La Crosse WT-8100U Bedienungsanleitung

The wall clock with timer is ideal for your kitchen, and fitness room. Displays

time, weekday, indoor temperature and a timer all on one easy to read

display.

Model: WT-8100U | Quick Setup Guide

BUTTONS

SETUP INSTRUCTIONS STEP BY STEP

Step 1:

•Insert one AA Alkaline battery into the timer clock. Observe polarity

markings.

•The timer clock will display calendar, indoor temperature and time (6:00).

•Do Not Mix Old and New Batteries

•Do Not Mix Alkaline, Standard, Lithium or Rechargeable Batteries

Step 2:

•Set Time

Note: If the timer clock does not display the indoor temperature after 30

seconds remove the batteries, and start the setup process again.

Timer Wall Clock

Timer Mode: Set

timer minutes.

Time/Date Mode:

moves through time

set mode items.

Press to switch to

timer mode.

Alarm sounds:

Press to snooze

alarm for 10

seconds

Time/Date Mode:

Changes values.

Alarm Mode:

Changes values.

Hold to enter

Alarm Mode.

Hold to switch

to Date Mode.

Timer mode:

Press to recall

saved timers.

Timer Mode: Set

timer seconds.

Timer Mode: Press

to start and to stop

the timer.

SET TIME

The SET button advances throught the menu and the + button changes a

value. Hold SET button for 5 seconds, to enter the time set mode.

1. 12/24-HOUR: 12 will flash. Press the + button to switch to 24-hour time.

Note:The date will display as Month/Day in 12-hour mode and Day/Month

in 24-hour mode. Press the SET button.

2. HOUR: The Hour will flash. Press the + button to adjust the Hours. Be sure

to AM or PM is showing as appropriate. Press the SET button.

3. MINUTES: The Minutes will flash. Press the + button to adjust the Minutes.

Hold the + button to change the Minutes quickly. Press the SET button.

4. YEAR: The Year will flash. Press the + button to adjust the Year. Press the

SET button.

5. MONTH: The Month will flash. Press the + button to adjust the Month.

Press the SET button.

6. DATE: The Date will flash. Press the + button to adjust the Date. Press the

SET button.

Note: Day of the Week will set automatically.

7. FAHRENHEIT/CELSIUS: °F will flash. Press the + button to switch to °C.

Press the SET button again.

8. LANGUAGE: US (English) will flash. Press the + button to change to

French (F), Spanish (E), German (d) or back to English (US). Press the

SET button to exit.

COUNTDOWN TIMER

The timer counts up or down from pre-selected times between one second to

99 minutes.An alarm sounds when countdown timer reaches 0. The timer

automatically starts counting up at zero seconds. Stores up to 8 countdown

time records

SET TIMER

Press the TIMER/SNZ button to enter the timer set mode. You will see this in

the lower left-hand corner replacing the date.

1. TIMER MINUTES: Press the TIMER/MIN button to adjust the minutes.

Hold the TIMER/MIN button to change the minutes quickly. Minutes can

be set from 0-99.

2. TIMER SECONDS: Press the TIMER/SEC button to adjust the seconds.

Hold the TIMER/SEC button to change the seconds quickly. Seconds can

be set from 0-59.

3. START OR STOP TIMER: Press the START/STOP button to begin the

timer countdown to 0:00. Press the START/STOP button to stop the timer.

4. TIMER ALARM: When the countdown timer reaches 0:00, the alarm will

sound one beep every 0.5 seconds for 30 seconds.

5. EXIT TIMER MODE: Hold the DATE/MEMO button for 2 seconds to exit

timer mode. The date will be displayed.

CREATE TIMER MEMORY

The Timer can be manually set (see set timer) or you can create up to eight

different timers in memory, which can be recalled and reused. From a normal

display, press the DATE/MEMO button to enter timer mode.

Count Up Timer:

1. Press the START/STOP button to begin counting up from 0:00.

2. When the timer value is reached, press the START/STOP button to stop

the count up.

3. Start the count down, then press the START/STOP button again to stop

the count down before it reaches 0:00 and the timer sounds.

4. This will commit the count up timer to memory.

Countdown Timer:

1. Set a countdown timer (see set timer) or select one from memory.

2. Press the START/STOP button to begin counting down.

3. Press the START/STOP button to stop the count down before it reaches

0:00 and the timer sounds.

4. This will commit the countdown timer to memory.

RECALL TIMER MEMORY

1. Press DATE/MEMO button to recall timer memory.

2. Timer will search from the smallest timer memory to find timer larger than

existing timer value and recall it.

Countdown Timer

Example: Set timer to 6:30, then press TIMER/SNZ button to recall the

memory. It will search the memory recall order 6:00, 7:00 & 23:00 and recall

7:00 as the next largest memory.

3. Press the START/STOP button to start the selected timer.

TIMER MEMORY OVERWRITE

•A time memory is created each time the countdown timer is started then

stopped before reaching 0:00 and sounds the alarm.

•When timer memory is full, it will delete the oldest timer and add the new

timer, in first-in-first-out order.

Clear Timer:

•In timer mode, with the timer stopped, press and hold the TIMER/MIN

button and TIMER/SEC button together for 5 seconds to clear the oldest

timer to 0:00.

Exit Timer Mode:

•Hold the TIMER/SNZ button for 2 seconds to exit timer mode.

•The date will be displayed.

ALARM SET

Press and hold the ALARM button for 5 seconds to enter the alarm set mode.

1. HOUR: The Hour will flash. Press the +button to adjust the Hours. Be

sure the AM or PM is showing as appropriate. Press the ALARM button.

2. MINUTES: The Minutes will flash. Press the +button to adjust the

Minutes. Hold the + button to change the Minutes quickly. Press the

DATE/MEMO button to exit.

The Alarm frequency is 2KHz for 90 seconds: The alarm sound pattern is one

beep every 2 seconds for 30 seconds, then one beep every 1 second for

30seconds and then one beep every 2 seconds for 30 seconds and stop.

ACTIVATE/DEACTIVATE TIME ALARM

Press the ALARM button to activate or deactivate the alarm.

When the alarm is active the clock displays the alarm icon

above the seconds. When deactivated, the alarm icon does

not display.

SNOOZE

•When the alarm sounds, press the TIMER/SNZ button to trigger snooze

alarm for 10 minutes.

•The alarm icon will flash when the snooze feature is active.

•Press and release the + button to deactivate the snooze function.

DISPLAY OPTIONS

POSITIONING TIMER CLOCK

Foldable Table Stands

The foldable table stands legs are located on the back below the

battery compartment. Unfold the stands out and place the timer

clock in an appropriate location.

Wall Mount

1. Install three mounting screws (not included) into a wall—

leaving approximately 3/16 of an inch (5mm) extended from

the wall.

2. Place the clock onto the screws, using the three hanging

holes on the backside.

3. Gently pull the clock down to lock the screws into place.

Note: Always ensure that the clock locks onto the screws before

releasing.

BATTERY REPLACEMENT

When the low battery icon appears above the seconds,

replace the Alkaline battery in the timer clock.

CHANGE DISPLAY:

From Timer mode, stop the tim

er.

Then hold the DATE/MEMO button to

change from Timer to Date display.

Note:

Date will show M/D when the clock

is in 12

-hour mode, and will show as D/M

in 24

-hour mode.

Countdown Timer or

Month/Date Display

Help us to keep our environment clean. Please do not dispose of old

electronic devices and empty batteries in household waste. To

protect the environment, take them to your retail store or to

appropriate collection sites according to national or local regulations.

CARE AND MAINTENANCE

•Keep the instrument in a dry place.

•Do not expose the clock to extreme temperatures, vibration or shock.

•Clean it with a soft damp cloth. Do not use solvents or scouring agents.

•If the clock does not work properly, change the battery.

•The product is not a toy. Keep it out of reach of children.

•The product is not to be used for medical purpose or for public

information. It is for home use only.

•The specifications of this product may change without prior notice.

•Improper use or unauthorized opening of housing will void the warranty.

•Do Not Mix Old and New Batteries

•Do Not Mix Alkaline, Standard, Lithium or Rechargeable Batteries

SPECIFICATIONS

Indoor Temperature Range: 14.4°F to 99.9°F (-9.9°C to +59.9°C).

Reads OFL if outside this range.

Resolution: 0.2°F (0.1 °C)

Measuring Period: Every 60 seconds.

Battery: Requires 1 x LR6 (AA) alkaline battery

(not included).

Clock Size: 9.23 L x 7.61 H x 1.04 inches W

(234.4 L x 193.4 H x 26.3mm W)

Time Display: Numbers are 1.77 inches H (4.5 cm)

WARRANTY INFORMATION

La Crosse Technology, Ltd provides a 1-year limited warranty on this product

against manufacturing defects in materials and workmanship.

This limited warranty begins on the original date of purchase, is valid only on

products purchased and used in North America and only to the original

purchaser of this product. To receive warranty service, the purchaser must

contact La Crosse Technology, Ltd for problem determination and service

procedures. Warranty service can only be performed by a La Crosse

Technology, Ltd authorized service center. The original dated bill of sale must

be presented upon request as proof of purchase to La Crosse Technology, Ltd

or La Crosse Technology, Ltd’s authorized service center.

La Crosse Technology, Ltd will repair or replace this product, at our option and

at no charge as stipulated herein, with new or reconditioned parts or products

if found to be defective during the limited warranty period specified above. All

replaced parts and products become the property of La Crosse Technology,

Ltd and must be returned to La Crosse Technology, Ltd. Replacement parts

and products assume the remaining original warranty, or ninety (90) days,

whichever is longer. La Crosse Technology, Ltd will pay all expenses for labor

and materials for all repairs covered by this warranty. If necessary repairs are

not covered by this warranty, or if a product is examined which is not in need

or repair, you will be charged for the repairs or examination. The owner must

pay any shipping charges incurred in getting the La Crosse Technology, Ltd

product to a La Crosse Technology, Ltd authorized service center. La Crosse

Technology, Ltd will pay ground return shipping charges to the owner of the

product to a USA address only.

The La Crosse Technology, Ltd warranty covers all defects in material and

workmanship with the following specified exceptions: (1) damage caused by

accident, unreasonable use or neglect (including the lack of reasonable and

necessary maintenance); (2) damage occurring during shipment (claims must

be presented to the carrier); (3) damage to, or deterioration of, any accessory

or decorative surface; (4) damage resulting from failure to follow instructions

contained in the owner’s manual; (5) damage resulting from the performance

of repairs or alterations by someone other than an authorized La Crosse

Technology, Ltd authorized service center; (6) units used for other than home

use (7) applications and uses that this product was not intended or (8) the

products inability to receive a signal due to any source of interference.. This

warranty covers only actual defects within the product itself, and does not

cover the cost of installation or removal from a fixed installation, normal set-up

or adjustments, claims based on misrepresentation by the seller or

performance variations resulting from installation-related circumstances.

LA CROSSE TECHNOLOGY, LTD WILL NOT ASSUME LIABILITY FOR

INCIDENTAL, CONSEQUENTIAL, PUNITIVE, OR OTHER SIMILAR

DAMAGES ASSOCIATED WITH THE OPERATION OR MALFUNCTION OF

THIS PRODUCT. THIS PRODUCT IS NOT TO BE USED FOR MEDICAL

PURPOSES OR FOR PUBLIC INFORMATION. THIS PRODUCT IS NOT A

TOY. KEEP OUT OF CHILDREN’S REACH.

This warranty gives you specific legal rights. You may also have other rights

specific to the State. Some States do not allow the exclusion of consequential

or incidental damages therefore the above exclusion of limitation may not

apply to you.

For warranty work, technical support, or information contact:

La Crosse Technology, Ltd

2817 Losey Blvd. S.

La Crosse, WI 54601

Contact Support: 1-608-782-1610

Product Registration:

www.lacrossetechnology.com/support/register

Information is available at:

www.lacrossetechnology.com/8100bk

in excerpts, or duplicated or processed using electronic, mechanical or

chemical procedures without written permission of the publisher.

This handbook may contain mistakes and printing errors. The information in

this handbook is regularly checked and corrections made in the next issue.

We accept no liability for technical mistakes or printing errors, or their

consequences.

All trademarks and patents are acknowledged.

Printed in China

Inhaltsverzeichnis

Andere La Crosse Timer Handbücher

La Crosse

La Crosse 919-186-60WH Bedienungsanleitung

Beliebte Timer Handbücher anderer Marken

Intermatic

Intermatic P1131 Bedienungsanleitung

Learning Resources

Learning Resources Time Tracker mini Bedienungsanleitung

CEBEK

CEBEK I-215 Bedienungsanleitung

Somogyi

Somogyi home TS MD 5 Bedienungsanleitung

Profile

Profile 010200280 Bedienungsanleitung

Gizmo

Gizmo T4 Bedienungsanleitung

Tekmar

Tekmar Timer 031 Bedienungsanleitung

Daikin

Daikin DST301B61 Bedienungsanleitung

sisel

sisel ENDA ETM2432 Bedienungsanleitung

B&Q

B&Q TE103 Bedienungs- und Wartungshandbuch

Hozelock

Hozelock AC Plus 2700 Bedienungsanleitung

GIC

GIC Eliro V7DDSS3Eliro V7DFTS3 Bedienungsanleitung

Tork

Tork TU40 Bedienungsanleitung

Emos

Emos EMT400F Bedienungsanleitung

FarmTek

FarmTek Polaris Bedienungsanleitung

Maximum

Maximum CRONUS Bedienungsanleitung

Uberhaus

Uberhaus TD133B Bedienungsanleitung

Clas Ohlson

Clas Ohlson 31-3766 Bedienungsanleitung
