KwickScreen Duo Bedienungsanleitung
DUO USER MANUAL
The most exible space management solutions
Portable, retractable, printable privacy screens; creating
private and dignied spaces adaptable to multiple uses.
2
3 /
4 /
5 /
13 /
15 /
If you have any questions please contact us at:
www.kwickscreen.com / info@kwickscreen.com
020 845 25975
GENERAL INSTRUCTIONS
Please read all instructions in this user guide prior to installation and operation of your
KwickScreen.
For personal and operational safety use only parts approved by KwickScreen. Before
installation ensure all parts are present, complete and without defects. If you believe
parts to be missing please contact us.
Packaging material should be disposed of in accordance with local rules and
regulations.
Push and pull the front handles gently during operation. If they need to be forced
please contact us. If there is resistance or you hear a crumpling sound then stop, pull
out and push in again gently.
KwickScreens are designed for use on smooth, horizontal surfaces. Extra care should be
taken when using on other surfaces. Make sure the front handles are vertical and that
its wheels are all in contact with the oor.
When moving the KwickScreen Duo check all four brakes have been released. The
unit should then be moved using the main body base handles. Do not run when using
a KwickScreen. If leaving the KwickScreen on an incline please ensure all brakes are
engaged.
CONTENTS
Welcome
View & Dimensions
Unit Assembly Guide
Replacing or Changing Inner Panels
Cleaning
3
Dear valued customer,
Thank you for choosing to purchase from KwickScreen.
I hope that your new KwickScreen will help you make better use of your spaces and if
you have chosen a printed screen, that you enjoy the benets which the images can
bring to your environment.
I am passionate about using technology to improve environments. As a designer and
engineer I invented the KwickScreen to help solve space issues. For a room to be used
efciently and appropriately it needs to be exible both spatially and visually. Every
multi-use room, from a hospital ward, to a gym, a private meeting room or an airport has
problems and limitations that can be solved by space saving portable screening systems.
Over the last ten years the product has developed signicantly, winning a number
of design and innovation awards. We now have an international supply chain with
distribution in Europe, North Asia, America and the Middle East.
Our customers and those who use and interact with our screens remain our top priority
and we are always striving to both improve the product and our service to you. This is our
passion and that is why we assemble and quality check every product ourselves locally in
England.
We hope that you have received the product in a perfect condition, but if for any reason
you are unhappy or have a query please let us know and we will do our best to help.
Each unit and screen has a unique code making it possible for us to trace all relevant
information about the product. (The unit number Uxxx is on the back of the unit on the
silver sticker and the screen number Sxxx is on the inside of the screen.)
KwickScreens are used in all manner of places, so if you can we would love to receive
pictures and feedback from you about using your KwickScreen whether it’s a query,
comment or suggestion. Please nd us on social media @KwickScreen or alternatively
get in touch via our website www.kwickscreen.com.
I wish you many years of use from your KwickScreen and look forward to hearing from
you.
Michael Korn
Inventor and Co-Founder of KwickScreen
4
VIEW & DIMENSIONS
Fully Assembled Weight: 24 kg
Bases Weight: 5 kg
Unit Weight: 19 kg
140mm/5.5in
219mm/8.6in
1902mm/74.9in
100mm/3.9in
6360mm/250in
590mm/24in
360mm/14.2in
3110mm/122in
5
ASSEMBLY GUIDE
x4
Braked Castors for Main
Body
Unbraked Castors for
Handles
Castor Pins
13mm Spanner
Main Body Base Front Handle Bases
x1
x1
x4
x2
x4
x8
x1
x2
Please read the
following instructions.
This is a two person job.
Please ensure all screws
are tight after assembly.
If you have any
questions please contact
us at:
www.kwickscreen.com
call us on:
020 845 25975
or email us:
info@kwickscreen.com
3mm Allen Key
x1x1
M6 BTN Screws M5 Cap Head Screws
4mm Allen Key
Main Body with Two Inner Screens
You will need to supply:
Included:
6
x1
Push wheels with brakes onto main body base
Insert castor pins and
tighten very well
Step 1
Step 2
x4
x1
x4
You will need:
MAIN BASE ASSEMBLY
7
Insert castor pins and tighten very well
x2
x4
x1
Tighten
very well
Step 1
HANDLE BASE ASSEMBLY
You will need:
x4
8
Push the wheels without
brakes onto handle base, and
repeat for other base.
Step 2
When repeated you will
have two handles bases
matching this
9
Step 1
x2
M5 Cap Head Screw
3mm Allen Key
x1
Tighten screws
very well
x1
x1
Make sure the at side is against the body
ASSEMBLING BASES TO BODY
For this step you will need:
10
Step 6
x4
M6 BTN Screw
4mm Allen Key
x1
There are two screws per
base.
Tighten screws very well
x2
For this step you will need:
