Battery voltage indicator
battery voltage drops, the indicator lights go out one by
one; When the 25% voltage indicator starts flashing, it
indicates that the battery is about to run out.
When the indicator light of this product is fully on, it does
not need to be charged, only when % brightness and
completely off, it needs to be charged.
It is divided into 4 levels:
25%, 50%, 75% and 100%.
During the charging process,
the indicator is flashing.
When it is full, the indicator is
all on.
When discharging, as the
Connection
Note: after the light goes out, it needs to wait for nearly 2 seconds
before it can be sensed again. The lights will only turn on when a
signal is detected at the end of this time.
Proper use of delay adjustment: it is used to adjust the delay time
from the light on to the automatic light off after the sensor
detects human movement. Users can adjust according to actual
demand. Because of the continuous induction function of
microwave induction products, in short, the system will restart
the timing of any sensor before the end of the delay time, and the
lights will not go out as long as people move within the detection
range. Therefore, users are advised to reduce the delay time to
achieve energy saving.
illumination value is about the day when the clockwise
spin is in the end.
unobstructed 360° rotation. Its adjustment limit is 230 °, please
pay attention.
It can be set in the range of 10 seconds
(anticlockwise to the bottom) to 12
minutes (clockwise to the bottom), and
the timing will be restarted when the
moving signal is detected before the end
(3)Delay setting
Note: this detection range value is measured by the body of a
person 1.6~1.7 meters tall, of medium build, and with a walking
speed of 1.0~1.5 meters/second. If the height, shape and walking
speed of the human body change, the sensing distance will also
change.
Notice: when using the product, please adjust the product
sensitivity to the appropriate position, do not adjust the product
sensitivity to the maximum, to avoid improper operation caused
by wind starting curtains, leaves, small animals, power grid and
electrical equipment, which may cause the product not to work
properly. When it is found that the product does not work
properly, the user can try to lower the sensitivity appropriately
before carrying out the test. Before or during the installation of
the product, if the functional test is carried out, the personnel
must leave the product sensor area and do not walk around to
prevent continuous work of the sensor due to human movement.
Friendly reminder: the installation distance of two or more
products must be more than 4 meters, otherwise it will cause
mutual interference and lead to misoperation.
Detection range is the term used to
describe the radii of the more or less
circular detection zone produced on the
ground after mounting the sensor light at
a height of 3m, turn the reach control
fully anticlockwise to select minimum
(3)Detection distance setting (sensitivity)
reach (approx.1m radii), and fully clockwise to select
maximum reach (approx. 5m radii).
The work illumination value can be
adjusted <10-2000LUX range.
The working illumination value is about
10LUX when rotating anticlockwise to
the bottom, and about 2000LUX when
rotating clockwise to the bottom. When
(3)Light-control setting
walking during the day to test or adjust the detection
area, this knob must be rotated clockwise to the bottom.
% brightness exit time: When it is
adjusted to 0, there is no
semi-brightness, and the induction
lamp is completely off; On the contrary,
the induction delay is maintained at %
brightness, and the delay is
determined by the actual potentiometer
(4) Low brightness time exit setting
position.
Note: % brightness exit is divided into: time exit and light
control exit. When the light control is >100Lux,the
semi-bright will automatically exit the energy saving.
Note: When adjusting the five function knobs, do not use too
much force because the five knobs are mounted directly on the
component. When adjusting the starting point to the end point,
there is a small limit device inside. When you use too much force
during operation, the limit device will be damaged, resulting in an
The single section can replace
the 18650 lithium battery.
NOTE: Make sure the positive and
negative electrodes are consistent
with the label when installing the
battery.
8W/16W machine power
switch button.
N
L
N L - Power
- Ground
Installation is based
on the wiring
diagram provided.
