KVM-TEC Media4Kconnect Merkblatt

FIRST AIDFIRST AID

6935 SET

media4Kconnect Special

redundante Version

6935L CPU/LOCAL

6935R CON/REMOTE

6936 SET

media4Kconnect Special

uncompressed Version

6936L CPU/LOCAL

6936R CON/REMOTE

CHECK YOUR EXTENDER

www.kvm-tec.com

kvm-tec

First

Aid

Check out our

Installation Channel:

4K DP 1.2 redundant and

uncompressed

media4Kconnect Special

with RS232 & sound

First

Aid

kvm-tec

4K DP 1.2 redundant and

uncompressed

media4Kconnect Special

with RS232 & sound

1. First check your delivery content Special redundant ...

2. Check your Installation Special redundant ....

LOCAL/CPU Unit

o 1 x Media4Kconnect - Special redundant local (CPU)

o 2 x 12VDC 2 A power supply

o 2 x SFP+ Multimode Modul up to 500m/1640ft

alt. Single Mode Modul up to 10km/6.2mi

o 1 x DP-DP cable 1.8m/5.9ft

o 1 x USB A-B cable 1.8m/5.9ft

o 4 x rubber feet

REMOTE/CON Unit

o 1 x Media4Kconnect - Special redundant remote (CON)

o 2 x 12VDC 2 A power supply

o 2 x SFP+ Multimode Modul up to 500m/1640ft

alt. Single Mode Modul up to 10km/6.2mi

o 4 x rubber feet

DP out

to Monitor

USB from

keyboard and mouse

power supply

for 12V 2A

1. Connect the CON/Remote and the CPU/Local Unit with the supplied 12V 2A power supply.

2. Now connect the USB cable to a USB socket of your PC and connect the other end of the USB cable to the

Local Unit. Connect the keyboard and mouse to the Remote Unit.

3. Connect the Local and the Remote Unit with a network ber cable.

4. Connect the DP cable to the DP socket of the PC to the DP socket DP/in of the Local device and connect

the screen on the remote side with the DP cable.

5. Connect the Audio cable from PC to Local Extender and connect the Audio cable from Remote Extender

to Speaker

6. Connect the Audio Cable from Microphone to Remote Extender and connect the Audio cable from Local

Extender to PC.

HAVE FUN - Your kvm-tec Extender is now in use for many years (MTBF approx. 10 years)!

Duplex multimode OM4-ber cable (LC) up to 300m/984 ft main link 1

Duplex multimode OM4-ber cable (LC) up to 300m/984 ft redundant

Audio out

to Speaker

power supply

for 12V 2A

DP in

from PC

USB to PC

Audio in

from PC

Audio out

to PC

Audio in

from Microphne

RS232

plug RS232

plug

First

Aid

kvm-tec

4K DP 1.2 redundant and

uncompressed

media4Kconnect Special

with RS232 & sound

1. First check your delivery content Special uncompressed ...

2. Check your Installation Special uncompressed....

LOCAL/CPU Unit

o 1 x Media4Kconnect - Special uncompressed local (CPU)

o 1 x 12VDC 2 A power supply

o 2 x SFP+ Multimode Modul up to 500m/1640ft

alt. Single Mode Modul up to 10km/6.2mi

o 1 x DP-DP cable 1.8m/5.9ft

o 1 x USB A-B cable 1.8m/5.9ft

o 4 x rubber feet

REMOTE/CON Unit

o 1 x Media4Kconnect - Special uncompressed remote (CON)

o 1 x 12VDC 2 A power supply

o 2 x SFP+ Multimode Modul up to 500m/1640ft

alt. Single Mode Modul up to 10km/6.2mi

o 4 x rubber feet

DP out

to Monitor

USB from

keyboard and mouse

power supply

for 12V 2A

1. Connect the CON/Remote and the CPU/Local Unit with the supplied 12V 2A power supply.

2. Now connect the USB cable to a USB socket of your PC and connect the other end of the USB cable to the

Local Unit. Connect the keyboard and mouse to the Remote Unit.

3. Connect the Local and the Remote Unit with a network ber cable.

4. Connect the DP cable to the DP socket of the PC to the DP socket DP/in of the Local device and connect

the screen on the remote side with the DP cable.

5. Connect the Audio cable from PC to Local Extender and connect the Audio cable from Remote Extender

to Speaker

6. Connect the Audio Cable from Microphone to Remote Extender and connect the Audio cable from Local

Extender to PC.

HAVE FUN - Your kvm-tec Extender is now in use for many years (MTBF approx. 10 years)!

Duplex multimode OM4-ber cable (LC) up to 300m/984 ft main link 1

Duplex multimode OM4-ber cable (LC) up to 300m/984 ft main link 2

Audio out

to Speaker

power supply

for 12V 2A

DP in

from PC

USB to PC

Audio in

from PC

Audio out

to PC

Audio in

from Microphne

RS232

plug RS232

plug

First

Aid

kvm-tec

4K DP 1.2 redundant and

uncompressed

media4Kconnect Special

with RS232 & sound

3. Check the LEDS to get more information....

Error Cause Solution

LED is not

lighting

The devices get no power Is the power supply connected? (white box)

LED is lighting

in red

No connection between

Loc and Rem

Check if the RJ45/network cable is connected well. (Clicking noise when

plugging in)

Control both, if it does not work please send an e-mail to support@kvm-

tec.com

LED is lighting

in orange

No picture on the monitor Check if the local/CPU (PC) cable is connected well.

Check if the remote/CON (monitor) cable is connected well.

If everything is connected well but no function appears, reconnect

power supply again.

If the menu is visible, press the Okey and choose the resolution of the

monitor. Then press the assigned number on your keyboard.

LED is lighting

green

Screen occurs but the

keyboard is not working

Plug out/in USB of keyboard and wait until driver is installed (after few

seconds).

Check all USB connections on both sides (Local and Remote)

If it is still not working, plug out/in DC once more

LED is lighting

green

No audio Establish audio connection:

plug stereo-jack to the audio output of the PC (green) connection with

local: IN

remote: headset OUT

Establish microphone connection:

plug stereo-jack to the microphone input of the PC (pink)

connection with local OUT

LED is lighting

green

The screen ickers, has

an incorrect display

Install current rmware from our homepage www.kvm-tec.com/

support/rmware-download

LED is blinking

green

Dierent rmware or

USB is not compatible

e-mail to support@kvm-tec.com

LED are

lighting

dierently

Dierent rmware To enter on screen menu/check rmware version:

To enter the On screen menu, press the Scroll Lock key ve times in

quick succession. The currently installed rmware version is displayed

below the menu

If rmware update does not work, please send an e-mail to support@

kvm-tec.com

First

Aid

kvm-tec

4K DP 1.2 redundant and

uncompressed

media4Kconnect Special

with RS232 & sound

4.Your Extender....

Video error

(stripes in the

picture)

USB is not

working

No Power

(No LED)

Check the

powerplug

Is the power

supply ok? Try

another Unit.

Try reprogramming

the Unit by using a

JTAG programmer

Contact kvm-tec

support

Are the USB

Devices plugged

in correctly?

Is the USB cable

on the Local side

plugged into the

PC?

Are the USB

Devices working

directly on the PC?

Check if local and

remote Unit have

the same rm-

ware

Replace the USB

cable from PC to the

Local Extender

Check if the local

or the remote

Unit is causing

the problem by

swaping rst the

local and than the

remote Unit to

another Unit

Contact kvm-tec

support

Check if all

cables are plug-

ged in correctly

Check if the PC is

sending a Image by

plugging in a

monitor on the

local out of the

local Unit

Check if the DDC is

set correctly (in menu

under point„O“)

Check if both

Units have the

correct rmware

No Video

Contact kvm-tec

support

Check if all

cables are plug-

ged in correctly

Check if the PC is

sending a Image by

plugging in a moni-

tor on the local out

of the local Unit

Check if local and re-

mote Unit have the

correct rmware

Check if the DDC

is set correctly (in

the menu under

point„o“)

Check if the net-

work switch is

setup correctly

and has enough

bandwidth

Contact kvm-tec

support

Check if other units

have the same

behaviour

We are here for you to answer

your questions about installation?

Manual download www.kvm-tec.com

kvm-tec Installationchannel on our homepage

personally +43 2253 81912

First

Aid

kvm-tec

4K DP 1.2 redundant and

uncompressed

media4Kconnect Special

with RS232 & sound

5. Check the rmware version ....

To view the rmware version

Make sure the main menu is open. The currently installed rmware version of the remote and local units are

displayed (e.g.‘4267’) and check that you have the same rmware on both units.

how to update the rmware

To perform a rmware update

Make sure that the main menu is open.

Press U to update the USB ash drive.

Update Service with kvm-tec Switching Manager Demoversion ....

This is a comfortable update management for your switching system.

You can update all extenders at the same time. The update is performed in the background and in a second step the

units are rebooting with the new rmware.

Only a short time is needed for the second step.

ATTENTION ! Only when the bar is grey, the update is nished.

Ways to update the rmware version ....

There are four ways to perform an update:

UBS stick update

First

Aid

kvm-tec

4K DP 1.2 redundant and

uncompressed

media4Kconnect Special

with RS232 & sound

o identify your extender

o rst check your delivery content

o are all needed upgrades unlocked

o all cables are connected and all units are switched on

o check the LED status

o Video - check if the DDC is set correctly (in menu under point„O“ )

o USB - are all cables connected

o in case of issues check the rmware version (download for the newest rmware kvm-tec.com/support )

if everything is working ne - perfect

Tipps from our engineers for engineers

• reduce the setting of your system and set up only one local and one remote at the same place

• connect the monitor directly to the PC - does the monitor display an image ? (follow the mentioned steps

from above)

• LED status is red or blinking - this can be a cable problem - try to get a short patchcable and to connect

the units and be sure that it´s not a cross - over cable

• USB problems with mouse and keyboard - please try a dierent type of mouse and keyboard

Further expert tipps for issues

• Adapter - our units are transmitting DVI signals. If you are using adapters try a PC with DVI signal

• PC - please try another machine

• If you have more sets please make a cross check and change of the units

Further steps

Please, ll out the support form

and contact our support team +43 2253 81912 - 30

6. Checklist ....

First

Aid

kvm-tec

4K DP 1.2 redundant and

uncompressed

media4Kconnect Special

with RS232 & sound

If the shoe pinches, then we are there for you!

Support Form

Support - request

If the shoe pinches, then we are there for you!

Contact Information

Company

Contact person

phone number

customer from

device type

Fiber copper

single

Switching Manager

Firmware & Upgrade

Firmware Nr.:

Memory Option

RS232

VGA

Sound

Switching

Other connected devices

(Switches, HUBs, Touch-

screens, Webcams,.....)

To support your case as quickly as possible

and to be able to process and track your data,

we ask you to provide us with

the following information.

After we have received your mail, a sup-

port ticket is automatically created in

our ticket system, where all informati-

on about your support case is stored.

and are traceable at any time.

This way the support team has all the infor-

mation about your system in a direct con-

versation and your advantage is that the

questions can be answered in a targeted and

faster way.

Problem description

Almost done! If you want to be even faster on the phone, the following data would be helpful:

No power

No Link

VGA problem

No connection

DOA (dead on

arrival)

Stripy screen

No Video

No USB

Mouse/ Key-

board doesn´t

work

LED Status local/CPU

LED Status remote/CON

red orange green

glowing ashing

red orange green

glowing ashing

Please send the form to [email protected].

Thank you very much! As soon as we have received your mail, it will be tracked in our system as a support case and we will

contact you immediately!

Resolution:

Fix

kvm-tec electronic gmbh

Gewerbepark Mitterfeld 1A, 2523 Tattendorf, Austria

+43 2253 81912-30 - support@kvm-tec.com

copper

dual

First

Aid

kvm-tec

4K DP 1.2 redundant and

uncompressed

media4Kconnect Special

with RS232 & sound

RMA Form

If the shoe pinches, then we are there for you!

RMA - request

If the shoe pinches, then we are there for you!

Contact Information

Company

Contact person

phone number

customer from

MVX1 Fiber copper

MX48 Fiber copper

MX2000 Fiber copper

UVX Fiber copper

Switching Manager

copper SVX2

MVX2 Fiber copper

copper

Firmware & Upgrade

Firmware Nr.:

Memory Option

RS232

VGA

Sound

Switching

Other connected devices

(Switches, HUBs, Touch-

screens, Webcams,.....)

Problem description

Almost done! If you want to be even faster on the phone, the following data would be helpful:

No power

No Link

VGA problem

No connection

DOA (dead on

arrival)

Stripy screen

No Video

No USB

Mouse/ Key-

board doesn´t

work

LED Status local/CPU

LED Status remote/CON

red orange green

glowing ashing

red orange green

glowing ashing

Please send your RMA to Heidi Brosig email heidi@kvm-tec.com

Resolution:

Fix

kvm-tec electronic gmbh

Gewerbepark Mitterfeld 1A, 2523 Tattendorf, Austria

+43 2253 81912-30 - support@kvm-tec.com

copper

RMA Number

ber

copper

Product

single dual

SWTICHING MANAGER

Andere Handbücher für media4Kconnect

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere KVM-TEC Extender Handbücher

KVM-TEC

KVM-TEC Smartline Dual SVX2 Series Bedienungsanleitung

KVM-TEC

KVM-TEC media4Kconnect 6930 DP1.2 Bedienungsanleitung

KVM-TEC

KVM-TEC ScalableLine KT-6990L Bedienungsanleitung

KVM-TEC

KVM-TEC MAXflex Bedienungsanleitung

KVM-TEC

KVM-TEC SmartLINE SVX Bedienerhandbuch

KVM-TEC

KVM-TEC FLEXLINE KT-6011L Original Betriebsanleitung

KVM-TEC

KVM-TEC Profiline PROVX1 Bedienungsanleitung

KVM-TEC

KVM-TEC media4Kconnect Bedienungsanleitung

KVM-TEC

KVM-TEC masterEASY Bedienerhandbuch

KVM-TEC

KVM-TEC SMARTflex Bedienungsanleitung

KVM-TEC

KVM-TEC Smartline SVX1 Bedienungsanleitung

KVM-TEC

KVM-TEC Profiline PROVX2 Bedienungsanleitung

KVM-TEC

KVM-TEC Smartline Dual SVX2 Series Bedienerhandbuch

KVM-TEC

KVM-TEC MATRIXLINE Original Betriebsanleitung

KVM-TEC

KVM-TEC USBflex Original Betriebsanleitung

KVM-TEC

KVM-TEC USBflex Original Betriebsanleitung

KVM-TEC

KVM-TEC Smartline Dual SVX2 Series Bedienungsanleitung

KVM-TEC

KVM-TEC USBflex Original Betriebsanleitung

KVM-TEC

KVM-TEC SmartLINE SVX Bedienungsanleitung

KVM-TEC

KVM-TEC Masterline MVX Bedienungsanleitung

KVM-TEC

KVM-TEC INDUSTRYFLEXline Bedienungsanleitung

KVM-TEC

KVM-TEC media4Kconnect DP 1.2 Original Betriebsanleitung

KVM-TEC

KVM-TEC masterEASY Bedienungsanleitung

KVM-TEC

KVM-TEC USBflex Bedienungsanleitung

Beliebte Extender Handbücher anderer Marken

SY HDBT-60T Bedienungsanleitung

Appsys ProAudio

Appsys ProAudio ADX-16 Bedienungsanleitung

Atlona

Atlona RS232 Bedienungsanleitung

IDK

IDK OPF-TH1000-A Bedienungsanleitung

Enable-IT

Enable-IT 824WP Bedienungsanleitung

Worx

Worx Landroid RadioLink WA0864 Technisches Datenblatt

TP-Link

TP-Link TL-WA730RE Bedienungsanleitung

Camplex

Camplex CMX-HDMI-SFPL Bedienungsanleitung

SC&T

SC&T HE03-4K Bedienungsanleitung

Marmitek

Marmitek MegaView70 Bedienungsanleitung

Samsung

Samsung SCS-26UC4 Bedienungsanleitung

Foxun

Foxun SX-GES24 Bedienungsanleitung

MuxLab

MuxLab 500771 Bedienungsanleitung

foxunhd

foxunhd SX-AEX01 Bedienungsanleitung

TERK Technologies

TERK Technologies LFIRX2 Bedienungsanleitung

Devolo

Devolo Audio Extender Handbuch

Edimax

Edimax EW-7438RPn V2 Bedienungsanleitung

Shinybow USA

Shinybow USA SB-6335T5 Bedienungsanleitung

KVM-TEC media4Kconnect Merkblatt

Beliebte Extender Handbücher anderer Marken
