Lenovo K10 Plus Bedienungsanleitung

Lenovo K10 Plus

User Guide V1.0

Lenovo L39051

Basics

Before using this information and the product it supports, be sure to read the following:

Quick Start Guide

Regulatory Notice

Appendix

The Quick Start Guide and the Regulatory Notice have been uploaded to the website at

http://support.lenovo.com.

Note: All pictures and illustrations in this document are for your reference

only and may differ from the final product.

Home screen

The home screen is the starting point for using your phone. For your convenience, the home

screen is already set up with some useful apps and widgets.

Note: Your phone's features and the home screen may be different depending on your

location, language, carrier, and model.

You can customize your home screen at any time.

To change the settings for the home screen, press and hold anywhere on the home screen

except the icons, select Home settings, and then select the option that you want to

make changes.

To add a widget to the home screen, press and hold anywhere on the home screen except

the icons, select Widgets, and then swipe up or down to locate the widget that you want,

press and hold the widget until it pops out, drag it to where you want to place it, and then

release it.

Tip: Some widgets are grouped by app, swipe left or right to locate the app that you

want and then tap it to see the available widgets.

To change the wallpaper, press and hold anywhere on the home screen except the icons,

select Wallpapers, and then choose your favorite wallpapers in Photos, Live

Wallpapers or Wallpapers.

To move a widget or an app to another screen, press and hold the widget or app until its

icon enlarges slightly, drag it to where you want to place it, and then release it.

To remove a widget from the home screen, press and hold the widget until its icon

enlarges slightly, slide your finger toward the top of the screen, and then drop the widget

over .

To uninstall an app, press and hold the app, slide your finger toward the top of the

screen, and then drop the app over .

Note: Some of the system apps cannot be uninstalled.

Screen buttons

There are three buttons at the bottom of the screen.

Back button: Tap to return to the previous page or exit the current app.

Home button: Tap to return to the default home screen.

Multitask button: Tap to see recent apps. Then you can do the following:

Tap an app to open it.

Swipe an app window left or right to close it.

Tap CLEAR ALL to stop running all the app.

In app interface, press and hold to enter split screen mode.

Note: Some apps may not support the split screen.

Screen lock

When your phone is on, press the Power button to lock the screen manually. Press the Power

button again to display the lock screen, and then swipe up from the bottom of the screen to

unlock.

Note: Swipe is the default screen unlocking method. To change your screen lock, see

Settings.

Notifications and Quick Settings

The Notifications panel informs you of new messages, USB connection, and activities in

progress such as file downloading. The Quick Settings panel allows you to access frequently-

used settings such as the Wi-Fi switch.

You can do any of the following:

To see notifications, swipe down from the top of the screen.

To close the Notification panel, swipe up from the bottom of the screen.

To dismiss a notification, swipe left or right across the notification.

To dismiss all notifications, tap Clear all at the bottom of the Notifications panel.

To open the Quick Settings panel, swipe down from the top of the screen.

To close the Quick Settings panel, swipe up from the bottom of the screen.

USB connection

When you connect your phone to a computer using a USB cable, the Notification panel

displays a notification such as "Charging this device via USB". You can tap the notification,

and then select one of the following options:

File Transfer: Select this mode if you want to transfer any files between your phone and

the computer.

PTP: Select this mode if you want to transfer only photos and videos between your phone

and the computer.

MIDI: Select this mode if you want MIDI-enabled applications on your phone to work with

MIDI software on the computer.

No data transfer: Select this mode if you want to charge your phone only.

USB tethering: Select this mode if you want to share your internet data connection

through a USB cable.

Calls

Making a call

Dialing a number manually

1. Open the Phone app.

2. Tap to display the dialpad if necessary.

3. Enter the phone number that you want to dial, and then tap .

Calling from the call log

1. Open the Phone app.

2. Tap the Recents tab.

3. Tap from a call log entry to make a call.

Calling a contact

1. Open the Phone app.

2. Tap the Contacts tab.

3. Locate the contact that you want to call, and tap the contact name to display the contact

details.

4. Tap the phone number that you want to dial.

Receiving calls

Answering or rejecting a call

When you receive a phone call, the incoming call screen appears. You can do one of the

following:

Swipe up from to answer the call.

Swipe down from to reject the call.

Silencing a call

You have the following ways to silence a call:

Press the volume up button or the volume down button.

Press the Power button.

Options during a call

When you are on a call, the following options are available on the screen:

Add call: displays the dialpad so you can call another person.

Hold: puts the current call on hold or resumes the call.

Mute: turns the microphone on or off.

Keypad: displays the keypad.

Speaker: turns the speaker on or off.

: ends the call.

You can also press the volume button to turn the volume up or down.

Note: The Hold function may be different depending on your carrier.

Using the call log

The call log contains missed, outgoing, and received call entries. You can tap a call log

entry, then the options menu appears, and then tap an option. For example, you can tap the

Add to a contact option to add the entry to the Contacts list.

Contacts

Creating a contact

1. Open the Contacts app.

2. Tap .

3. Enter the contact information.

4. Tap Save.

Searching for a contact

1. Open the Contacts app.

2. Do one of the following:

Scroll the Contacts list up or down to locate the desired contact.

Tap Search contacts, and then enter the contact name or initials. Matching contacts

are displayed as you type.

Editing a contact

1. Open the Contacts app.

2. Find and tap the contact that you want to edit.

3. Tap , and then edit the contact information.

4. Tap Save.

Sharing a contact

1. Open the Contacts app.

2. Tap > Select, then select the contact that you want to share with others, and then tap

Deleting a contact

1. Open the Contacts app.

2. Tap > Select, then select the contact that you want to delete, and then tap .

Importing contacts

1. Open the Contacts app.

2. Tap > Settings > Import.

3. Tap SIM card. If your phone has dual SIM cards, choose whether to import from SIM 1 or

SIM 2.

4. Tap OK.

Exporting contacts

1. Open the Contacts app.

2. Tap > Settings > Export.

3. Tap SAVE.

Messages

Sending a message

You can use the Messages app to send text messages and multimedia messages.

1. Open the Messages app.

2. Tap Start chat.

3. Tap the recipient text box, and then enter a contact name or phone number. Matching

contacts are displayed as you type. Select a contact.

Or tap to add more recipients.

4. Tap the message text box, and then enter a message.

Tip: If you want to send a multimedia message, tap to select a media

object type such as pictures or video clips, and then attach a desired

media object to the message.

5. Tap .

Searching for a message

1. Open the Messages app.

2. Tap , and then enter all or part of the contact name, the phone number, or the message

into the search text box.

Deleting messages

1. Open the Messages app.

2. In the list of message threads, tap a contact name or phone number to view the message

thread.

3. Tap > Delete, and then tap Delete in the popped up dialog box.

Or in the list of message threads, press and hold a message until it is selected, then tap ,

and then tap Delete in the popped up dialog box.

Camera

Camera basics

You can use the Camera app to take photos and record videos.

Tap to take a photo in Photo mode.

Tap , then tap in the poped dialog box, and then tap to record a video in Video

mode.

Tap the photo or video thumbnail to view the photo or video in the Photos app. For more

information, see Photos.

Tap to switch between flash modes.

Tap to switch between the front-facing camera and the rear-facing camera.

Tap to configure the other camera settings.

Taking a screenshot

Press and hold the Power button and the volume down button at the same time to take a

screenshot.

By default, the screenshots are stored in your phone's internal storage. To view the

screenshots, do one of the following:

Open the Photos app and find the Screenshots album.

Open the Files app and go to the Images > Screenshots folder.

Photos

Viewing photos and videos

1. Open the Photos app.

2. Tap a photo or video to view it in full screen mode.

3. Do any of the following:

To see the next or previous photo or video, swipe left or right.

To zoom in or out of a photo, stretch or pinch the photo. When you zoom in, you can

drag to see other parts of the photo.

To view a video, tap .

Sharing photos and videos

When you are viewing a photo or video, tap anywhere on the screen, tap , and then select

a sharing channel such as Messages or Bluetooth to share the photo or video with

others. If you want to share multiple photos and videos at the same time, do all of the

following:

1. Open the Photos app.

2. When viewing a group of photos or videos, press and hold the photo or video that you

want to share until it is selected.

3. Tap and select the photos or videos that you want to share with others.

4. Tap , and then select a sharing channel such as Messages or Bluetooth to share

the photo or video with others.

Deleting photos and videos

When you are viewing a photo or video, tap anywhere on the screen, then tap ,and then

tap Move to trash to delete the photo or video.

If you want to delete multiple photos and videos at the same time, do all of the following:

1. Open the Photos app.

2. When viewing a group of photos or videos, press and hold the photo or video that you

want to delete until it is selected.

3. Tap and select the photo or video that you want to delete.

4. Tap , and then tap Move to trash in the poped dialog box.
