Quick Start Guide
Read this guide carefully before using your smartphone.
Lenovo S90-A
First glance
Front-facing camera
3
Fill Light
1Receiver
2
On/Off button
6
Light/Proximity sensor
4Volume buttons
5
Home button
9
Touch screen
7Back button
8
Flashlight
12
Menu button
10 Rear-facing camera
11
Speaker
15
Headset connector
13 Micro-SIM-card tray
14
16 17 Micro USB connector
Microphone
8
10 1713 16
9
2
3
4
1
5
6
7
11 12 13 14
15
Installing the Micro SIM card
A Micro SIM card provided by your carrier is required in order to use
cellular services. Install the Micro SIM card as shown.
Step 1.
Step 2.
Step 3.
Insert the SIM eject tool that comes with your smartphone
into the hole in the Micro-SIM-card tray.
Pull out the Micro-SIM-card tray and position the Micro SIM
card into the tray in correct orientation.
Carefully insert the tray with the installed Micro SIM card
back into the slot.
Only Micro SIM cards work with your smartphone.
Always turn off your smartphone first before you insert or remove a
Micro SIM card. Insert or remove a Micro SIM card with your
smartphone on may damage your Micro SIM card or smartphone
permanently.
SIM2
SIM1
SIM2
SIM1
SIM2
Charging the battery
Low battery power Fully charged Charging
Your smartphone has a built-in rechargeable battery. For more
information about battery safety, see the “Built-in rechargeable
battery notice” section. The battery in this product cannot be easily
replaced by users themselves.
Charge the battery as shown.
Turning on or turning off your smartphone
Turn on: Press and hold the On/Off button until
the Lenovo logo appears.
Tur n of f: Press and hold the On/Off button for a
few seconds, then tap Power off.
Restart: Press and hold the On/Off button for
about 10 seconds.
Method 1.
Method 2.
Connect your smartphone to a power outlet using the
cable and USB power adapter that come with your
smartphone.
Connect your smartphone to a computer using the cable
that comes with your smartphone.
2
1
① Depending on the measuring method, the dimensions and weight
might vary slightly.
② In some countries, LTE is not supported. To know if your
smartphone works with LTE networks in your country, contact
your carrier.
Type: CMOS
Pixels: 13 megapixels (back) + 8 megapixels (front)
Processor: Qualcomm 8916
,
quad-core
,
1.2 GHz
Size: 5.0 inches
Resolution: 1280 × 720 pixels
Model: Lenovo S90-A
Bluetooth 4.0; WLAN 802.11 b/g/n;
②FDD-LTE/WCDMA/GSM; GPS
Battery: 2300 mAh
Height: 146 mm (5.75 inches)
Depth: 6.9 mm (0.27 inch)
Model and system
Display
Battery
Processor
①Dimensions and weight
Camera
Wireless communication
Technical specifications
System: Android
Width: 71.7 mm (2.82 inches)
Weight: 129 g (0.28 lb)
Screen: multi-touch
LCD type: S-AMOLED
Important regulatory, safety, and handling
information
This section contains important regulatory, safety, and handling
information for Lenovo smartphones. Additional safety and handling
information is provided in the User Guide. See the “Accessing your
User Guide” section for details.
Read rst — regulatory information
Be sure to read the Regulatory Notice for your country or region
before using the wireless devices contained in your Lenovo Mobile
Phone. To obtain a PDF version of the Regulatory Notice, see the
“Downloading publications” section. Regulatory information of India,
Malaysia, and Philippines is also available in Settings > About phone
> Regulatory information on your smartphone.
General battery notice
Batteries supplied by Lenovo for use with your product have been
tested for compatibility and should only be replaced with approved
parts. Risk of explosion if the battery is replaced with an incorrect
type. Dispose of used batteries according to the instructions.
Rechargeable battery notice
CAUTION: Risk of explosion if the battery is replaced with an incorrect
type.
When replacing the lithium battery, use only the same or an equivalent
type that is recommended by the manufacturer. The battery contains
lithium and can explode if not properly used, handled, or disposed of.
Dispose of used batteries according to the instructions.
Do not:
Throw or immerse into water
Heat to more than 100°C (212°F)
Repair or disassemble
Built-in rechargeable battery notice
CAUTION: Do not attempt to replace the internal rechargeable lithium
ion battery. Contact Lenovo Support for factory replacement.
Charging
Lenovo is not responsible for the performance or safety of products
not manufactured or approved by Lenovo. Use only approved
Lenovo ac adapters and batteries. Adapter shall be installed near the
equipment and shall be easily accessible.
Plastic bag notice
DANGER: Plastic bags can be dangerous. Keep plastic bags away
from babies and children to avoid danger of suffocation.
Prevent hearing damage
Lenovo Phone has a headphone connector. Always use the
headphone connector for headphones (also called a headset) or
earphones.
CAUTION: Excessive sound pressure from earphones and
headphones can cause hearing loss. Adjustment of the equalizer to
maximum increases the earphone and headphone output voltage and
the sound pressure level. Therefore, to protect your hearing, adjust
the equalizer to an appropriate level.
Excessive use of headphones or earphones for a long period of time
at high volume can be dangerous if the output of the headphone or
earphone connectors do not comply with specifications of EN
50332-2.
The headphone output connector of Lenovo Phone complies with EN
50332-2 Sub clause 7. This specification limits Lenovo Phone's
maximum wide band true RMS output voltage to 150 mV. To help
protect against hearing loss, ensure that the headphones or
earphones you use also comply with EN 50332-2 (Clause 7 limits) for
a wide band characteristic voltage of 75 mV. Using headphones that
do not comply with EN 50332-2 can be dangerous due to excessive
sound pressure levels.
If Lenovo Phone came with headphones or earphones in the
package, as a set, the combination of the headphones or earphones
and Lenovo Phone already complies with the specifications of EN
50332-1. If different headphones or earphones are used, ensure that
they comply with EN 50332-1 (Clause 6.5 Limitation Values). Using
headphones that do not comply with EN 50332-1 can be dangerous
due to excessive sound pressure levels.
Sound pressure warning statement
For the device that is tested in accordance with EN 60950-1:
2006+A11:2009:+A1:2010+A12:2011, it is mandatory to perform
audio tests for EN50332.
This device has been tested to comply with the Sound Pressure Level
requirement in the applicable EN 50332-1 and/or EN 50332-2
standards. Permanent hearing loss may occur if earphones or
headphones are used at high volume for prolonged periods of time.
Warning statement: To prevent possible hearing damage, do not listen
at high volume levels for long periods.
Operating temperature
Use Lenovo Phone only in the temperature range of -10°C (14 °F) —
40°C (104 °F) to avoid damage.
Polyvinyl Chloride (PVC) cable and cord notice
WARNING: Handling the cord on this product or cords associated
with accessories sold with this product will expose you to lead, a
chemical known to the State of California to cause cancer, and birth
defects or other reproductive harm. Wash hands after handling.
Disposing according to local laws and regulations
When Lenovo Phone reaches the end of its useful life, do not crush,
incinerate, immerse in water, or dispose of Lenovo Phone in any
manner contrary to local laws and regulations. Some internal parts
contain substances that can explode, leak, or have an adverse
environmental effect if disposed of incorrectly. See “
Recycling and
environmental information
” for additional information.
Eurasian compliance mark
Service, support, and warranty information
The following information describes the technical support that is
available for your product, during the warranty period or throughout
the life of your product. Refer to the Lenovo Limited Warranty for a full
explanation of Lenovo warranty terms.
Online technical support
Online technical support is available during the lifetime of a product at
http://www.lenovo.com/support.
Telephone technical support
Where applicable, you can get help and information from the
Customer Support Center by telephone. Before contacting a Lenovo
technical support representative, please have the following
information available: model and serial number, the exact wording of
any error message, and a description of the problem.
Your technical support representative might want to walk you through
the problem while you are at your phone during the call.
Worldwide Lenovo Support telephone list
IMPORTANT: Telephone numbers are subject to change without
notice. The most up-to-date telephone list for the Customer Support
Center is always available at
http://support.lenovo.com/serviceproviders
.
The Customer Support Center phone number is subjected to be
change, and please go to the e-support website for the latest phone
number. If the telephone number for your country or region is not
listed, contact your Lenovo reseller or Lenovo marketing
representative.
Lenovo Limited Warranty notice
Read the full Lenovo Limited Warranty (LLW) at
http://support.lenovo.com/smartphone-llw. You can view the LLW in
a number of languages from this Web site. If you cannot view the
LLW either from the Web site or from your phone, contact your local
Lenovo office or reseller to obtain a printed version of the full LLW.
IMPORTANT: Lenovo Smartphone Products do not have International
Warranty Services.
Recycling and environmental information
General recycling statement
Lenovo encourages owners of information technology (IT) equipment
to responsibly recycle their equipment when it is no longer needed.
Lenovo offers a variety of programs and services to assist equipment
owners in recycling their IT products. For information on recycling
Lenovo products, go to: http://www.lenovo.com/recycling.
Recycling information for India
Recycling and disposal information for India is available at:
http://www.lenovo.com/social_responsibility/us/en/sustainability/ptb_india.html
Important WEEE information
Electrical and electronic equipment marked with the
symbol of a crossed-out wheeled bin may not be disposed
as unsorted municipal waste. Waste of electrical and
electronic equipment (WEEE) shall be treated separately
using the collection framework available to customers for
the return, recycling, and treatment of WEEE.
Country-specific information is available at:
http://www.lenovo.com/recycling
Restriction of Hazardous Substances Directive (RoHS)
Turkish
The Lenovo product meets the requirements of the Republic of
Turkey Directive on the Restriction of the Use of Certain Hazardous
Substances in Waste Electrical and Electronic Equipment (WEEE).
India
RoHS compliant as per E-Waste (Management & Handling) Rules, 2011.
Ukraine
Atık Elektrikli ve
AEEE
AEEE
AEEE
Elektronik Eşya
Andere Handbücher für S90-A
5
Inhaltsverzeichnis
Andere Lenovo Handy Handbücher
Lenovo
Lenovo K900 Bedienungsanleitung
Lenovo
Lenovo A526 Bedienungsanleitung
Lenovo
Lenovo IDEAPHONE S720 Bedienungsanleitung
Lenovo
Lenovo A2010-l Bedienungsanleitung
Lenovo
Lenovo VIBE X2-AP Bedienungsanleitung
Lenovo
Lenovo K6 Bedienungsanleitung
Lenovo
Lenovo C2 POWERK10a40 Bedienungsanleitung
Lenovo
Lenovo S580 Bedienungsanleitung
Lenovo
Lenovo A690 Bedienungsanleitung
Lenovo
Lenovo VIBE P1m SERIES Bedienungsanleitung
Lenovo
Lenovo IDEAPHONE S720 Bedienungsanleitung
Lenovo
Lenovo VIBE P1 Bedienungsanleitung
Lenovo
Lenovo VIBE K4 Note Bedienungsanleitung
Lenovo
Lenovo Vibe Shot Z90a40 Bedienungsanleitung
Lenovo
Lenovo S856 Bedienungsanleitung
Lenovo
Lenovo S60 Bedienungsanleitung
Lenovo
Lenovo K900 Bedienungsanleitung
Lenovo
Lenovo Legion Phone Duel 2 Bedienungsanleitung
Lenovo
Lenovo VIBE P1m SERIES Bedienungsanleitung
Lenovo
Lenovo A7000-a Bedienungsanleitung
Beliebte Handy Handbücher anderer Marken
Point Mobile
Point Mobile PM60 Bedienungsanleitung
Blackbe;rry
Blackbe;rry Q10 Bedienungsanleitung
Blackbe;rry
Blackbe;rry Bold 9900 Bedienungsanleitung
Blackbe;rry
Blackbe;rry STORM 9500 - VERSION 5.0 Bedienungsanleitung
LG
LG LM-K420EMW Bedienungsanleitung
ISAFE MOBILE
ISAFE MOBILE IS655.2 Bedienungsanleitung
