LCT PGH45064 Bedienungsanleitung
LCT ENGINES
DE MOTORES LCT
LCT MOTEURS
Operation Manual / Manual De Empleo / Manuel D’opération
SAVE THIS MANUAL FOR FUTURE USE.
CONSERVE ESTE MANUAL PARA SU REFERENCIA FUTURA.
CONSERVEZ LE GUIDE POUR CONSULTATION ULTÉRIEURE.
This spark ignition system complies with the Canadian standard ICES-002.
Este sistema de la ignición de la chispa se conforma con los HIELOS
estándar canadienses-002.
Ce système d’allumage par étincelle de véhicule est conforme à la norme
NMB-002 du Canada.
PGH45064 03/29/12 rev O
California Proposition 65
WARNING:
The engine exhaust from this product and this product
contains chemicals known to the state of California to
cause cancer and birth defects, or other reproductive harm.
CARBON MONOXIDE HAZARD
NEVER use engine inside homes, garages, crawl spaces,
or other partially enclosed areas. Poisonous gases that can
be harmful or fatal can build up in these areas. Using a fan
and opening doors or windows does NOT provide enough
fresh air.
Engine exhaust contains carbon monoxide - a poisonous
gas that can be harmful or fatal. You CANNOT see or smell
this gas.
Use a battery-powered carbon monoxide detector when
running an engine.
If you start to feel sick, dizzy, or weak while using an engine,
shut it off and get to fresh air RIGHT AWAY. See a doctor.
You may have carbon monoxide poisoning.
DANGER
Using an engine or engine application indoors CAN KILL YOU IN MINUTES.
Exhaust contains carbon monoxide, a poison gas you cannot see or smell.
NEVER use in the home or in partly
enclosed areas such as garages.
Avoid other engine dangers.
READ MANUAL BEFORE USE.
ONLY use outdoors and far from
open windows doors, and vents.
Liquid Combustion Technology, LLC Engines Manual 1rev. 03/29/12
When using this engine, your safety and the safety of others should
be your top priority.
To assist you in making informed decisions regarding safety, we have provided
operating procedures and other information on labels and in this manual. This
information warns you of potential hazards that could hurt you or others.
Please stay safety conscious when using this engine.
We have provided important safety information in a variety of forms, including:
• Safety Labels: placed on the engine.
• Safety messages: preceded by a safety alert symbol and one of three signal words,
DANGER, WARNING, or CAUTION. These safety alert symbols mean:
If you do not follow instructions, it WILL cause you
SERIOUS INJURY or DEATH.
If you do not follow instructions, it MAY cause you
SERIOUS INJURY or DEATH.
If you do not follow instructions, it may cause you
SERIOUS INJURY or EQUIPMENT DAMAGE.
• Safety Headings: such as IMPORTANT SAFETY INSTRUCTIONS.
• Safety Section: such as ENGINE SAFETY.
• Instructions: How to use this engine correctly and safely.
Thoroughly read and review this manual to know how to stay safe and get maximum
benet and enjoyment from using this engine.
Introduction
DANGER
WARNING
CAUTION
Liquid Combustion Technology, LLC Engines Manual 2rev. 03/29/12
Engine Safety
IMPORTANT SAFETY INSTRUCTIONS
Accidents occur less frequently when instructions are followed, the operator is safety
conscious and the engine is properly maintained. Some of the most common hazards
are discussed below, along with the best way to protect yourself and others.
Owner and Operator Responsibilities
Owners and operators should perform the following suggestions:
• Carefully read the owners manual.
• Follow the instructions in this manual carefully.
• Familiarize yourself with all controls and know how to stop the engine quickly
in case of an emergency.
• Keep children away from the engine and do not let them operate it. Keep children
and pets away from the area of operation.
• Operate this engine in well-ventilated areas. NEVER run engine indoors.
Refueling the Engine
Gasoline is extremely ammable, and gasoline vapor can explode. When refueling
the engine, take the following precautions.
• Perform when the engine is cool.
• Refuel outdoors in well-ventilated areas.
• The engine should not be running.
• Make sure the engine is grounded to prevent static electrical spark.
• Do not smoke or use cell phones when refueling.
• Keep away from ames or sparks.
• If spillage occurs, be sure all areas are dry and vapor has dissipated prior to starting
the engine.
Liquid Combustion Technology, LLC Engines Manual 3rev. 03/29/12
Engine Safety CONTINUED
Exhaust / Muffler
Engine exhaust is dangerous because of intense heat and emission of carbon
monoxide (poisonous gas).
• The mufer becomes very hot during operation and remains hot for a while after
stopping the engine. Do not touch the mufer while it is hot. Do not store the engine
until it is cool.
• To prevent re hazards and for adequate ventilation, keep the engine at least 3 feet
(1 meter) away from building walls and other equipment during operation. Do not
place ammable objects close to the engine.
• Carbon Monoxide Hazard:
Exhaust gas contains carbon monoxide, a poisonous
gas. Avoid inhalation of exhaust gas. Always run the
engine in a well-ventilated area. Never run the
engine indoors.
Other Equipment
Review the instructions provided with the equipment powered by this engine for any
additional safety precautions that should be observed in conjunction with engine
startup, shutdown, operation, or protective safety gear that may be needed to operate
the equipment.
DANGER
WARNING
Do not touch hot sections of engine (see muffler figure
above). The hot sections of the engine can cause severe
burns.
Liquid Combustion Technology, LLC Engines Manual 4rev. 03/29/12
Contents
Introduction 1
Engine Safety 2–3
Controls & Features 5
Before Operation 6–7
Pre-Operation Checks 6–7
Operation 8–10
Safe Operation Precautions 8
Starting the Engine 8
4 Step Starting Procedure 8
Stopping the Engine 9
Setting Engine Speed 9
High Altitude Operation 10
Servicing Your Engine 11–16
The Importance of Maintenance 11
Maintenance Safety 12
Refueling 13
Fuel Recommendations 14
Engine Oil Level Check 14
Engine Oil Change 15-16
Engine Oil Recommendations 15
Air Filter Inspection 16
Air Filter Service 16
Spark Plug Service 16
Helpful Tips and Suggestions 17–19
Storing your engine 17
Maintenance Schedule 18
Storage Precautions 19
Transportation 19
Technical & Consumer Information 20
Emission Control System Information 20
Consumer Information 02
Emissions Control System Warranty 21-22
Manufacturer’s Warranty Information 23
California Emission Control Warranty Statement 24
General Emission Warranty Coverage 25
Warranted Parts 26
Specications 27
Liquid Combustion Technology, LLC Engines Manual 5rev. 03/29/12
CONTROLS
1. Fuel Valve
The fuel valve opens and closes the passage between the fuel tank and the carburetor.
The fuel valve must be in the ON position for the engine to run. When the engine is not
in use, be sure the fuel valve is in the OFF position to prevent carburetor ooding and
to reduce the possibility of fuel leakage.
2. Engine ON/OFF Switch (per engine specification)
The engine switch enables and disables the ignition system. Turn the engine switch to
the ON position to start the engine. Turn the engine switch to the OFF position to stop
the engine.
3. Choke Lever
The choke lever opens and closes the choke valve in the carburetor. The “ON” position
enriches the fuel mixture which makes it easier when starting a cold engine. The
opposite position provides the correct fuel mixture for operation after engine warms up.
4. Throttle Lever (per engine specification)
The throttle lever controls engine speed (RPMs). Moving the throttle lever in the
directions shown makes the engine run faster or slower. (Non-generator applications.)
5. Recoil Starter Grip
Pulling the starter grip operates the recoil starter to crank the engine. Always grip snugly
and have your body positioned properly when pulling. Keep thumb on the end of the
handle in case of kick-back.
Controls & Features
1
3
4
5
2
WARNING
Do not touch hot
sections of engine.
The hot sections
of the engine can
cause severe burns.
Liquid Combustion Technology, LLC Engines Manual 6rev. 03/29/12
Before Operation
PRE-OPERATION CHECKS
For your safety, and to maximize the service life of your equipment, it is very important
to take a few moments before you operate the engine to check its condition. Be sure to
take care of any problem you nd, or have your servicing dealer correct it, before you
operate the engine.
Improperly maintaining this engine or failing to correct a problem
before operation, could cause a malfunction in which you could
be seriously injured.
Always perform a pre-operation inspection before each operation
and correct any problem.
Before beginning your pre-operation checks, be sure the engine is level and the engine
switch is in the OFF position (per engine specication).
Check the General Condition of the Engine
• Remove any excess dirt or debris, especially around the mufer, recoil starter, and
cylinder head ns.
• Inspect for signs of damage and oil leakage.
• Be sure all shields and covers are in place. All nuts, bolts, and screws must be tight.
Check the Engine
• Check the engine oil level. Running the engine with a low oil level or improper oil
can cause engine damage. To avoid the inconvenience of an unexpected shutdown,
always check the engine oil on a level surface before startup.
WARNING
Max Upper Level
Min Lower Level
Liquid Combustion Technology, LLC Engines Manual 7rev. 03/29/12
• Check the air lter. A dirty air lter will restrict air ow to the carburetor, reducing
engine performance and can cause excessive wear on the engine.
• Check the fuel level before start-up. Since the engine must be cool before
refueling, starting with a full tank will help to eliminate or reduce operating
interruptions for refueling.
Check all Equipment Powered by this Engine
Review the instructions provided with the equipment powered by this engine for
all precautions and procedures that should be followed before starting the engine.
Before Operation CONTINUED
