Multi Type Air Conditioner

OWNER'S MANUAL

IMPORTANT

• Please read this owner's manual carefully and thoroughly

before installing and operating your room air conditioner.

• Please retain this owner's manual for future reference after

reading it thoroughly.

Prior to installation, this air-

conditioning unit must be submitted

for approval by the utility service

which provides electricity

(EN 61000-2, EN 61000-3 Norm).

ENGLISH FRANÇAIS ESPAÑOL

MPS (Multi Power System)

Conventional (On/Off Operation)

•During a Conventional Air Conditioning Cycle, the

Compressor must turn on and off to reach desired

Temperature setting.

•A large portion of power is used during Restart.

This causes unnecessary power consumption.

00:05 0:10 0:15 0:20

Operation time (min)

Indoor Temp (°C)

ON OFF ON OFF

MPS

•MPS(Multi Power System) is a power saving system

WithTwo rotary compressors of different capacity

(60% & 40%) Operating an A/C at high power until it

reaches desired temperature.

•And when it reaches the temperature, only the 40%

Capacity rotary compressor operates.

00:05

100% operation 40% operation

0:10 0:15 0:20

Operation time (min)

Indoor Temp (°C)

ENGLISH

2Room Air Conditioner

Room Air Conditioner Owner’s Manual

TABLE OF CONTENTS

FOR YOUR RECORDS

Write the model and serial numbers here:

Model #

Serial #

You can find them on a label on the side of each unit.

Dealer's Name

Date Purchased

■

Staple your receipt to this page in the event you need it

to prove date of purchase or for warranty issues.

READ THIS MANUAL

Inside you will find many helpful hints on how to use and

maintain your air conditioner properly. Just a little

preventive care on your part can save you a great deal

of time and money over the life of your air conditioner.

You'll find many answers to common problems in the

chart of troubleshooting tips. If you review our chart of

Troubleshooting Tips first, you may not need to call for

service at all.

PRECAUTION

•Contact the authorized service technician for repair or

maintenance of this unit.

•Contact the installer for installation of this unit.

•The air conditioner is not intended for use by young

children or invalids without supervision.

•Young children should be supervised to ensure that

they do not play with the air conditioner.

•When the power cord is to be replaced, replacement

work shall be performed by authorized personnel only

using only genuine replacement parts.

•Installation work must be performed in accordance

with the National Electric Code by qualified and

authorized personnel only.

Safety Precautions.................3

Prior to Operation ..................8

Operating Instructions...........9

Remote Controller ..............9

Remote Control

Operation...........................10

Additional features...............17

Maintenance and Service ....20

Operation Tips ..................22

Troubleshooting ..............23

Safety Precautions

Owner's Manual 3

ENGLISH

Safety Precautions

To prevent injury to the user or other people and property damage, the following instructions must be

followed.

■Incorrect operation due to ignoring instruction will cause harm or damage. The seriousness is classified

by the following indications.

WARNING

CAUTION

This symbol indicates the possibility of death or serious injury.

This symbol indicates the possibility of injury or damage to properties only.

■Meanings of symbols used in this manual are as shown below.

Be sure not to do.

Be sure to follow the instruction.

WARNING

■Installation

Do not use a defective or

underrated circuit breaker.

Use this appliance on a

dedicated circuit.

• There is risk of fire or electric

shock.

For electrical work, contact

the dealer, seller, a qualified

electrician, or an Authorized

Service Center.

• Do not disassemble or repair

the product. There is risk of fire

or electric shock.

Always ground the product.

• There is risk of fire or electric

shock.

Install the panel and the

cover of control box

securely.

• There is risk of fire or electric

shock.

Always install a dedicated

circuit and breaker.

• Improper wiring or installation

may cause fire or electric shock

Use the correctly rated

breaker or fuse.

• There is risk of fire or electric

shock.

Safety Precautions

4Room Air Conditioner

Do not modify or extend the

power cable.

• There is risk of fire or electric

shock.

Do not install, remove, or

re-install the unit by

yourself (customer).

• There is risk of fire, electric

shock, explosion, or injury.

Be cautious when

unpacking and installing

the product.

• Sharp edges could cause injury.

Be especially careful of the

case edges and the fins on the

condenser and evaporator.

For installation, always contact the dealer or an Authorized

Service Center.

• There is risk of fire, electric shock, explosion, or

injury.

Do not install the product on a defective

installation stand.

• It may cause injury, accident, or damage to the

product.

Be sure the installation area does not

deteriorate with age.

• If the base collapses, the air conditioner could fall

with it, causing property damage, product failure,

and personal injury.

Do not let the air conditioner run for a long

time when the humidity is very high and a

door or a window is left open.

• Moisture may condense and wet or damage

furniture.

■Operation

Do not touch(operate) the

product with wet hands.

• There is risk of fire or electrical

shock.

Do not place a heater or

other appliances near the

power cable.

• There is risk of fire and electric

shock.

Do not let electric parts of

the product get wet.

• It may cause There is risk of

fire, failure of the product, or

electric shock.

Safety Precautions

Owner's Manual 5

ENGLISH

Be cautious that water could not enter the

product.

• There is risk of fire, electric shock, or product

damage.

Turn the main power off when cleaning or

maintaining the product.

• There is risk of electric shock.

Gasolin

Do not store or use flammable

gas or combustibles near the

product.

• There is risk of fire or failure of

product.

If strange sounds, or small or

smoke comes from product. Turn

the breaker off or disconnect the

power supply cable.

• There is risk of electric shock or

fire.

When the product is soaked

(flooded or submerged),

contact an Authorized

Service Center.

• There is risk of fire or electric

shock.

When the product is not be used for a long

time, disconnect the power supply plug or

turn off the breaker.

• There is risk of product damage or failure, or

unintended operation.

Take care to ensure that nobody could step

on or fall onto the outdoor unit.

• This could result in personal injury and product

damage.

Safety Precautions

6Room Air Conditioner

■Installation

CAUTION

■Operation

Always check for gas

(refrigerant) leakage after

installation or repair of product.

• Low refrigerant levels may

cause failure of product.

Install the drain hose to ensure

that water is drained away

properly.

• A bad connection may cause

water leakage.

Keep level even when

installing the product.

• To avoid vibration.

Do not install the product

where the noise or hot air from

the outdoor unit could be

offensive to the neighborhoods

or damage property.

• It may cause a problem for your

neighbors.

Use two or more people to

lift and transport the

product.

• Avoid personal injury.

Do not install the product

where it will be exposed to

sea wind (salt spray)

directly.

• It may cause corrosion on the

product. Corrosion, particularly on

the condenser and evaporator

fins, could cause product

malfunction or inefficient

operation.

90°

Do not expose the skin directly to cool air

for long periods of time.

(Don't sit in the draft.)

•This could harm to your health.

Do not use the product for special purposes,

such as preserving foods, works of art, etc.

It is a consumer air conditioner, not a

precision refrigeration system.

•There is risk of damage or loss of property.

Safety Precautions

Owner's Manual 7

ENGLISH

Do not block the inlet or

outlet of air flow.

•It may cause product failure.

Use a soft cloth to clean. Do

not use harsh detergents,

solvents, etc.

•There is risk of fire, electric

shock, or damage to the plastic

parts of the product.

Do not touch the metal parts of

the product when removing the

air filter. They are very sharp!

•There is risk of personal injury.

Wax

Thinner

Do not step on or put

anyting on the product.

(outdoor units)

•There is risk of personal injury

and failure of product.

Always insert the filter

securely. Clean the filter

every two weeks or more

often if necessary.

•

A dirty filter reduces the efficiency

of the air conditioner and could

cause product malfunction or

damage.

Do not insert hands or other

objects through the air inlet

or outlet while the product

is operated.

•There are sharp and moving

parts that could cause personal

injury.

Do not drink the water

drained from the product.

•It is not sanitary and could

cause serious health issues.

Use a firm stool or ladder

when cleaning or

maintaining the product.

•Be careful and avoid personal

injury.

Replace the all batteries in the

remote control with new ones

of the same type. Do not mix

old and new batteries or

different types of batteries.

•Could adversley effect

operation.

Do not recharge or disassemble the

batteries. Do not dispose of batteries in a

fire.

•They may burn or explode.

If the liquid from the batteries gets onto your skin

or clothes, wash it well with clean water. Do not

use the remote if the batteries have leaked.

•The chemicals in batteries could cause burns or

other health hazards.

Prior to operation

8Room Air Conditioner

Prior to operation

1. Contact an installation specialist for installation.

2. Connect the power cable between indoor unit and outdoor unit properly.

3. Use a dedicated circuit.

4. If the cord/plug is damaged, replace it with only an authorized replacement part.

1. Being exposed to direct airflow for an extended period of time could be hazardous to your health.

Do not expose occupants, pets, or plants to direct airflow for extended periods of time.

2. Do not use this air conditioner for non-specified special purposes (e.g. preserving precision devices,

food, pets, plants, and art objects). Such usage could damage the items.

1. Do not touch the metal parts of the unit when removing the filter. Injuries can occur when handling

sharp metal edges.

2. Do not use water to clean inside the air conditioner. Exposure to water can destroy the insulation,

leading to possible electric shock.

3. When cleaning the unit, first make sure that the power and breaker are turned off. There is a

possibility of injury if the unit’s power is accidentally triggered on while cleaning inner parts of the

unit.

For repair and maintenance, contact your authorized service dealer.

Preparing for operation

Usage

Cleaning and maintenance

Service

Symbols Used in this Manual

This symbol alerts you to the risk of electric shock.

This symbol alerts you to hazards that could cause harm to the

air conditioner.

This symbol indicates special notes.

NOTICE

Andere Handbücher für LM360CE

Inhaltsverzeichnis

Andere LG Klimaanlage Handbücher

LG LM-2063H3L Bedienungsanleitung

LG LW1813HR Montageanleitung

LG AVNW36GM1P0 Bedienungsanleitung

LG AMNW18GECA0 Bedienungsanleitung

LG LT-C1260CL Bedienungsanleitung

LG Art Cool LMAN121CNM Bedienungsanleitung

LG Multi V ARUN053GF2 Bedienungsanleitung

LG LW1811ER Bedienungsanleitung

LG LW7010HR Bedienungsanleitung

LG Multi V ARNU073B3G2 Bedienungsanleitung

LG Multi V Bedienungsanleitung

LG Ceiling Cassette-Type Air Conditioner Bedienungsanleitung

LG LSU5AP2M Bedienungsanleitung

LG ARNU12GB1G2.ENWALEU Bedienungsanleitung

LG LT-H282PLE1 Bedienungsanleitung

LG MULTI V JRUN120LTE5 Bedienungsanleitung

LG WG6005R Bedienungsanleitung

LG MFL40910614 Bedienungsanleitung

LG ASNW096MMF0 Bedienungsanleitung

LG mfl68802402 Bedienungsanleitung

LG A4UW36GFA0 Bedienungsanleitung

LG LW8013ER Bedienungsanleitung

LG LW8018ER Bedienungsanleitung

LG Multi Type Air Conditioner Bedienungsanleitung

Beliebte Klimaanlage Handbücher anderer Marken

Spheros

Spheros CC 355 Bedienungsanleitung

Bosch

Bosch Climate 5000 SCI 24 CAS/ OU- OUE Bedienungsanleitung

Panasonic

Panasonic CS-E12HKEW Bedienungsanleitung

nedis

nedis ACMB1WT7 Bedienungsanleitung

Samsung

Samsung AR KV Series Leitfaden

Daikin

Daikin FCFV50A Bedienungsanleitung

Fujitsu

Fujitsu Inverter ASBA30JFC Bedienungsanleitung

Toshiba

Toshiba RAS-M10SMUV-E Bedienungsanleitung

Daikin

Daikin FXLQ20MAVE Bedienungsanleitung

Hitachi

Hitachi RAS-E24CAK Bedienungsanleitung

CIAT

CIAT Magister 2 Series Leitfaden

Bestron

Bestron AAC6000 Bedienungsanleitung

Hisense

Hisense 7K Technisches Handbuch

Frigidaire

Frigidaire FFRE0533S1E0 Bedienungsanleitung

Samsung

Samsung AS09HM3N Bedienungsanleitung

Frigidaire

Frigidaire CRA073PU11 Betriebsanleitung

Soleus Air

Soleus Air GB-PAC-08E4 Bedienungsanleitung

McQuay

McQuay MCK020A Bedienungsanleitung
