Latte LV70 Bedienungsanleitung

User’s Guide

Version 1.2

Latte

LV70 Android Tablet

(English)

•This guide shall only be used for providing information and operating instruction

•Latte Communications, Inc. reserves the right to modify the specifications and other

information without prior notice

•Software, music, or film, etc with copyrights shall be protected by relative laws

•Shape and color of actual product may vary slightly from the pictures shown in this guide

•Display screens in default setting may vary from the screen contents used in this guide

English: 3-32

Español: 34-64

+ SAFETY PRECAUTIONS

•Do not use the tablet in extremely hot, cold, dusty or damp environments

•Do not leave the tablet inside a car with all windows closed in summer weather

•Do not drop the tablet when using it. It might seriously damage the components inside and

crack the screen

•Do not pull out the adapter cord or touch the power plug with wet hands

•Do not use a damaged power cord, a damaged plug or a loose power outlet

•Do not disassemble, repair, or modify the tablet arbitrarily. These actions will void the

manufacturer’s standard warranty

•Ensure that the battery is charged only with the original adapter included in the package

•When formatting the tablet or uploading/downloading files, do not disconnect the tablet

from the PC. This may damage files or the tablet itself

•Do not visit unreliable websites

•Delete suspicious messages and e-mails sent by unidentified senders

•Install an anti-virus application and execute a virus check regularly

+ CONTENTS

5 About LV70

6 Main Specifications

7 Memory Partition

8Exterior

9 Basic Operations

10 Charging

11 Turning On/Off

12 Unlocking The Screen

13 Buttons

14 Using Touch Screen

15 Moving Files from PC to ICE Smart

17 Downloading Applications

18 Home Screens

19 Changing your Wallpaper

19 Moving Icons

19 Removing Icons

20 Application Screens

21 Accessing the Application Screen

21 Creating a shortcut to Home Screen

22 System Settings

24 Wireless and Network

25 Language and Keyboard

26 Applications

28 Factory Reset

29 Extras

30 Real Tips from Inside Latte

31 Legal

32 FCC Notification and Cautions

ABOUT LV70

Main Specifications

Memory Partitions

Exterior

+ MAIN SPECIFICATIONS

•O/S: Android 4.0 Ice Cream Sandwich

•Screen: 7.0”TFT Capacitive Screen (800 X 480, 16million colors)

•CPU: Cortex A8 up tp 1.2Ghz (Built-in 3D accelerator)

•RAM: DDR3 512 MB

•Connectivity: Wi-Fi (IEEE802.11 b/g/n)

•Video: 1080P HD Video support

MPEG-2, MPEG-4, H.264, WMV, MP4, RMVB, FLV, MKV

•Audio: MP3, WAV, WMA, ASF, APE, FLAC

•Photo: JPEG, BMP, PNG, TIFF

•Memory Expansion: External Micro SD card slot (Up to 32GB)

•Applications: Access to Google Play Store

•Others

•G-Sensor

•Built-in speaker and MIC

•Internet browsing, emails, eBook, documents, games, VOIP, etc

+ MEMORY PARTITIONS

Internal built-in memory on the tablet is split into 2 areas. This is very important concept to understand

(this is an Android O/S memory structural requirements)

•The system memory, often called Internal memory in Android system (~1GB):

This is the area where your downloaded applications will be stored by default

•The user memory, often called SD card in Android system (~total memory 4GB/ 8GB /16GB

minus system memory): This is the area where you can store music, video or picture files. You can

also move downloaded applications from the system memory to the user memory

Please free up the system memory by moving files to the user memory. Once system memory is full,

you can not download applications any more

+ EXTERIOR

BASIC OPERATIONS

Charging

Turning on/off

Unlocking the screen

Buttons

Using touch screen

Moving files from PC to the tablet

Downloading applications

Home Screens

Application/Widget Screens

System Settings

Factory Reset

+ CHARGING

Please connect the power adapter to the tablet. It takes about 3-4 hours to be fully charged.

Please charge the tablet in the following instances

•The battery icon is showing a low power level

•The player turns off automatically or turns off soon after restart

•The buttons and screen do not respond properly

Notes:

•Only use the original power adapter included in the package. Using a power adapter

with wrong specifications might damage the tablet and will void the standard warranty

•The battery is a consumable part and the lifespan of the battery will decrease slowly as

you use the tablet over time

•Charging time will be longer if you use the tablet while you are charging
