KYY K3 Bedienungsanleitung
15.6"Full HD
Portable Monitor
K3 User Guide
Note: Any technical problem pls contact support team
Service
12-MONTH WARRANTY
plus online responsive customer service
provides
Please Contact:
Not Satisfied?
Monitor Damaged?
Can’t Connect?
We apologize for any inconveniences,
if the monitor you received damaged or can’t connect
the monitor successfully with your devices,
Package List .......................................................................1
Introduction ..................................................................... 2
Smart Cover ..................................................................... 4
Connect with Devices ................................................... 6
Mode Settings ............................................................... 11
Supported Devices and Models .............................. 17
Specications ................................................................. 19
Notices .............................................................................. 20
Troubleshooting ........................................................... 21
Content
1
15.6"Portable Monitor Magnetic Smart Cover
USB-C to
USB-C Cable
Mini HDMI to
HDMI Cable
USB-C to USB-A
Cable (Power Supply)
5V/2.4A Power
Adapter
Package List
2
1
2
3
4
Dual Speakers
Listen to music, movies, games, and multimedia les.
Power Button/Back Button
Long press for 3s to turn the screen on/o. Short press to back to the previous page.
Trackwheel
• Press the trackwheel to turn to the OSD menu. Scroll the trackwheel to control
the cursor on the menu, and press to conrm;
• In the main interface, scroll up to open the adjust shortcut menu.
3.5mm Audio Outport
Headsets, speakers or digital audio equipment extension interface.
Introduction
3
5
6
7
Type-C Power Supply Port
External power supply 5~20V voltage input.
(Only support power supply)
Type-C Full Function Port
• Supply power;
• Transmit the audio, video signal.
Mini HDMI Port
Audio and video signal transmission.
Introduction
4
Smart Cover
Place the screen on
the backside of the
smart cover.
Cover the screen
side of the smart
cover on the screen
for protection.
Back Side Screen Side
5
Use the smart cover to make the monitor stands
at a proper viewing angle.
Fold the screen side of the
smart cover back to support
the screen's bottom.
Smart Cover
6
Connect with Devices
2
Connect without External Power Supply
Only works with full-function USB-C port.
Please plug in the [usb-c to usb-c cable] to the second
USB-C full-function port and make sure the USB-C port
of your device is full-function.
Note: The monitor does not have an internal battery.
Before using, please make sure the connected devices
or power adapter can supply at least 5V/2.4A power.
1
Connect with External Power Supply
Connect your monitor to the power supply
with the [usb-c to usb-a cable] and the Adapter provided,
plug in the [usb-c to usb-c cable] OR [mini HDMI to
HDMI cable] for video output.
USB-C Laptop
USB-C to USB-C
7
Note: Please check if the USB-C port of your laptop
is compatible with audio and video signal transmission.
If not, it would need a corresponding adapter to connect.
External Power Supply Needed Conditions
1. Brightness or volume is greater than 80%.
2. The type-c cable does not have a power supply function.
Connect with Devices
