LD DS2.1 Bedienungsanleitung
LD DS2.1
2+1 -CHANNEL SPEAKER PROCESSOR
Vers.1.23
USER´S MANUAL
BEDIENUNGSANLEITUNG
MODE D´EMPLOI
24/BIT DSP / 48 KHZ SAMPLING RATE
DS2.1 2+1 -CHANNEL
SPEAKER PROCESSOR
Thank you for choosing LD-Systems!
We have designed this product to operate reliably over many years. Therefore LD-Systems guarantees for high
quality products with its name and many years of experience as a producer.
Please, take a few moments to read these instructions carefully, as we want you to enjoy your new LD-Systems
products quickly and to the fullest.
For information about LD-Systems check out our website WWW.LD-SYSTEMS.COM
02
ENGLISHDEUTSCHFRANCAIS
03
ENGLISHDEUTSCHFRANCAIS
LD DS2.1
2+1 - CHANNEL SPEAKER PROCESSOR
24/BIT DSP / 48 KHZ SAMPLING RATE
DS2.1 2+1 -CHANNEL
SPEAKER PROCESSOR
04
ENGLISHDEUTSCHFRANCAIS
PREVENTIVE MEASURES:
1. Please read the attached safety instructions as well as the following instructions carefully.
2. Please keep the manual and all the instructions.
3. Please use the device only as intended.
4. Please respect the valid waste management rules. Deliver the packaging divided into plastic and
paper / cardboard to the recycling management.
5. If the device is damaged, exposed to liquid / rain or if it does not operate normally please refer all servicing
exclusively to qualified personel.
6. This product must be earthed. If it should be malfunction or break down, grounding provides a path of
least resistance for electric current to reduce risk of electric shock. This product is equipped with a cord
having an equipment-grounding conductor and a grounding plug. The plug must be plugged into an
appropriate outlet that is properly installed and earthed in accordance with all local codes and ordinance.
7. Please, do not expose to any kind of heat such as ovens, radiators, or any other devices (incl. amplifiers).
Please check for enough distance between amplifiers and walls, racks, etc. to prevent overheating.
8. After all connections are made please check the wiring to prevent any kind of accident or damage.
Please never use any kind of damaged cable and wiring.
9. Only use authorized and stable stands, brackets, shelfs, tables etc.. for installations. Please check for
adequate stability against collapse.
Adam Hall GmbH, all rights reserved. The technical data and the functional product characteristics can be subject
to modifications. The photocopying, the translation, and all other forms of copying of fragments or of the integral-
ity of this user’s manual is prohibited.
CAUTION:
To reduce the risk of electric shock, do not remove the cover (or back). No user serviceable parts inside. Refer all
servicing to qualified personnel.
The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the
user to the presence of uninsulated “dangerous voltage” within the product´s enclosure that may be
of sufficient magnitude to constitute a risk to persons.
The exclamation mark within an equilateral triangle is intended to alert the user to the presence of
important operating and maintenance (servicing) instructions in the literature accompanying the
appliance.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT O PEN
05
ENGLISHDEUTSCHFRANCAIS
Features:
• 24 bit DSP.
• 3-way output: left channel, right channel and subwoofer channel;
link function for L/R stereo setting.
• 3 bands PEQ; EQ types: Lowshelf, Highshelf.
• Crossover range: 20 Hz 20 kHz.
• Selectable Crossover Slopes: 6dB, 12dB, 18dB and 24dB.
• Filter types: Bessel, Butterworth. Q value adjustable.
• Polarity reverse control.
• Max 12.5ms delay for each output.
• Independent Limiter: treshold adjustable.
• USB port; Friendly user interface; 6 user memories.
• 2x 16 LCD.
24/BIT DSP / 48 KHZ SAMPLING RATE
DS2.1 2+1 -CHANNEL
SPEAKER PROCESSOR
06
ENGLISHDEUTSCHFRANCAIS
LD DS2.1 FEATURES:
FRONT PANEL:
REAR PANEL:
Parameter
Navigate menu
Recall
Recall a programm
2x 16 LCD
View menu and parameter
Power socket
Fuse
USB port
Edit encoder
Adjust the parameter value
Power
Power on / off
Outputs
Inputs
1
1
2
2
3
3
4
4
5
5
24/BIT DSP / 48 KHZ SAMPLING RATE
DS2.1 2+1 -CHANNEL
SPEAKER PROCESSOR
07
ENGLISHDEUTSCHFRANCAIS
SYSTEM SETUP:
L: R:
Sub:
SUB DELAY
TIME= 0ms
SUB VOLUME
GAIN= 0.0dB
SUB LIMIT
Treshold= off
SUB MUTE
[ De-Mute ]
SUB LIMIT
HOLD= 100
SUB PHASE
[ 0 ]
Realtime metering of the inputs.
Adjust the input level of the subwoofer with the Edit-knob.
Use the Edit-knob to mute or unmute the subwoofer.
Here you can adjust the phase of the subwoofer using the Edit-
knob.
You can adjust the delay time for the subwoofer using the Edit-
knob.
Here you can activate or deactivate the limiter for the subwoofer
channel as well as adjust the limiters’ threshold value using the
Edit-knob.
You can also adjust the hold time of the limiter using the Edit-
knob.
When you power up the unit, the system displays the main interface, showing the realtime input levels. Press
“PARAMETER” to view the menu.
By repeatedly pressing the “PARAMETER” button you can access the system settings.
08
ENGLISHDEUTSCHFRANCAIS
SYSTEM SETUP:
L&R PHASE
[ 0 ]
L&R Limit
Hold= 100
L&R XOVER
XOVER= OFF
RECALL PROGRAM
P1: PRESET 1
L&R DELAY
Time= 0ms
L&R Limit
Treshold= off
Adjust the output level of the L&R channels using the Edit-knob.
Adjust the phase of the L&R channels using the Edit-knob.
Adjust the XOVER of the L&R channels using the Edit-knob.
Adjust the delay time of the L&R Channels using the Edit-knob.
Here you can activate or deactivate the limiter for the L&R
channels as well as adjust the limiters’ threshold value using the
Edit-knob.
You can also adjust the hold time of the limiter using the Edit-
knob.
To recall a program press the recall button.
Now select the program you would like to recall using the Edit-
knob and press recall to recall the program.
L&R VOLUME
GAIN= 0.0dB
09
ENGLISHDEUTSCHFRANCAIS
SPECIFICATIONS:
Input Channels Left, Right
Output channels Left, Right, Subwoofer
Gain -60dB 6dB 0.5dB/step
Delay
Max 12.5ms
EQ
3 bands
EQ Gain -12dB 12dB, 0.1dB/step
EQ Frequence 20 20kHz
EQ Q value 0.4 128 HighShelf, lowShelf
Polarity 0°, 180°
Highpass frequence 10.0Hz 16kHz
Highpass slopes 6dB/12dB/24dB Butterworth
12dB718dB/24dB Bessel
24dB Linkwiz-Riley
12sB/Q=0.5 12dB/Q=2.0
Lowpass frequence 35.0Hz 20kHz
Lowpass slopes 6dB/12dB/18dB24dB Butterworth
12dB/18dB/24dB Bessel
Limiter -40dBu 10dBu, OFF
Voltage 90V-250V 18VA 50Hz-60Hz
Power supply 18VA
Size 227 x 145 x 50mm
Weight 1.2kg
LIMITED wARRANTY
This Limited Warranty applies to the Adam Hall, LD Systems, Defender, Palmer and Eminence branded products.
The statutory warranty rights towards the seller are not affected by this guarantee. In fact it justifies additional
independent warranty claims towards Adam Hall.
Adam Hall warrants that the Adam Hall product you have purchased from Adam Hall or from an Adam Hall autho-
rized reseller is free from defects in materials or workmanship under normal use for a period of 2 or 5 years from
the date of purchase.
The Limited Warranty Period starts on the date of purchase. In order to receive warranty services you are required
to provide proof of the purchase date. Your dated sales or delivery receipt showing the date of purchase is your
proof of the purchase date. Should products of the brands named above be in need of repair within the limited war-
ranty period, you are entitled to warranty services according to the terms and conditions stated in this document.
This Limited Warranty extends only to the original purchaser of this Adam Hall branded product and is not transfe-
rable to anyone who obtains ownership of the Adam Hall branded product from the original purchaser. During the
Limited Warranty Period Adam Hall will repair or replace the defective component parts or the product. All compo-
nent parts or hardware products removed under this Limited Warranty become the property of Adam Hall.
In the unlikely event that your Adam Hall product has a recurring failure, Adam Hall, at its discretion, may elect to
provide you with a replacement unit of Adam Hall´s choice that is at least equivalent to your Adam Hall branded
product in hardware performance.
Adam Hall does not warrant that the operation of this product will be uninterrupted or error-free. Adam Hall is not
responsible for damage that occurs as a result of your failure to follow the instructions included with the Adam
Hall branded product.
This Limited Warranty does not apply,
- to wear parts (e.g. accumulator)
- to any product from which the serial number has been removed or that has been damaged or rendered defec-
tive as the result of an accident
- in case of misuse, abuse, or other external causes
- by operation outside the usage parameters stated in the user´s documentation shipped with the product
- by use of spare parts not manufactured or sold by Adam Hall
- by modification or service by anyone other than Adam Hall
These terms and conditions constitute the complete and exclusive warranty agreement between you and Adam
Hall regarding the Adam Hall branded product you have purchased.
10
ENGLISHDEUTSCHFRANCAIS
MANUFACTURER´S DECLARATIONS:
