the appliance.
•Clean the appliance with a moist soft cloth. Only use
neutral detergents. Do not use abrasive products, abrasive
cleaning pads, solvents or metal objects.
•When the appliance is empty for long period, switch it off,
defrost, clean, dry and leave the door open to prevent
mould from developing within the appliance.
3
•Do not store explosive substances such as aerosol cans
with a flammable propellant in this appliance.
•If the supply cord is damaged, it must be replaced by the
manufacturer, its Authorised Service Centre or similarly
qualified persons in order to avoid a hazard.
SAFETY INSTRUCTIONS
Installation
WARNING! Only a qualified
person must install this
appliance.
• Remove all the packaging.
• Do not install or use a damaged
appliance.
• Do not use the appliance before
installing it in the built-in structure due
to safety manner.
• Follow the installation instructions
supplied with the appliance.
• Always take care when moving the
appliance as it is heavy. Always use
safety gloves and enclosed footwear.
• Make sure the air can circulate around
the appliance.
• At first installation or after reversing the
door wait at least 4 hours before
connecting the appliance to the power
supply. This is to allow the oil to flow
back in the compressor.
• Before carrying out any operations on
the appliance (e.g. reversing the door),
remove the plug from the power socket.
• Do not install the appliance close to
radiators or cookers, ovens or hobs.
• Do not expose the appliance to the
rain.
• Do not install the appliance where there
is direct sunlight.
• Do not install this appliance in areas
that are too humid or too cold.
• When you move the appliance, lift it by
the front edge to avoid scratching the
floor.
• The appliance contains a bag of
desiccant. This is not a toy. This is not
food. Please dispose of it immediately.
Electrical connection
WARNING! Risk of fire and
electric shock.
WARNING! When positioning
the appliance, ensure the
supply cord is not trapped or
damaged.
WARNING! Do not use multi-
plug adapters and extension
cables.
• The appliance must be earthed.
• Make sure that the parameters on the
rating plate are compatible with the
electrical ratings of the mains power
supply.
• Always use a correctly installed
shockproof socket.
• Make sure not to cause damage to the
electrical components (e.g. mains plug,
mains cable, compressor). Contact the
Authorised Service Centre or an
electrician to change the electrical
components.
• The mains cable must stay below the
level of the mains plug.
• Connect the mains plug to the mains
socket only at the end of the
installation. Make sure that there is
access to the mains plug after the
installation.
• Do not pull the mains cable to
disconnect the appliance. Always pull
the mains plug.
Use
WARNING! Risk of injury,
burns, electric shock or fire.
4
The appliance contains flammable
gas, isobutane (R600a), a natural gas with
a high level of environmental compatibility.
Be careful not to cause damage to the
refrigerant circuit containing isobutane.
• Do not change the specification of this
appliance.
• Do not put electrical appliances (e.g.
ice cream makers) in the appliance
unless they are stated applicable by the
manufacturer.
• If damage occurs to the refrigerant
circuit, make sure that there are no
flames and sources of ignition in the
room. Ventilate the room.
• Do not let hot items to touch the plastic
parts of the appliance.
• Do not store flammable gas and liquid
in the appliance.
• Do not put flammable products or items
that are wet with flammable products
in, near or on the appliance.
• Do not touch the compressor or the
condenser. They are hot.
Internal lighting
WARNING! Risk of electric
shock.
• The type of lamp used for this
appliance is for household appliances
only. Do not use it for house lighting.
Care and cleaning
WARNING! Risk of injury or
damage to the appliance.
• Before maintenance, deactivate the
appliance and disconnect the mains
plug from the mains socket.
• This appliance contains hydrocarbons
in the cooling unit. Only a qualified
person must do the maintenance and
the recharging of the unit.
• Regularly examine the drain of the
appliance and if necessary, clean it. If
the drain is blocked, defrosted water
collects in the bottom of the appliance.
Service
• To repair the appliance contact the
Authorised Service Centre. Use original
spare parts only.
• Please note that self-repair or non-
professional repair can have safety
consequences and might void the
guarantee.
• The following spare parts will be
available for 7 years after the model
has been discontinued: thermostats,
temperature sensors, printed circuit
boards, light sources, door handles,
door hinges, trays and baskets. Please
note that some of these spare parts are
only available to professional repairers,
and that not all spare parts are relevant
for all models.
• Door gaskets will be available for 10
years after the model has been
discontinued.
Disposal
WARNING! Risk of injury or
suffocation.
• Disconnect the appliance from the
mains supply.
• Cut off the mains cable and discard it.
• Remove the door to prevent children
and pets to be closed inside of the
appliance.
• The refrigerant circuit and the insulation
materials of this appliance are ozone-
friendly.
• The insulation foam contains
flammable gas. Contact your municipal
authority for information on how to
discard the appliance correctly.
• Do not cause damage to the part of the
cooling unit that is near the heat
exchanger.
5
INSTALLATION
WARNING! Refer to Safety
chapters.
WARNING! Refer to
installation instruction
document to install your
appliance.
WARNING! Fix the appliance
in accordance with installation
instruction document to avoid a
risk of instability of the
appliance.
Dimensions
B
A
H1
W1
D1
W2
D2
W3
D3
Overall dimensions
1)
H1 mm 1769
W1 mm 556
6
Overall dimensions
1)
D1 mm 549
1) the height, width and depth of the appliance without
the handle and feet
Space required in use
1)
H2 (A+B) mm 1816
W2 mm 560
D2 mm 552
A mm 1780
B mm 36
1) the height, width and depth of the appliance includ‐
ing the handle, plus the space necessary for free circu‐
lation of the cooling air
Overall space required in use
1)
H3 (A+B) mm 1816
W3 mm 780
D3 mm 1085
1) the height, width and depth of the appliance includ‐
ing the handle, plus the space necessary for free circu‐
lation of the cooling air, plus the space necessary to
allow door opening to the minimum angle permitting
removal of all internal equipment
Location
To ensure appliance's best functionality,
you should not install the appliance in the
nearby of the heat source (oven, stoves,
radiators, cookers or hobs) or in a place
with direct sunlight. Make sure that air can
circulate freely around the back of the
cabinet.
Positioning
This appliance should be installed in a dry,
well ventilated indoor position.
This appliance is intended to be used at
ambient temperature ranging from 10°C to
38°C.
If you have any doubts
regarding where to install the
appliance, please turn to the
vendor, to our customer service
or to the nearest Authorised
Service Centre.
It must be possible to
disconnect the appliance from
the mains power supply. The
plug must therefore be easily
accessible after installation.
Electrical connection
• Before plugging in, ensure that the
voltage and frequency shown on the
rating plate correspond to your
domestic power supply.
• The appliance must be earthed. The
power supply cable plug is provided
with a contact for this purpose. If the
domestic power supply socket is not
earthed, connect the appliance to a
separate earth in compliance with
current regulations, consulting a
qualified electrician.
• The manufacturer declines all
responsibility if the above safety
precautions are not observed.
• This appliance complies with the E.E.C.
Directives.
Ventilation requirements
The airflow behind the appliance must be
sufficient.
5 cm min.
200 cm2
min.
200 cm2
7
CAUTION! Refer to the
installation instructions for the
installation.
Door reversibility
Please refer to the separate document
with instructions on installation and door
reversal.
CAUTION! At every stage of
reversing the door protect the
floor from scratching with a
durable material.
CONTROL PANEL
Functions
32
45
6
1
1Display
2Temperature warmer button
3Temperature colder button
4OK
5Functions
6ON/OFF
It is possible to change predefined sound
of buttons by pressing together Functions
and temperature colder button for a few
seconds. Change is reversible.
Display
Off
min
A B C D
EFG
A. Timer indicator
B. Shopping function
C. NaturaFresh function
D. Temperature indicator
E. Alarm indicator
F. ChildLock function
G. DrinksChill function
Switching on
1. Connect the mains plug to the power
socket.
2. Press the appliance ON/OFF if the
display is off. The temperature
indicators show the set default
temperature.
To select a different set temperature refer
to "Temperature regulation".
If "dEMo" appears on the display, refer to
"Troubleshooting" .
Switching off
1. Press the appliance ON/OFF for 3
seconds.
The display switches off.
8
2. Disconnect the mains plug from the
power socket.
Temperature regulation
Set the temperature of the appliance by
pressing the temperature regulators.
Default recommended set temperature is:
• +4°C for the fridge
The temperature range may vary between
2°C and 8°C for fridge.
The temperature indicators show the set
temperature.
The set temperature will be
reached within 24 hours.
After a power failure the set
temperature remains stored.
Shopping function
If you need to insert in the fridge
compartment a large amount of warm
food, for example after doing the grocery
shopping, we suggest activating the
Shopping function to chill the products
more rapidly and to avoid warming the
other food which is already in the
refrigerator.
1. Press the Functions until the
corresponding icon appears.
The Shopping indicator flashes.
2. Press the OK to confirm.
The Shopping indicator is shown.
This function stops automatically after
approximately 6 hours.
You can deactivate the Shopping function
before its automatic end by repeating the
procedure or by selecting a different fridge
set temperature.
NaturaFresh compartment
setting
The storage temperature and the relative
humidity in NaturaFresh compartment
provide optimal conditions for the storage
of various kinds of fresh food (like fish,
meat, seafood, etc.) as it preserves its
high nutritional values, as well as high
humidity level much longer than regular
refrigerator.
1. Press Functions until the
corresponding icon appears.
The display shows 3. This is the default
setting that ensures the most effective
performance.
The possible settings can vary from 1 (the
coldest) to 5 (the warmest).
Settings from 1 to 3 are suitable for fish
and meat.
Settings 4 and 5 are suitable for
vegetables and fruits. In these settings the
compartment works similarly to the fridge
compartment.
2. Press the temperature buttons on the
control panel to select the required
setting.
3. Press OK to confirm the setting.
The indicator returns to the fridge
temperature setting in a few seconds.
ChildLock function
Activate the ChildLock function to lock the
buttons from unintentional operation.
1. Press Functions until the
corresponding icon appears.
The ChildLock indicator flashes.
2. Press OK to confirm.
The ChildLock indicator is shown.
To deactivate the ChildLock function,
repeat the procedure until the ChildLock
indicator goes off.
DrinksChill function
The DrinksChill function is to be used to
set an acoustic alarm at the preferred
time, useful for example when a recipe
requires to cool down food products for a
certain period of time.
1. Press Functions until the
corresponding icon appears.
The DrinksChill indicator flashes.
The Timer shows the set value (30
minutes) for a few seconds.
2. Press the Timer regulator to change
the Timer set value from 1 to 90
minutes.
3. Press OK to confirm.
The DrinksChill indicator is shown.
The Timer starts to flash (min).
9
At the end of the countdown the "0 min"
indicator flashes and an audible alarm
sounds. Press OK to switch off the sound
and terminate the function.
To switch off the function repeat the
procedure until the DrinksChill goes off.
It is possible to change the time
at any time during the
countdown and at the end by
pressing the Temperature
colder button and the
Temperature warmer button.
Door open alarm
If the fridge door is left open for
approximately 5 minutes, the sound is on
and alarm indicator flashes.
The alarm stops after closing the door.
During the alarm, the sound can be muted
by pressing any button.
If you do not press any button,
the sound switches off
automatically after around one
hour to avoid disturbing.
DAILY USE
Positioning the door shelves
To permit storage of food packages of
various sizes, the door shelves can be
placed at different heights.
1. Gradually pull the shelf up until it
comes free.
2. Reposition as required.
Movable shelves
The walls of the refrigerator are equipped
with a series of runners so that the
shelves can be positioned as desired.
This appliance is also equipped with a
shelf consisting of two parts. The front half
of the shelf can be placed under the
second half to make better use of space.
To fold the shelf:
1. Take out the front half gently.
2. Slide it into the lower rail and under the
second half.
1
2
Do not move the glass shelf
above the vegetable drawer to
ensure correct air circulation.
NaturaFresh compartment
The storage temperature and the relative
humidity in this compartment provide
optimal conditions for the storage of
various kinds of food.
10
Dieses Handbuch passt für folgende Modelle
1
Inhaltsverzeichnis
Sprachen:
Andere Kuppersbusch Kühlschrank Handbücher
Kuppersbusch
Kuppersbusch KG 178 Bedienungsanleitung
Kuppersbusch
Kuppersbusch FKG8500 1i Series Bedienungsanleitung
Kuppersbusch
Kuppersbusch KSG 88 Bedienungsanleitung
Kuppersbusch
Kuppersbusch IKE3270-1-2T Bedienungsanleitung
Kuppersbusch
Kuppersbusch IKEF 238-5 Bedienungsanleitung
Kuppersbusch
Kuppersbusch IKEF3290-2 Bedienungsanleitung
Kuppersbusch
Kuppersbusch IKE248-7 Bedienungsanleitung
Kuppersbusch
Kuppersbusch IKEF3290-1 Bedienungsanleitung
Kuppersbusch
Kuppersbusch KE 650-2-2T Bedienungsanleitung
Kuppersbusch
Kuppersbusch FKG9501.0E Bedienungsanleitung
Kuppersbusch
Kuppersbusch IKE246-0 Bedienungsanleitung
Kuppersbusch
Kuppersbusch ? ???KE9600-0-2T Bedienungsanleitung
Kuppersbusch
Kuppersbusch IKE2460-2 Bedienungsanleitung
Kuppersbusch
Kuppersbusch FKF4800.0i Bedienungsanleitung
Kuppersbusch
Kuppersbusch IKU 169-0 Bedienungsanleitung
Kuppersbusch
Kuppersbusch ITE 109 series Bedienungsanleitung
Kuppersbusch
Kuppersbusch IKE 188-5 Bedienungsanleitung
Kuppersbusch
Kuppersbusch FK4505.0i Bedienungsanleitung
Kuppersbusch
Kuppersbusch IKE 318-4-2T Bedienungsanleitung
Kuppersbusch
Kuppersbusch FK2500.0i Bedienungsanleitung
Beliebte Kühlschrank Handbücher anderer Marken
Bonnet Neve
Bonnet Neve SKYVIEW PLUS Bedienungsanleitung
Zanussi Electrolux
Zanussi Electrolux ZERB 8441 Bedienungsanleitung
Sharp
Sharp SJ-BA31IEXW2-EU Bedienungsanleitung
CORBERO
CORBERO CC2300MCW Bedienungsanleitung
KitchenAid
KitchenAid 2205264 Bedienungsanleitung
Stengel
Stengel KU 1101 A++ Bedienungsanleitung
