1.4” Photo Gallery Digital Photo Frame Start Guide
1690-97
Select
Mode:
Toggles display of time and alarm
Up
Set:
Push this button to set the time
Down
Adjust: Toggles the alarm, and the
display of US and International Time
Set the Clock in the Top Screen:
Before Using, Charge the Photo Frame
Plug the USB power cord into a PC and the Photo Frame.
Contents: Set the Bottom Screen Time: Set the Alarm in the Bottom Screen:
Controls and Connections:
Charge the Leed’s Photo Frame
Bottom Screen Controls
Top Screen
Controls
Bottom LCD Screen
Displays Time,
Alarm and Temperature
Mini-USB Jack
For transferring images
and charging Top LCD
Top
LCD
Screen
Battery Cover
L1130 batteries (2) for the Bottom LCD
Mode
Toggles the display between showing
the time and showing the alarm. Push
once or twice to ensure the clock shows
the time with seconds.
Up/Down
Toggle the display between
U.S. and International Time.
Up/Down
Increase or decrease the ashing number.
Select:
Hold the Select button for two seconds, and the
numbers on the display begin ashing. Quickly
pushing the Select button cycles through the elds
in this order:
Mode
Toggles the display between showing the time and
showing the alarm. Push once or twice to ensure
the clock shows the alarm (time displays without
seconds).
Set
Push once to change the Hour
(Hour should start to ash).
Set
When the hour is correct, press Set to
move to minutes. The minutes should
now begin ashing.
Set
When the minute is correct, press Set to
move to seconds.
Set
Push to stop any numbers from ashing.
The clock is set.
Adjust
Push once to increase by one hour.
Hold the button in to increase the hours
automatically.
Adjust
Push once to increase by one minute.
Hold the button in to increase the
minutes automatically.
Adjust
Push once to reset the seconds to zero.
You cannot set the seconds manually.
Up
Down
Select
Select “USB Charge” using the
UP/DOWN buttons below, and
click to charge the Leed’s Frame
In the bottom left of the display,
the battery icon will ash. When
completely charged, it will stop.
NOTE: The battery should be completely charged before use.
To get the longest life from the battery, it should be completely
emptied and fully charged for the rst three charge cycles.
Setting the alarm is much the same as the clock,
but with the difference that there is no seconds to set. Instead
of resetting the seconds, there is the alarm melody selection.
2Photo Frame
3USB Power Cord
1User Manual
