LEXIBOOK RCD100DC Bedienungsanleitung

QUICK REFERENCE

Disney Elements © Disney

The Quick Reference guide is given to provide basic operation of the unit.

Please completely read the user’s guide to take advantage of all the features

this unit has to offer.

TO LISTEN TO THE RADIO:

1. For best sound quality, extend both speakers outward.

2. Slide the OFF/ON switch to ON to turn the unit on.

3. Slide the FUNCTION switch to select AM or FM.

4. Tune a desired station by rotating the TUNING control.

5. Adjust the VOLUME control as desired.

6. To turn the unit off, slide the OFF/ON switch to OFF.

TO PLAY A CD:

1. For best sound quality, extend both speakers outward.

2. Slide the OFF/ON switch to ON to turn the unit on.

3. Slide the FUNCTION switch to the CD position.

4. With a CD inserted, press the PLAY/PAUSE (®p)button to start playback.

5. Adjust the VOLUME control as desired.

CONTINUED ON THE NEXT PAGE

6. To skip forward or backward through the tracks on the disc, press the

Skip/Search oor nbutton. To search forward or backward through a specif-

ic track on the disc, press and hold the Skip/Search oor nbutton.

7. When the disc is through playing, it will stop. Press the Stop (■)button to

stop the disc before it is ﬁnished.

8. To turn the unit off, slide the OFF/ON switch to OFF.

TO PLAY BACK THE TRACKS RANDOMLY

1. To play the tracks on the CD in a random order, simply press the RANDOM but-

ton. If you are in the Stop mode, you will also need to press the PLAY/PAUSE

(®p)button to start playback.

2. To cancel Random play, press the RANDOM button again.

TO REPEAT PLAY BACK ONE TRACK/ALL TRACKS:

1. Follow steps 1 to 3 in the TO PLAY A CD section on the previous page.

2a.ONE TRACK REPEAT: Select a track using the Skip/Search oor nbutton.

Press the REPEAT ( ) button once, " " will blink in the display. Press the

PLAY/PAUSE (®p)button and the unit will play the selected track over and

over until the Stop (■)button is pressed.

2b.ALL TRACKS REPEAT: Press the REPEAT ( ) button twice, " " will light

solid in the display. Press the Play/Pause (®p)button and the unit will play all

tracks on the CD over and over until the Stop (■)button is pressed.

3. To cancel Repeat play, repeatedly press the REPEAT ( ) button until " "

disappears from the display.

QUICK REFERENCE (CONTINUED)

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT

REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE.

REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

Caution Marking is located at the bottom

enclosure of the unit.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

DANGEROUS VOLTAGE:

The lightning ﬂash with arrowhead symbol within an equilateral triangle is intended to alert the

user to the presence of uninsulated dangerous voltage within the product’s enclosure that may

be of sufficient magnitude to constitute a risk of electric shock to persons.

ATTENTION:

The exclamation point within an equilateral triangle is intended to alert the user to the

presence of important operating and maintenance (servicing) instructions in the literature

accompanying the appliance.

DANGER:

This product utilizes a Class 1 laser to read Compact Discs. This laser Compact Disc Player

is equipped with safety switches to avoid exposure when the CD door is open and the safe-

ty interlocks are defeated. Invisible and hazardous laser radiation when open and interlock

failed or defeated. Avoid direct exposure to beam. Please do not attempt to defeat or bypass

the safety switches.

SAFETY PRECAUTIONS

● 10cm minimum distances around the apparatus for sufficient ventilations

● the ventilation should not be impeded by covering the ventilation openings

with items such as newspaper,table-cloths, curtains etc

● no naked flame sources such as lighted candles should be placed on the

apparatus;

● attention should be drawn to the environmental aspects of battery disposal;

● the use of apparatus in moderate climates

The marking plate and

WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT

EXPOSE THIS UNIT TO RAIN OR MOISTURE.

LASER SAFETY: This unit employs a laser. Only qualified service personnel

should attempt to service this device due to possible eye injury.

CAUTION: USE OF CONTROLS, ADJUSTMENTS OR PERFORMANCE

PROCEDURE HEREIN MAYRESULT IN HAZARDOUS RADIATION

EXPOSURE.

INFORMATION:

This equipment has been tested and found to comply with the limits for a Class

Bdigital device, pursuant to Part 15 of the FCC Rules. These limits are

designed to provide reasonable protection against harmful interference in a

residential installation. This equipment generates, uses and can radiate radio

frequency energy and, if not installed and used in accordance with the

instructions, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular

installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off and

on, the user is encouraged to try to correct the interference by one or more of

the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which

the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

ATTENTION:

POUR ÉVITER LES CHOC ÉLECTRIQUES, INTRODUIRE LA LAME LA PLUS

LARGE DE LA FICHE DANS LA BORNE CORRESPONDANTE DE LA PRISES

ET POUSSER JUSQU’AU FOND.

This Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe B est conforme à la norme NMB-003

du Canada.

SAFETY PRECAUTIONS

Dear Customer:

Selecting fine audio equipment such as the unit you’ve just purchased is only the start of

your musical enjoyment. Now it’s time to consider how you can maximize the fun and

excitement your equipment offers. This manufacturer want you to get the most out of your

equipment by playing it at a safe level. One that lets the sound come through loud and

clear without annoying blaring or distortion and, most importantly, without affecting your

sensitive hearing.

Sound can be deceiving. Over time your hearing “comfort level” adapts to higher volumes

of sound. So what sounds “normal” can actually be loud and harmful to your hearing. Guard

against this by setting your equipment at a safe level BEFORE your hearing adapts.

To establish a safe level:

• Start your volume control at a low setting.

• Slowly increase the sound until you can hear it comfortably and clearly, and without dis-

tortion.

Once you have established a comfortable sound level:

• Set the dial and leave it there.

Taking a minute to do this now will help to prevent hearing damage or loss in the future.

After all, we want you listening for a lifetime.

We Want You Listening For A Lifetime

Used wisely, your new sound equipment will provide a lifetime of fun and enjoyment. Since

hearing damage from loud noise is often undetectable until it is too late, this manufacturer

and the Electronic Industries Association’s Consumer Electronics Group recommend you

avoid prolonged exposure to excessive noise. This list of sound levels is included for your

protection.

Decibel

Level Example

30 Quiet library, soft whispers

40 Living room, refrigerator, bedroom away from traffic

50 Light traffic, normal conversation, quiet office

60 Air conditioner at 20 feet, sewing machine

70 Vacuum cleaner, hair dryer, noisy restaurant

80 Average city traffic, garbage disposals, alarm clock at two feet

THE FOLLOWING NOISES CAN BE DANGEROUS UNDER CONSTANT EXPOSURE:

90 Subway, motorcycle, truck traffic, lawn mower

100 Garbage truck, chain saw, pneumatic drill

120 Rock band concert in front of speakers, thunderclap

140 Gunshot blast, jet engine

180 Rocket launching pad

Information courtesy of the Deafness Research Foundation.

EST. 1924

EIA

LISTENING

For A Lifetime

Want You

Before using the unit, be sure to read all operating instructions carefully. Please note that these are

general precautions and may not pertain to your unit. For example, this unit may not have the capabili-

ty to be connected to an outdoor antenna.

1. READ INSTRUCTIONS

All the safety and operating instructions should be read before the product is operated.

2. RETAIN INSTRUCTIONS

The safety and operating instructions should be retained for future reference.

3. HEED WARNINGS

All warnings on the product and in the operating instructions should be adhered to.

4. FOLLOW INSTRUCTIONS

All operating and use instructions should be followed.

5. CLEANING

Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners.

Use a dry cloth for cleaning.

6. ATTACHMENTS

Do not use attachments not recommended by the product's manufacturer as they may cause hazards.

7. WATER AND MOISTURE

Do not use this product near water–for example: near a bathtub, washbowl, kitchen sink or laundry tub; in

a wet basement; or near a swimming pool.

8. ACCESSORIES

Do not place this product on an unstable cart, stand, tripod, bracket or table. The product may fall, causing

serious injury and serious damage to the product. Use only with a cart, stand, tripod, bracket or table rec-

ommended by the manufacturer or sold with the product. Any mounting of the product

should follow the manufacturer’s instructions, and should use a mounting accessory rec-

ommended by the manufacturer.

8A. An appliance and cart combination should be moved with care. Quick stops, excessive

force and uneven surfaces may cause the appliance and cart combination to overturn.

9. VENTILATION

Slots and openings in the cabinet and in the back or bottom are provided for ventilation,

to ensure reliable operation of the product and to protect it from overheating. These

openings must not be blocked or covered. The openings should never be blocked by

placing the product on a bed, sofa, rug or other similar surface. This product should never be placed near

or over a radiator or heat source. This product should not be placed in a built-in installation such as a

bookcase or rack unless proper ventilation is provided or the manufacturer's instructions have been

adhered to.

10. POWER SOURCES

This product should be operated only from the type of power source indicated on the marking label. If you

are not sure of the type of power supply to your home, consult your appliance dealer or local power com-

pany. For products intended to operate from battery power, or other sources, refer to the operating instruc-

tions.

11. LIGHTNING

To protect your product from a lightning storm, or when it is left unattended and unused for long periods of

time, unplug it from the wall outlet and disconnect the antenna or cable system. This will prevent damage

to the product due to lightning and power-line surges.

12. POWER LINES

An outside antenna system should not be located in the vicinity of overhead power lines or other electric

light or power circuits, or where it can fall into such power lines or circuits. When installing an outside

antenna system, extreme care should be taken to keep from touching such power lines or circuits as con-

tact with them might be fatal.

IMPORTANT SAFETY INSTRUCTIONS

The AC/DC adaptor and appliance shall not be exposed to dripping or splashing and that no

objects filled with liquids,such as vases,shall be placed on apparatus.

AC/DC adaptor and mains plug is used as the disconnect device and it should remain readily

operable.In order to disconnect the AC/DC adaptor from the mains completely ,the AC/DC

adaptor should be disconnected from the mains socket outlet completely.

13. OVERLOADING

Do not overload wall outlets and extension cords as this can result in a risk of fire or electric shock.

14. OBJECT AND LIQUID ENTRY

Never push objects of any kind into this product through openings as they may touch dangerous voltage points

or short out parts that could result in fire or electric shock. Never spill or spray any type of liquid on the product.

15. SERVICING

Do not attempt to service this product yourself as opening or removing covers may expose you to danger-

ous voltage or other hazards. Refer all servicing to qualified service personnel.

16. REPLACEMENT PARTS

When replacement parts are required, be sure the service technician uses replacement parts specified by

the manufacturer or those that have the same characteristics as the original part. Unauthorized substitu-

tions may result in fire, electric shock or other hazards.

17. SAFETY CHECK

Upon completion of any service or repairs to this product, ask the service technician to perform safety

checks to determine that the product is in proper operating condition.

18. WALL OR CEILING MOUNTING

The product should be mounted to a wall or ceiling only as recommended by the manufacturer.

19. DAMAGE REQUIRING SERVICE

Unplug the product from the wall outlet and refer servicing to qualified service personnel under the follow-

ing conditions:

a. When the power-supply cord or plug is damaged.

b. If liquid has been spilled or objects have fallen into the product.

c. If the product has been exposed to rain or water.

d. If the product does not operate normally by following the operating

instructions. Adjust only those controls that are covered by the

operating instructions, as an adjustment of other controls may result

in damage and will often require extensive work by a qualified

technician to restore the product to its normal operation.

e. If the product has been dropped or the cabinet has been damaged.

f. When the product exhibits a distinct change in performance–this

indicates a need for service.

20. HEAT

The product should be situated away from heat sources such as radiators, heat registers, stoves or other

products (including amplifiers) that produce heat.

21. NOTE TO CATV SYSTEM INSTALLER

This reminder is provided to call the CATV system installer's attention to Article 820-40 of the NEC that

provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be con-

nected to the grounding system of the building, as close to the point of cable entry as practical.

IMPORTANT SAFETY INSTRUCTIONS

EXAMPLE OF ANTENNA GROUNDING

1. Carrying Handle

2. PHONES (Headphones) Jack

3. Display

4. CD Door Open/Close Area

5. CD Compartment

6. OFF/ON Switch

7. Left Speaker

8. REPEAT Button

9. RANDOM Button

10. Skip/Search oButton

11. VOLUME Control

12. FM Antenna

13. DC Power Jack

(Bottom of Unit)

14. Battery Compartment

(Bottom of Unit)

15. FUNCTION (AM/FM/CD)

Switch

16. Right Speaker

17. STOP (■) Button

18. PLAY/PAUSE (®p) Button

19. Skip/Search nButton

20. TUNING Control

LOCATION OF CONTROLS

BATTERY PRECAUTIONS

Follow these precautions when using batteries in this device:

1. Use only the size and type of batteries speciﬁed.

2. Be sure to follow the correct polarity when installing the batteries as indicated in the battery compartment.

Reversed batteries may cause damage to the device.

3. Do not mix different types of batteries together (e.g. Alkaline, Rechargeable and Carbon-zinc) or old batter-

ies with fresh ones.

4. If the device is not to be used for a long period of time, remove the batteries to prevent damage or injury from

possible battery leakage.

5. Do not try to recharge batteries not intended to be recharged; they can overheat and rupture. (Follow battery

manufacturer’s directions.)

HEADPHONES JACK

For private listening, connect 3.5mm (32 ohm) stereo headphones (not included) to this

jack. The speakers are automatically disconnected when the headphone plug is inserted in

the jack.

This unit is designed to operate on AC household current or DC (batteries).

BATTERY INSTALLATION

To use this unit with battery power, remove

the battery door on the bottom of the unit by

pressing in on the battery door tabs and

lifting the battery door off. Insert six (6) ‘C’

size batteries following the diagram in the

compartment.

NOTE: The DC power cord must be discon-

nected from the DC power jack on the bot-

tom of the unit in order for the unit to oper-

ate on battery power.

POWER SOURCES

BATTERY PRECAUTIONS

Follow these precautions when using batteries in this device:

1. Use only the size and type of batteries speciﬁed.

2. Be sure to follow the correct polarity when installing the batteries as indicated in the battery compartment.

Reversed batteries may cause damage to the device.

3. Do not mix different types of batteries together (e.g. Alkaline, Rechargeable and Carbon-zinc) or old batter-

ies with fresh ones.

4. If the device is not to be used for a long period of time, remove the batteries to prevent damage or injury from

possible battery leakage.

5. Do not try to recharge batteries not intended to be recharged; they can overheat and rupture. (Follow battery

manufacturer’s directions.)

HEADPHONES JACK

For private listening, connect 3.5mm (32 ohm) stereo headphones (not included) to this

jack. The speakers are automatically disconnected when the headphone plug is inserted in

the jack.

OPERATION

Slide the OFF/ON switch to ON to turn

the unit on.

For best sound quality, extend both

speakers outward as shown above.

Slide the FUNCTION switch to the AM

or FM position to select a band; the AM

or FM indicator and the frequency will

appear in the display.

Rotate the TUNING control to select a

station. When an FM stereo station is

tuned in, the FM stereo indicator will

appear in the display. If the station is not

broadcast in stereo or the reception is

not strong enough, the FM stereo indi-

cator will not appear in the display.

To turn the unit off, slide the OFF/ON

switch to OFF.

LISTENING TO THE RADIO

ANTENNAS

AM–This unit has a built-in ferrite rod antenna, which provides adequate reception in most areas. If

reception is weak, turn the unit to improve reception.

FM–The FM Antenna is for FM reception only. If reception is weak, adjust the length of the antenna.

Adjust the VOLUME control as

desired.

Inhaltsverzeichnis

Andere LEXIBOOK Stereoanlage Handbücher

LEXIBOOK

LEXIBOOK HPI500 Bedienungsanleitung

Beliebte Stereoanlage Handbücher anderer Marken

LG CM3330B Bedienungsanleitung

Sony

Sony SS-CEP50 Bedienungsanleitung

Cetacea Sound

Cetacea Sound CVS-II Bedienungsanleitung

Aiwa

Aiwa XR-H66MD Bedienungsanleitung

Denon

Denon UCD-250 Bedienungsanleitung

Sanyo

Sanyo DC-MX41i Bedienungsanleitung

Sharp

Sharp CD-ES600V Bedienungsanleitung

Exibel

Exibel BDX600-UK Bedienungsanleitung

Sanyo

Sanyo DC-F320 Bedienungsanleitung

Philips

Philips FWM583X Bedienungsanleitung

Sharp

Sharp CD-C462 Bedienungsanleitung

Onkyo

Onkyo CBX 300 - CD / MP3 Clock Radio Bedienungsanleitung

Aiwa

Aiwa XR-EM70 Bedienungsanleitung

Cyrus

Cyrus Lyric Bedienungsanleitung

Philips

Philips MCM159/98 Bedienungsanleitung

Philips/Magnavox

Philips/Magnavox Magnavox FW 62C Bedienungsanleitung

RCA

RCA RS3965SB Bedienungsanleitung

Sharp

Sharp XL-UH240 Bedienungsanleitung
