USER´S MANUAL / BEDIENUNGSANLEITUNG /
MANUEL D´UTILISATION / MANUAL DE USUARIO /
INSTRUKCJA OBSŁUGI / MANUALE D´USO
MIBS
MICROPHONE DESKTOP BASE WITH CONFIGURABLE SWITCH
LDMIBS
CONTENTS / INHALTSVERZEICHNIS / CONTENU / CONTENIDO / TREŚĆ / CONTENUTO
ENGLISH
INTENDED USE 4
SAFETY INFORMATION 4
INTRODUCTION 5
COMPONENTS, CONNECTIONS, DISPLAYS AND CONTROLS 5
WIRING EXAMPLE 6
TECHNICAL DATA 7
DISPOSAL 8
MANUFACTURER´S DECLARATIONS 9
DEUTSCH
VERWENDUNGSZWECK 10
SICHERHEITSHINWEISE 10
EINLEITUNG 11
KOMPONENTEN, ANSCHLÜSSE, ANZEIGEN UND BEDIENELEMENTE 11
VERKABELUNGSBEISPIEL 12
TECHNISCHE DATEN 13
ENTSORGUNG 14
ERKLÄRUNGEN DES HERSTELLERS 15
FRANCAIS
UTILISATION RÉGLEMENTÉE 16
INFORMATIONS RELATIVES À LA SÉCURITÉ 16
INTRODUCTION 17
COMPOSANTS, CONNECTEURS, AFFICHEURS ET COMMANDES 17
EXEMPLE DE CÂBLAGE 18
CARACTÉRISTIQUES TECHNIQUES 19
MISE AU REBUT 20
DÉCLARATIONS DU FABRICANT 21
ESPAÑOL
USO PREVISTO 22
INFORMACIÓN DE SEGURIDAD 22
INTRODUCCIÓN 23
COMPONENTES, CONEXIONES, PANTALLAS Y CONTROLES 23
EJEMPLO DE CABLEADO 24
DATOS TÉCNICOS 25
RECICLAJE 26
DECLARACIÓN DEL FABRICANTE 27
POLSKI
ZAMIERZONE ZASTOSOWANIE 28
WSKAZÓWKI BEZPIECZEŃSTWA 28
WPROWADZENIE 29
ELEMENTY, POŁĄCZENIA, WYŚWIETLACZE I ELEMENTY STERUJĄCE 29
PRZYKŁAD OKABLOWANIA 30
DANE TECHNICZNE 31
DISPOSAL 32
DEKLARACJA PRODUCENTA 33
ITALIANO
USO PREVISTO 34
INFORMAZIONI SULLA SICUREZZA 34
INTRODUZIONE 35
COMPONENTI, COLLEGAMENTI, DISPLAY E CONTROLLI 35
ESEMPIO DI CABLAGGIO 36
DATI TECNICI 37
SMALTIMENTO 38
DICHIARAZIONI DEL PRODUTTORE 39
4
ENGLISH
YOU‘VE MADE THE RIGHT CHOICE!
We have designed this product to operate reliably over many years. LD Systems
stands for this with its name and many years of experience as a manufacturer of
high-quality audio products. Please read this User’s Manual carefully, so that you
can begin making optimum use of your LD Systems product quickly. You can find
more information about LD SYSTEMS at our Internet site WWW.LD-SYSTEMS.COM
INTENDED USE
The product is a device for professional audio installation!
The product has been developed for professional use in the field of audio
installation and is not suitable for use in households!
Furthermore, this product is only intended for qualified users with specialist
knowledge of dealing with audio installations!
Use of the product outside of the specified technical data and operating
conditions is considered improper use!
Liability for damage and third-party damage to persons and property due to
improper use is excluded!
The product is not suitable for:
• People (including children) with reduced physical, sensory or mental abilities
or lack of experience and knowledge.
• Children (Children must be instructed not to play with the device).
SAFETY INFORMATION
1. Please read these instructions carefully.
2. Keep all information and instructions in a safe place.
3. Follow the instructions.
4. Use the appliance only in the manner intended.
5. Do not open or modify the unit.
CAUTION: Connecting signal cables can lead to considerable
noise interference. Make sure that the input channel of e.g.
an installation mixer is muted when plugging a device in.
Otherwise, these noise levels might cause damage.
DEUTSCH FRANCAIS ESPAÑOLENGLISH ITALIANOPOLSKI
5
DANGER OF SUFFOCATION! KEEP AWAY FROM CHILDREN! THE PRODUCT CONTAINS
SMALL PARTS THAT CAN BE SWALLOWED AND PACKAGING MATERIAL THAT CAN BE
SWALLOWED! PLASTIC BAGS MUST BE KEPT OUT OF REACH OF CHILDREN!
INTRODUCTION
The LD MIBS solid microphone base features a female XLR connector, a push
button and an illuminated status indicator on the top, a male XLR connector on
the rear and an operating mode selector switch on the bottom. Phantom power
is required for operation. The microphone base is suitable for both dynamic and
condenser microphones.
COMPONENTS, CONNECTIONS, DISPLAYS AND CONTROLS
5
1
3
2
4
1Female 3-pin XLR connector for connecting a microphone .
2Push-button with multiple functions
(see item 5Operating mode selector switch).
3Microphone symbol with illumination to indicate the operating status.
The microphone symbol lights up white when the microphone is active.
4Male 3-pin XLR socket for connecting the microphone signal to an installation
mixer or similar.
DEUTSCHFRANCAIS
ESPAÑOLITALIANO POLSKI ENGLISH
6
5The operating mode selector switch is located on the underside of the base.
PUSH TO TALK The microphone is only active as long as you press the
button 2. To mute the microphone, release the button.
PUSH TO MUTE The microphone is permanently active and is only muted
as long as the button 2is pressed.
LATCH ON/OFF
Push-button 2with switch function. Press the button
briefly to activate the microphone and again briefly to
mute it.
WIRING EXAMPLE
Preamplifier / Mixing amplifier (not included)
Microphone (not included)
Microphone cable (not included)
Preamplifier / Mixing amplifier (not Included)
Microphone cable
(not included)
Microphone
(not included)
DEUTSCH FRANCAIS ESPAÑOLENGLISH ITALIANOPOLSKI
7
TECHNICAL DATA
Article number LDMIBS
Product type Desktop microphone base with push-button
Controls Push-button with 3 selectable modes,
mode selector switch:
PUSH TO TALK / PUSH TO MUTE / LATCH ON/OFF
Display elements Status LED (lights up white when the
microphone is active)
Maximum input voltage 870 mV RMS
Frequency response 90 Hz – 20 kHz (–3 dB)
Input impedance 47 kohms (balanced)
Output impedance 800 ohms (balanced)
Mute damping > 75 dB @ 1 kHz
CMRR > 65 dB (CMRR IEC)
Gain @ 48 V phantom power IN vs. OUT 5.5dB
Inputs 1x 3-pole XLR female
Outputs 1x 3-pole XLR male
Phantom power requirements
15 VDC – 48 VDC (±10%), 6 mA typical
Power consumption (mute) 3 mW (microphone muted)
Power consumption 6 mA
Operating temperature 0°C – 40°C
Relative humidity < 85% , non-condensing
General
Material Zinc housing, plastic front panel
Colour Black
Dimensions (W x H x D)
109.8mm x 38.7mm x 126.2mm (height with rubber feet)
Weight 0,54 kg
DEUTSCHFRANCAIS
ESPAÑOLITALIANO POLSKI ENGLISH
8
DISPOSAL
PACKAGING:
1. Packaging can be disposed of via the usual waste
disposal channels.
2. Please separate the packaging according to the waste disposal
and materials regulations in your country.
DEVICE:
1. This device is subject to the European Directive on Waste
Electrical and Electronic Equipment in its applicable version.
WEEE Directive- Waste Electrical and Electronical Equipment. Old
devices and batteries do not belong in household waste. The old
device or batteries must be disposed of via an approved waste
disposal service or a municipal waste disposal facility. Follow the
directives in your country!
2. Follow the disposal laws in your country.
3. As a private customer, you can obtain information on
environmentally friendly disposal options from the retailer
from whom you purchased the product or from the relevant
regional authorities.
DEUTSCH FRANCAIS ESPAÑOLENGLISH ITALIANOPOLSKI
9
MANUFACTURER´S DECLARATIONS
MANUFACTURER’S WARRANTY & LIMITATION OF LIABILITY
Adam Hall GmbH, Adam-Hall-Str. 1, 61267 Neu Anspach, Germany
Our current warranty conditions and limitation of liability can be found at:
https://cdn-shop.adamhall.com/media/pdf/MANUFACTURERS-DECLARATIONS_LD_SYSTEMS.pdf.
Contact your distribution partner for service.
UKCA- CONFORMITY
Hereby, Adam Hall Ltd. declares that this product meets the following guidelines
(where applicable) Electrical Equipment (Safety) Regulations 2016
Electromagnetic Compatibility Regulations 2016 (SI 2016/1091)
The Restriction of the Use of Certain Hazardous Substances in Electrical
and Electronic Equipment
Regulation 2012 (SI 2012/3032)
Radio Equipment Regulations 201 7(SI 2016/2015)
UKCA- DECLARATION OF CONFORMITY
Products that are subject to Electrical Equipment(Safety)Regulation 2016, EMC
Regulation 2016 or
subject to the Radio
Equipments Regulations 2017 (SI2017/1206) can be downloaded from
www.adamhall.com/compliance/
FOR INDOOR USE ONLY
This symbol indicates electrical equipment designed primarily for
indoor use.
Misprints and errors as well as technical or other changes are reserved!
DEUTSCHFRANCAIS
ESPAÑOLITALIANO POLSKI ENGLISH
10
DEUTSCH
SIE HABEN DIE RICHTIGE WAHL GETROFFEN!
Wir haben dieses Produkt so konzipiert, dass es über viele Jahre hinweg zuver-
lässig funktioniert. Dafür steht LD Systems mit seinem Namen und seiner lang-
jährigen Erfahrung als Hersteller von hochwertigen Audioprodukten. Bitte lesen
Sie dieses Benutzerhandbuch sorgfältig durch, damit Sie Ihr LD Systems Produkt
schnell optimal nutzen können. Weitere Informationen über LD SYSTEMS finden
Sie auf unserer Internetseite WWW.LD-SYSTEMS.COM
BESTIMMUNGSGEMÄSSER GEBRAUCH
Das Produkt ist ein Gerät für die professionelle Audioinstallation!
Das Produkt wurde für den professionellen Einsatz im Bereich der Audioinstallation
entwickelt und ist nicht für den Gebrauch in Haushalten geeignet!
Außerdem ist dieses Produkt nur für qualifizierte Benutzer mit Fachkenntnissen
im Umgang mit Audioinstallationen bestimmt!
Die Verwendung des Produkts außerhalb der angegebenen technischen Daten
und Betriebsbedingungen gilt als unsachgemäße Verwendung!
Die Haftung für Schäden und Drittschäden an Personen und Sachen durch
unsachgemäßen Gebrauch ist ausgeschlossen!
Das Produkt ist nicht geeignet für:
• Menschen (einschließlich Kinder) mit eingeschränkten körperlichen, sensorischen
oder geistigen Fähigkeiten oder einem Mangel an Erfahrung und Wissen.
• Kinder (Kinder müssen angewiesen werden, nicht mit dem Gerät zu spielen).
SICHERHEITSHINWEISE
1. Bitte lesen Sie diese Anweisungen sorgfältig durch.
2. Bewahren Sie alle Informationen und Anweisungen an einem sicheren Ort auf.
3. Folgen Sie den Anweisungen.
4. Verwenden Sie das Gerät nur in der vorgesehenen Weise.
5. Öffnen oder verändern Sie das Gerät nicht.
