Lenovo TAB3 7 Essential TB3-710F Bedienungsanleitung

Lenovo TAB3 7 Essential

User Guide

Lenovo TB3-710F

Lenovo TB3-710I

All information labeled with * in this guide only refers to the

WCDMA model (Lenovo TB3-710I).

Basics

Notes: Before using this information and the product it supports, be sure to

read the following:

Safety, Warranty & Quick Start Guide

Regulatory Notice

"Important safety and handling information" in "Appendix".

The

Safety, Warranty & Quick Start Guide

and the

Regulatory Notice

are

available on the website at http://support.lenovo.com.

Lenovo Companion

Looking for help? The Lenovo Companion app can offer you support for getting

direct access to Lenovo's web assistance and forums*, frequent Q&A*, system

upgrades*, hardware function tests, warranty status checks*, service

requests**, and repair status**.

Note:

* requires data network access.

** is not available in all countries.

You have two ways to get this app:

Search for and download the app from Google Play.

Scan the following QR code with a Lenovo Android device.

Technical specifications

Model Lenovo TB3-710F *Lenovo TB3-710I

CPU MTK MT 8127 *MTK MT 8321

Battery 3450 mAh 3450 mAh

Wireless

communication Bluetooth; WLAN;

GPS; Bluetooth; WLAN;

GPS; *WCDMA/GSM

Note: Lenovo TB3-710I supports GSM Band 2, 3, 5, 8 and WCDMA Band 1, 2, 5,

Home screen

The home screen is the starting point for using your device. For your

convenience, the home screen is already set up with some useful apps and

widgets.

NOTE: Your device features and the home screen may be different,

depending on your location, language, carrier, and device model.

You can customize your own home screen at any time.

Home screen

On the first home screen, there is a Google Search bar.

Preview screen

Tap and hold anywhere on the home screen except the icons.

At the bottom of the screen appear WALLPAPERS, LOCK SCREEN

WALLPAPER and WIDGETS.

Add a widget to a home screen

Tap at the bottom of the preview screen, tap and hold the widget you

want to add, then drag to where you want to place it and release.

Change the wallpaper

Go to Settings > Display > Wallpaper and choose the wallpaper that

you like.

Tap and hold anywhere on the home screen except the icons, select

WALLPAPERS at the bottom of the screen, and then choose the

wallpaper that you like.

Move an app to another screen

Tap and hold an app that you want to move, drag it to the left or right

side of the screen, then release it where you want to place it.

Screen buttons

There are three buttons at the bottom of the home screen.

Back button: Tap to return to the previous page.

Home button: Tap to return to the default home screen.

Recent button: Tap to see the recent apps. Then you can do the

following:

Tap an app to open it.

Tap to lock the app or tap to unlock it.

Tap to stop running the app.

Tap to stop running all the apps except the locked ones.

Notifications and Quick Settings

Swipe down from the top of the screen to view system notification messages

and quick settings. By tapping on switch, you can quickly turn a number of

frequently used functions on or off.

Force shutdown

Press and hold the On/Off button for more than 10 seconds until the screen

goes dark.

Camera

To open the Camera app, go to Camera.

Taking photos and videos

You can take photos and record videos with your device's built-in camera.

Tap to turn on the smile mode.

Tap to turn on/turn off the HDR mode.

Tap to switch between the front and the back camera.

Tap to take a photo.

Tap to record a video.

Tap to configure other camera settings.

Tap to use the Normal mode.

Tap to use the Live Photo mode.

Tap to use the Face beauty mode.

Tap to use the Panorama mode.

Tap to use the Multi angle view mode.

Tap to set the shooting effect.

Taking screenshots

Press and hold the On/Off button and the Volume down button at the same

time.

Viewing pictures and videos

Photos and videos are stored in your device's internal storage. You can view

your photos and videos by using the following methods:

Tap the photo review icon when using the Camera app.

Go to Gallery.

Screenshots are stored in your device's internal storage. You can view your

screenshots by Gallery.

Network

You need to set up a wireless network before connecting to the Internet.

Set up a WLAN network

*Set up a mobile network

Set up a VPN network

*You can also set up a hotspot to share your mobile network with others.

Setting up a WLAN network

Go to Settings > WLAN.

Turn on the WLAN and tap a WLAN hotspot in the list to connect to the

Internet. When you access a secure link, you need to enter your login name and

password to connect.

NOTE: You need to have a valid WLAN hotspot to connect to.

*Setting up a mobile network

Go to Settings > Data usage, tap CELLULAR and turn on Cellular data.

NOTE: You need a valid SIM card with a data service. If you don't have a SIM

card, contact your carrier.

Setting up a VPN network

VPNs used within organizations allow you to communicate private information

securely over a non-private network. You may need to configure a VPN, for

example, to access your work email. Ask the network’s administrator for the

settings necessary to configure a VPN for your network. When one or more VPN

settings are defined, you can:

Go to Settings > More > VPN.

Tap to edit the VPN profile, including the server name, the type and

the server address, and then tap SAVE.

Tap the VPN server name, enter the username and password, and then

tap CONNECT to connect to the VPN network.

Tap and hold the VPN server name to edit or delete the VPN.

*Setting up a hotspot

You can use personal hotspot to share an Internet connection with a computer

or other device.

Go to Settings > More > Tethering & portable hotspot and do the

following:

Turn on WLAN hotspot.

Tap Set up WLAN hotspot to configure the hotspot.

You can also use Bluetooth tethering and USB tethering.

NOTE: Tell your friends the Network SSID and password, and then they can

share your mobile network.
