14HPX Heat Pump

Home Comfort Systems

LENNOX’ MERIT®SERIES

14HPX

Economical, environmentally responsible

home cooling

Compatible with the exclusive Humiditrol®

whole-home dehumidification system—

indoor air quality you can feel

Components designed for

exceptional durability and

easy maintenance

Compatible with the exclusive

Humiditrol®whole-home

dehumidification system*

Ozone-responsible R410A

refrigerant meets the EPA’s

(Environmental Protection

Agency) most stringent

environmental guidelines

ENERGY STAR®qualified

(select models)

Merit®Series 14HPX Heat Pump

EFFICIENT, ECONOMICAL COOLING AND HEATING

Innovation never felt so good.

™

Visit us at www.lennox.com, or contact us at 1-800-9-LENNOX.

(30W19) 14HPX 06/08

PC54608

Merit®Series 14HPX Specifications

14HPX 018 024 030 036 042 048 060

Dimensions 29-1/4 x 24-1/4 29-1/4 x 24-1/4 33-1/4 x 24-1/4 29-1/4 x 32-1/4 37 x 32-1/4 37 x 32-1/4 43-1/4 x 32-1/4

HxWxD (in.) x 24-1/4 x 24-1/4 x 24-1/4 x 32-1/4 x 32-1/4 x 32-1/4 x 32-1/4

HxWxD (mm) 743 x 616 x 616 743 x 616 x 616 845 x 616 x 616 743 x 819 x 819 940 x 819 x 819 940 x 819 x 819 1099 x 819 x 819

Note: Due to Lennox’ ongoing commitment to quality, all specifications, ratings and dimensions are subject to change without notice.

Direct-Drive Fan – Precision-

balanced direct-drive outdoor fan

is designed to provide quieter

operation and longer product life.

Dependable Scroll Compressor –

Provides reliable and efficient

operation.

High-Efficiency Outdoor Coil –

Provides exceptional heat transfer

and low air resistance for

high-efficiency operation.

Corrosion-Resistant Cabinet –

Protects against rust and corrosion

with heavy-gauge, galvanized

steel construction and a durable,

baked-on finish.

Durable Coil Guard – Provides

long-lasting coil protection with

non-corrosive, PVC-coated

steel-wire construction.

EFFICIENCY RATING

Meets or exceeds 13.00

SEER (Seasonal Energy

Efficiency Ratio) and

7.7 HSPF (Seasonal

Performance Factor).

WARRANTY**

5-year limited warranty

on the compressor and

all remaining covered

components.

13.00-15.00

21.0013.00

THIS MODEL

Quality you can trust.

Lennox employs state-of-the-art,

helium-leak testing equipment to

ensure leak-free construction.

Choosing an ENERGY STAR®product

can help you improve comfort

and save money. Get details at

www.itpaystolivesmart.com.

The 14HPX heat pump can be

combined with a gas furnace to

enhance comfort and fuel efficiency

by alternating between electric and

gas heat, optimizing energy use and

minimizing heating costs.

*Must be accompanied by either a

variable speed air handler or furnace

and the ComfortSense™7000 Series

Touchscreen Thermostat.

**Applies to residential applications

only. See actual warranty certificate

for details.

Lennox is proud of the fact that

these products have earned

the Good Housekeeping Seal.

Proper sizing and installation

of equipment is critical to

achieve optimal performance.

Split system air conditioners

and heat pumps must be

matched with appropriate coil

components to meet ENERGY

STAR®criteria. Ask your

Lennox dealer for details, or

visit www.energystar.gov.
