Laserworld Tarm Series Bedienungsanleitung

Manual / Bedienungsanleitung /

Mode d´emploi

tarm Series

tarm 3 | tarm 6

tarm 12 | tarm G9 LD

Please spend a few minutes to read this manual fully

before operating this laser!

Bitte lesen Sie diese Bedienungsanleitung sorgfältig

vor Inbetriebnahme dieses Showlasersystems!

Avant d’utiliser cet appareil pour la première fois

nous vous recommandons de lire cette notice d’utilisation!

05/2020

English

Deutsch

Français

Manual: tarm Series

page 2 / 28

Rechtlicher Hinweis:

Die Firma Laserworld (Switzerland) AG behält sich das Recht vor, Änderungen an ihren Pro-

dukten vorzunehmen, die der technischen Weiterentwicklung dienen. Diese Änderungen

werden nicht notwendigerweise in jedem Einzelfall dokumentiert.

Diese Betriebsanleitung und die darin enthaltenen Informationen wurden mit der gebotenen

Sorgfalt zusammengestellt. Die Firma Laserworld (Switzerland) AG übernimmt jedoch keine

Gewähr für Druckfehler, andere Fehler oder daraus entstehende Schäden.

Die in dieser Bedienungsanleitung genannten Marken und Produktnamen sindWarenzeichen

oder eingetragene Warenzeichen der jeweiligen Titelhalter.

Achtung: Bei diesem Gerät handelt es sich um ein Showlasergerät für den gewerblichen Ein-

satz. Dieses Gerät ist kein Laserpointer, nicht für Zeigezwecke geeignet und darf auch nicht

dafür verwendet werden.

Legal notice:

Thank you for purchasing this Laserworld product. Due to continual product developments

and technical improvements, Laserworld (Switzerland) AG reserves the right to make modi-

cations to its products.

This manual and its content have been made with due care but Laserworld (Switzerland) AG

cannot however, take any responsibility for any errors, omissions or any resulting damages

forthwith.

The brands and product names mentioned in this manual are trade marks or registered trade

marks of their respective owners.

Attention:This device is a show laser device for commercial use. This device is not a laser poin-

ter, not suitable for pointing purposes and must not be used as a laser pointer.

Information juridique :

L’entreprise Laserworld (Switzerland) AG se réserve le droit d’eectuer des modications con-

cernant leurs produits et ainsi de répondre au développement technique. Ces modications

ne seront pas nécessairement annoncées en tout cas spécique. Ce mode d’emploi et les in-

formations contenues dedans ont été établis avec le soin minutieux qui s’impose dans ce cas.

Laserworld (Switzerland) AG ne pourra pas être tenue responsable pour d’éventuelles erreurs

d’impression ou dommages en résultants.

En cas de doutes, veuillez toujours contacter Laserworld (Switzerland) AG . Les noms de

marques et de produits utilisés dans ce mode d’emploi sont des marques de fabrique ou des

marques déposées.

L’utilisation est réservée à un usage professionnel selon décret n°2007-665 du 2 mai

2007 relatif à la sécurité des appareils à laser sortant!

Article 4 bis :

« Les usages spéciques autorisés pour les appareils à laser sortant d’une classe supérieure à 2

sont les usages professionnels suivants : (…)

9° Spectacle et achage :

Toutes les applications de trajectoire, de visualisation, de projection ou de reproduction

d’images en deux ou trois dimensions. »

Attention : Cet appareil est un projecteur laser destiné à un usage commercial. Cet appareil

n‘est pas un pointeur laser, il ne convient pas pour le pointage et ne doit pas être utilisé à cette

n.

Manual: tarm Series

page 3 / 28

Content:

1. Product and package contents

2. Preliminary warning notices

3. Initial operations, safety instructions

4. Working on the device

5. Service notes

6. Warnings and other notices on the device

7. Device connections

8. General Operation

9. Operation Modes

Final statement

Find information on how to operate your laser here:

https://www.laserworld.com/en/online-manual

Manual: tarm Series

page 4 / 28

1. Product and package contents

Please check if all listed parts are included and undamaged. Included in delivery:

Laser system, power cable, key, interlock bridge plug, manual, technical datasheetA

3. Initial operations, safety instructions

1. Make sure to use correct voltage; see in-

formation on device & in this manual.

2. Make sure that the device is not connec-

ted to mains during installation.

3. Installation has to be done by technical

experienced and qualied persons ac-

cording to safety regulations of the res-

pective country.

4. Always ensure that maximum permissib-

le exposure (MPE) is not exceeded in are-

as accessible to the public or members of

sta.

5. In some countries an additional ins-

pection by technical control institutes

could be necessary.

6. The power supply should be easily acces-

sible.

7. When installing the laser mount it with

a minimum distance of 15 cm from walls

and objects.

8. For safe setup e.g. on walls or ceilings

please use a safety cord. The safety cord

should be able to withstand tenfold the

weight of the device. Please follow the

accident prevention regulations of pro-

fessional associations and/or comparable

regulations for accident prevention.

9. If the device has been exposed to great

temperature changes, do not switch it

on immediately.

10. Never use dimmer, RC or other electroni-

cally switched sockets. Whenever possib-

le, do not use the laser projector together

with large appliances (especially fog ma-

chines) on the same mains!

2. Preliminary warning notices

1. Please use this device only according to these operating instructions.

2. Do not use the device if there are any visible damages on housing, connector panels,

power cords.

3. Never look directly into the light source of a laser projector. Danger of damage to the

eyes or even blindness in extreme circumstances!

4. This device must not be permanently connected to mains. Disconnect it from mains to

switch it o if not in use.

5. Do not operate the device at high humidity, in the rain or in dusty environments.

6. Protect device against dripping or splashing water. Do not place any liquid lled

containers near to this device.

Any warranty claims are void if the warranty label is removed or tampered

with in any way.

Manual: tarm Series

page 5 / 28

11. Ensure sucient ventilation and do not

place the device on any warm or heat ra-

diating surface. Especially the ventilati-

on openings must not be covered!

12. Ensure that device does not get over-

heated. Make sure that the device is not

exposed to spotlights (especially moving

heads). Heat of spotlights could overheat

laser in a little while and leads to a degra-

dation of performance.

4. Working on the device

1. This product has no user serviceable parts inside and should only

be maintained and serviced by a qualied engineer.

2. Be sure that the mains plug is not connected to the power

supply while installing the device.

3. Take o all reecting things like rings, watches etc. befo-

re starting to work with or at the projector.

4. Only use non-reecting tools to work on device.

5. Wear protective clothing (like goggles, gloves etc.) according to laser power and

wavelength of the laser.

5. Service notes

• Moisture and heat can reduce lifetime of

the laser system dramatically and expires

any warranty claim.

• Quick on/o switching of this device will

reduce durability of the laser diode dra-

matically.

• Avoid sharp knocks and shocks to this

device and ensure sucient protection

during transportation. Look after your La-

serworld product.

• To increase durability of your laser,

protect device against overheating:

-Always ensure sucient ventilation.

-Do not face spotlights (especially mo-

ving heads) to the device.

-Check temperature after approx. 30

minutes with each new installation.

If necessary install the projector at a

place with dierent temperature.

-Keep the device dry. Protect it from

moisture, rain and damp.

-Switch o device when it is not nee-

ded. Diodes are switched on and can

wear out even if there is no visible la-

ser output.

• Please ensure the fans and heatsinks are

clear from dust and debris otherwise the

risk of overheating may occur. If the unit

and airways appear to be blocked then

please contact a qualied service engi-

neer to maintain and service the product.

•Removal of the warranty label as well

as damages to the device caused by

improper handling, neglect of the sa-

fety instructions and service notes will

void the warranty.

Manual: tarm Series

page 6 / 28

6. Warnings and other notices on the device

Laser radiation!

Avoid exposure

to beam.

Laser class 4

Caution of

radiation if cover

is removed Power supply

& consumption

Model type

Wavelength

Output power

Production

year

Please read manual before operation

Use in enclosed spaces only!

7. Device connections

Laser aperture

Beam block

Emission LED

Manual: tarm Series

page 7 / 28

Version: ShowNET Mainboard

Version: Pangolin FB4

RJ45 for LAN connection

in / through computer

with Pangolin Software

RJ45 for

Interlock

in / through

Key switch

DMX out

ILDA through

Mains

connection

in / through

ILDA in

ShowNET Display

DMX in

ShowNET

rotary knob

loop for

safety cord

LAN / ShowNET

LAN through

DMX out

DMX in

Key switchILDA throughILDA in

RJ45 for

Interlock

in / through

FB4 Display FB4 rotary knob

unused

Mains

connection

in / through

loop for

safety cord

Scan safety

Manual: tarm Series

page 8 / 28

8. General Operation

1. Power

Connect the power cord to the device and to the mains. Make sure that your device is pro-

vided with the correct voltage. Wrong voltage could lead to irreparable damages. Please

nd the correct voltage data in the synoptical table at the end of this manual. Make sure

that the device is not directed to people or inammable objects during installation. To

start the device, connect the interlock bridge and switch the device on. The “Emission

- Laser on“ LED at the front side of the device begins to light up when the device is

ready for use.

2. Key Switch

There is a key switch at the back of the laser system. Please plug the key to the switch and

turn it on. The laser device only runs when the key is inserted and switched on. Prevent

misuse! Unplug the key when the laser is unattended to prevent misuse of the sys-

tem.

3. Safety Presets

This device has an integrated Scan Safety (SFS). If the Scan Safety is active (on), single

beams are prevented. If the Scan Safety is switched o, it is possible to create full power

single beams - be careful! On ShowNET devices, SFS can be activated / deactivated by

operating the push button on the back side of the device. On FB4 devices, SFS function is

accessible through FB4 menu.

Operating the laser system with disabled SFS may not be allowed in some countries.

Always ensure that maximum permissible exposure (MPE) is not exceeded in areas

accessible to the public or members of sta.

4. Modes / Functions

The dierent operation modes can be selected with using the rotaty knob at the back of

the device. Any change of the operation mode requires a restart of the device (dis-

connect power and reconnect it again). Do not change any setting during operation. Ran-

dom and dangerous laser output can occur!

5. Turn device o

To turn o the device, turn the key to ‚OFF‘ and disconnect the power cable from the

mains.

Manual: tarm Series

page 9 / 28

9. Operation Modes

This laser system can be operated in many dierent operation modes.

Information, videos and tutorials are available online!

Find information on how to operate your laser here:

https://www.laserworld.com/en/online-manual

Manual: tarm Series

page 10 / 28

Final statement

tarm products are tested and product packaging is inspected before leaving our

warehouse.

Users must to follow the local safety regulations and warnings within this manual and adhere

to any regulations within its place of use. Damages through inappropriate use will void any

liability or warranty of our products.

Due to continual product developments, please check for the latest update of this product

manual at www.tarm.com. If you do have any further questions, then please contact

your dealer/place of purchase or use our contact section on our website.

For service issues, please contact your dealer/place of purchase and ensure only genuine

Laserworld spare parts are used in any service repairs.

Errors and Omissions excepted and products are subject to change.

tarm laser technologies tlt GmbH & Co.KG

Lindenallee 27

44625 Herne

Germany

Registered oce: Herne / Germany

Company number: HRA 4462

CEO: Richard Krumhus

UID: DE 22 87 70 68 6

WEEE-Reg.-No. (Germany): DE85045116

www.tarm.com

[email protected]

Andere Handbücher für tarm Series

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Sprachen:

Andere Laserworld Beleuchtungsausrüstung Handbücher

Laserworld

Laserworld V PRO-OEM Bedienungsanleitung

Laserworld

Laserworld Ecoline Series Bedienungsanleitung

Laserworld

Laserworld CS-150G DMX Bedienungsanleitung

Laserworld

Laserworld Club Series Bedienungsanleitung

Laserworld

Laserworld Club Series Bedienungsanleitung

Laserworld

Laserworld BLUE-10000-445 F Bedienungsanleitung

Laserworld

Laserworld GREEN-3000 Bedienungsanleitung

Laserworld

Laserworld SwissLas Purelight Series Bedienungsanleitung

Laserworld

Laserworld GREEN-2000 Bedienungsanleitung

Laserworld

Laserworld GREEN-200A Bedienungsanleitung

Laserworld

Laserworld GREEN-100E Bedienungsanleitung

Laserworld

Laserworld Evolution ES-800S RGB 3D Bedienungsanleitung

Laserworld

Laserworld CS-2000RGB Bedienungsanleitung

Laserworld

Laserworld LW25K Bedienungsanleitung

Laserworld

Laserworld Ecoline EL-D100G Bedienungsanleitung

Laserworld

Laserworld Ecoline Series Bedienungsanleitung

Laserworld

Laserworld GREEN-400 Bedienungsanleitung

Laserworld

Laserworld GREEN-8000 Bedienungsanleitung

Laserworld

Laserworld EL-200 RGY Bedienungsanleitung

Laserworld

Laserworld Pro-300B-473 Bedienungsanleitung

Laserworld

Laserworld CS-500 RGY Bedienungsanleitung

Laserworld

Laserworld Club Series Bedienungsanleitung

Laserworld

Laserworld BLUE-5000-445 F Bedienungsanleitung

Laserworld

Laserworld Diode Series Bedienungsanleitung

Beliebte Beleuchtungsausrüstung Handbücher anderer Marken

Brizo

Brizo 8SP-MU-4 Bedienungsanleitung

LUCE&LIGHT

LUCE&LIGHT BROM 1.0 Bedienungsanleitung

IKEA

IKEA BJÖRKSPIREA Bedienungsanleitung

Alien

Alien RG STAR Bedienungsanleitung

EuroLite

EuroLite LED B-40 Bedienungsanleitung

Qazqa

Qazqa Suplux SL 3 Black 103062 Bedienungsanleitung

Commercial Electric

Commercial Electric 54568141 Bedienungsanleitung

CREE LIGHTING

CREE LIGHTING 304 Series Bedienungsanleitung

Goobay

Goobay 49867 Bedienungsanleitung

ECOMAN ITALIA

ECOMAN ITALIA LED T8 Bedienungsanleitung

Alkalite

Alkalite Krypton KT-81 Bedienungsanleitung

Clas Ohlson

Clas Ohlson GU10 Bedienungsanleitung

DTS

DTS DELTA 10 F Bedienungsanleitung

ring

ring Solar Steplight Bedienungsanleitung

One Stop Gardens

One Stop Gardens 57696 Montageanleitung

Chauvet DJ

Chauvet DJ COREpar UV120 ILS Bedienungsanleitung

SIREM

SIREM Swimeo A2 Bedienungsanleitung

Silvair

Silvair MESH-CEDRP Bedienungsanleitung

Laserworld tarm Series Bedienungsanleitung

Beliebte Beleuchtungsausrüstung Handbücher anderer Marken
