Technical documentation F 200 K Compact flame detector

Sensors and systems

for industrial flame monitoring

• Compact casing with integrated flame

sensor and switching amplifier

• Sensitivity adjustment in multiple steps

• Digital circuit design for flame evaltion

• LED status indicator

• 24 V DC operating voltage

• Dual-channel system with electronic self-

monitoring

• LED bar flame intensity indicator and

4 (0) ... 20 mA measuring output

• Selectable trend indicator allowing opti-

mum adjustment to the flame direction

- 2 -

Table of Contents

1 General remarks ..........................................................................................................4

1.1 Allow for compliance with the Equipment Safety Act ................................................................................. 4

2 Safety instructions ......................................................................................................5

3 Operating instructions ................................................................................................6

3.1 Application .................................................................................................................................................. 6

3.2 Purpose intended ....................................................................................................................................... 6

3.3 Design......................................................................................................................................................... 6

3.4 Mode of operation....................................................................................................................................... 7

3.5 Basic circuit diagram .................................................................................................................................. 8

4 Technical parameters..................................................................................................9

4.1 Characteristics............................................................................................................................................ 9

4.2 Operating conditions................................................................................................................................... 9

5 Selection criteria........................................................................................................11

6 Installation and assembly instructions....................................................................12

6.1 Assembly / Basic instructions ................................................................................................................... 12

6.2 Installation ................................................................................................................................................ 13

6.2.1 External installation .................................................................................................................................. 14

6.2.2 Device connection .................................................................................................................................... 14

7 Instructions on commissioning and maintenance .................................................14

7.0 Display and operational controls .............................................................................................................. 14

7.0.1 Intensity indicator including the “Adjust“ function / section 9.1 + 9.2, items 3 and 6................................ 15

7.0.2 Sensitivity range - indication / section 9.2 items 10 and 11 .................................................................... 15

7.0.3 Operating state - indication / sections 9.1 + 9.2, items 1 and 2 .............................................................. 15

7.0.4 Sensitivity – Switch/ sections 9.1 + 9.2, items 4 and 5 ........................................................................... 16

7.0.5 Frequency – Switch / section 9.2, item 6.................................................................................................. 16

7.0.6 Service – Switch Serv. / section 9.1 + 9.2, item 6 ................................................................................ 16

7.0.7 Adjust – Switch / section 9.1 + 9.2, item 6 ............................................................................................... 16

7.0.8 Start-up suppression - Potentiometer / sections 9.1 + 9.2, item 9 ........................................................... 16

7.0.9 Measuring points / section 9.1 + 9.2, items 7 and 8................................................................................ 16

7.1 Commissioning ......................................................................................................................................... 16

7.1.1 General remarks....................................................................................................................................... 17

7.1.2 Preparative measures .............................................................................................................................. 17

7.1.3 Adjustment................................................................................................................................................ 18

7.1.4 Checking the flame shut-down on fault .................................................................................................... 20

7.1.5 Fault on flame detection ........................................................................................................................... 20

7.1.6 Faults during ignition ................................................................................................................................ 21

7.1.7 Faults during operation............................................................................................................................. 22

7.2 Troubleshooting........................................................................................................................................ 20

7.3 Commissioning flow chart......................................................................................................................... 22

7.4 Maintenance ............................................................................................................................................. 23

7.4.1 General remarks....................................................................................................................................... 24

7.4.2 Instructions on troubleshooting ................................................................................................................ 24

- 3 -

8 Guarantee and delivery terms.................................................................................. 23

9 Layout of the operational controls .......................................................................... 24

9.1 F 200 K1 … (in the state as delivered)..................................................................................................... 24

9.2 F 200 K2 … (Ex-proof), (in the state as delivered) .................................................................................. 25

10 Dimensional drawings .............................................................................................. 26

10.1 F 200 K … and F 200 K Compact Flame Detectors... Z2 (hazardous area II)......................................... 26

10.2 F 200 K2 … Compact Flame Detector Ex (hazardous area I) ................................................................. 27

10.3 Connection housing FG 24 Ex ................................................................................................................. 27

11 Pin configuration....................................................................................................... 28

11.1 F 200 K1 … .............................................................................................................................................. 28

11.2 F 200 K2 ... (Ex) ....................................................................................................................................... 29

12 Examples of application ........................................................................................... 30

12.1 Interconnection with Etamatic .................................................................................................................. 30

12.2 Interconnection with FMS......................................................................................................................... 30

13 Accessories............................................................................................................... 31

13.1 FN 20 mains supply unit........................................................................................................................... 31

13.1.1 Purpose .................................................................................................................................................... 33

13.1.2 Technical parameters............................................................................................................................... 33

13.1.3 Pin configuration....................................................................................................................................... 35

13.2 Adjustable holding devices....................................................................................................................... 36

13.2.1 FS 19-10 (for IR and UV, without ball-and socket-joint, with purge air connection) ................................ 38

13.2.2 FS 20-10 (for IR and UV, with ball-and socket-joint and purge air connection)....................................... 38

13.2.3 FV 19-10 (for IR and UV, without socket-and-ball-joint, with purge air connection) ................................ 39

13.2.4 FV 20-10 (for IR and UV, with ball-and-socket-joint and purge air connection)....................................... 39

13.2.5 FS 50 (without ball-and-socket-joint and cooling air housing) ................................................................. 40

13.2.6 FS 51 (with ball-and-socket joint and cooling air housing)....................................................................... 41

13.3 Installation in the cooling air housing ....................................................................................................... 40

14 EG Certificate of Conformity.................................................................................... 41

15 EC Prototype testing certificate............................................................................... 42

16 TÜV Certificate .......................................................................................................... 43

- 4 -

1 General remarks

1.1 Allow for compliance with the Equipment Safety Act

The Equipment Safety Act provides the following:

Comply with the operating instruction!

Proceed as instructed by this technical documentation

(Printed matter no. DLT 7620-04D-0001).

Make sure to only use the equipment for the purpose as described herein.

Operation to be carried out by qualified staff only. The equipment may only be oper-

ated and maintained by persons capable of properly doing so based on their knowl-

edge and qualification level.

Liability for proper functioning of the equipment will be transferred to the owner

or operator by law.

Liability for proper functioning of the equipment will be transferred to the owner or op-

erator by law if the equipment is improperly operated, maintained or repaired by per-

sons that do not have the knowledge required, or if the equipment is handled in a way

not complying with the purpose intended.

LAMTEC GmbH & Co KG shall not be held liable for any damage caused by non-

compliance with the instructions given in this manual. The warranty and liability condi-

tions of LAMTEC GmbH & Co KG shall not be extended by the instructions as given

hereinafter.

Any reference to laws, regulations and standards shall be subject to the legislation of

the Federal Republic of Germany.

- 5 -

2 Safety instructions

This operator manual uses the following symbols to mark important safety instructions

to be complied with by the user. In the following sections, this symbols appear in texts

at places where the information is required. Make sure to comply with these safety in-

structions, in particular note the warnings.

WARNING

marks possible risks for persons, especially emanating from electrical equipment.

WARNING

makes reference to possible risks for persons if system components are handled im-

properly.

CAUTION!

makes reference to dangers for system components or to a possible deterioration of

the equipment's operability.

NOTE:

comprises additional information of importance for the user on the system or system

components, and provides additional hints.

This appears in instructive texts to indicate that something has to be done.

In this context, we remind the operator to comply with the accident prevention regula-

tions in connection with all activities, and to do its best to avoid injury to persons and

damage to property in way as circumstances will allow.

- 6 -

3 Operating instructions

3.1 Application

These operating instruction apply to the F 200 K compact flame detector.

The devices comply with the following standards and rules:

DIN EN 230

DIN EN 298

DIN VDE 0116

97/23/EG (directive on pressurised equipment)

90/396/EWG (directive on gas equipment)

DIN EN 60730, part 1 and IEC 801, part 5 (leakage paths and sparking-distance in air

as well as interference susceptibility)

Product identification no.: CE- 0085 BO 0005

3.2 Purpose intended

In single-burner and multiple-burner furnaces, the flame detector performs a high-

safety monitoring of the burner flames. When the flame goes out, the safe control

state “Flamme out“ is reached.

The flame detector is mainly used in large-scale power plants, thermal power stations

and chemical plants as well as for monitoring furnaces which are operated from

- OIL

- GAS

- BIO-MASS

- DUST COAL

- CHEMICALS AND OTHER WASTE PRODUCTS.

3.3 Design

The compact-type flame detector is composed of a cylindrical casing comprising a

light incidence aperture that is in line with the axis a processing status indicator on its

rear side as well as operational controls, which can be accessed there when removing

the cover.

When closed the flame detector complies with the requirements of IP 67 protection

degree.

The detector is installed at the burner by optionally using the FS 19, FV 19, FS 20, FV

20 adjustable holding devices or with an air-cooled housing of the FS 50 or FS 51

types.

The detector consists of the following functional units:

- Sensor unit providing for digitalisation of the flame signal

- digital frequency evaluation

- Self-monitoring

- Switching amplifier

The device is connected through an integrated standard plug and using the a connec-

tion cable required for this (8 pins, static screen,

cable type LiYCY 8x1x0,5 mm²) with coupler.

- 7 -

The cable provides for the following connections:

- Infeed of auxiliary energy

- Connection of the operational earthing FPE

- Connection of external power circuits to a failsafe change-over contact to control

the control states "Flame out" and "Flame in"

- Connection of the intensity measurement output

- Connection for an external sensitivity change-over, only for F 200 K2

- Connection of the screen via the plug enclosure

The layout of the operational controls is represented in section 10.

3.4 Mode of operation

The compact flame detector converts the flame radiation pulses of the burner flame

into electrical signals. These representative signals are routed to an electronic

changeover switch, which alternately applies them to one of the independently work-

ing processing channels, where the signals are digitised. This reduces the initial signal

quantity to the information "pulse period" (information carrier: pulse frequency of the

flame radiation). The digitised signals are compared with the related reference signals

by means of a digital frequency evaluation unit. This makes sure that only those flame

signals that are within the pre-selected frequency transmission range will be included

in a continued processing, irrespective of their original amplitude. A control switch (for

the F 200 K2 only) located below the removable cover allows to change the lower fre-

quency limit if required. After evaluation, the flame signal is routed to the switching

amplifier, which also controls the related shut-down time. A safe monitoring of the

antivalent control states as well as the response and shut-down periods is performed

at the output of the signal processing channels, before an activation of the output re-

lays at the end of each signal processing channel is carried out. Antivalence faults and

deviation in time delays going beyond the admissible limit values result in the control

state "Flame out". The control states “Flame out“ and “Flame in“ are indicated on the

rear side of the device by means of a red and/or green LED, the change-over between

the two signal processing channels being indicated by pulsation of the green LED dur-

ing the “Flame in“ control state. Moreover, one or two six-step control switches provide

for a sensitivity adjustment to adapt the system to the flames to be monitored, this be-

ing indicated by means of a six-step chain of green LEDs designed to be the device's

flame intensity indicator.

Miscellaneous

Self-monitoring principle

Signal processing is carried out by means of two transmission channels working inde-

pendently of each other and alternately triggered. The output levels are permanently

checked for antivalence within a given time grid.

Parameter adjustment, furnace type →Monitoring equipment

The turning knob controls of the F 200 K1 / F 200 K2 compact flame detectors allow to

set 6 to 12 sensitivity levels, the F 200 K version providing an increased sensitivity

level in range II. A six-step green LED indicator indicates the evaluated flame intensity

on the rear side of the device. The transmission range of the digital flame frequency

evaluation allows for signal passage between10 ... 190 Hz (F 200 K1) and/or 10 / 30 /

45 ... 190 Hz (F 200 K2).

- 8 -

3.5 Basic circuit diagram

Intensity remote

indicator

Visual intensity

indicator

GND

GND GND

Self-

monitoring

Monitoring

cycle

Output relay

cycl

safe de-coupling safe de-coupling

digital band pass digital band pass

0/20/30...190 Hz

Switching amplifier

channel A

Switching amplifier

channel B

Channel A Channel B

Detector

Flame sensor

Stabilisation

BCycle

Switch-over

contact

1...6 7...1

21...6 7...1

Sensitivity

selector switch

0/4...20mA

Output

contacts

10/20/30...190 Hz

- 9 -

4 Technical parameters

4.1 Characteristics

The compact flame detector is available in 2 basic versions, apart from an ex-proof enclosure type with several

spectral varieties (IR / UV).

Design type F 200 K1... F 200 K2... (Ex)

Sensitivity range 1 sensitivity range

6 levels

2 sensitivity range

increased sensitivity in

range II, can externally be

switched over,

6 levels each

Frequency range 10 ... 190 Hz 10/30/45 ... 190 Hz,

can be adjusted on the device

Signals lying in the mains frequency range or its multiples are suppressed for 50 Hz

mains generally. For 60 Hz application, please indicate separately in your order form.

The related stop ranges are changed in factory. The compact flame detector is ac-

cordingly marked by a type plate.

4.2 Operating conditions

Input parameters

Auxiliary energy, input

- Supply voltage 24 V DC ± 20%, protection class III

- Power consumption ≤4 W

spectral radiation range and sight angle

- F 200 K1 UV-1 and F 200 K2 UV-1 (Ex) 260 ... 400 nm about 8°

- F 200 K1 UV-2 and F 200 K2 UV-2 (Ex) 210 ... 380 nm about 8°

- F 200 K1 IR-2 and F 200 K2 IR-2 (Ex) 850 … 1200 nm about 50°

- F 200 K1 IR-1 and F 200 K2 IR-1 (Ex) 1200 ... 2800 nm about 60°

Response sensitivity 25 mV AC

Range remote switch-over (F 200 K2 only) floating contact, can be controlled by

means of the supply voltage (refer to section 12.2)

- Control current about 10 mA

Output parameters

Output contact Chang-over contact (floating)

- admissible switching voltage 48 V DC max., protection class II

(250 V AC by mains supply FN 20)

6 V AC/DC min.

- 10 -

- admissible switching current 0.5 A maximally

10 mA minimally, at a limit

load of 50 mA

- Switching capacity 0.1 W minimally

30 W maximally

- Internal fuses, 500 mA slow IEC and/or

750 mA slow UL

- Safety period "Operation" t VOff ≤1 s and/or ≤3 s,

factory set

- Start-up delay t VOn ≈1 s and/or ≈3 s

Measuring output for intensity

- Output continuous current 4 (0 )... 20 mA, there is no insulation

of potential towards the supply

voltage

- Maximum working resistance 220 Ω

- Floating DC voltage 6.6 V

- Basic error ±2 %

Dynamic characteristics

Self-monitoring cycle t CYCLE ca. 3.0 s for safety period

VOff ≤1 s

CYCLE ca. 7.0 s for safety period

VOff ≤3 s

Cable length LiYCY 8x1x0.5

Coupling part with standard cable length 3 m

(is also available in variable length if the customers requires so)

Extension of more than 3 m with LiYCY 8x1x0.5 to 50 m

Extension of more than 3 m with LiYCY 8x1x1.0 to 100 m

Extension of more than 3 m with LiYCY 8x1x2.5 to 250 m

Taking into account the electrical basic conditions, it also possible to bridge major dis-

tances using smaller cable core sections. An important criterion is the compliance with

the supply voltage limits at the compact flame detector, and thus the voltage drop in

supply voltage coming through the supply line.

Technical stressability

Operating mode DB

Creepage distances and clearances DIN EN 60730 part 1

Interference susceptibility DIN EN 60730-1, EN 61000-4

Emitted interference DIN EN 55011/A1

Radio interference suppression

The output contacts of the flame detector have no radio interference suppression. The

user is required to take the appropriate radio interference suppression measures on

the basis of the overall installation design. In order to ensure the required safety, carry

out the installation circuitry in such a way as to avoid shorting-out of the contacts by

defective components of the interference suppression unit.

Climatic stressability

Installation category Temp. min. - 20 °C

max. +60 °C

rel. air humidity 80 % at 35 °C

Inhaltsverzeichnis

Andere Lamtec Sicherheitssensor Handbücher

Lamtec

Lamtec F152 Bedienungsanleitung

Beliebte Sicherheitssensor Handbücher anderer Marken

THORLABS

THORLABS PDA10JT Bedienungsanleitung

Waeco

Waeco UV-DETECT Bedienungsanleitung

Intermatic

Intermatic IOS-DSIMF Bedienungsanleitung

urmet domus

urmet domus 1083 Bedienungsanleitung

Siemens

Siemens AZL66 Series Bedienungsanleitung

BTI

BTI Profiline Multi Finder Bedienungsanleitung

Challenger

Challenger SL01 Bedienungsanleitung

DMP Electronics

DMP Electronics 1122INT Bedienungsanleitung

Rielta

Rielta Ladoga MK-RK Bedienungsanleitung

Mirion Technologies

Mirion Technologies ACCURAD PRD Bedienungsanleitung

Bosch

Bosch DS835 Bedienungsanleitung

DBI SALA

DBI SALA EZ Stop Bedienerhandbuch

Lamptime

Lamptime ST05C Bedienungsanleitung

Ubiquiti

Ubiquiti MFI-MSC Bedienungsanleitung

Subsite

Subsite 910R Montageanleitung

Satel

Satel OPAL Pro Bedienungsanleitung

Aleph

Aleph XC-1XTEU Bedienungsanleitung

Pima

Pima LARIS QUAD Bedienungsanleitung
