Leica ICC50 HD Manual 2

Contents

The Leica ICC50 HD

Introduction 9

The basics 10

The basics (cont.) 11

Leica ICC50 HD: Overview 12

Unpacking 14

Get Ready!

Preparation for Use 16

Get Set!

Connection and Operation for Imaging using a Computer 19

Limitations in PC Mode 20

Using an Additional HDMI Monitor in PC Mode 21

Capturing Images without a computer 22

Capturing Images without a computer (cont.) 23

How to handle SD memory cards 24

Using High Deﬁnition Video without a computer 25

Setting a new white balance for the ICC50 HD 26

The Camera Menu

Optional remote control 28

Viewing images and movies with the optional remote control 29

Calling up the Camera Menu 30

COLOR (Automatic White Balance) 31

COLOR (Manual White Balance) 32

EXPOSURE 33

RESOLUTION 34

SETUP CAM (Camera Settings) 35

SETUP USER (User-deﬁned Settings) 36

Predeﬁned Illumination Scenarios 37

Go!

Ready! Set! Go! 39

Care and Cleaning

Care and Cleaning 41

Specications

Leica ICC50 HD camera module 43

Leica ICC50 HD Manual 3

General Instructions

Safety concept

Before using your Leica ICC50 HD camera for

the ﬁrst time, please read the "Safety concept"

brochure included with your instrument. It

contains additional information about handling

and care.

Use in clean rooms

The Leica ICC50 HD camera can be used in clean

rooms without any problems.

Cleaning

ϘDo not use any unsuitable cleaning agents,

chemicals or techniques for cleaning.

ϘNever use chemicals to clean colored

surfaces or accessories with rubberized

parts. This could damage the surfaces,

and specimens could be contaminated by

abraded particles.

ϘIn most cases, we can provide special solu-

tions on request. Some products can be

modiﬁed, and we can oﬀer other accesso-

ries for use in clean rooms.

Servicing

ϘRepairs may only be carried out by Leica

Microsystems-trained service technicians.

Only original Leica Microsystems spare

parts may be used.

Responsibilities of person in charge of

instrument

ϘEnsure that the Leica ICC50 HD is operated,

maintained and repaired by authorized and

trained personnel only.

Leica ICC50 HD Manual 4

Safety concept

The Leica ICC50 HD camera include an interac-

tive CD-ROM with all relevant user manuals.

Keep it in a safe place, and readily accessible

to the user. User manuals and updates are also

available for you to download and print from

our web site at www.leica-microsystems.com.

This operating manual describes the special

functions of the individual modules of the Leica

DM microscopy series and contains important

instructions for their operational safety, main-

tenance, and accessories.

The "Safety concept" booklet contains addi-

tional safety information regarding the service

work, requirements and the handling of the

microscope, accessories and electrical accesso-

ries as well as general safety instructions.

You can combine individual system articles

with articles from external suppliers (e.g. cold

light sources, etc.). Please read the user manual

and the safety requirements of the supplier.

Before installing, operating or using the instru-

ments, read the user manuals listed above. In

particular, please observe all safety instructions.

To maintain the unit in its original condition

and to ensure safe operation, the user must

follow the instructions and warnings contained

in these user manuals.

Leica ICC50 HD Manual 5

Symbols used

Warning of a danger

•This symbol indicates especially impor-

tant information that must be read and

complied with. Failure to comply can cause the

following:

ϘHazards to personnel

ϘFunctional disturbances or damaged

instruments

Warning of hazardous electrical voltage

This symbol indicates especially impor-

tant information that, if not observed,

can cause the following:

ϘHazards to personnel

ϘFunctional disturbances or damaged

instruments.

Danger due to hot surface

This symbol warns against touching hot

surfaces, e.g. those of light bulbs.

Important information

This symbol indicates additional infor-

mation or explanations that intend to

provide clarity.

Leica ICC50 HD Manual 6

Safety regulations

Description

The individual modules fulﬁll the highest

requirements for observation and documenta-

tion of the Leica ICC50 HD camera.

Designated use

ϘSee "Safety concept" booklet

Non-intended use

ϘSee "Safety concept" booklet

The devices and accessories described in this

operating manual have been tested for safety

and potential hazards. The responsible Leica

aﬃliate must be consulted whenever the device

is altered, modiﬁed or used in conjunction with

non-Leica components that are outside of the

scope of this manual.

Unauthorized alterations to the instrument or

noncompliant use shall void all rights to any

warranty claims!

Location of use

ϘSee "Safety concept" booklet

ϘSet up the electrical components at least

10 cm from walls and combustible objects.

ϘAvoid large temperature ﬂuctuations,

direct sunlight and vibrations. These condi-

tions can distort measurements and micro-

graphic images.

ϘIn warm and warm-damp climatic zones,

the individual components require special

care in order to prevent the build up of

fungus.

Requirements for the owner/operator

ϘSee "Safety concept" booklet

Ensure that:

ϘThe Leica ICC50 HD camera is operated,

maintained and repaired by authorized and

trained personnel only.

ϘAll operators have read, understood and

observe this user manual, and particularly

the safety instructions.

Leica ICC50 HD Manual 7

Safety regulations (continued)

Repair, service work

ϘSee "Safety concept" booklet

ϘOnly original Leica Microsystems spare

parts may be used.

ϘBefore opening the instruments, switch oﬀ

the power and unplug the power cable.

ϘTouching the live circuit can cause injury.

Transport

ϘUse the original packaging for shipping or

transporting the individual modules of the

Leica ICC50 HD camera.

ϘIn order to prevent damage from vibrations,

disassemble all moving parts that (accord-

ing to the user manual) can be assembled

and disassembled by the customer and

pack them separately.

Installation in third-party products

ϘSee "Safety concept" booklet

Disposal

ϘSee "Safety concept" booklet

Legal regulations

ϘSee "Safety concept" booklet

EC Declaration of Conformity

ϘSee "Safety concept" booklet

Health risks

Workplaces equipped with microscopes facili-

tate and improve the viewing task, but they

also impose high demands on the eyes and

holding muscles of the user. Depending on the

duration of uninterrupted work, asthenopia

and musculoskeletal problems may occur. For

this reason, appropriate measures for reduction

of the workload must be taken:

ϘOptimal arrangement of workplace, work

assignments and work ﬂow (changing tasks

frequently).

ϘThorough training of the personnel, giving

consideration to ergonomic and organiza-

tional aspects.

The ergonomic design and construction of the

Leica DM microscopy series are intended to

reduce the exertion of the user to a minimum.

Leica ICC50 HD Manual 8

The Leica ICC50 HD

Leica ICC50 HD Manual 9

Congratulations on purchasing the Leica ICC50

HD Digital Camera Module by Leica Microsys-

tems. The special design of the Leica ICC50 HD

makes it a universal, highly versatile tool for

viewing microscopic specimens and capturing

still images or even video.

Real Full HD display

The integrated HDMI output allows the micro-

scope image to be output to a High-Deﬁnition

(HD)-capable monitor, where the following

resolutions are possible:

Ϙ1920×1080i ("Full HD"). This resolution

provides the best possible imaging perfor-

mance on a Full HD-capable television.

Ϙ1280×720p ("HD ready"). This resolution is

suitable for display on televisions labeled

"HD ready".

Leica Application Suite

Along with your Leica ICC50 HD, you also obtain

the "Leica Application Suite EZ" software (LAS

Core on request). It allows additional scenarios

to be implemented in which the television and

monitor can even be used together. Thus you

are ideally prepared for every situation: work at

the computer, presentations, training sessions,

trade show appearances, material testing and

more.

User-friendly even in the smallest detail

Like every digital camera, the Leica ICC50 HD

reacts diﬀerently to diﬀerent light sources.

However, the white balance is factory set to

match the Leica LED illuminators. This means

that if you use a Leica LED illuminator, you auto-

matically obtain the best results!

Introduction

Leica ICC50 HD Manual 10

Your Leica HD camera has many possibili-

ties for various applications and condi-

tions of use. Below are some basic concepts to

help you get the most performance for your

application.

High Deﬁnition

High Deﬁnition – 1920 × 1080 resolution with-

out any scaling. (An HD wide screen display is

required.)

HD Mode – For use without a computer

ϘThe camera always powers up in HD mode.

ϘThe camera provides an HD image directly

to an HD display via the HDMI cable. This

image is in a wide screen 16:9 format.

ϘImages can be captured directly onto an SD

card.

ϘThe optional remote control is usable in HD

mode for ﬁne tuning the image, remote

SD card capture, capturing of movie clips,

viewing a gallery of images which are on

the SD card,etc.

Power

Power can be provided to the camera in the

following ways:

Ϙvia the USB cable from a computer

Ϙvia the optional USB power supply

Ϙa computer will not see the camera when

the camera is in HD mode.

If you would like to switch to PC mode,

then launch the Leica imaging software

or press the Black Multipurpose button for 5

seconds.

The basics

Inhaltsverzeichnis

Andere Leica Digitalkamera Handbücher

Leica

Leica SL Bedienungsanleitung

Leica

Leica C-LUX 1 Gebrauchsanweisung

Leica

Leica LEICA X-U 113 Bedienungsanleitung

Leica

Leica D-Lux 4 Bedienungsanleitung

Leica

Leica S Bedienungsanleitung

Leica

Leica C-LUX 1 Bedienungsanleitung

Leica

Leica M 10 Bedienungsanleitung

Leica

Leica R7 Bedienungsanleitung

Leica

Leica M8 Handbuch

Leica

Leica V-LUX 1 Gebrauchsanweisung

Leica

Leica M8 Bedienungsanleitung

Leica

Leica C Bedienungsanleitung

Leica

Leica SL2 Bedienungsanleitung

Leica

Leica V-LUX 5 7741 Bedienungsanleitung

Leica

Leica Digital-Modul R Bedienungsanleitung

Leica

Leica V-LUX 1 Bedienungsanleitung

Leica

Leica M11-P Bedienungsanleitung

Leica

Leica Q Bedienungsanleitung

Leica

Leica TL Bedienungsanleitung

Leica

Leica IC90 E Bedienungsanleitung

Leica

Leica M10-R Bedienungsanleitung

Leica

Leica M8 Bedienungsanleitung

Leica

Leica M10-R Bedienungsanleitung

Leica

Leica CALONOX SIGHT SE Bedienungsanleitung

Beliebte Digitalkamera Handbücher anderer Marken

Mercury

Mercury 350K Bedienungsanleitung

Pentax

Pentax Optio LS 465 Bedienungsanleitung

Sanyo

Sanyo VPC-S1085 Bedienungsanleitung

GE SMART A1255 Bedienungsanleitung

Point Grey

Point Grey Gazelle Bedienungsanleitung

Nikon

Nikon COOLPIX A Bedienungsanleitung

Pentax

Pentax P-5 Bedienungsanleitung

BlazeVideo

BlazeVideo A280 Bedienungsanleitung

Sony

Sony MCA-20 Bedienungsanleitung

Sony

Sony Alpha DSLR-A290 Bedienungsanleitung

ATIK Cameras

ATIK Cameras One Bedienungsanleitung

CohuHD Costar

CohuHD Costar 3930 Series Bedienungsanleitung

FujiFilm

FujiFilm FinePix A700 Bedienungsanleitung

Lorex

Lorex LNZ81P25 Series Bedienungsanleitung

GE J1470S Bedienungsanleitung

Sony

Sony A6700 Benutzerhandbuch

Canon

Canon EOS ELAN7 Bedienungsanleitung

Nikon

Nikon Coolpix 100 Bedienungsanleitung
