Tab 3 Pro 10”

Safety, Warranty & Quick Start Guide

Lenovo YT3–X90F

Lenovo YT3–X90L

Lenovo YT3–X90X

English/Polski

Read before using your tablet

Read ﬁrst-Regulatory information

Device models equipped with wireless communications comply with the radio frequency

and safety standards of any country or region in which it has been approved for wireless

use. In addition, if your product contains a telecom modem, it complies with the

requirements for connection to the telephone network in your country.

Be sure to read the Regulatory Notice for your country or region before using the

wireless devices contained in your device. To obtain a PDF version of the Regulatory

Notice, refer to the “Downloading publications” section below.

Getting support

To get support on network service and billing, contact your wireless network operator.

To learn how to use your tablet and view its technical speciﬁcations, go to

http://support.lenovo.com/.

Downloading publications

Electronic versions of your publications are available from http://support.lenovo.com. To

download the publications for your tablet, go to http://support.lenovo.com and follow the

instructions on the screen.

Accessing your User Guide

Your User Guide contains detailed information about your tablet. To access your User

Guide, use one of the following methods:

• Go to http://support.lenovo.com and follow the instructions on the screen.

• Start your device, access the User Guide app.

Legal notices

Lenovo and the Lenovo logo are trademarks of Lenovo in the United States, other

countries, or both.

Other company, product, or service names may be trademarks or service marks of

others.

Manufactured under license from Dolby Laboratories. Dolby, Dolby Atmos, and the

double-D symbol are trademarks of Dolby Laboratories.

LIMITED AND RESTRICTED RIGHTS NOTICE: If data or software is delivered pursuant

a General Services Administration “GSA” contract, use, reproduction, or disclosure is

subject to restrictions set forth in Contract No. GS-35F-05925.

Read this guide carefully before using your tablet.

All information labeled with * in this guide refers only to the LTE model

(Lenovo YT3–X90L, Lenovo YT3–X90X).

English

Contents

YOGA TAB 3 PRO 10” Overview......................................................................... 1

Preparing your tablet........................................................................................... 2

Starting to use your tablet................................................................................... 3

Using the projector.............................................................................................. 4

Important safety and handling information ......................................................... 5

European Union Compliance Statement............................................................. 6

Service and Support information ........................................................................ 7

Warranty information ........................................................................................... 8

Environmental, recycling, and disposal information............................................ 9

YOGA TAB 3 PRO 10” Overview

Model Version

Lenovo YT3–X90F WLAN

Lenovo YT3–X90L

Lenovo YT3–X90X LTE

121

101

1Front camera 2Volume button 3Micro USB

4On/Off button 5Speakers 6Earphone jack

7Projector On/Off button 8Kickstand 9Hang mode hole

10 *Micro SIM card slot 11 Micro SD card slot 12 Kickstand release button

13 Projector lens 14 Rear camera

The WLAN model (Lenovo YT3–X90F) does not have a Micro SIM card slot.

Preparing your tablet

You can use cellular services with the WLAN + LTE models (Lenovo YT3–X90L

and Lenovo YT3–X90X) by inserting the Micro SIM card that was provided by your

carrier.

Install the Micro SIM and Micro SD cards as shown.

Micro

SIM

Micro

SIM

Step 1. Press the kickstand release

button to release the

kickstand.

Step 2. Open the card slot cover.

Insert the Micro SIM and

Micro SD cards, and then

replace the card slot cover.

Step 3. Push back the kickstand.

This tabet only supports Micro SIM cards.

!!! DO not insert or remove the Micro SIM card while your tablet is turned on. Doing so

can permanently damage your Micro SIM card or tablet.

Starting to use your tablet

You might need to charge the battery before using your tablet.

Charge the battery as shown.

Connect your tablet to a power outlet using the included cable and USB power

adapter.

Low battery Fully charged Charging

Turning on/off

Turn on: Press and hold the On/Off button until the

Lenovo logo appears.

Turn off: Press and hold the On/Off button for a few

seconds, then tap Power off.

Taking screenshots

Press and hold the On/Off and volume down buttons at the same time.

!!! DO not insert your ﬁnger into the hang mode hole. Doing so might hurt your ﬁnger.

Using the projector

Use the projector feature as shown.

Step 1. Lay the tablet on its back

and adjust the kickstand to

a suitable angle.

Step 2. Press and hold the projector

On/Off button to turn it on.

Step 3. When the projector is no

longer in use, press and hold

the projector On/Off button to

turn it off.

Important safety and handling information

Plastic bag notice

DANGER: Plastic bags can be dangerous. Keep plastic bags away from babies and

children to avoid danger of suffocation.

Built-in rechargeable battery notice

Do not attempt to replace the internal rechargeable lithium ion battery. Risk of explosion

if the battery is replaced with an incorrect type. Contact Lenovo Support for factory

replacement.

Polyvinyl Chloride (PVC) cable and cord notice

WARNING: Handling the cord on this product or cords associated with accessories sold

with this product will expose you to lead, a chemical known to the State of California to

cause cancer, and birth defects or other reproductive harm. Wash hands after handling.

Prevent hearing damage

Your device has a headphone connector. Always use the headphone connector for

headphones (also called a headset) or earphones.

CAUTION: Excessive sound pressure from earphones and headphones can cause

hearing loss. Adjustment of the equalizer to maximum increases the earphone and

headphone output voltage and the sound pressure level. Therefore, to protect your

hearing, adjust the equalizer to an appropriate level.

Excessive use of headphones or earphones for a long period of time at high volume can

be dangerous if the output of the headphone or earphone connectors do not comply with

speciﬁcations of EN 50332-2.

The headphone output connector of your device complies with EN 50332-2 Sub clause 7.

This speciﬁcation limits the device’s maximum wide band true RMS output voltage to

150 mV. To help protect against hearing loss, ensure that the headphones or earphones

you use also comply with EN 50332-2 (Clause 7 limits) for a wide band characteristic

voltage of 75 mV. Using headphones that do not comply with EN 50332-2 can be

dangerous due to excessive sound pressure levels.

If your device came with headphones or earphones in the package, as a set, the

combination of the headphones or earphones and the device already complies with the

speciﬁcations of EN 50332-1. If different headphones or earphones are used, ensure that

they comply with EN 50332-1 (Clause 6.5 Limitation Values). Using headphones that do

not comply with EN 50332-1 can be dangerous due to excessive sound pressure levels.

Sound pressure warning statement

For the device that is tested in accordance with EN 60950-1:

2006+A11:2009+A1:2010+A12:2011, it is mandatory to perform audio tests for

EN 50332.

This device has been tested to comply with the Sound Pressure Level requirement laid

down in the applicable EN 50332-1 and/or EN 50332-2 standards. Permanent hearing

loss may occur if earphones or headphones are used at high volume for prolonged

periods of time.

Warning statement: To prevent possible hearing damage, do not listen at high volume

levels for a long period of time.

European Union Compliance Statement

Radio and Telecommunications Terminal Equipment Directive

Lenovo declares that this product is in compliance with:

• The essential requirements and other relevant provisions of the Radio and

Telecommunications Terminal Equipment Directive, 1999/5/EC

• All other relevant EU directives

The Declaration of Conformity information is located in the Regulatory Notice. To obtain

a PDF version of the Regulatory Notice, go to http://support.lenovo.com/.

0560

Service and Support information

The following information describes the technical support that is available for your

product, during the warranty period or throughout the life of your product. Refer to the

Lenovo Limited Warranty for a full explanation of Lenovo warranty terms. See “Lenovo

Limited Warranty notice” later in this document for details on accessing the full warranty.

Online technical support

Online technical support is available during the lifetime of a product at:

http://www.lenovo.com/support

Telephone technical support

You can get help and information from the Customer Support Center by telephone.

Before contacting a Lenovo technical support representative, please have the following

information available: model and serial number, the exact wording of any error message,

and a description of the problem.

Your technical support representative might want to walk you through the problem while

you are at your device during the call.

Worldwide Lenovo Support telephone list

Important: Telephone numbers are subject to change without notice. The most up-to-

date telephone list for the Customer Support Center is always available at:

http://www.lenovo.com/support/phone

If the telephone number for your country or region is not listed, contact your Lenovo

reseller or Lenovo marketing representative.
