Laars FT Series Bedienungsanleitung

User's Manual Document 1506

WARNING

If the information in this manual is not

result causing property damage, personal

injury or loss of life.

Do not store or use gasoline or other

this or any other appliance.

WHAT TO DO IF YOU SMELL GAS

• Do not try to light any appliance.

• Do not touch any electrical switch; do not

use any phone in your building.

• Immediately call your gas supplier from a

nearby phone. Follow the gas supplier's

instructions.

• If you cannot reach your gas supplier, call

Installation and service must be performed

supplier.

FOR YOUR SAFETY: This product must be installed and serviced by a professional service technician,

, property damage, or

death. Improper installation and/or operation will void the warranty.

AVERTISSEMENT

Assurez-vous de bien suivres les instructions

données dans cette notice pour réduire au

minimum le risque d’incendie ou d’explosion

ou pour éviter tout dommage matériel, toute

blessure ou la mort.

Ne pas entreposer ni utiliser d’essence ou ni

le à proximité de cet appareil ou de tout autre

appareil.

QUE FAIRE SI VOUS SENTEZ UNE ODEUR DE

GAZ:

•Ne pas tenter d’allumer d’appareils.

• Ne touchez à aucun interrupteur. Ne pas vous servir

des téléphones dans lebâtiment où vous vous

trovez.

• Appelez immédiatement votre fournisseur de

gaz depuisun voisin. Suivez les instructions

du fournisseur.

•Si vousnepouvez rejoindre le fournisseur de

gaz, appelez le sservice des incendies.

L’installation et l’entretien doivent être assurés par

ou par le fournisseur degaz.

User's Manual for

Floor Standing, Modulating

Gas, Condensing, Combination Boiler

Model FTCF199N

199,000 BTU/h

•

•Propane Gas (LP) - Field-Convertible

Page 2

1. Familiarizing yourself to

CONTENTS Pgs -

1. Familiarizing yourself to the FT .............................2

2. Caring For Your FT ................................................2

3. Start Up and Shut Down. ......................................4

4. Control Display and Operation .........................4-10

The FT is a floor standing, condensing and

fully modulating, residential boiler and

water heater.

This Users Manual will guide you into the basics

of operating your FT floorstanding boiler.

Please reference the Installation and Operation

Manual for complete details (Doc 1505).

2. Caring For Your FT

Your FT will require very little maintenance.

However, as with any ne appliance, there are certain

steps that should be taken to ensure continuing

optimum performance.

2.1 General Care

Keep the area around the FT clean and free from

combustible materials, gasoline and other ammable

liquids and vapors.

The FT must be completely isolated and protected

from any source of corrosive chemical fumes such as

trichlorethylene, perchlorethylene, chlorine, etc.

Keep openings on the boiler free for proper

ventilation of interior components.

Do not obstruct or block a free ow of air to the

boiler to ensure proper ventilation.

If desired, clean the jacket surfaces with a

damp cloth and mild detergent. Do not use ammable

cleaning materials.

If sidewall vented, keep the vent terminal clear

of obstructions — do not allow snow to cover the vent

terminal. Clean the intake screen often, and then

develop an appropriate maintenance schedule.

2.2 Annual Inspection of Flue and Vents

Visually inspect the vent pipe once a year. Should

any deterioration exist, have the affected parts replaced

by a qualied service person.

2.3 In the Event of a Power Failure

The FT can not be operated during an electrical

power outage. If there is an extended power outage with

danger from freezing, then the FT (and all other water

systems) should be drained completely. When draining

this combi boiler, turn off main electrical disconnect

switch. When placing back in service, refer to Section 3

of this Manual for instruction. All draining and lling must

only be done by a qualied service person.

2.4 Full Service Every Year

In addition to the annual visual inspections, a

qualied service agency should conduct a detailed

inspection of all ue product carrying areas of the boiler

and its venting system.

THE FT

Insert sketch from

Slide 12 here

Page 3

# Name of Component

1Pressure Relief Valve

2Air Vent (air eliminator)

3Boiler Return Connection

4DHW Recirculation Connection

5 Boiler Supply Connection

6Vent Pipe Collar

7 Boiler Pressure Gauge

8Cold Water Flow Sensor

9Air Intake Collar

10 DHW Inlet Connection

11 DHW Outlet Connection

12 DHW Filter and Flow Restrictor

13 Gas Inlet Adapter

14 Air Gas Mixing Pipe

15 Gas Valve

16 BLDC Fan (Blower)

17 Low Water Cut O󰀨

18 Burner High Limit Switch

19 Flame Detecting Sensor

20 Manual Power Switch (ON / OFF)

21 Heat Exchanger

22 Main PCB

23 Boiler Pump

24 Blocked Condensate Switch

25 Condensate Trap

26 Condensate neutralizer and Drain pump

(optional equipment)

27 Drain Valve

28 Low Loss Header and DHW Coil

29 Terminal Block

30 Overheat Temperature Sensor

31 Sight Glass

32 Igniter

33 Exhaust Pipe

34 Control Panel and Display

35 Air Pressure Sensor

The FT Series Floor Standing, Combination Boiler

Names of Components

The FT Series Floor Standing, Combination Boiler Page 7

# Name of Component

1 Pressure Relief Valve

2 Air Vent (air eliminator)

3 ‘CH’ Return Connection

4 DHW Recirculation Connection

5 ‘CH’ Supply Connection

6 Vent Pipe Collar

7 CH Pressure Gauge

8 Flow Sensor

9 Air Intake Collar

10 DHW Inlet Connection

11 DHW Outlet Connection

12 DHW Filter and Flow Restrictor

13 Gas Inlet Adapter

14 Air Gas Mixing Pipe

15 Gas Valve

16 BLDC Fan (Blower)

17 Low Water Cut O󰀨

18 Burner High Limit Switch

19 Flame Detecting Sensor

20 Manual Power Switch (ON / OFF)

21 Heat Exchanger

22 Main PCB

23 Boiler Pump

24 Blocked Condensate Switch

25 Condensate Trap

26 Condensate Drain Pump

27 Drain Valve

28 DHW Water Tank

29 Terminal Block

30 Overheat Temperature Sensor

31 Sight Glass

32 Spark Plug

33 Exhust Duct

34 Control Panel and Display

35 Air Pressure Sensor

2.4 Names of Components

5 4

11 10 9

678

Page 4

3. Shut Down and Restart

3.1 To Start the FT

If drained, please refer to the Install and Operating

Manual to ensure that the complete ‘Setup’

procedure has been followed before starting this

boiler. A complete ‘Setup’ must be performed by a

qualied service person.

3.2 Shutting Down the FT

1. Turn off the main electrical disconnect switch.

2. Close all manual gas valves.

3. If freezing is anticipated, drain the FT and be

sure to also protect the building piping from

freezing. All water must be removed from heat

exchanger and condensate trap or else damage

from freezing may occur. Please refer to the

Install and Operating Manual. This step to be

performed by a qualied service person.

4. The Control Display and Operation

Page 50

SECTION 5. Control Display and Operation 5.1 Control Dial and Buttons

• Temperature Specifi cations

Operating ambient Temperature Range : 14F - 140°F (-10 to 60°C).

• Operating Relative Humidity up to: 90% at 104°F (40°C).

• Shipping & Storage Temperature Range of : -4F - 176°F (-20 to 80°C).

Buttons Functionality

PRESS (Tap) PRESS and HOLD (5 seconds)

A Display Power Turns Control Display ON/OFF

B Modes Tap to return to menu (If Display Power was On ) Status Display Mode

(If Display Power was Off ) Installer Mode

CHot Water DHW Set-Point LOW Range

95 - 120°F (35 - 49°C) DHW Set-Point HIGH Range

121 - 140°F (49.5 - 60°C)

DCentral Heat CH set-point mode (boiler only) Toggle (°C / °F)

EScroll / Select Turn to scroll, tap to select

(clockwise or counterclockwise)

The Control Display has a Control Dial (E), 4 buttons (A, B, C, D), and a Liquid

Crystal Display (with 72 back-lit segments). This section of this manual gives

instruction on how to navigate into the many functions of the FT and to change

temperature set points, set system variables and controller parameters.

Status Light

(constant green

when operating

normally)

The Control Display

User’s Manual - The FT Series Floor Standing, Combination Boiler Page 5

4. The Control Display and Operation (continued)

The FT Series Floor Standing, Combination Boiler Page 51

SECTION 5. Control Display and Operation 5.2 LCD Overview

CH mode Central Heat mode icon can be adjusted

Anti-freeze mode Anti-freeze mode icon

Storage Heating mode Stored Water Being Heated, can be adjusted

Lock mode Buttons-locked mode icon

Communication Communication icon

Summer mode Only DHW Mode, can be adjusted (warm weather shutdown)

Status and Installer mode The Status Mode or the Installer Mode is Active (all parameters)

Flame signal Flame Signal icon

Pump icon Water pump operation (CH or DHW) icon

Numeric Display Number and character display, to display all parameters

DHW mode Combination boiler Set Point, can be adjusted

Outside temp or 0-10 V mode Operating by outside temperature or 0-10V

Numeric Display

Domestic Hot Water Mode

Anti-Freeze

Mode Storage

Heating Lock Communicating

Status and

Installer

Modes

Flame

Signal

Pump

Outside

Temp Mode

or 0-10V

Summer Mode

(warm

weather

shutdown)

Central

Heat

WARNING

Do not use this appliance if any part has been under

water. Immediately call a quali ed service technician

to inspect the appliance and to replace any part of

the control system and any gas control that may have

been under water.

The LCD will illuminate when a user action is detected (a button is pressed) and will turn

back off after 20 seconds.

* NOTE: The display will not allow changes when the lock mode is activated.

To exit the Lock mode, press the button.

The FT Series Floor Standing, Combination Boiler Page 6

Operating Mode

After the Power is turned on, and/or the Control Display is turned on , the Control Display

will go through a ‘Start Up’ checklist and briefly show a sequence of diagnostic codes

before entering into the ‘Operating Mode. It will then display the following information.

Indicate Example

Current Operating Temperature 110°F

Temperature sign Celsius or Fahrenheit letter °C or °F

Display and Controller are communicating

If pump is operating

Outdoor sensor or 0-10V

55page

56page

B C

A D

Note: The house symbol will blink when the outdoor sensor

is not connected to the boiler.

Page 7

Status Display Mode

Digital

Display Status Display Parameter Description

O:ot Outdoor temperature (when --- is

displayed, no outdoor sensor is connected) Current outdoor sensor temperature

A: Li or A:

GA DHW Flow Rate Current DHW Flow(Li: L/m, GA: GPM)

b: It CH Return Water Temperature Current Return Water Sensor Temperature

C: Fr Fan rpm Current FAN speed ( RPM)

d: Lc Lock mode Lock mode ON/OFF

E: oP CH supply temperature (Operating

temperature) Current Boiler Supply temperature

F: dH DHW temperature (Operating temperature) Current DHW temperature

H: Eh Exhaust gas temperature Current exhaust gas temperature

I : St DHW Recirculation temperature (when 0

F is displayed, no DHW Recirc sensor is

connected)

Current DHW Recirc water temperature

J: oH CH Overheat Temperature Current CH Overheat Temperature

L: rt

Burner

Operation

Time

Time for supply power

L: rt on display

on sub menu

Unit : 1000hour

2: rh Time for burner operation Unit : 1hour

3: rH Time for burner operation Unit : 1,000hour

4: It Cycle for ignition Cycle: 10 times the

displayed unit

5: IH Cycle for ignition Cycle: 10,000 times the

displayed unit

P: Ou PUMP Operation

CP1 System

PUMP Current PUMP Operation

(CP1) (CP2) (CP3)

All Activate

CP2 activate

CP2 Boiler

PUMP

CP3

DHW

Recirc

PUMP

55page

56page

B C

A D

1. STATUS DISPLAY MODE (When button is pressed for 5 seconds When power to display panel is ON , status

display will be activated)

To view any of the above listed Status Parameters,

Press and Hold Button B to get into the Status Display Mode.

Rotate Dial E until you find the Parameter that you wish to view. Tap Dial E to enter that

Parameter. Adjust to the setting that you require and then press (tap) Dial E to save and to Exit.

The FT Series Floor Standing, Combination Boiler Page 8

* Default DHW set point is 125°F (51.5°C)

• DHW 95-120°F (35 - 49°C) LOW range (Default)

-To change LOW range, press the C Button. The DHW icon and current DHW LOW will ash (a ashing

value means it can be changed).

-Turn dial E clockwise to increase and counterclockwise to decrease until desired temperature is reached.

-Press dial E to save set point changes.

• DHW 121 - 140°F (49.5 - 60°C) HIGH range

-To change HIGH range, press and HOLD the C button for more than 5 seconds. The DHW icon and

current DHW HIGH will ash (a ashing value means it can be changed).

-Turn dial E clockwise to increase and counterclockwise to decrease until desired temperature is reached.

-Press dial E to save set point changes and to Exit.

Indicate Example

Current DHW set point temperature 120°F

Temperature sign Celsius or Fahrenheit letter °C or °F

If display is communicating with the main controller normally, the

communication icon will be indicated.

When DHW set point range is high : from 121°F (49.5°C) to 140°F (60.0°C) H . 140°F

When changing DHW set point, the DHW icon will ash S24

DHW Set Point Change Mode

The display shows the following information

when changing water heating temperature set

points.

Changing between Celsius and Fahrenheit

When the button D is pressed (for more

than 5 seconds), temperature unit will toggle

between °C and °F.

Scalding may occur within 5 seconds at a setting of 140°F (60°C). Water temperatures

over 125°F can cause severe burns, or death from scalding. Children, disabled,

and elderly are at highest risk of being scalded. Read all instructions before setting

temperature at appliance. Feel water before bathing or showering.

57page

DANGER

User’s Manual - The FT Series Floor Standing, Combination Boiler Page 9

The FT Series Floor Standing, Combination Boiler Page 55

button. The CH Icon and

current CH Setpoint will  ash.

Turn the E dial clockwise to increase, and counterclockwise to decrease CH setpoint, until

desired temperature is reached.

Press E dial to save changes and to Exit.

Default CH set-point is 130°F (54°C)

CH set-point range is 130 - 180°F (54.4 ~ 82.0°C)

To change CH Setpoint, press the button D

Indicate Example

Current Operating Temperature 110°F

Temperature sign Celsius or Fahrenheit letter °C or °F

Display and Controller are communicating

If  ame detected

If pump is operating

When changing CH Setpoint, the CH Icon will  ash

SECTION 5. Control Display and Operation

5.6 CH Set Point Change Mode

Changing between Celsius and Fahrenheit

When the button D is pressed (for more than

5 seconds), temperature unit will toggle between

°C and °F.

To activate heat storage function, First turn OFF the power to the Control Display.

Then Press and Hold Button B to get into the Installer Mode.

Rota te Dial E until you fi nd 5:St Tap Dial E to enter Storage Mode. Storage Mode indicates that the

boiler is heating the water held in the internal storage tank. When Storage Mode is active, the display

will appear as shown.

Turn the E dial clockwise to increase, and counterclockwise to decrease setting.

Press E dial to save changes and to Exit.

Indicate Example

Current Operating Temperature 110°F

Temperature sign Celsius or Fahrenheit letter °C or °F

Display and Controller are communicating

If  ame detected

Storage mode indication

If Pump is operating

5.7 Storage Mode

Page 54

SECTION 5. Control Display and Operation 5.5 DHW Set Point Change Mode

DHW Set Point Change Modes

The display shows the following

information when changing water heating

temperature set points.

* Default DHW set-point is 125°F (51°C)

• DHW 95-120°F (35 - 49°C) LOW range (Default)

-To change LOW range, press the C Button. The DHW icon and current DHW LOW will ash (a

ashing value means it can be changed).

-Turn dial E clockwise to increase and counterclockwise to decrease until desired temperature is reached.

-Press dial E to save setpoint changes.

• DHW 121 - 140°F (49.5 - 60°C) HIGH range

-To change HIGH range, press and HOLD the C button for more than 5 seconds. The DHW icon

and current DHW HIGH will ash (a ashing value means it can be changed).

-Turn dial E clockwise to increase and counterclockwise to decrease until desired temperature is reached.

-Press dial E to save setpoint changes and to Exit.

Indicate Example

Current DHW set-point temperature 125°F

Temperature sign Celsius or Fahrenheit letter °C or °F

If display is communicating with the main controller normally, the

communication icon will be indicated.

When DHW set-point range is high : from 121°F (49.5°C) to 140°F (60.0°C) H . 140°F

When changing DHW setpoint, the DHW icon will ash S24

Changing between Celsius and Fahrenheit

When the button D is pressed (for more

than 5 seconds), temperature unit will toggle

between °C and °F.

DANGER

Scalding may occur within 5 seconds at a setting of 140°F (60°C). Water temperatures

over 125°F can cause severe burns, or death from scalding. Children, disabled,

and elderly are at highest risk of being scalded. Read all instructions before setting

temperature at appliance. Feel water before bathing or showering.

AUTODESK � � � � � � � � � �

User’s Manual - The FT Series Floor Standing, Combination Boiler Page 10

Notes:

Andere Handbücher für FT Series

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Laars Kessel Handbücher

Laars

Laars Mighty Therm AP Bedienungsanleitung

Laars

Laars NEOTHERM NTH Bedienungsanleitung

Laars

Laars FT Series Bedienungsanleitung

Laars

Laars NTV1700 Bedienungsanleitung

Laars

Laars FT Series Bedienungsanleitung

Laars

Laars EBP0110 Allgemeine Anweisungen

Laars

Laars FT Series Bedienungsanleitung

Laars

Laars Mighty Therm 2 200 Leitfaden

Laars

Laars MFTCF140 Bedienungsanleitung

Laars

Laars Mini-Therm JVi JVH Bedienungsanleitung

Laars

Laars Horizon Handbuch

Laars

Laars MagnaTherm HTD Series Bedienungsanleitung

Laars

Laars NEOTHERM NTV Bedienungsanleitung

Laars

Laars FTCF140 Bedienungsanleitung

Laars

Laars NEOTHERM NTH Series Bedienungsanleitung

Laars

Laars MagnaTherm MGH1600 Bedienungsanleitung

Laars

Laars FT Series Bedienungsanleitung

Laars

Laars Mighty Therm AP Bedienungsanleitung

Laars

Laars Mighty Therm Bedienungsanleitung

Laars

Laars LMC Bedienungsanleitung

Laars

Laars MASCOT FT MFTCW Bedienungsanleitung

Laars

Laars FT Series Bedienungsanleitung

Laars

Laars Rheos RHCH Bedienungsanleitung

Laars

Laars NTV Bedienungsanleitung

Beliebte Kessel Handbücher anderer Marken

Vaillant

Vaillant uniSTOR VIH SW GB 500 BES Bedienungsanleitung

Radijator

Radijator BIO max 23.1 Bedienungsanleitung

Brunner

Brunner BSV 20 Bedienungsanleitung

Buderus

Buderus Logamax GB062-24 KDE H V2 Bedienungsanleitung

Potterton

Potterton 50e Datenblatt

UTICA BOILERS

UTICA BOILERS TriFire Bedienungsanleitung

Joannes

Joannes LADY Series Handbuch

ECR International

ECR International UB90-125 Gebrauchsanweisung

Froling

Froling FHG Turbo 3000 Bedienungsanleitung

Froling

Froling P4 Pellet 8 - 105 Bedienungsanleitung

U.S. Boiler Company

U.S. Boiler Company K2 Bedienungsanleitung

Henrad

Henrad C95 FF Bedienungsanleitung

NeOvo

NeOvo EcoNox EF 36 Bedienungsanleitung

Potterton

Potterton PROMAX SL 12 Bedienungsanleitung

Eco Hometec

Eco Hometec EC 25 COMPACT Bedienungsanleitung

Viessmann

Viessmann VITODENS 200 Leitfaden

Baxi

Baxi Prime 1.24 Bedienungsanleitung

REXNOVA

REXNOVA ISA 20 BITHERMAL Bedienungsanleitung
