Levoit VeSync Core™ 600S

Smart True HEPA Air Puriﬁer

Product Series: Core 600S

Model: LAP-C601S-WEU

USER MANUAL

Questions or Concerns?

[email protected]

EN  DE  FR  ES  IT

Package Contents

Speciﬁcations

Safety Information

Getting to Know Your Smart Air Puriﬁer

Controls & Display

Getting Started

Using Your Smart Puriﬁer

About the Filter

Care & Maintenance

Troubleshooting

VeSync App Troubleshooting

Warranty Information

Customer Support

Inhaltsverzeichnis

Table des matières

Índice

Indice

Table of Contents

EN  ENGLISH ES  ESPAÑOL

IT  ITALIANO

DE  DEUTSCH

FR  FRANÇAIS

Lieferumfang

Technische Daten

Sicherheitshinweise

Ihr Smart-Luftreiniger

Bedienungstasten und Display

Erste Schritte

Der Gebrauch Ihres Smart Luftreinigers

Informationen zum Filter

Pﬂege und Wartung

Problemlösung

VeSync App Problembehebung bei Fehlern

Garantie

Kundendienst

Contenu du paquet

Caractéristiques techniques

Consignes de sécurité

Prise en main de votre puriﬁcateur d’air

intelligent

Commandes et achage

Prise en main

Utilisation de votre puriﬁcateur intelligent

À propos du ﬁltre

Entretien et maintenance

Dépannage

Dépannage de l’application VeSync

Informations relatives à la garantie

Service client

Contenido de la caja

Especiﬁcaciones

Información de seguridad

Componentes del puriﬁcador de aire

inteligente

Controles y pantalla

Primeros pasos

Usar el puriﬁcador de aire inteligente

El ﬁltro

Cuidado y mantenimiento

Solución de problemas

Solución de problemas de la aplicación

VeSync

Información sobre la garantía

Atención al Cliente

Contenuto della confezione

Speciﬁche

Informazioni di sicurezza

Componenti del puriﬁcatore d’aria smart

Comandi e display

Preparazione

Uso del puriﬁcatore d’aria smart

Il ﬁltro

Cura e manutenzione

Risoluzione dei problemi

Risoluzione dei problemi dell’app VeSync

Informazioni sulla garanzia

Assistenza Clienti

100

102

104

106

107

Package Contents

1 ×Smart Air Puriﬁer

1 ×True HEPA 3-Stage Original Filter (Pre-Installed)

1 ×User Manual

1 ×Quick Start Guide

Specifications

Power Supply AC 220–240V, 50/60Hz

Rated Power 49W

Ideal Room Size 147 m / 1588 ft

Note:

• Eective for larger rooms, but puriﬁcation will take

longer.

• Ideal Room Size is based on 2 air changes per

hour (ACH).

CADR (CFM) 697 m/h / 410 CFM

Operating

Conditions

Temperature: 10°40°C / 14°104°F

Humidity: < 85% RH

Noise Level 2655dB

Dimensions 31.3 x 31.3 x 60 cm / 12.3 x 12.3 x 23.6 in

Weight 6.2 kg / 13.7 lb

Wi-Fi® Frequency Range 2412–2472MHz

E.I.R.P.: < 17dBm

Bluetooth® Frequency Range 2402–2480MHz

E.I.R.P.: < 7dBm

Note: To access additional smart functions, download the free VeSync app (see page 10).

ENGLISH

User Manual

Levoit VeSync Core™ 600S Smart True HEPA Air Purifier

Model: LAP-C601S-WEU

SAFETY INFORMATION

• Only use your air puriﬁer as described in this

manual.

• Do not use without removing the plastic wrap from

the ﬁlter. The air puriﬁer will not ﬁlter air, and may

overheat, causing a ﬁre hazard.

• Do not use the air puriﬁer outdoors.

• Keep the air puriﬁer away from water, and wet or

damp areas. Never place in water or liquid.

• Do not use in excessively humid areas.

• Keep the air puriﬁer away from heat sources.

• Do not use where combustible gases, vapours,

metallic dust, aerosol (spray) products, or fumes

from industrial oil are present.

• Keep 1.5 m / 5 ft away from where oxygen is

being administered.

• Supervise children when they are near the air

puriﬁer. Do not allow children to play with the

air puriﬁer.

• Do not place anything into any opening in the

air puriﬁer.

• Do not sit on or place heavy objects on the air

puriﬁer.

• Keep the inside of the air puriﬁer dry. To prevent

moisture buildup, avoid placing in rooms with

major temperature changes or underneath air

conditioners.

• Always unplug the air puriﬁer before servicing

(such as changing the ﬁlter).

• Do not use the air puriﬁer if it is damaged or

not working correctly, or if the cord or plug is

damaged. Do not try to repair it yourself. Contact

Customer Support (see page 23).

• WARNING: To reduce the risk of ﬁre or electric

shock, do not use this air puriﬁer with any solid-

state speed controls (such as a dimmer switch).

To reduce the risk of ﬁre, electric shock, or other injury, follow all instructions and safety guidelines.

General Safety

READ AND SAVE THESE

INSTRUCTIONS

• Children should not clean or perform maintenance

on the air puriﬁer without supervision.

• This air puriﬁer can be used by children 8 years

and older as well as persons with reduced physical,

sensory, or mental capabilities or lack of experience

and knowledge if they have been given supervision

or instruction concerning use of the air puriﬁer in a

safe way and understand the hazards involved.

• Not for commercial use. Household use only.

• Keep the air puriﬁer near the outlet it is plugged into.

• Never place the cord near any heat source.

• Do not cover the cord with a rug, carpet, or other

covering. Do not place the cord under furniture

or appliances.

• Keep the cord out of areas where people walk often.

Place the cord where it will not be tripped over.

• If the power supply cord is damaged, it must

be replaced by Arovast Corporation or similarly

qualiﬁed persons in order to avoid an electric or

ﬁre hazard. Please contact Customer Support

(see page 23).

• Unplugging the power cord will disable remote

control of the air puriﬁer and temporarily

disconnect the air puriﬁer from VeSync and other

third-party apps.

Electromagnetic Fields (EMF)

Your Levoit air puriﬁer complies with all standards

regarding electromagnetic ﬁelds (EMF). If handled

properly and according to the instructions in this

user manual, the appliance is safe to use based on

scientiﬁc evidence available today.

Power & Cord

SAFETY INFORMATION CONT.

This symbol means the product must not be discarded as household waste, and

should be delivered to an appropriate collection facility for recycling. Proper disposal

and recycling helps protect natural resources, human health and the environment.

For more information on disposal and recycling of this product, contact your local

municipality, disposal service, or the shop where you bought this product.

This product is RoHS compliant.

This product is in compliance with Directive 2011/65/EU, and its amendments,

on the restriction of the use of certain hazardous substances in electrical and

electronic equipment.

GETTING TO KNOW YOUR SMART AIR PURIFIER

A. Fan Speed Indicators

B. Fan Speed Button

C. Sleep Mode Button

D. Air Quality Indicator Rings

E. Check Filter Indicator Reset Button

F. Light Sensor

G. Timer Button

H. On/O Button

I. Check Filter Indicator

J. Wi-Fi® Indicator

K. Auto Mode Button

L. Display Lock Indicator

M. Display O Button

N. PM2.5/Timer Display

O. Display Lock Button

P. Air Outlets

Q. AirSight Plus™ Laser Dust Sensor

R. Air Inlets

S. Air Puriﬁer Top

T. True HEPA 3-Stage Original Filter

U. Air Puriﬁer Bottom

V. Anti-Skid Pads

CONTROLS & DISPLAY

On/O Button

• Turns the air puriﬁer on/o.

• Press and hold for 5

seconds to conﬁgure the

air puriﬁer. See the VeSync

in-app instructions for more

information.

• Press and hold for 15 seconds

to reset the air puriﬁer and

disconnect from Wi-Fi (see

page 10).

Wi-Fi Indicator

• Turns on, o, or blinks to

indicate pairing status. See the

VeSync in-app instructions for

more information.

Fan Speed Button

• Cycles through fan speeds:

low (1 indicator will light up),

medium (2 indicators), high (3

indicators), and turbo

(4 indicators).

• Tapping the Fan Speed Button

while the air puriﬁer is in Auto

Mode or Sleep Mode (if the

display is on) will exit that

mode.

Sleep Mode Button

• Turns Sleep Mode on/o (see

page 11).

Light Sensor

• When Light Detection is turned

on in the VeSync app, this sensor

detects the amount of light in the

room to automatically adjust air

puriﬁer settings (see page 14).

Timer Button

• Cycles through timer options

(see page 13).

• Press and hold for 2

seconds to begin cycling

through the timer options in

1-hour increments.

Auto Mode Button

• Turns Auto Mode on/o (see

page 12).

Air Quality Indicator Rings

• These indicators use an

automatic sensor to display

the air quality: Blue (Very

Good), Green (Good), Orange

(Moderate), and Red (Bad).

Note: You can also use the VeSync app to control these functions, as well as additional app-only features

(see page 15).

Display Lock Button

• Prevents current settings from

being changed (see page 13).

Press and hold for 3 seconds

to turn Display Lock on/o.

• The Display Lock Indicator (

) will blink when any other

button is tapped to indicate

that Display Lock is on.

Check Filter Indicator Reset

Button

• Press and hold for 3 seconds

to reset the Check Filter

Indicator.

• The Check Filter Indicator

( ) lights up when the ﬁlter

should be checked (see page

18).

Display O Button

• Turns the display o

(see page 13).

• Tap any button (except ) to

turn the display back on.

USING YOUR PURIFIER CONT.

3. Place the top half of the air puriﬁer

directly back onto the bottom half of the

air puriﬁer, aligning each corner. Press

down to snap the top into place.

[Figure 1.3]

a. The top of the air puriﬁer can face in

any direction, as long as the corners

align.

Figure 1.4

38 cm /

15 in

GETTING STARTED

1. Place the air puriﬁer on a ﬂat, stable

surface with the display facing up.

Twist the top half of the air puriﬁer

anticlockwise and lift up to remove it.

[Figure 1.1]

Figure 1.1

Figure 1.2

2. Remove the ﬁlter from inside the

bottom half of the air puriﬁer. Remove

the plastic packaging from the ﬁlter

and place the ﬁlter back into the air

puriﬁer. [Figure 1.2]

4. When using the air puriﬁer, allow at

least 38 cm / 15 inches of clearance on

all sides. Keep away from anything that

would block airﬂow, such as curtains.

[Figure 1.4]

Figure 1.3

38 cm /

15 in

Note: You must create your own VeSync account

to access voice assistants.

• To disconnect Wi-Fi, press and hold the

On/O button for 15 seconds until the

Wi-Fi indicator turns o. This will restore

the smart air puriﬁer’s default settings and

disconnect it from the VeSync app.

• To reconnect, please follow the

instructions in the VeSync app for adding

a device.

You can use the VeSync app to connect

your smart air puriﬁer to Amazon Alexa or

Google Assistant™. Please follow the in-app

instructions to set up your voice assistant.

Wi-Fi Connection:

Connect with Amazon Alexa or

Google Assistant™

Note: The VeSync app is continually being

improved and may change over time. If there are

any dierences, follow the in-app instructions.

Note: For Android™ users, choose “Allow” to

use VeSync.

Note: You must create your own VeSync

account to use third-party services and

products. These will not work with a guest

account. With a VeSync account, you can

also allow your family and friends to control

your smart air puriﬁer.

Note: Your phone must have Location

turned on while your phone is connecting to

your smart air puriﬁer. This is required to

establish the Bluetooth® connection. You

can turn Location o after your smart

air puriﬁer is ﬁnished connecting to

the VeSync app.

1. To download the VeSync app, scan the

QR code or search “VeSync” in the Apple

App Store® or Google Play Store.

VeSync App Setup

2. Open the VeSync app. Log In or

3. Follow the in-app instructions to set up

your smart air puriﬁer.

GETTING STARTED CONT.

Andere Handbücher für VeSync Core 600S Series

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Sprachen:

Andere Levoit Luftreiniger Handbücher

Levoit

Levoit HERA LAP-C302S-WUSB Bedienungsanleitung

Levoit

Levoit Vital 100S Bedienungsanleitung

Levoit

Levoit Core 200S Bedienungsanleitung

Levoit

Levoit LV-H132 Bedienungsanleitung

Levoit

Levoit Vista 200-RXW Bedienungsanleitung

Levoit

Levoit Core 200S Bedienungsanleitung

Levoit

Levoit Tower Pro True HEPA Bedienungsanleitung

Levoit

Levoit LV-PUR131 Bedienungsanleitung

Levoit

Levoit VeSync Core 600S Series Bedienungsanleitung

Levoit

Levoit LV-H132 Bedienungsanleitung

Levoit

Levoit Core LAP-C161-WAS Bedienungsanleitung

Levoit

Levoit Vital 100 Bedienungsanleitung

Levoit

Levoit Classic 300S Bedienungsanleitung

Levoit

Levoit LV-H126 Bedienungsanleitung

Levoit

Levoit Core 300 Bedienungsanleitung

Levoit

Levoit EverestAir LAP-EL551S-AUS Bedienungsanleitung

Levoit

Levoit Core P350-RAC Bedienungsanleitung

Levoit

Levoit LV-PUR131 Bedienungsanleitung

Levoit

Levoit LV-PUR131S Bedienungsanleitung

Levoit

Levoit LV-H13EU Bedienungsanleitung

Levoit

Levoit Core 300 Bedienungsanleitung

Levoit

Levoit Core 400S Series Bedienungsanleitung

Levoit

Levoit LV-H135-RWH Bedienungsanleitung

Levoit

Levoit LV-H133 Bedienungsanleitung

Beliebte Luftreiniger Handbücher anderer Marken

IKEA

IKEA UPPÅTVIND Bedienungsanleitung

Nash

Nash AP-1 PureSmart Bedienungsanleitung

LG PH-U450 Series Bedienungsanleitung

DeLonghi

DeLonghi DDSX 220WFA Bedienungsanleitung

Mitsubishi Electric

Mitsubishi Electric MA-E85R-E Bedienungsanleitung

Sharp

Sharp FU-40SE Bedienungsanleitung

Philips

Philips AC2721 Bedienungsanleitung

Hitachi

Hitachi EP-A3000 Bedienungsanleitung

TruSens

TruSens Z-2000 Bedienungsanleitung

Motorola

Motorola MBP87SN Bedienungsanleitung

Beko

Beko ATP 7100I Bedienungsanleitung

Carrier

Carrier INFINITY 1620 Bedienungsanleitung

AtmosAir

AtmosAir P2002 Bedienungsanleitung

Winix

Winix NK300 Bedienungsanleitung

Friedrich

Friedrich C-90A Bedienungs- und Montageanleitung

Surgically Clean Air

Surgically Clean Air JADE2.0 Bedienungsanleitung

Base aire

Base aire 555 Pro Bedienungsanleitung

Champion

Champion CP25 Bedienungsanleitung
