PowerIntegrator
The features of the Timing/State ANALYZER are:
Trace In timing mode the analyzer can trace
• up to 102 channels with 500 MHz sampling rate
• up to 204 channels with 25 0MHz sampling rate
In state mode the analyzer can trace
• up to 204 channels with 200 MHz sample rate
• up to 102 channels with 200 MHz sample rate, double data
rate
The trace depth is 512 K records.
For 500 MHz mode and Double Data Mode it is 1024 K records.
Transient Recording The sampling of the input lines is stored to the trace buffer by
changes of the input level only. The total recording time depends on
the occurrence of changes of the input signals. If the traced signals
only changes once per ms, the total sampling time will be 512 s. The
minimum trace time is 2 ms, which may appear if high-speed clock
signals are recorded.
Mixed Trace The input channels are split into two groups of 102 channels each.
Each group can be used for timing or state mode recording.
Timing mode: Fixed sample rate of 250/500 MHz.
State mode: For each group a 1of2 qualifier selects the sampling
clock out of the dedicated clock inputs (CLKA/B, CLKJ/K).
The sampled data are synchronized to the asynchronous trace
information.
Simple Triggering The simple trigger unit uses one trigger mask, which can include
level or edge detection, a trigger filter and a trigger counter for
generating a trigger event. Trigger programming can be done in the
data window as easy as setting trigger conditions on a scope.
Complex Triggering tbd.
