Lexmark Optra C710 Bedienungsanleitung

Quick Reference

Lexmark Optra C710

Color Laser Printer

Press <Menu> to:

•Enter the menus from the ready state

•Scroll through menus or values

•Increase or decrease a numerical value

•Display the Job Menu or the Supplies Menu while the printer is busy

Press Select to:

•Select the item on the second line of the display

•Save the selection as a new default setting

Press Return to:

•Back up to the previous menu level

Press Stop to:

•Temporarily stop all print activity without losing data

Press Go to:

•Exit printer menus and return to the ready state

•Clear messages

Operator

Panel

Ready

1 Menu 2 Select 3

Go 5

Return 4

Stop 6

Overview of Printer Menus

Menus or menu items in italics are displayed only when the

required option is installed. Capitalized menu items (for example,

PAPER SIZE) have submenus.

PCL EMUL MENU

Font Source

Font Name

Point Size

Pitch

Symbol Set

Orientation

Lines per Page

A4 Width

Auto CR after LF

Auto LF after CR

TRAY RENUMBER

JOB MENU

Cancel Job

Reset Printer

Print Buffer

CONFIDENTIAL JOB

HELD JOBS

SETUP MENU

Printer Language

Power Saver

Resource Save

Download Target

Print Timeout

Wait Timeout

Auto Continue

Jam Recovery

Page Protect

Print Area

Display Language

Alarm Control

Toner Alarm

Job Buffer Size

Job Accounting

Job Acct Limit

POSTSCRIPT MENU

Print PS Error

Font Priority

Image Smoothing

UTILITIES MENU

Print Menus

Print Net1 Setup

Print Net2 Setup

Print Net3 Setup

Print Fonts

Print Directory

Factory Defaults

Format Flash

Defragment Flash

Format Disk

Job Acct Stat

Hex Trace

CHANGE TONER

SERIAL MENU

STANDARD SERIAL

SERIAL OPTION 1

SERIAL OPTION 2

SERIAL OPTION 3

PCL SmartSwitch

PS SmartSwitch

NPA Mode

Serial Buffer

Job Buffering

RS-232/RS-422

RS-422 Polarity

Serial Protocol

Robust XON

Baud

Data Bits

Parity

Honor DSR

INFRARED MENU

Infrared Port

PCL SmartSwitch

PS SmartSwitch

NPA Mode

Infrared Buffer

Job Buffering

Window Size

Transmit Delay

Max Baud Rate

COLOR MENU

Color Correction

Print Resolution

Image Enhancement

SUPPLIES MENU

<color> Toner

Tray 1 Status

Tray 2 Status

Tray 3 Status

Coating Roll

Transfer Belt

LOCALTALK MENU

LocalTalk Port

PCL SmartSwitch

PS SmartSwitch

NPA Mode

LocalTalk Buffer

Job Buffering

NPA Hosts

LocalTalk Name

LocalTalk Addr

LocalTalk Zone

FAX MENU

Fax Port

Fax Baud

Fax Data Bits

Fax Parity

Fax Buffer

Job Buffering

Fax Paper Size

Fax Paper Type

FAX SETUP

FAX LOGS

FAX SEND

FAX RECEIVE

PARALLEL MENU

STD PARALLEL

PARALLEL OPT 1

PARALLEL OPT 2

PARALLEL OPT 3

PCL SmartSwitch

PS SmartSwitch

NPA Mode

Parallel Buffer

Job Buffering

Advanced Status

Protocol

Honor Init

Parallel Mode 1

Parallel Mode 2

NETWORK MENU

NETWORK OPTION1

NETWORK OPTION 2

NETWORK OPTION 3

PCL SmartSwitch

PS SmartSwitch

NPA Mode

Network Buffer

Job Buffering

NETWORK x SETUP

USB MENU

USB OPTION 1

USB OPTION 2

USB OPTION 3

PCL

SmartSwitch

PS SmartSwitch

NPA Mode

USB Buffer

Job Buffering

FINISHING MENU

Duplex

Duplex Bind

Copies

Blank Pages

Collation

Separator Sheets

Separator Source

Multipage Print

Multipage Order

Multipage View

Multipage Border

PAPER MENU

Paper Source

PAPER SIZE

PAPER TYPE

PAPER WEIGHT

CUSTOM TYPES

Substitute Size

Configure MP

Paper Loading

Loading Paper and Transparencies

Important! Move the rear and side guides to properly position the

guides for the media size.

Note: Labels and card stock can only be used in the multipurpose

feeder. Transparencies can only be fed from the multipurpose feeder or

tray 1.

Important! Recommended Lexmark transparencies are P/N 12A5150

(letter) or P/N 12A5151 (A4).

Clearing Printer Paper Jams

Printer Paper Path

Clearing Duplex Unit Paper Jams

Duplex Unit Paper Path

Paper or

transparencies

Rear guide

Maximum stack height

Paper face up top

edge entering printer

Adjust Guides Flex Paper

Load Paper Tray

Multipurpose Feeder

Paper face down top

edge entering printer Envelope face down

with flap to the right

Top output bin

Message Location

202 Paper Jam Fuser and output rollers

201 Paper Jam Transfer belt and fuser

250 Paper Jam Multipurpose feeder

24x Paper Jam Paper tray

202 Paper Jam - Fuser and Output Rollers

1 Open the fuser cover, fuser door, and front cover.

2 Remove coating roll.

3 Carefully remove jammed paper.

4 Close the front cover, fuser door, and fuser cover.

Note: Paper jammed in the fuser rollers must be

removed from the underside of the fuser.

201 Paper Jam - Transfer Belt and Fuser

1 Open the front cover.

2 Carefully remove any jammed paper.

3 Close the front cover.

250 Paper Jam - Multipurpose Feeder

1 Open the front cover.

2 Carefully remove any jammed paper.

3Closethefrontcover.

24x Paper Jam - Check Paper Tray x

1 Remove the paper tray.

2 Carefully remove any jammed paper.

3 Place the tray inside the printer.

Note: You may have to remove the drawer above the

paper jam or clear the jam from inside the front cover.

Message Location

230 Paper Jam Top duplex assembly

231 Paper Jam Rear duplex assembly

232 Paper Jam Duplex unit base and tray

230 Paper Jam - Top Duplex Assembly

1 Open the top duplex assembly door.

2 Carefully remove jammed paper.

3 Close the top duplex assembly door.

231 Paper Jam - Rear Duplex Assembly

1 Open the rear cover.

2 Carefully remove any jammed paper.

3 Close the rear cover.

232 Paper Jam - Duplex Unit Base and

Tray

1 Completely remove duplex unit inverter tray.

2 Carefully remove jammed paper (check inside

duplex unit base).

3 Insert duplex unit inverter tray into duplex unit.

Printed in U.S.A.

This document is printed on recycled paper. 9/99

E.C. 1C0105 P/N 10E0243
