Lenovo TB350FU Anleitung zur Verwendung

Lenovo

Tab P11 (2nd Gen)

Safety, Warranty &

Quick Start Guide

TB350FU

TB350XU

English/Français

Contents

English............................................................................................................1

Français.......................................................................................................19

................................................................................................................. 37

..............................................................................................................55

Reading before using your device

Reading ﬁrst - regulatory information

Device models equipped with wireless communications comply with the radio

frequency and safety standards of any country or region in which it has been

approved for wireless use. In addition, if your product contains a telecom modem,

it complies with the requirements for connection to the telephone network in your

country.

Be sure to read the Regulatory Notice for your country or region before using

the wireless devices contained in your device. To obtain a PDF version of the

Regulatory Notice, go to https://support.lenovo.com.

Getting support

To get support on network services and billing, contact your wireless network

operator. To learn how to use your device and view its technical speciﬁcations, go

to https://support.lenovo.com.

Accessing your User Guide

Your User Guide contains detailed information about your device. To download

the publications for your device, go to https://support.lenovo.com and follow the

instructions on the screen.

Legal notices

Lenovo and the Lenovo logo are trademarks of Lenovo in the United States, other

countries, or both.

Other company, product, or service names may be trademarks or service marks of

others.

Dolby, Dolby Atmos, and the double-D symbol are registered trademarks of Dolby

Laboratories Licensing Corporation. Manufactured under license from Dolby

LIMITED AND RESTRICTED RIGHTS NOTICE: If data or software is delivered

pursuant a General Services Administration “GSA” contract, use, reproduction, or

disclosure is subject to restrictions set forth in Contract No. GS-35F-05925.

English

Read this guide carefully before using your device.

All information labeled with * in this guide only refers to the WLAN + LTE model.

Device overview

Model Version

TB350FU WLAN

TB350XU WLAN + LTE

109

4 2 532

12 13

1Volume buttons 2Microphone 3Light/Proximity sensor

4Front-facing

camera 5Card tray 6Headset connector

7Speaker 8USB-C connector 9Touch screen

10 4-point pogo-pin smart connector (for the compatible keyboard and Smart

Charging Station)

11 Power button 12 Flashlight 13 Rear camera

All pictures and illustrations in this document are for your reference only and

may differ from the final product.

Preparing your device

Installing cards

Install the cards as shown in the ﬁgure.

microSD

SIM

microSD

• Power o the device before inserting or removing a card.

• The WLAN version does not have a Nano-SIM card slot.

Charging your device

Connect your device to a power

outlet using the USB cable and

power adapter provided.

Turning on

Press and hold the Power button until the

Lenovo logo appears.

Accessories (optional)

The accessories do not come with all models, and are sold separately.

Keyboard pack

Name Model

Lenovo Keyboard Pack for Tab P11 (2nd Gen) KB565U

1Keyboard connector 2Trackpad 3Pen case

4Hinge 5Kickstand

The keyboard layout may vary by country or region, please refer to the actual

product.

Attaching the Keyboard Pack

Make sure that the camera hole is aligned with the Tablet’s rear camera when

attaching the Stand Cover to the Tablet.

Opening and adjusting the Kickstand

You can adjust the Tablet angle by using the Stand Cover. Grasp either side of the

Kickstand and gently open it until you reach the desired angle.

1 2

To prevent damage, do not apply excessive pressure to the Stand Cover or

force the Kickstand beyond its natural range of motion.

Using the device

You can use your device in these two modes:

With the keyboard via a pogo pin Without the keyboard

Storing the pen

Push up to open the pen case and then store the pen in the pen case.

1 2

• DonotovertiltorapplyexcessivepressuretotheStandCover,doingsomay

damage the hinges.

• TheTablet,KeyboardandStandCoverallcontainmagneticmaterials.Toavoid

loss of magnetism, avoid exposing the Tablet, Keyboard and Stand Cover to

high temperatures or direct sunlight.

• Topreventdemagnetizationofcreditcardsandotheritemswithmagneticdata,

keep them away from the Tablet, Keyboard and Stand Cover.

• Don’tuseyourdeviceintemperaturesbelow0°Corabove40°C.

• Don’tstoreortransportyourdeviceintemperaturesbelow-20°Corabove

60°C.

Charging the pen

1. Remove the pen cap in the

direction shown in the ﬁgure.

2. Connect the pen to a charger

with a USB-C cable.

3. Replace the pen cap on the

pen. You can start to use the

pen after charging.

1 2 3

Lenovo Precision Pen 2 (2023)

You can use Lenovo Precision Pen 2 (2023) in place of your ﬁngers for a better

experience, such as working with speciﬁc applications to write or draw on the screen.

Name Model

Lenovo Precision Pen 2 (2023) Lenovo LP-151

Overview

1Pen cap

2Indicator LED

3Upper button

4Lower button

5Tip

• The indicator light will have an amber glow while charging the pen and a

white glow after it is fully charged.

• Please be cautious when using the pen. The pen contains sensitive electronic

components. Dropping it may cause damage.

Replacing the tip

1.Pinchthetipwithtweezersoranothersuitabletool.

2. Remove the tip.

3. Install the stand-by tip (supplied).

Using the Pen

1. Hold the pen close to the tablet until a white dot appears on the screen.

2. Use the upper and lower button functions of the pen.

Using the pen on a coated screen may interfere with the pen-writing experience.

If your pen is not responsive, please try switching pen protocols. Hold both buttons

consecutively for 25 seconds to switch between pen protocols (WGP& AES).
