ThinkPadOneLink+DockUserGuide

http://www.lenovo.com/safety

Note:eforeinstallingtheproduct,besuretoreadthewarrantyinformationinAppendix“LenovoLimited

Warranty”onpage23.

FirstEdition(August2015)

©CopyrightLenovo2015.

LIMITEDANDRESTRICTEDRIGHTSNOTICE:IfdataorsoftwareisdeliveredpursuantaGeneralServicesAdministration

“GSA”contract,use,reproduction,ordisclosureissubjecttorestrictionssetforthinContractNo.GS-35F-05925.

Contents

Chapter1.Aboutthedok.......1

Productdescription..............1

Locatingconnectorsandcontrolsonthedock...2

Systemrequirements.............4

Chapter2.Installingthedok......5

Connectingthedocktoyournotebookcomputer..5

InstallingthedevicedriveronWindowsoperating

systems..................5

InstallingupdatepackagesthroughSystem

Update...................6

Chapter3.Usingthedok.......7

Usingtheheadsetandmicrophonecombo

connector.................7

UsingtheUS3.0connectorwithbatterycharging

function..................7

UsingtheUSconnectors...........8

UsingtheGigabitEthernetconnector.......8

UsingtheDPandVGAconnectors........8

Chapter4.Workingwiththedok...9

Understandingthevideooutputmodes......9

Enteringavideooutputmode..........9

Enteringextendmode...........9

Enteringmirrormode..........10

Enteringsingle-displaymode.......11

Enteringthree-displaymode.......12

Manuallyenablingtheheadsetandmicrophone

comboconnector.............12

Rotatingtheexternalmonitordisplay......12

Settingthecolorqualityoftheexternalmonitor..14

Settingtheresolutionoftheexternalmonitor...14

Supportedresolutions............15

Chapter5.Troubleshooting......19

AppendixA.ServieandSupport...21

Onlinetechnicalsupport...........21

Telephonetechnicalsupport.........21

Accessibilityinformation...........21

AppendixB.LenovoLimited

Warranty................23

Part1-GeneralTerms...........23

Part2-Country-speciﬁcTerms........25

Part3-WarrantyServiceInformation......28

SuplementodeGarantíaparaMéxico......29

AppendixC.Eletroniemission

noties................31

FederalCommunicationsCommissionDeclaration

ofConformity...............31

AppendixD.Noties..........35

Recyclinginformation............35

RecyclinginformationforChina........35

Recyclinginformationforrazil........36

ExportClassiﬁcationNotice.........36

ImportantWEEEinformation.........36

Trademarks................36

AppendixE.RestritionofHazardous

SubstanesDiretive(RoHS).....39

EuropeanUnionRoHS...........39

ChinaRoHS................39

TurkishRoHS...............39

UkraineRoHS...............39

IndiaRoHS................40

©CopyrightLenovo2015i

iiThinkPadOneLink+DockUserGuide

Chapter1.Aboutthedok

Thischaptercontainsproductdescription,connectorandcontrollocations,andsystemrequirementsforthe

ThinkPad®OneLink+Dock(hereaftercalleddock).

Produtdesription

Thedockisaportableexpansionmodulethatenablesyoutoeasilyconnectyournotebookcomputertothe

Ethernetandmultipledevices,suchasaDisplayPort®(DP)orVideoGraphicsArray(VGA)monitor;aheadset

ormicrophone;andUniversalSerialus(US)devices.ThedockprovidesfourUS3.0connectorsfor

higherbandwidthandbetterperformance,andtwoUS2.0connectorsforcommonUSdevices.The

dockalsosupportsGigabitEthernetspeedwhenyouconnectittonetworks.

YoucansetupyourworkareabyconnectingyournotebookcomputertothedockwiththeOneLink+cable,

connectingmultipledevicestothedock,andsettingthedockonyournotebookcomputer;then,youare

readytousethemultipledeviceseachtimeyouconnectyournotebookcomputertothedock.

Youroptionpackageincludesthefollowing:

•ThinkPadOneLink+Dock

•Poweradapter

•Powercord

•Warrantyposter

Contactyourplaceofpurchaseifanyitemismissingordamaged.esuretoretainyourproofofpurchase

andpackingmaterial.Theymightberequiredtoreceivewarrantyservice.

©CopyrightLenovo20151

Loatingonnetorsandontrolsonthedok

Thefollowingillustrationhelpsyoulocatetheconnectorsandcontrolsonthedock.

Figure1.Overviewofthedock

1Powerbutton2US3.0connectorwithbatterychargingfunction

3US3.0connector4Headsetandmicrophonecomboconnector

5Powerindicator6Security-lockslot

7US2.0connector8DPconnectors

9GigabitEthernetconnector10US3.0connectors

11US2.0connector12VGAconnector

13Powerconnector14OneLink+cable

1Powerbutton

Thepowerbuttonisusedtoturnonorturnoffyournotebookcomputer,ortoputthenotebookcomputer

intosleeporhibernationmode.Toachievethis,youneedtochangethepowerplansettingsofyour

notebookcomputer.Formoreinformation,refertotheuserguidethatcomeswithyournotebookcomputer.

2USB3.0onnetorwithbatteryhargingfuntion

TheUS3.0connectorwithbatterychargingfunctionisusedtodothefollowing:

•ConnectingUSdevices(US1.0,US1.1,US2.0,andUS3.0compatible)

•Chargingdevicesevenwhenyournotebookcomputeristurnedoff,insleepmode,orinhibernation

mode;orwhenthedockisdisconnectedfromyournotebookcomputer

2ThinkPadOneLink+DockUserGuide

3USB3.0onnetor

TheUS3.0connectorisusedtoconnectUSdevices(US1.0,US1.1,US2.0,andUS3.0

compatible).

4Headsetandmirophoneomboonnetor

Theheadsetandmicrophonecomboconnectorisusedtoconnectaheadset,amicrophone,oraspeaker.

5Powerindiator

Thepowerindicatorisusedtoindicatethepowerstatusofthenotebookcomputerthatconnectswiththe

dock.

•Ifthepowerindicatorislitinred,itindicatesthatthenotebookcomputeristurnedon.

•Ifthepowerindicatorisoff,itindicatesthatyournotebookcomputeristurnedoff,insleepmode,orin

hibernationmode;orthedockisdisconnectedfromyournotebookcomputer.

6Seurity-lokslot

Thesecurity-lockslotisusedtosecurethedockwithasecuritycablelock.

Note:Thesecuritycablelockisnotincludedinyouroptionpackage.Ifnecessary,purchaseasecurity

cablelock.

7USB2.0onnetor

TheUS2.0connectorisusedtoconnectUSdevices(US1.0,US1.1,andUS2.0compatible).

Notes:

1.Whenusingakeyboardormousewiththedock,itisrecommendedthatyouconnectthekeyboard

cableormousecabletotheUS2.0connector(withthemouseandkeyboardsymbols)onthedock.

2.IfyouareusingaUS3.0device,itisrecommendedthatyouconnectittoaUS3.0connectorrather

thanUS2.0connectorforfasterUStransmissionspeed.

8DPonnetor

TheDPconnectorisusedtoconnectanexternalmonitortothedockusingaDPcable.

9GigabitEthernetonnetor

TheGigabitEthernetconnectorisusedtoconnectthedocktoanetworkusinganEthernetcable.

10USB3.0onnetors

TheUS3.0connectorsareusedtoconnectUSdevices(US1.0,US1.1,US2.0,andUS3.0

compatible).

11USB2.0onnetor

TheUS2.0connectorisusedtoconnectUSdevices(US1.0,US1.1,andUS2.0compatible).

12VGAonnetor

TheVGAconnectorisusedtoconnectaVGAmonitor.

Chapter1.Aboutthedock3

13Poweronnetor

Thepowerconnectorisusedtoconnectthepoweradapter.

Note:Thepowerinputratingofthedockis20Vand4.5A.

14OneLink+able

TheOneLink+cableisusedtoconnectthedocktoyournotebookcomputer.

CAUTION:Toavoidanyﬁredamage,ensurethatthenotebookcomputerconnectingtheOneLink+cable

meetseitherofthefollowingrequirements:

•TheﬂammabilityofthenotebookcomputerenclosureisnotlowerthanClassV-1.

•Thenotebookcomputerenclosureismetallic.

Systemrequirements

eforeusingthedock,ensurethatyournotebookcomputerhasoneofthefollowingoperatingsystems

installed:

•Microsoft®Windows®7

•MicrosoftWindows8.1

•MicrosoftWindows10

4ThinkPadOneLink+DockUserGuide

Chapter2.Installingthedok

Thischapterprovidesinstructionsonhowtoconnectthedocktoyournotebookcomputer,manuallyinstall

thedevicedriver,andinstallupdatepackagesthroughtheSystemUpdateprogram.

Connetingthedoktoyournotebookomputer

ThistopicprovidesinstructionsonhowtoconnectthedocktoyournotebookcomputerusingtheOneLink+

cablealongwiththepoweradapterandpowercord.

Note:Ensurethatyoucorrectlyconnectthedocktoanacpowersource.

Toconnectthedocktoyournotebookcomputer,dothefollowing:

1.Connectthepoweradaptertothepowercord1.

2.Connectthedc-inconnectorofthepoweradaptertothepowerconnectoronthedock2.

Note:Itisrecommendedtousethe90Wpoweradapterthatcomeswiththedock.

3.ConnecttheOneLink+cabletotheLenovo®OneLink+connectoronyournotebookcomputer3.

4.Connectthepowerplugofthepowercordtoanelectricaloutlet4.Thedockisreadyforuse.

Figure2.Connectingthedocktothepowersupplyandyournotebookcomputer

InstallingthedeviedriveronWindowsoperatingsystems

TheLenovonotebookcomputerwithOneLink+connectorhasthedockdevicedriverpreinstalled.Inthis

situation,thedockisreadyforuseafteryousuccessfullyconnectittoanacpowersourceandyournotebook

computer.Forthedetailedcomputermodelinformation,gotohttp://www.lenovo.com/support/docks

andclickThinkPadOneLink+Dok.

©CopyrightLenovo20155

ThelatestdevicedriverforthedockalsoisavailablefordownloadingfromtheLenovoWebsite.Go

tohttp://www.lenovo.com/support/docks,clickThinkPadOneLink+Dok,anddownloadthedriver

installationﬁle.Thenfollowtheinstructionsonthescreentoinstallthedevicedriver.

InstallingupdatepakagesthroughSystemUpdate

TheSystemUpdateprogram(preinstalledonsomenotebookcomputers)enablesyoutokeepthesoftware

onyourcomputerup-to-date.Youcaneasilydownloadandinstallvarioussystemupdatepackagesthrough

SystemUpdate,includingupdatesforthedockdriverandﬁrmware.

ToinstallupdatepackagesforthedockthroughSystemUpdate,dothefollowing:

FortheWindows7operatingsystem:

1.ClickStartandsearchSystemUpdateinthesearchbox.

2.LaunchSystemUpdateonthescreen.

3.ClickGetnewupdates.

4.SelectDriversforThinkPadOneLink+Doks,ThinkPadOneLink+DoksSynaptisFirmware,

orThinkPadOneLink+DoksVIAFirmware.

5.Followtheinstructionsonthescreentocompletetheinstallation.

FortheWindows8.1operatingsystem:

1.ClickStartandclickthearrowiconinthebottom-leftcornerofthescreentogototheAppsscreen.

2.LaunchSystemUpdateontheAppsscreen.

3.ClickGetnewupdates.

4.SelectDriversforThinkPadOneLink+Doks,ThinkPadOneLink+DoksSynaptisFirmware,

orThinkPadOneLink+DoksVIAFirmware.

5.Followtheinstructionsonthescreentocompletetheinstallation.

FortheWindows10operatingsystem:

1.Fromthedesktop,searchLenovoCompanioninthesearchboxonthetaskbar.

2.LaunchLenovoCompaniononthescreen.

3.ClickSYSTEMUPDATEandclickChekfornewupdates.

4.SelectDriversforThinkPadOneLink+Doks,ThinkPadOneLink+DoksSynaptisFirmware,

orThinkPadOneLink+DoksVIAFirmware.

5.Followtheinstructionsonthescreentocompletetheinstallation.

IftheSystemUpdateprogramisnotpreinstalledonyournotebookcomputer,goto

http://www.lenovo.com/support/docks,clickThinkPadOneLink+Dok,anddownloadtheupdate

packagesforthedockdriverandﬁrmware.

6ThinkPadOneLink+DockUserGuide
